Omron V530-R150E-3 Operation Manual

2-dimensional code reader (fixed type)
Hide thumbs Also See for V530-R150E-3:
Table of Contents

Advertisement

Quick Links

Download this manual
Cat. No. Z155-E1-01
V530-R150E-3, V530-R150EP-3
2-Dimensional Code Reader
(Fixed Type)
OPERATION MANUAL

Advertisement

Table of Contents

Troubleshooting

loading

Related Manuals for Omron V530-R150E-3

Summary of Contents for Omron V530-R150E-3

  • Page 1 Cat. No. Z155-E1-01 V530-R150E-3, V530-R150EP-3 2-Dimensional Code Reader (Fixed Type) OPERATION MANUAL...

  • Page 2: Dimensional Code Reader

    V530-R150E-3, V530-R150EP-3 2-Dimensional Code Reader (Fixed Type) Operation Manual Produced August 2001...

  • Page 3: Visual Aids

    Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ........xi Safety Precautions .
  • Page 5 TABLE OF CONTENTS SECTION 5 Operations ..........99 Menu Operations .
  • Page 6 TABLE OF CONTENTS Appendices ASCII Codes ..........263 FCS Check Program Examples (BASIC) .

  • Page 8: About This Manual

    About this Manual: This manual describes the features, specifications and operation of the V530-R150 2-Dimensional Code Reader and includes the following sections. Section 1 gives an overview of the features, applications and basic configura- tions for the V530-R150 2-Dimensional Code Reader. Section 2 describes the different parts of the V530-R150 2-Dimensional Code Reader, and details the connections and other procedures necessary for instal- lation.

  • Page 10: Precautions

    PRECAUTIONS This section provides general precautions for using the V530-R150 2-Dimensional Code Reader. The information contained in this section is important for the safe and reliable application of the V530-R150 2-Dimensional Code Reader. You must read this section and understand the information contained before attempting to set up or operate a V530-R150 2- Dimensional Code Reader.

  • Page 11: Safety Precautions

    Safety Precautions Safety Precautions • Do not touch fluorescent or halogen light while the power in ON or immediately after the power is turned OFF. These lights generate heat and can cause burns. The following must be followed to ensure the safety.

  • Page 12: General Precautions

    OMRON representative. Make sure that the ratings and performance characteristics of the...
  • Page 13 Installation Precautions Installation Orientation of Controller To improve heat dissipation, install the controller in the following ori- entation only: CORRECT Do not install the controller in the orientations shown in the following diagram. INCORRECT INCORRECT Ambient Temperature • Maintain a minimum clearance of 50mm above and below V530- R150 components to improve air circulation.
  • Page 14 Installation Precautions • Provide a forced-air fan or air conditioning if the ambient temper- ature might exceed 50•C. Control Box V530-R150 Louver Noise Resistance Use the following measures to help increase noise resistance. • Do not install V530-R150 components in a cabinet containing high-voltage equipment.

  • Page 15: Video Monitor

    Installation Precautions Video Monitor (When using the recommended F150-M09) Heed the following precautions to prevent noise interference if the video monitor case is metallic, because it is connected to the 0V line in the internal circuits. • Do not ground the video monitor. •...

  • Page 16: Package Contents

    Package Contents Confirming Package Contents Check the contents of the package as soon as you receive the V530- R150. Contact the nearest OMRON representative if any of the fol- lowing items are missing. • V530-R150 2-Dimensional Code Reader Controller • Operation Manual (this manual)

  • Page 18: Features

    SECTION 1 Features This section gives an overview of the features, applications and basic configurations for the V530- R150 2-Dimensional Code Reader. Overview of V530-R150 Application ....Functions .

  • Page 19: Overview Of V530-R150 Application

    Section 1-1 Overview of V530-R150 Application Overview of V530-R150 Application The following illustrations show configurations and typical applica- tions for the V530-R150. Unit Connections and Wiring Monitor Power Supply Console Camera Refer to SECTION 2 Installation for detailed descriptions. Connections for Peripheral Devices Programmable Personal Computer Controller...
  • Page 20 Section 1-1 Overview of V530-R150 Application Displaying Images Switch to through image and adjust the focus, camera setting dis- tance, and lighting. Camera Lighting Monitor Refer to 2-4 Cameras, 2-5 CCTV Lens, 2-6 Lighting, and 2-7 Two- camera Unit for detailed descriptions. Setting Reading Conditions Operate the Console while checking menus on the Monitor.

  • Page 21: Functions

    Section 1-2 Functions Performing Reading Refer to 6-2 MON (Monitor) Mode and 6-3 RUN Mode for detailed descriptions. Functions Reading Specifications Reading is possible for both QR Code and Data Matrix in either Nor- mal or Pattern mode. Usually, the Normal mode can be used. Use the Pattern mode for codes with poor marking quality or codes made up of dots.
  • Page 22 Section 1-2 Functions Note Adjust the field of vision to be at least five pixels per cell. Pixel number is measured by SET/Image Analysis/Measure Length. “ page 176 Shutter Select a shutter speed that is appropriate for the speed of the work- Speed piece.
  • Page 23 Section 1-2 Functions Store Images Up to 24 images can be stored in memory. The images can be used to check what kind of errors have occurred. The stored images will be cleared when the power goes OFF, so the images must be backed up in the computer if you want to save them long term.
  • Page 24 Section 1-2 Functions Example 1: Reading Two Lines with a Single Controller A single F150-A20 can read two kinds of 2-dimensional codes. F150-A20 Two- V530-R150 camera Unit Controller Note The F150-A20 cannot process the two images from two Cameras simultaneously. Set reading conditions so that each process is processed with separate screens.
  • Page 25 Section 1-2 Functions Example 2: Increasing the Field of Vision The F150-A20 can be used for applications where it is difficult to posi- tion the object in a single Camera’s field of vision. F150-A20 Two- V530-R150 camera Unit Controller Field of vision Field of vision of Camera 0 of Camera 1...

  • Page 26: Trigger Inputs And Outputs

    Section 1-3 Trigger Inputs and Outputs Trigger Inputs and Outputs Trigger Inputs “ • Trigger inputs from terminal blocks: page 35 Enter input signals to perform one shot reading, continuous reading and level trigger. “ • Trigger inputs from RS-232C: page 56, page 83 Enter input signals to perform one shot reading and continuous reading.

  • Page 28: Installation

    SECTION 2 Installation This section describes the different parts of the V530-R150 2-Dimensional Code Reader, and details the connections and other procedures necessary for installation. Component Names and Functions ....Connections .

  • Page 29: Component Names And Functions

    Section 2-1 Component Names and Functions Component Names and Functions The following diagram shows the terminals, connectors, and indica- tors on the V530-R150 2-Dimensional Code Reader. Ground Power supply Output Input terminal terminals terminals terminals POWER indicator Monitor connector indicator ERROR indicator Console...

  • Page 30: Connections

    Section 2-2 Connections Connections !Caution Components marked with an asterisk are specially designed for the V530-R150. Other products cannot be used. (Using other products may damage other components in the system.) Connect the basic components as shown in the following diagram. Details are provided later in this section.
  • Page 31 Section 2-2 Connections Cameras *Camera with Intelligent Light Source “ page 18 F150-SLC20 (20-mm field of vision) *F150-VS Camera Cable (3m) F150-SLC50 (50-mm field of vision) “ *Camera with F150-LT10A Light Source page 18 F150-SL20A (20-mm field of vision) F150-SL50A (50-mm field of vision) *F150-VS Camera Cable (3m)
  • Page 32 Section 2-2 Connections “ page 16 Power Supply (We recommend the OMRON S82K-01524 or S82K-05024.) *F150-KP Console (Cable length: 2m) V530-R150 2-Dimensional “ Code Reader page 12 BNC Jack F150-VM Monitor (Attached to F150-VM Cable (2m) Monitor Cable) Monitor F150-M05L...

  • Page 33: Power Supply And Ground

    Section 2-3 Power Supply and Ground Power Supply and Ground Wire the power supply and the ground to the top terminal block, and tighten the screws to a torque of between 0.5 and 0.6 N•m. After wir- ing, check to make sure that the wiring is correct. !Caution Cover the terminal blocks with the Terminal Block Protection Cov- ers.

  • Page 34: Wiring The Power Supply

    Power supply voltage 24 VDC+10%, –15% Use a power supply with the following specifications when connecting the V530-R150 and F150-M05L LCD Monitor to one power supply. We recommend using OMRON’s S82K-05024 Power Supply. Output current 1.6 A min. Power supply voltage 24 VDC+10%, –15%...

  • Page 35: Cameras

    Section 2-4 Cameras Cameras 2-4-1 Cameras with Light Sources The Cameras with Light Sources are special cameras with a lens and light source attached. The light source and lens are a single unit and are thus compact and easy to mount. The Camera must be mounted at a distance from the measurement object where it can correctly view the object.
  • Page 36 Section 2-4 Cameras Cameras with F150-LT10A Light Source Field of vision Working distance Model ™ 20 mm 20 mm 61 to 71 mm F150-SL20A ™ 50 mm 50 mm 66 to 76 mm F150-SL50A Working distance Object Field of vision Cameras with Intelligent Light Source Field of vision Working distance...

  • Page 37: Cctv Lens

    Section 2-5 CCTV Lens 2-4-2 Camera Only If the object size and field of vision are incompatible, use a standard CCTV lens and light source with a F150-S1A Camera. Use C-mount lenses. Camera Model Camera F150-S1A Note Use lighting that is appropriate for the object being measured. CCTV Lens When using a F150-S1A Camera, refer to the following graph to select the appropriate Lens and Extension Tube.
  • Page 38 Section 2-5 CCTV Lens Extension Tubes. A value of “t0” indicates no Tube is required and “t5.0” indicates a 5 mm Tube is required. For example when a 30mm field of vision is required at the working distance and a 3Z4S-LE B2514D Lens is being used, use a 1-mm Extension Tube and a working distance of 250 mm.
  • Page 39 Section 2-5 CCTV Lens Extension Tubes One or more Extension Tubes are inserted between the lens and the Camera to focus the Camera image. Use a combination of one or more of the six sizes of tube to achieve the required length. Extension Tube Model Max.

  • Page 40: Lighting

    Section 2-6 Lighting Lighting A stable image must be obtained to ensure accurate inspection. Use appropriate lighting for the application and the reading object. Lighting Methods Back Lighting A stable, high-contrast image can be obtained using back lighting. Applications: Reading codes on transparent objects such as sheet glass Camera Object...
  • Page 41 Section 2-6 Lighting Reflected Lighting Ring Lighting Objects can be illuminated shone uniformly. Applications: Paper labels and relatively large objects Camera Light source Object Oblique Lighting Detection is made by distinguishing regular and diffuse reflected light. Applications: Relatively small objects Camera Light source Object...
  • Page 42 Section 2-6 Lighting Coaxial Lighting A stable image with few shadows can be obtained of a reading object with an uneven surface by detecting only regular reflected light. Applications: Reading codes from objects with highly reflective surfaces such as semiconductor wafers Camera Half mirror Light source...

  • Page 43: Two-Camera Unit

    Section 2-7 Two-camera Unit Two-camera Unit When the F150-A20 Two-camera Unit is used, two cameras can be connected to a single V530-R150 and images can be received at the same time. Note If the V530-R150 and the Two-camera Unit are not turned ON simultaneously, be sure to turn ON the Two-camera Unit first.

  • Page 44: Mounting To Din Track

    2-8-1 Mounting to DIN Track The 2-Dimensional Code Reader can be easily mounted to or removed from 35-mm DIN Track. The following DIN Tracks are available from OMRON. PFP-100N (1 m) PFP-50N (50 cm) PFP-100N2 (1 m) PEP-M End Plate...

  • Page 45: Mounting The V530R150

    Section 2-8 Mounting the V530-R150 Mounting the V530R150 Hook the V530-R150 into the DIN Track as shown in the diagram and then press in at the bottom until the V530-R150 locks into place. Removing the V530-R150 Use a screwdriver to pull the hook down and then pull out the V530- R150 from the bottom.

  • Page 46: Mounting On A Flat Surface

    Section 2-8 Mounting the V530-R150 2-8-2 Mounting on a Flat Surface Two-camera Unit V530-R150 Four, M4 Four, M4 (Unit: mm)

  • Page 48: Terminal Blocks

    SECTION 3 Terminal Blocks This section describes the specifications, procedures, inputs and outputs used when operating the V530-R150 2-Dimensional Code Reader via terminal blocks. Specifications ........3-1-1 Crimp Terminals and Cables .

  • Page 49: Specifications

    3-1-2 Specifications !Caution Use a DC power supply with safe extra low-voltage circuits on the secondary side. Input Specifications Item V530-R150E-3 (NPN model) V530-R150EP-3 (PNP model) – Input voltage 12 to 24 VDC ON current 5 to 15 mA ON voltage 8.8 V max.

  • Page 50: Terminals

    Section 3-1 Specifications Output Specifications Item V530-R150E-3 (NPN model) V530-R150EP-3 (PNP model) – Output voltage 12 to 24 VDC Load current 45 mA max. ON residual voltage 2 V max. OFF leakage current 0.1 mA max. Internal circuits Output terminal...
  • Page 51 Section 3-1 Specifications There are 3 kinds of COM OUT (*1 to *3) for each output terminal. Connect with reference to the following table. Table A Bottom Power supply Not connected – Appropriate ground Control output Error output BUSY GATE Control output OK/NG Judgment output...

  • Page 52: Trigger Input And Output Format

    Section 3-2 Trigger Input and Output Format Trigger Input and Output Format 3-2-1 Trigger Input Reading is performed by inputting a signal to the TRIG A or B termi- nals when in MON (monitor) or RUN mode. TRIG A Terminal (One shot mode) One reading is performed on the rising edge (OFF to ON) of TRIG A signal.
  • Page 53 Section 3-2 Trigger Input and Output Format OK: ON or NG: ON (i.e.: whether output turns ON for an OK judgment or an NG judgment) can be selected in the communications specifi- cations settings. The default setting is NG: ON. “ page 199 DO0 to DO3 Terminals While the coincidence judgment function is ON, the signals are as fol- lows:...

  • Page 54: Timing Chart

    Section 3-3 Timing Chart Timing Chart 3-3-1 One Shot Mode Enter RUN mode Leave RUN mode TRIG A BUSY Image read Image read Image read Judgment OK/NG Coincidence judgment DO 0 to 3 GATE Gate ON delay Gate ON time Output period (RS-232C) Note The output time to RS-232C changes depending on the data vol-...
  • Page 55 Section 3-3 Timing Chart Output Terminals Terminal Function Turns ON during RUN mode. BUSY Shows that the V530-R150 is reading an image, changing settings, etc. Do not input the next command while the BUSY signal is ON. Otherwise, the commands input during command execution or processing may not be properly executed.

  • Page 56: Continuous Mode

    Section 3-3 Timing Chart 3-3-2 Continuous Mode Enter RUN mode Leave RUN mode TRIG B *Delay of 33.3 ms max. occurs before starting to read images after TRIG B signal is turned ON. BUSY Image read Image read Image read Judgment OK/NG Coincidence...
  • Page 57 Section 3-3 Timing Chart Output Terminals Terminal Function Turns ON during RUN mode. BUSY Shows that the V530-R150 is reading an image, changing settings, etc. Do not input the next command while the BUSY signal is ON. Otherwise, the commands input during command execution or processing may not be properly executed.

  • Page 58: Reading Level Trigger (When Trigger Mode Is "Level Trigger")41

    Section 3-3 Timing Chart 3-3-3 Reading Level Trigger (when trigger mode is “Level Trigger”) OK judgment (Readable) Enter RUN mode Leave RUN mode TRIG B *Delay of 33.3 ms max. occurs before starting to load images after TRIG B signal is turned ON. BUSY Reading (OK) Judgment (OK)
  • Page 59 Section 3-3 Timing Chart OK judgment obtained after repeated reading: TRIG B BUSY Reading Reading (NG) (OK) OK/NG Judgment (OK) Coincidence judgment DO 0 to 3 (RS-232C) Note The output time to RS-232C will vary according to the data vol- ume and baud rate.
  • Page 60 Section 3-3 Timing Chart NG judgment after repeated reading: NG is output when TRIG B is turned OFF. TRIG B BUSY Reading Reading Reading (NG) (NG) (NG) Judgment (NG) OK/NG DO 0 to 3 (RS-232C) (Error codes) Note The output time to RS-232C will vary according to the data vol- ume and baud rate.

  • Page 61: System Examination

    Section 3-4 System Examination System Examination Processing Time Calculation Processing time (reading time) is calculated as follows: Processing Shutter time Delay of loading Loading image time of camera image (see note) time (33.3 ms fixed) Decode time Display time Note A delay of 33.3 ms max. will occur before starting to load monitor images if through images are displayed.
  • Page 62 Continuous Reading Regardless of the displayed image (through/freeze), a 33.3 ms max. delay occurs before loading the image after the TRIG B signal is input. Standard Processing Time (values for OMRON’s standard codes) QR Code (Normal Mode) Matrix size Processing time ™...

  • Page 64: Rs-232C

    SECTION 4 RS-232C This section describes the specifications, procedures, inputs and outputs used when operating the V530-R150 2-Dimensional Code Reader via RS-232C. Specifications ........4-1-1 Connector.

  • Page 65: Specifications

    Section 4-1 Specifications Specifications 4-1-1 Connector The V530-R150 uses 9-pin D-Sub female connectors. The pin num- bers and names are shown below. Recommended OMRON Connector Model Model No. Plug XM2A-0901 Hood XM2S-0911 Signal Name FG (GND) Frame ground SD (TXD)

  • Page 66: Wiring

    Section 4-1 Specifications 4-1-2 Wiring Only use a shielded RS-232C cable. Standard Connections V530-R150 External device Signal Signal Shield Connections for RS/CS Control V530-R150 External device Signal Signal Shield Note Pin numbers will depend on the external device being connected. Refer to the manual for the external device.

  • Page 67: Connection

    Section 4-1 Specifications 4-1-3 Connection Align the connector with the socket and press the connector straight into place. Tighten the two screws on the edges of the connector. Note Always turn OFF the power supply before connecting or discon- necting cables. Peripheral devices can be damaged if connected or disconnected with the power supply turned ON.

  • Page 68: Communication Settings

    Section 4-2 Communication Settings Communication Settings 4-2-1 Normal Communications Mode If the Normal communications mode is selected, data can be output in normal format to an external device via the RS-232C port. Communications method setting menu “ page 194 I/O via the RS-232C Port V530-R150 Host computer Input command...

  • Page 69: Host Link

    Section 4-2 Communication Settings TRIG A Signal as Reading Trigger Programmable Controller V530-R150 Unit number: 00 (fixed) Perform reading The BUSY terminal turns ON while readings are being performed. Gate ON time varies according to data Output judgment volume and baud rate. Receive judgment A timeout error occurs if there is no response from the host computer within the set time when RS/CS or Xon/off is selected for flow control...
  • Page 70 Section 4-2 Communication Settings I/O via the RS232C Port Commands for the V530-R150 are written to the Read Area in the Programmable Controller. The V530-R150 automatically reads these commands, executes them, and writes any judgments to the Write Area. Read Area Write Area V530-R150 Programmable Controller...
  • Page 71 Section 4-2 Communication Settings TRIG A Signal as Reading Trigger The trigger is used to cause the V530-F150 to read data and the data is written to the Programmable Controller. Set the Read Area to “None.” Write Area V530-R150 Programmable Controller Unit number: 00 (fixed) TRIG A Executes reading.
  • Page 72 Section 4-2 Communication Settings Using TXD Instructions Commands are sent from the Programmable Controller to the V530- R150 using TXD instructions in the Programmable Controller’s ladder program instead of the Read Area The V530-R150 executes the command and writes the results of processing to the Programmable Controller.

  • Page 73: Trigger Inputs And Output Format

    Section 4-3 Trigger Inputs and Output Format Trigger Inputs and Output Format 4-3-1 Normal Commands 1:1 Connection Function Command Page One Shot Reading page 59 Polling page 59 Polling with Digit Position Specification page 59 Start Continuous Reading page 60 Stop Continuous Reading page 60 QR Code Teaching...
  • Page 74 Section 4-3 Trigger Inputs and Output Format 1:N (Multi-drop) Connections Function Command Page One Shot Reading page 80 Polling page 80 QR Code Teaching page 80 Data Matrix Teaching page 81 Read Scene Number page 81 Switch Scene page 81 Error Codes The following error codes are output according to the cause of error when the reading is NG.
  • Page 75 Section 4-3 Trigger Inputs and Output Format Data Matrix • Normal Mode or Pattern Mode Error Code Description E100 No candidate for FP E110 No FP E111 Error 1 FP E112 FP in wrong position E120 Decode error E121 E122 E123 E150 E200...
  • Page 76 Section 4-3 Trigger Inputs and Output Format One Shot Reading (@GL) 1:1 Connection Reading ends when the reading is correctly performed (OK). When the reading is not correctly performed (NG), reading continues to be performed for the number of retries specified in the setting conditions. Send @ G L <Footer>...
  • Page 77 Section 4-3 Trigger Inputs and Output Format Continuous Reading (@GC, @SC) 1:1 Connection Performs continuous reading until the stop command (@SC) is sent. Send Starts reading. @ G C <Footer> Receive Refer to the explanation of the output format. “ page 82 Send Stops continuous reading.
  • Page 78 Section 4-3 Trigger Inputs and Output Format Set the matrix size in 2 or 4 digits. Use two digits when the matrix is square, i.e., “@TD 10” if the matrix is 10™10. Use four digits when the matrix is rectangular, i.e., “@TD 1648” if the matrix is 16™48. Refer to Appendix C for tables listing the matrix sizes.
  • Page 79 Section 4-3 Trigger Inputs and Output Format “ER” indicates that the command was not executed correctly: <Header> E R <Footer> Load System and Scene Data (@AL) 1:1 Connection Loads the system and scene data. The data transfer is performed with XMODEM (–CRC or SUM) protocol. (The XMODEM (–1K) proto- col is not supported.) The V530-R150 sends the character string “READY”...
  • Page 80 Section 4-3 Trigger Inputs and Output Format Load Image Data (@BL) 1:1 Connection Loads the image data. The data transfer is performed with XMODEM (–CRC or SUM) protocol. (The XMODEM (–1K) protocol is not sup- ported.) The V530-R150 sends the character string “READY” to the external device when the V530-R150 has completed its initialization.
  • Page 81 Section 4-3 Trigger Inputs and Output Format Read Scene Number (@SN) 1:1 Connection Outputs the scene number (0 to 9) of the scene being displayed. Send @ S N <Footer> Receive The scene number is returned if the command was executed cor- rectly: <Header>...
  • Page 82 Section 4-3 Trigger Inputs and Output Format “ER” indicates that the command was not executed correctly: <Header> E R <Footer> Monitor Display (@DL) 1:1 Connection Switches the display image to “Through,” and displays the specified region. Send <X1> <Y1> <X2> <Y2>...
  • Page 83 Section 4-3 Trigger Inputs and Output Format Read Measurement Time (@MT) 1:1 Connection Reads the most recent read-processing time. Send @ M T <Footer> Receive The 5-digit processing time (00000 to 99999 ms) is returned if the command was executed correctly. <Header>...
  • Page 84 Section 4-3 Trigger Inputs and Output Format Change Mode (@MC) 1:1 Connection Changes the mode to Monitor mode or Run mode. Send <Mode> <Footer> Set the mode to 0 to specify Monitor mode or 1 to specify Run mode. Monitor mode: 0 Run mode: Receive “OK”...
  • Page 85 Section 4-3 Trigger Inputs and Output Format Read Version Information (@VR) 1:1 Connection Reads the system’s version information. Send @ V R <Footer> Receive The version information is returned if the command was executed correctly: <Header> <Version> <FCS> <Footer> Example version information: V530-R150 Ver3.00 2001/04/01 12:00 Read System Data (@SR) 1:1 Connection...
  • Page 86 Section 4-3 Trigger Inputs and Output Format Number System data Host Link Read source data 0: IR/CIO, 1: HR, 2: LR, 3: DM, 4: None area Start address 0000 to 9995 (See note 2.) Write destination data 0: IR/CIO, 1: HR, 2: LR, 3: DM, 4: None area Start address 0000 to 9996 (See note 2.)
  • Page 87 Section 4-3 Trigger Inputs and Output Format Number System data 3964(R) Character delay time 10 to 655350 in 10-ms units. Acknowledge delay 10 to 655350 in 10-ms units. time Setup attribute count 1 to 255 Transfer attribute 1 to 255 count Master/Slave 0: Master, 1: Slave...
  • Page 88 Section 4-3 Trigger Inputs and Output Format Read Scene Data (@CR) 1:1 Connection Reads the settings data for the scene that is currently being dis- played. To read the settings data for another scene, first change the screen number with the Change Scene Number command and then execute this command.
  • Page 89 Section 4-3 Trigger Inputs and Output Format Settings Data for QR Code (Normal) Number Settings data for QR Code (Normal) Digit(s) Image Shutter Speed 0: 1/100 s, 1: 1/500 s, Digit 1 Adjust 2: 1/2,000 s, 3: 1/10,000 s Filtering 0: OFF, 1: Weak Smoothing, Digit 2 2: Strong Smoothing,...
  • Page 90 Section 4-3 Trigger Inputs and Output Format Settings Data for QR Code (Pattern) Number Settings data for QR Code (Pattern) Digit(s) Image Shutter Speed 0: 1/100 s, 1: 1/500 s, Digit 1 Adjust 2: 1/2,000 s, 3: 1/10,000 s Filtering 0: OFF, 1: Weak Smoothing, Digit 2 2: Strong Smoothing,...
  • Page 91 Section 4-3 Trigger Inputs and Output Format Settings Data for Data Matrix (Normal) Number Settings data for Data Matrix (Normal) Digit(s) Image Shutter Speed 0: 1/100 s, 1: 1/500 s, 2: 1/2,000 s, Digit 1 Adjust 3: 1/10,000 s Filtering 0: OFF, 1: Weak Smoothing, Digit 2 2: Strong Smoothing,...
  • Page 92 Section 4-3 Trigger Inputs and Output Format Code Size 2 EC200 EC000 to 140 00: None 11: 36 x 36 23: 9 x 9 01: 10 x 10 12: 40 x 40 24: 11 x 11 02: 12 x 12 13: 44 x 44 25: 13 x 13 03: 14 x 14...
  • Page 93 Section 4-3 Trigger Inputs and Output Format Settings Data for Data Matrix (Pattern) Number Settings data for Data Matrix (Pattern) Digit(s) Image Shutter Speed 0: 1/100 s, 1: 1/500 s, 2: 1/2,000 s, Digit 1 Adjust 3: 1/10,000 s Filtering 0: OFF, 1: Weak Smoothing, Digit 2 2: Strong Smoothing,...
  • Page 94 Section 4-3 Trigger Inputs and Output Format Write Scene Data (@CW) 1:1 Connection Writes the settings data for the scene that is currently being dis- played. To write the settings data for another scene, first change the screen number with the Change Scene Number command and then execute this command.
  • Page 95 Section 4-3 Trigger Inputs and Output Format Read Light Level Settings (@LR) 1:1 Connection Reads the light levels set for the specified Camera’s Intelligent Light Source. Send <Camera number> <Footer> Set the camera number to 0 or 1. Receive If the command was executed correctly, the light level settings will be returned.
  • Page 96 Section 4-3 Trigger Inputs and Output Format Write Light Level Settings (@LW) 1:1 Connection Changes the light level settings for the specified Camera’s Intelligent Light. Send The command format depends on the Intelligent Light Source that is being used. There are 5 settings in the F150-SLC20 Intelligent Light Source and 8 settings in the F150-SLC50 Intelligent Light Source.
  • Page 97 Section 4-3 Trigger Inputs and Output Format One Shot Reading (@GL) 1:N Connection Uses a trigger to read from the V530-R150 with the specified unit number. Reading ends when the reading is correctly performed (OK). When the reading is not correctly performed (NG), reading continues to be performed for the number of retries specified in the setting con- ditions.
  • Page 98 Section 4-3 Trigger Inputs and Output Format Data Matrix Teaching (@MD) 1:N Connection Performs teaching in Data Matrix (normal) mode. If the reading judge- ment is OK, the optimum settings will be registered automatically. If the reading judgement is NG, the settings will not be updated. Auto- matically discriminates between EC200 and EC000 to EC140 based on the matrix size.
  • Page 99 Section 4-3 Trigger Inputs and Output Format “ER” indicates that the command was not executed correctly: <Header> E R <Footer> Output Format of Reading data The following diagrams show the output format used when outputting reading data. There is a setting in the communications specifications setting menu that selects whether or not the Polling Command will be used to control output timing.

  • Page 100: Communications Mode: Host Link

    Section 4-3 Trigger Inputs and Output Format 4-3-2 Communications Mode: Host Link Command Table Command Function Page Code One Shot Reading page 85 Start Continuous Reading page 85 Stop Continuous Reading page 85 Switch to the Specified Scene Number page 86 Increment the Current Scene Number by One page 86 Decrement the Current Scene Number by One...
  • Page 101 Section 4-3 Trigger Inputs and Output Format QR Code (Normal Mode or Pattern Mode) Error Code Description E000 No FP E001 Missing 2 FPs E002 Missing 1 FP E003 3 FPs in wrong position E004 More than 3 FPs E010 Decode error E011 E012...
  • Page 102 Section 4-3 Trigger Inputs and Output Format One Shot Reading (10) 1:1 Connection Reading ends and the judgments are output when the reading is cor- rectly performed. When the reading is not correctly performed, read- ing continues to be performed for the number of retries specified in the setting conditions.
  • Page 103 Section 4-3 Trigger Inputs and Output Format • The data capacity (max.) of codes is as follows. Letters and numbers: 56 letters The reading data after 56th letter are ignored. • When reading is NG, error codes are output to word +1. •...
  • Page 104 Section 4-3 Trigger Inputs and Output Format Read the Current Scene Number (23) 1:1 Connection Read Begin read Setting word 15 to 12 11 to 8 7 to 4 3 to 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 1 Command code...

  • Page 105: Fcs Calculation

    Section 4-4 FCS Calculation FCS Calculation FCS (Frame Check Sequence) can be attached to output data to improve communications. (For normal communications only). FCS is the result of taking the XOR for each byte between header and footer (8 bits) and converting to 2-character ASCII codes. Each time data is received, the host link calculates the FCS and checks it against the FCS attached to sending data so that sending data can be checked for errors.

  • Page 106: Connection Examples

    Section 4-5 Connection Examples Connection Examples 4-5-1 Connection Examples for Programmable Controller (Normal) System Configuration Sync. Sensor Power Supply Monitor (24 VDC) RS-232C Cable XW2Z-200T (2 m) V530-R150 or XW2Z-500T (5 m) Programmable Controller Power Supply Unit: CQM1-PA** Camera CPU Unit: CQM1H-CPU*** Cable Wiring (XW2Z-200T (2 m) or XW2Z500T (5 m)) V530-R150...
  • Page 107 Section 4-5 Connection Examples Communication Settings • V530-R150 “ page 194 Item Setting Baud rate 19200 bps Data length 8 bit Parity bits EVEN Stop bits 2 bit Header None Footer Mode Normal • Programmable Controller: Turn OFF the DIP switch of CQM1H. Set DM6645 to [1001], DM6646 to [0904], DM6648 to [1000] and DM6649 to [0D00].

  • Page 108: Plc Connection Examples (Host Link)

    Section 4-5 Connection Examples 4-5-2 PLC Connection Examples (Host Link) System Configuration Power Supply (24 VDC) Monitor RS-232C Cable XW2Z-200T (2 m) or XW2Z-500T (5 m) V530-R150 Programmable Controller Power Supply Unit: C200H-PA204S Camera CPU Unit or Host Link Unit: CS1H-CPU64 I/O Unit: C200H-ID212 Cable Wiring (XW2Z200T (2 m) or XW2Z500T (5 m)) V530-R150...
  • Page 109 Section 4-5 Connection Examples Communication Settings • V530-R150 Settings “ page 194 and page 196 Item Setting Communication setting Baud rate The same settings as those of the Program- Data length mable Controller. Parity bits Stop bits Mode Host link Host Link setting Read area Begin read word...

  • Page 110: Computer Connection Examples (Normal)

    Section 4-5 Connection Examples Check whether or not data has been written by checking the sta- tus of the Write Flags in DM0110. Each time that data is written, the Write Flags are switched between “0000” and “1111”. One Shot Reading Command Increment the Current Scene Number Command (+1) Decrement the Current Scene...

  • Page 111: Multi-Drop Connection Examples (Normal)

    Section 4-5 Connection Examples Cable Wiring (XW2Z-200S-V (2 m) or XW2Z-200S-V (5 m)) V530-R150 Personal computer Signal Pin No. Pin No. Signal Shield Pin numbers will depend on the type of personal computer connected. Refer to the manual of the personal computer. Communication Settings Match the communication settings (baud rate, data length, parity bits, and stop bits) of the personal computer and V530-R150.
  • Page 112 The number of RS-232C/RS-422(485) converters/adapters required will be one more than the number of V530-R150s in the system. An example of a configuration using OMRON’s NT-AL001 Adapter is given below. Descriptions of connections 1 to 4 are given after the diagram.
  • Page 113 Section 4-5 Connection Examples Cable Wiring Connection 1 The wiring required between V530-R150s and NT-AL001s is shown below. V530-R150 NT-AL001 Meaning Signal Signal Pin No. Pin No. SD (TXD) SD (TXD) Send data RD (RXD) RD (RXD) Receive data RS (RTS) RS (RTS) Request to send CS (CTS)
  • Page 114 Section 4-5 Connection Examples Connection 4 The wiring required between the host and the NT-AL001 is shown below. Host NT-AL001 Meaning Signal Signal Pin No. Pin No. SD (TXD) SD (TXD) Send data RD (RXD) RD (RXD) Receive data RS (RTS) RS (RTS) Request to send CS (CTS)
  • Page 115 Section 4-5 Connection Examples Note If a reading trigger is turned ON before the data is downloaded, the V530-R150 will operate as shown below and the previous reading data will be overwritten. START V530-R150 V530-R150 V530-R150 Host Unit number 00 Unit number 01 Unit number 02 Reading...

  • Page 116: Operations

    SECTION 5 Operations This section gives an overview of menu operations for the V530-R150 2-Dimensional Code Reader and explains the procedures required to perform basic operations. For more details of operations on the V530-R150, refer to SECTION 6 Functions and Operations. Menu Operations .

  • Page 117: Menu Operations

    Section 5-1 Menu Operations Menu Operations Console The Console is used to perform menu operations. Be sure to familiar- ize yourself with Console operations before actually using the menus. TRIG (trigger) Key ESC (escape) Key ENT (enter) Key Up, Down, Left, and Right Keys SHIFT Key Function...
  • Page 118 Section 5-1 Menu Operations Screen Displays Scene No. The current scene number is given. 10 different reading conditions can be set. Mode (*1) The current mode is displayed. Displayed Image The type of image current- ly displayed on the screen is indicated.

  • Page 119: Step 1 Starting

    Section 5-2 STEP 1 Starting STEP 1 Starting Procedure 1,2,3... Be sure that the basic system components have been connected correctly. “ page 13 Turn ON the power supply on the monitor. Turn ON the power supply on the V530-R150. A startup message appears followed by a processing message.
  • Page 120 Section 5-2 STEP 1 Starting Be sure that the 2-dimensional code is correctly displayed within the field of vision on the monitor. The through image is displayed by pressing the SHIFT + Down Keys. If not displayed correctly, adjust the focus, camera setting distance, and lighting.

  • Page 121: Step 2 Setting Reading Conditions

    Section 5-3 STEP 2 Setting Reading Conditions STEP 2 Setting Reading Conditions The default setting is for MON (monitor) mode to be displayed when the power is first turned ON. Before setting the reading conditions it is necessary to switch to SET mode. Note This section only describes the functions necessary for basic operations.
  • Page 122 Section 5-3 STEP 2 Setting Reading Conditions When using Data Matrix Reading, proceed to Data Matrix Read- ing below. When using QR Code Reading, proceed to QR Code Reading on page 108. Data Matrix Reading Select the required shutter speed and matrix size. The other reading conditions can be set using the teaching function.
  • Page 123 Section 5-3 STEP 2 Setting Reading Conditions Select the shutter speed according to the movement of the reading object. Press the ENT Key to set the shutter speed. The display will return to the window shown in step 5. Press the ESC Key once to go back to the window shown in step 4.
  • Page 124 Section 5-3 STEP 2 Setting Reading Conditions Select the matrix size for the code using the Up/Down Keys. Press the ENT Key to validate the setting and go back to the window shown in step 8. Matrix size ™ ™ ™...
  • Page 125 Section 5-3 STEP 2 Setting Reading Conditions 12 Press the TRIG Key on the Console to perform one reading. Parameters are set based on the data obtained with this reading. The obtained parameters are displayed. These parameters are registered as reading conditions. In RUN mode, only the read data (ABCDE12345 in this example) is output to RS-232C.
  • Page 126 Section 5-3 STEP 2 Setting Reading Conditions Select QRCode (Normal). The following screen will be displayed. Select 0.Image Adjust. Select Shutter Speed. Select the shutter speed according to the movement of the read- ing object. Press the ENT Key to set the shutter speed. The display will re- turn to the window shown in step 5.
  • Page 127 Section 5-3 STEP 2 Setting Reading Conditions Press the ESC Key once to go back to the window shown in step Moving rate Slow Fast Select Read QR (Normal). Select Reading Settings (Teaching). Select the symbol color using the Up/Down Keys. Press the ENT Key to validate the setting and go back to the win- dow shown in step 8.
  • Page 128 Section 5-3 STEP 2 Setting Reading Conditions 10. Press the ESC Key once to go back to the window shown in step 11. Press the ESC Key once more to return to MON (monitor) mode. 12. Press the TRIG Key on the Console to perform one reading. Parameters are set based on the data obtained with this reading.

  • Page 129: Step 3 Checking Reading

    Section 5-4 STEP 3 Checking Reading (Manual) from the screen shown in step 8, and press the ENT Key. The teaching function will be turned OFF by entering the Reading Settings (Manual) window. 13. This completes the settings. STEP 3 Checking Reading Confirm whether reading is performed correctly under the setting conditions.
  • Page 130 Section 5-4 STEP 3 Checking Reading Press the TRIG Key on the Console. One reading is performed. A trigger can be input via terminal blocks or RS-232C. Reading judgement is not output to the termi- nal blocks or RS-232C but displayed on the monitor. Note For details on troubleshooting when reading is not performed cor- rectly, refer to 9-1 Improving Reading.

  • Page 131: Step 4 Starting Code Reading

    Section 5-5 STEP 4 Starting Code Reading STEP 4 Starting Code Reading Enter RUN mode to perform readings. The reading judgment is out- put to external devices through terminal blocks or RS-232C. Procedure 1,2,3... Move the cursor to MON (monitor) and press the ENT Key. The mode selections are displayed.

  • Page 132: Step 5 Quitting

    Section 5-6 STEP 5 Quitting STEP 5 Quitting Note Be sure to save the revised setting data to flash memory before turning OFF. As the V530-R150 loads data from flash memory at startup, any new data be will lost if it is not saved to flash memory. Also, images in RAM are cleared when power is turned OFF.
  • Page 133 Section 5-6 STEP 5 Quitting Note Never input the reset signal or turn OFF the power when process- ing messages are displayed. Data may be lost, and the V530- R150 may not operate properly the next time it is started. Turn OFF the power for the V530-R150.

  • Page 134: Functions And Operations

    SECTION 6 Functions and Operations This section gives details of the functions and operations possible with the V530-R150 2- Dimensional Code Reader, including the procedures necessary for communications with external devices. SET (Setting) Mode ......6-1-1 Menu Registration .

  • Page 135: Set (Setting) Mode

    Section 6-1 SET (Setting) Mode SET (Setting) Mode 6-1-1 Menu Registration The V530-R150 has the four reading modes shown below. Choose the mode that is appropriate for the type of code and the conditions in which it is to be read. Menu Contents QR Code (Normal)
  • Page 136 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Enter the SET mode. The following items will be displayed. Select the required item using the Up/Down Keys and press the ENT Key. Example: If DataMatrix (Normal) is selected, the following screen will be displayed. The initial screen for the selected menu will be displayed.

  • Page 137: Using A Two-Camera Unit

    Section 6-1 SET (Setting) Mode 6-1-2 Using a Two-camera Unit When a Two-camera Unit will be used, change the settings in the SYS/Device settings menu in advance. “ page 210 Procedure 1,2,3... Press the SHIFT + ENT Keys while the menu’s initial screen is displayed.

  • Page 138: Menu Tree

    Section 6-1 SET (Setting) Mode Camera Mode Camera mode Screen image Explanation Two-camera The images from the two cameras are input at switching the same time with each trigger input. The image from camera 0 is read first. If the code is not read in camera 0’s image, camera 1’s image is read.
  • Page 139 Section 6-1 SET (Setting) Mode Data Matrix Code Reading in Normal Mode 1/100 s 0. Image Adjust Shutter Speed 1/500 s page 126 1/2000 s 1/10000 s Filtering Weak Smoothing page 127 Strong Smoothing Enhance Edges page 128 Filtering Retry Upper BGS Levels page 129...
  • Page 140 Section 6-1 SET (Setting) Mode Data Matrix Code Reading in Pattern Mode 1/100 s 0. Image Adjust Shutter Speed 1/500 s page 126 1/2000 s 1/10000 s Filtering Weak Smoothing page 127 Strong Smoothing Enhance Edges page 128 Filtering Retry Upper page 129 BGS Levels...
  • Page 141 Section 6-1 SET (Setting) Mode QR Code Reading in Normal Mode 1/100 s 0. Image Adjust Shutter Speed 1/500 s page 126 1/2000 s 1/10000 s Filtering Weak Smoothing page 127 Strong Smoothing Enhance Edges page 128 Filtering Retry Upper page 129 BGS Levels Lower...
  • Page 142 Section 6-1 SET (Setting) Mode QR Code Reading in Pattern Mode 1/100 s 0. Image Adjust Shutter Speed 1/500 s page 126 1/2000 s 1/10000 s Filtering Weak Smoothing page 127 Strong Smoothing Enhance Edges page 128 Filtering Retry page 129 Upper BGS Levels Lower...

  • Page 143: Image Adjust

    Section 6-1 SET (Setting) Mode 6-1-4 Image Adjust Shutter Speed 0. Image Adjust The shutter speed can be adjusted to a value appropriate for the speed of the objects with the codes. Procedure 1,2,3... Select 0. Image Adjust. Select Shutter Speed. Select an appropriate speed while viewing the image.
  • Page 144 Section 6-1 SET (Setting) Mode Filtering 0. Image Adjust Select the way the image taken by the Camera is to be processed before it is displayed. Filtering selection Function No filtering is performed. Smoothing The effects of noise are suppressed to produce a smooth image.
  • Page 145 Section 6-1 SET (Setting) Mode Filtering Retry 0. Image Adjust If this setting is turned ON, the filtering process selected with Image Adjust/Filtering will be performed twice. The time required for filter- ing will increase by approximately 33 ms, but when reading codes made up of dots, reading can be performed with greater stability by performing smoothing twice.
  • Page 146 Section 6-1 SET (Setting) Mode Select either OFF or ON, and press the ENT Key to validate the setting. BGS Levels 0. Image Adjust Densities lower than the set lower limit will be converted to 0 (i.e., areas with densities lower than that value will not be read) and densi- ties higher than the set upper limit will be converted to 255, and inter- mediate densities will be graded between 0 and 255.
  • Page 147 Section 6-1 SET (Setting) Mode Select BGS Levels. Change the upper and lower limits as required. Press the Right Key to increase values by 1. Press the Left Key to decrease values by 1. Press the SHIFT Key together with Right/ Left Key to increase/decrease values by 10.
  • Page 148 Section 6-1 SET (Setting) Mode Light Control 0 (or 1) 0. Image Adjust When a Camera with an Intelligent Light Source is connected, the light level can be adjusted from the V530-R150. Light Control 0 is the lighting for Camera 0 and Light Control 1 is the lighting for Camera 1.
  • Page 149 Section 6-1 SET (Setting) Mode Intelligent Lighting Adjustment Screen B. Light level display A. Adjustment display C. Sample Lighting pattern number A. Adjustment Display F150-SLC20 F150-SLC50 Viewed from this direction The light levels The light levels in 5 areas can in 8 areas can be adjusted.
  • Page 150 Section 6-1 SET (Setting) Mode Method 1: Using a Sample Lighting Pattern There are 15 sample lighting patterns registered, so the best lighting pattern can be selected just by switching through the pattern num- bers and determining which pattern gives the sharpest image. The sample pattern number can be switched by pressing the SHIFT Key together with the Left or Right Key.
  • Page 151 Section 6-1 SET (Setting) Mode F150-SLC50 Pattern Light levels Pattern Light levels Pattern Light levels Method 2: Adjusting Light Levels Individually The light level for each area can be set independently between 0 and 7. (0 is OFF and 7 is the brightest.) After selecting one of the sample patterns, the light level in each area can be fine-tuned if necessary.
  • Page 152 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select 0. Image Adjust. Select Light Control 0 (or 1). Change the light level settings. Press the SHIFT Key together with the Left or Right Key to select the desired lighting pattern. Press the Left/Right Keys to select the lighting area to be adjust- Press the Up/Down Keys to adjust the area’s light level.

  • Page 153: Read Dm (Normal)

    Section 6-1 SET (Setting) Mode 6-1-5 Read DM (Normal) Reading Settings (Teaching) 1. Read DM (Normal) Using the teaching function, a reading image is obtained, measure- ment is performed on this image, and based on the results of this measurement, parameters for reading conditions (symbol color, Right &...
  • Page 154 Section 6-1 SET (Setting) Mode Select the code size. Use the Up/Down Keys to select the required setting, and validate this setting by pressing the ENT Key. The display will return to the window shown in step 2. Code size 10 x 10 to 64 x 64 ECC200 8 x 18 to 16 x 48...
  • Page 155 Section 6-1 SET (Setting) Mode Press the TRIG Key on the Console to perform one reading. The parameters obtained are displayed. These parameters are registered as settings. In RUN mode, only the read data (1234567890 in this example) is output to RS-232C. Note Parameters will be set based on the results of this reading.
  • Page 156 Section 6-1 SET (Setting) Mode 1. Read DM (Normal) Reading Settings (Manual) Set the various reading condition parameters. This menu can also be used to view or change parameters set using the teaching function. Note “Length of Finder” is the length of the finder patterns for the code expressed in pixel units.
  • Page 157 Section 6-1 SET (Setting) Mode Select whether Right & Left Reverse of Data Matrix is necessary. Necessary For reading an image after reflection, or through the back of a transparent material, such as glass. For normal reading (from the front of the object) (Default setting) Auto...
  • Page 158 Section 6-1 SET (Setting) Mode Select the number of retries to be made if the reading is NG. (0 to 9; Default setting: 0.) Reading will be executed for the spec- ified number of retries. Normal Procedure 1,2,3... Select Read DM (Normal). Select Reading Settings (Manual).

  • Page 159: Display Settings

    Section 6-1 SET (Setting) Mode 6-1-6 Display Settings Display Settings Display Settings 1. Read QR (Normal) 1. Read DM (Normal) Display Settings Display Settings 1. Read QR (Pattern) 1. Read DM (Pattern) Set the contents displayed in MON (monitor) mode and RUN mode. The processing time will increase in proportion to the number of dis- play items selected.
  • Page 160 Section 6-1 SET (Setting) Mode Specifies whether or not to display the Cell Position on the screen. A cross cursor will be displayed at the position identified as (default) the cell. Do not display the cell’s position. Note When the Function Settings/Cell Verify setting is set to Verify, that setting takes precedence and this Cell Verify position setting is invalid.
  • Page 161 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select Read**. Select Display Settings. Set the items as required. Select Register to validate the settings and leave this window.

  • Page 162: Function Settings

    Section 6-1 SET (Setting) Mode 6-1-7 Function Settings 1. Read QR (Normal) 1. Read DM (Normal) Function Settings Function Settings Function Settings Function Settings 1. Read DM (Pattern) 1. Read QR (Pattern) There are functions that can be used to increase the reliability of reading.
  • Page 163 Section 6-1 SET (Setting) Mode Data 0 to 3: The data read in the next trigger is registered as the number of standard data. Verify: Every time reading is performed, the registered standard data and reading data are verified. The judgment result is output to the terminal block (DO0 to DO3) and RS-232C (Normal).
  • Page 164 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select Read**. Select Function Settings. Set the items as required. Select Register to validate the settings and leave this window.

  • Page 165: Read Dm (Pattern)

    Section 6-1 SET (Setting) Mode 6-1-8 Read DM (Pattern) Pattern Settings 1. Read DM (Pattern) The method of registering model images of finder patterns, and using these models to find finder patterns from input images is called “pat- tern search.” Because image patterns are used, code positions can still be found with greater accuracy than with Normal mode, even if the printing quality is poor.
  • Page 166 Section 6-1 SET (Setting) Mode Model Registration Use the following procedure to register models of finder patterns. Procedure 1,2,3... Select Read DM (Pattern). Select Pattern Settings. Select Model Registration. The display image can be changed by pressing the SHIFT Key to- gether with the Up/Down Keys.
  • Page 167 Section 6-1 SET (Setting) Mode Display the image to be used in model registration. “ page 184 Press the ENT Key to validate the selection. Select the matrix size. Matrix size 10 x 10 to 64 x 64 ECC200 8 x 18 to 16 x 48 9 x 9 to 25 x 25 ECC000 to ECC140 The ECC will be set automatically when the matrix size is select-...
  • Page 168 Section 6-1 SET (Setting) Mode Draw the Finder Pattern to fit the code. Specify the three end points on the pattern. Move the arrow cur- sor with the Up/Down/Left/Right Keys and press the ENT Key to confirm the position. Select the code’s direction. (The “4 directions” setting results in a longer processing time than the other settings.) •...
  • Page 169 Section 6-1 SET (Setting) Mode Press the ENT Key to complete the model registration. To correct the last two steps, press the ESC Key and redo steps 7 and 8. Note Go to Reference Model, and check that models, including back- ground, are registered in 3 places.
  • Page 170 Section 6-1 SET (Setting) Mode Select Pattern Settings. Select Reference Model. The model image will be displayed. Back- ground Code If a square contains a space, repeat the procedure. Wrong Space Press the ENT or ESC Key to leave this screen.
  • Page 171 Section 6-1 SET (Setting) Mode Search Region Specify the range over which to search for the model. Procedure 1,2,3... Select Read DM (Pattern). Select Pattern Settings. Select Search Region. Draw a square over the region to be searched. Under normal con- ditions, draw the whole screen.
  • Page 172 Section 6-1 SET (Setting) Mode Reading Settings 1. Read DM (Pattern) Set the reading conditions and the conditions for searching for a model when reading Data Matrix codes. 1,2,3... Select the color of symbol. Black Black symbol printed on white base. (Default setting) White...
  • Page 173 Section 6-1 SET (Setting) Mode After changing the setting, perform a search to confirm whether the search can be performed correctly. Pixel Skipping X Pixel Skipping Y Set the number of pixels skipped when searching. Set the correlation threshold value for detecting finder patterns. Correlation values equal to or higher than the threshold are de- tected.
  • Page 174 Section 6-1 SET (Setting) Mode Select Reading Settings. Set the items as required. Select Register to validate the settings and leave this window.

  • Page 175: Read Qr (Normal)

    Section 6-1 SET (Setting) Mode 6-1-9 Read QR (Normal) Reading Settings (Teaching) 1. Read QR (Normal) Using the teaching function, a reading image is obtained, measure- ment is performed on this image, and based on the results of this measurement, parameters for reading conditions (Right & Left Reverse, Gray Edge Value) are automatically determined.
  • Page 176 Section 6-1 SET (Setting) Mode Use the Up/Down Keys to select the required setting, and validate this setting by pressing the ENT Key. The display will return to the window shown in step 2. Black Black symbol printed on white base. White White symbol printed on black base.
  • Page 177 Section 6-1 SET (Setting) Mode Press the TRIG Key on the Console to perform one reading. The parameters obtained are displayed. These parameters are used as settings. In RUN mode, only the read data (ABCDE12345 in this example) is output to RS-232C. Note Parameters will be registered based on the results of the first reading.
  • Page 178 Section 6-1 SET (Setting) Mode Reading Settings (Manual) 1. Read QR (Normal) The reading conditions can be set manually. If parameters have been set using the teaching function, those parameters can be viewed or changed, if necessary, from this menu. *: Indicates items set automatically using the teaching function.
  • Page 179 Section 6-1 SET (Setting) Mode Set the timeout time for decode processing of a single image read. (Setting range: 200 to 2,000 ms; default setting: 500 ms.) Select the number of times reading is repeated in the event of in- correct reading.

  • Page 180: Read Qr (Pattern)

    Section 6-1 SET (Setting) Mode 6-1-10 Read QR (Pattern) Pattern Settings 1. Read QR (Pattern) The method of registering model images of finder patterns, and using these models to find finder patterns from input images is called “pat- tern search.” Because image patterns are used, code positions can still be found with greater accuracy than with Normal mode, even if the printing quality is poor.
  • Page 181 Section 6-1 SET (Setting) Mode Select Pattern Settings. Select Model Registration. The display image can be changed by pressing the SHIFT Key to- gether with the Up or Down Key. Display the image to be used in model registration. “ page 184 Press the ENT Key to validate the selection.
  • Page 182 Section 6-1 SET (Setting) Mode Up/Down/Left/Right Keys and press the ENT Key to confirm the position. Approx. 0.5 cells Note Register a finder pattern with a margin of approx. 0.5 cells around the edges. Press the ENT Key to complete the model registration. To correct the last two steps, press the ESC Key and redo steps 6 and 7.
  • Page 183 Section 6-1 SET (Setting) Mode Reference Model It is possible to view the model image (without the surrounding code) by displaying it on the monitor screen. After registering a model, be sure to use this function to check that the finder patterns for the model have been registered.
  • Page 184 Section 6-1 SET (Setting) Mode The model image will be displayed. Press the ENT or ESC Key to leave this screen. Search Region Specify the range over which to search for the model. Procedure 1,2,3... Select Read QR (Pattern). Select Pattern Settings. Select Search Region.
  • Page 185 Section 6-1 SET (Setting) Mode Draw a square over the region to be searched. Under normal con- ditions, draw the whole screen.
  • Page 186 Section 6-1 SET (Setting) Mode Reading Settings 1. Read QR (Pattern) Set the reading conditions and the conditions for searching for a model for QR Code reading. 1,2,3... Select the color of symbol. Black Black symbol printed on white base. (Default setting) White...
  • Page 187 Section 6-1 SET (Setting) Mode After changing the setting, perform a search to confirm whether the search can be performed correctly. Pixel Skipping X Set the number of pixels Pixel Skipping Y skipped when searching. Set the correlation threshold value for detecting finder patterns. Correlation values equal to or higher than the threshold are de- tected.
  • Page 188 Section 6-1 SET (Setting) Mode Select Reading Settings. Set the items as required. Select Register to validate the settings and close the window.

  • Page 189: Image Analysis

    Section 6-1 SET (Setting) Mode 6-1-11 Image Analysis Display Pixel Value 2. Image Analysis Displays the density information in the range 0 to 255 for a specific area. 1,2,3... Specified area is 16 x 16 pixels. Use Up/Down/Left/Right Keys to move to the position for which density information is required.
  • Page 190 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select 2.Image Analysis. Select Display Pixel Value. Move to the required area by using the Up/Down/Left/Right Keys. The density information will be displayed. Press the SHIFT Key at the same time to move faster. Press the ESC Key to leave this screen.
  • Page 191 Section 6-1 SET (Setting) Mode Image Magnifier 2. Image Adjust Magnifies the image in a specified area. 1,2,3... The specified area is 32 x 32 pixels (fixed). Use the Up/Down/Left/Right Keys to move to the position to be magnified. Press the SHIFT Key at the same time to move faster. The image in the specified area is magnified.
  • Page 192 Section 6-1 SET (Setting) Mode Select Image Magnifier. Move to the specified area using Up/Down/Left/Right Keys. Press the SHIFT Key at the same time to move faster. Press the ENT Key. A magnified image is displayed within a dotted frame. Press the ESC Key to leave this screen.
  • Page 193 Section 6-1 SET (Setting) Mode Measure Length 2. Image Analysis Measures the size of cells in pixels. For stable reading, adjust the field of vision to be at least five pixels per cell. 1,2,3... Specify the beginning and end point of the line to be measured. The number of pixels per cell is displayed for QR Codes.
  • Page 194 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select 2.Image Analysis. Select Measure Length. Move the cross cursor to the beginning point using Up/Down/Left/ Right Keys and press the ENT Key. Press the SHIFT Key at the same time to move faster. Specify the end point in the same way.
  • Page 195 Section 6-1 SET (Setting) Mode Contrast (Line Bright) 2. Image Analysis The Contrast (Line Bright) function can be used to check variables such as the contrast between the code and background, as well as the contrast between the code’s white cells and black cells. The lower the contrast, the less stable the measurements will be, so adjust the lighting and settings if the contrast is too low.
  • Page 196 Section 6-1 SET (Setting) Mode trast ranges from 0.00 to 1.00, with higher values indicating high- er contrast and lower values indicating lower contrast. Note Analysis is not performed on through images. Procedure 1,2,3... Select 2. Image Analysis. Select Contrast (Line Bright). Set the gray edge level for black and white judgment (1 to 255) and select Register.
  • Page 197 Section 6-1 SET (Setting) Mode To change the line, press the ESC Key and repeat steps 4 and 5 as required. Press the ESC Key to leave this screen.
  • Page 198 Section 6-1 SET (Setting) Mode Contrast (Region) 2. Image Analysis The Contrast (Region) function can be used to check variables such as the contrast between the code and background, as well as the contrast between the code’s white cells and black cells. The contrast will be displayed for the specified white cell region and black cell region.
  • Page 199 Section 6-1 SET (Setting) Mode Procedure 1,2,3... Select 2. Image Analysis. Select Contrast (Region). Move the cross cursor with the Up/Down/Left/Right Keys and press the ENT Key when the cursor is at the top-left corner of the desired white cell. Press the SHIFT Key together with the above keys to move the cursor faster.

  • Page 200: Mon (Monitor) Mode

    Section 6-2 MON (Monitor) Mode MON (Monitor) Mode Confirms whether the reading can be correctly performed with the set conditions. The reading judgment and data are not output to the terminal blocks or RS-232C but displayed on a monitor. Procedure 1,2,3...
  • Page 201 Section 6-2 MON (Monitor) Mode being used, the light will be about 20% dimmer after 1,500 hours of operation. Types of Displayed Image Freeze (@) A still image immediately after measurement. The memory number (0 to 23) under which the image is stored is displayed in @. When reading moving objects, display freeze images.
  • Page 202 Section 6-2 MON (Monitor) Mode Displays Vary with the Settings of Read****/Display Settings When Reading Data is ON: OK: Reading data are displayed. NG: Error codes are displayed. (e.g.) Reading OK When Detail Data is ON: Detailed data of reading codes are displayed. The displayed contents will vary depending on the code.
  • Page 203 Section 6-2 MON (Monitor) Mode QR Code (Normal or Pattern Mode) Item Contents Normal Pattern Symbol Color Displays the Symbol Color setting. Right & Left Reverse Displays the Right & Left Reverse setting. Gray Edge Value Displays the Gray Edge Value setting. Pixel Skipping Displays the Pixel Skipping setting.
  • Page 204 Section 6-2 MON (Monitor) Mode Data Matrix (Normal or Pattern Mode) Item Contents Normal Pattern ECC Level Displays the ECC setting that was set automatically when the code size was selected. Symbol Color Displays the Symbol Color setting. Right & Left Reverse Displays the Right &...
  • Page 205 Section 6-2 MON (Monitor) Mode When Finder Pattern is ON: A cross cursor will be displayed at the position recognized as a finder pattern. However, the finder pattern position is not displayed when the Func- tion Settings/Cell Verify setting is set to Verify. Example When Cell Position is ON: A cross cursor will appear at the position recognized as a cell.
  • Page 206 Section 6-2 MON (Monitor) Mode Displays Vary with the Settings of Read****/Function Settings When Cell Verify is set to Verify: The data will be verified with reference data and the cross cursor will be displayed at a different position. The result of the Cell Verify func- tion will take precedence and be displayed even when the Display Settings/Cell Position or Display Settings/Finder Pattern is ON.
  • Page 207 Section 6-2 MON (Monitor) Mode When Data History is ON: The number of readings and the number of OK readings recorded since this setting was turned ON, and error count results are dis- played. To reset Data History, set to OFF and select Register. Turn OFF Judge Coincidence and Reading Accuracy functions because they cannot be used together with Data History.

  • Page 208: Run Mode

    Section 6-3 RUN Mode RUN Mode Reading is performed under the setting conditions for the scene dis- played. Reading judgement and data are output to external devices. For details regarding the display items, refer to page 183 MON (Monitor) Mode. “ page 183 Procedure 1,2,3...

  • Page 209: System

    Section 6-4 System System 6-4-1 Menu Tree For explanations of the various operations, refer to the pages given in the following table.
  • Page 210 Section 6-4 System Baud rate RS-232C Communications Data length Parity bits Stop bits page 194 Header Footer Mode Flow control Normal page 195 Timeout Read area Host link Begin read word page 196 Write area Begin write word PLC mode check 3964(R) Cha.

  • Page 211: Communications Method

    Section 6-4 System 6-4-2 Communications Method Sets communications methods when communicating to external devices via terminal blocks or RS-232C. • When communicating in normal format via RS-232C: Set the communications method for RS-232C and Normal. • When communicating with host link via RS-232C: Set the communication method for RS-232C and Host link.
  • Page 212 Section 6-4 System Normal If Normal is selected for the communications mode, it is possible to communicate with host devices such as personal computers with nor- mal format via RS-232C. MON (Monitor) Mode Receives command inputs, but the reading results are not output. RUN Mode Possible to input commands and output the reading results.
  • Page 213 Section 6-4 System Host Link When Host link is selected for the communications mode, it is possi- ble to communicate with host devices such as Programmable Con- troller with host link format via RS-232C. MON (Monitor) Mode Receives command inputs, but the reading results are not output. RUN Mode Possible to input commands and output the reading results.
  • Page 214 Section 6-4 System forcibly switch the Programmable Controller to MONITOR mode. 3964(R) The 3964(R) procedure controls data transmission via a point-to- point connection between a Siemens product and a communications partner. 3964(R) Cha. delay time [ 22]x10ms Ack. delay time [ 200]x10ms Setup att.
  • Page 215 Section 6-4 System This parameter defines the maximum number of attempts the product is allowed in order to establish a connection. Select 1 to 255. (Default setting: 6) This parameter defines the maximum number of attempts permit- ted to transfer a message frame (including the first one) in the event of an error.
  • Page 216 Section 6-4 System 1,2,3... Select a trigger mode for TRIG B. Continuous Performs continuous reading while the TRIG B termi- (Default) nal is turned ON. In this mode, the settings for reading accuracy and the number of retries are invalid with TRIG B input.
  • Page 217 Section 6-4 System These settings determine how data will be output through RS-232C (Normal) communications. 030 221223 060 2001 03 2 6 - ABCDEFG - 0815 Example: 1,2,3... Select whether or not to include the number of digits of Reading Data.
  • Page 218 Section 6-4 System Note If polling is turned ON, RS-232C and terminal block data (DO0 to DO3) will not be output until the polling command is received. Select whether or not to output just a part of the Reading Data. Select OFF or ON.

  • Page 219: Image Storage

    Section 6-4 System Set each item. (e.g.) RS-232C Select End before leaving this screen. 6-4-3 Image Storage Image storage Selects whether to store the reading image or not. A maximum of 24 images can be stored. Note The stored images are cleared when the power is turned OFF. Back up to a personal computer to keep the image data.
  • Page 220 Section 6-4 System Procedure 1,2,3... Select Image storage. Select the conditions. Select End before leaving this screen.

  • Page 221: Startup Mode

    Section 6-4 System 6-4-4 Startup Mode Sets the scene number and mode to be displayed when the power is turned ON. If the V530-R150 is set to start in RUN mode for the scene where the desired reading conditions are registered, reading can be started by simply turning the power ON.

  • Page 222: Multi Drop

    Section 6-4 System 6-4-5 Multi Drop One host (personal computer or Programmable Controller) can com- municate with more than one V530-R150 by connecting the RS- 232C/RS-422/(485) converter (32 max.). The unit number is attached to the prefix of all communication data so, set a different unit number for each V530-R150.
  • Page 223 Section 6-4 System Note Refer to the manual of the converter for the number of V530- R150 that can be connected. The number is different depending on the converter. 1,2,3... Select whether or not multi-drop connections are being used. Multi-drop connections are not being used. (Default setting) Multi-drop connections are being used.
  • Page 224 Section 6-4 System Set each item. Select End before leaving this screen.

  • Page 225: Error Method

    Section 6-4 System 6-4-6 Error Method A V530-R150 does not perform reading while the BUSY terminal is ON even when TRIG A is input. Set whether or not to turn ON the ERR terminal if a trigger signal is sent while the BUSY terminal is ON to inform the external device that the trigger has not been accepted.
  • Page 226 Section 6-4 System Select the error method. Select End to leave this screen.

  • Page 227: Device Settings

    Section 6-4 System 6-4-7 Device Settings Change the Device Settings with this menu when a Two-camera Unit or Intelligent Light Source is connected. 1,2,3... Specify whether or not a Two-camera Unit is being used. Out of use A Two-camera Unit is not being used. (Default setting) F150-A20 An F150-A20 Two-camera Unit is being used.
  • Page 228 Section 6-4 System Procedure 1,2,3... Select Device settings. Specify which device(s) are connected. Select End to leave this screen.

  • Page 229: Version

    Section 6-4 System 6-4-8 Version The model of the Controller and the version of the software can be displayed. 1,2,3... The model is displayed. The version and production date of the software are displayed. Procedure 1,2,3... Select Version. The version information is displayed. The model and the version of the software can be displayed Select OK to leave this screen.

  • Page 230: Computer Data Backup (Tool Menu)

    Section 6-5 Computer Data Backup (Tool Menu) Computer Data Backup (Tool Menu) The following four kinds of setting data can be backed up to a per- sonal computer. This is a useful function for setting other devices with the same data. Backing up the setting data is recommended as a precaution against loss due to data damage or device malfunctions.
  • Page 231 Section 6-5 Computer Data Backup (Tool Menu) Data may be lost, and the V530-R150 may not operate properly the next time it is started. Saving Data to a Personal Computer (V530-R150 “ Personal Computer) Procedure 1,2,3... Connect the COM1 port on the computer and the V530-R150 us- ing an RS-232 cable.
  • Page 232 Section 6-5 Computer Data Backup (Tool Menu) Once the computer preparations have been completed, display the Monitor mode or Run mode screen. Move the cursor to RUN or MON and press the ENT Key. The mode selection menu will be displayed. Select TOOL from the menu.
  • Page 233 Section 6-5 Computer Data Backup (Tool Menu) If scene data or image data is being transferred, select the de- sired scene number or memory number. Scene number Image data (0 to 9) (Memory 0 to 23, image 0 or 1) A confirmation message will be displayed.
  • Page 234 Section 6-5 Computer Data Backup (Tool Menu) Loading Data From the Computer (V530-R150 ‘ Personal Computer) Procedure 1,2,3... Follow steps 1 to 3 in the above procedure to connect the V530- R150 and the computer. Select Transfer/Send File from the Hyper Terminal menu. Select the file to be loaded.
  • Page 235 Section 6-5 Computer Data Backup (Tool Menu) Select the kind of data to load. (In this case, system data is being loaded from the computer.) 10. If scene data or image data is being transferred, select the de- sired scene number or memory number. Scene number Image data (0 to 9)

  • Page 236: Scenes

    Section 6-6 Scenes Scenes The V530-R150 has 10 scenes. Set different reading conditions for each scene. Procedure 1,2,3... Display the basic screen. Move the cursor to Scn 0 and press the ENT Key. Move the cursor to Scn 1 and press the ENT Key. Scene 1 appears.
  • Page 237 Section 6-6 Scenes Copying Scene Data Procedure 1,2,3... Move the cursor to the desired scene number and press the SHIFT+ ESC Keys. Select Copy. Set the original scene number. Move the cursor to “Scn@” and press the ENT Key. A list of choic- es will be displayed.
  • Page 238 Section 6-6 Scenes Clearing Scene Data Procedure 1,2,3... Move the cursor to the scene number to be cleared and press the SHIFT + ESC Keys. Select Clear. The confirmation message is displayed. Select Execute. Execute Cancel...

  • Page 239: Saving To Flash Memory

    Section 6-7 Saving to Flash Memory Saving to Flash Memory Be sure to save revised setting data to flash memory before power is turned OFF. As the V530-R150 loads data from flash memory at startup, any new data will be lost if it is not saved to flash memory. Procedure 1,2,3...

  • Page 240: Maintenance

    SECTION 7 Maintenance This section describes basic maintenance procedures and inspection items for the V530-R150 2- Dimensional Code Reader. Maintaining and Replacing Light Sources ... . 7-1-1 F150-SL20A/SL50A Maintenance ....7-1-2 F150-SLC20/SLC50 Maintenance.

  • Page 241: Maintaining And Replacing Light Sources

    Section 7-1 Maintaining and Replacing Light Sources Maintaining and Replacing Light Sources • The Light Source will gradually become dimmer as it is used (approx. 20% dimmer after 1,500 hours of operation). Replace the Light Source after approx. 1,500 hours of use. •...
  • Page 242 Section 7-1 Maintaining and Replacing Light Sources Installing the Light Source Camera base Light Source Camera cable Light source connector connector 1,2,3... Mount the Light Source on the Camera. Replace the two screws that secure the Light Source. Insert the light source cable in the slot in the camera base. Connect the light source cable to the light source connector on the back of the Camera.

  • Page 243: F150-Slc20/Slc50 Maintenance

    Section 7-1 Maintaining and Replacing Light Sources 7-1-2 F150-SLC20/SLC50 Maintenance Part Field of vision Model number Light 20 mm F150-LTC20 Source 50 mm F150-LTC50 Removing the Light Source Camera base Light Source Hold this section when removing the cable. 1,2,3... Disconnect the light source cable from the light source connector on the back of the Camera.
  • Page 244 Section 7-1 Maintaining and Replacing Light Sources Installing the Light Source Camera base Light Source 1,2,3... Mount the Light Source on the Camera. Replace the bottom two screws that secure the Light Source. Replace the top two screws that secure the Light Source. Insert the light source cable in the slot in the camera base.

  • Page 245: Regular Inspections

    Section 7-2 Regular Inspections Regular Inspections To maintain the V530-R150 in the best condition, perform the follow- ing regularly. • Lightly wipe off dirt with a soft cloth. • Clean the lens and indicators with a cloth for a lens or air brush. Inspection Items Details Required Tools...

  • Page 246: Specifications/Dimensions

    SECTION 8 Specifications/Dimensions This section gives specifications and dimensions for the component parts of the V530-R150 2- Dimensional Code Reader. 2-Dimensional Code Reader ..... . Console.

  • Page 247: 2-Dimensional Code Reader

    Section 8-1 2-Dimensional Code Reader 2-Dimensional Code Reader V530-R150 (Unit: mm) Four, 4.5 dia. 165 min.
  • Page 248 Section 8-1 2-Dimensional Code Reader Specifications Supply voltage 20.4 to 26.4 VDC (including ripple) Current consumption Approx. 0.5 A Insulation consumption 20 M min. between all DC external terminals and GR terminal (at 100 VDC, with internal surge absorber removed.) Dielectric strength 1,000 VAC, 50/60 Hz between all DC external terminals and GR ter- minal (with internal surge absorber removed.)

  • Page 249: Console

    Section 8-2 Console Console F150-KP (Unit: mm) TRIG SHIFT 2000 Specifications Item Specification Vibration resistance 10 to 150 Hz; half-amplitude: 0.15 mm, 4 times for 8 minutes each in 3 directions Shock resistance 196 m/s , 3 times each in 6 directions •...

  • Page 250: Camera

    Section 8-3 Camera Camera 8-3-1 Camera Only F150-S1A (Unit: mm) Special Light Source connector (8.8 dia.) Camera cable C mount connector (1"-32UN-2A) (11.8 dia.) Two M4 holes with depth of 8 mm 1/4-20UNC with depth of 8 mm...

  • Page 251: Cameras With Intelligent Light Sources

    Section 8-3 Camera 8-3-2 Cameras with Intelligent Light Sources F150-SLC20 F150-LTC20 Light Source (Unit: mm) Two M4 holes with depth of 10 mm 1/4-20UNC with depth of 10 mm...
  • Page 252 Section 8-3 Camera F150-SLC50 F150-LTC50 Light Source (Unit: mm) Two M4 holes with depth of 10 mm 1/4-20UNC with depth of 10 mm...

  • Page 253: Cameras With Light Sources

    Section 8-3 Camera 8-3-3 Cameras with Light Sources F150-SL20A/SL50A (Unit: mm) F150-LT10A Light Source Two M4 holes with depth of 8 mm 1/4-20UNC with depth of 8 mm Specifications F150-SL20A F150-SL50A F150-SLC20 F150-SLC50 F150-S1A Supply voltage 12 VDC Current con- 110 mA max.
  • Page 254 Section 8-3 Camera Performance F150- F150- F150- F150- F150-S1A SL20A SL50A SLC20 SLC50 Camera Picture ele- 1/3” interline CCD (reading all pixels) ment Effective pixels 659 x 494 (H x V) Synchroniza- External sync. via horizontal sync signal tion Shutter speed Electronic shutter: 1/100, 1/500, 1/2000, 1/10000 sec Lens mounting C mount Lens...

  • Page 255: Cables

    Section 8-4 Cables Cables F150-VS Camera Cable (Unit: mm) Item Specification Vibration resistance 10 to 150 Hz; half-amplitude: 0.15 mm, 4 times for 8 minutes each in 3 directions Shock resistance 196 m/s , 3 times each in 6 directions •...
  • Page 256 Section 8-4 Cables F150VM Monitor Cable (Unit: mm) Item Specification Vibration resistance 10 to 150 Hz; half-amplitude: 0.15 mm, 4 times for 8 minutes each in 3 directions Shock resistance 196 m/s , 3 times each in 6 directions • •...

  • Page 257: Two-Camera Unit

    Section 8-5 Two-camera Unit Two-camera Unit F150-A20 (Unit: mm) Two, 4.5 dia. (mounting holes) Mounting hole placement diagram Two, M4...
  • Page 258 Section 8-5 Two-camera Unit Item Specification Supply voltage 20.4 to 26.4 VDC Power consumption Approx. 0.3 A Vibration resistance 10 to 150 Hz; half-amplitude: 0.35 mm (approx. 50 m/s max. accel- eration), 10 times for 8 minutes each in 3 directions Shock resistance 150 m/s , 3 times each in 6 directions...

  • Page 259: Camera Unit Cable

    Section 8-6 Camera Unit Cable Camera Unit Cable F150-VA (Unit: mm) Item Specification Vibration resistance 10 Hz to 150 Hz; half-amplitude: 0.35 mm (max. acceleration: 50 m/s ) 10 times for 8 min. in each 3 directions Shock resistance 150 m/s , 3 times each in 6 directions •...

  • Page 260: Video Monitor

    Section 8-7 Video Monitor Video Monitor F150-M09 (Unit: mm) Item Specification Supply voltage 85 to 264 VAC, 50/60 Hz Power consumption 20 W max. Vibration resistance 5 to 100 Hz, 6 times for 10 minutes each in 3 directions; 0.16-mm full-amplitude or 7.35 m/s acceleration (whichever is smaller) •...

  • Page 261: Lcd Monitor

    Section 8-8 LCD Monitor LCD Monitor F150-M05L Panel thickness: 1.6 to 4.8 46 max. Mounting hooks Monitor Cable (F150-VM) Tolerance: ±1 mm Dimensions in parentheses indicate reference values Panel cutout dimensions (Unit: mm)
  • Page 262 Section 8-8 LCD Monitor Item Specification Supply voltage 20.4 to 26.4 VDC Current consumption 700 mA max. Vibration resistance 10 to 150 Hz; half-amplitude: 0.1 mm, maximum acceleration: 15 m/s , 10 times for 8 minutes each in 3 directions Shock resistance 150 m/s , 3 times each in 6 directions...

  • Page 264: Troubleshooting

    SECTION 9 Troubleshooting This section details errors that may occur with the V530-R150 2-Dimensional Code Reader and gives procedures for dealing with those errors. Improving Reading......9-1-1 Environment and Setup .

  • Page 265: Improving Reading

    Section 9-1 Improving Reading Improving Reading If correct reading is not performed, check the items listed below. 9-1-1 Environment and Setup “ Image Adjust the lighting and the focus to produce a suitable image. The image can be checked in real time by switching to a through image. page 184 “...

  • Page 266: Condition Settings

    Section 9-1 Improving Reading 9-1-3 Condition Settings Confirm the following settings. Item Possible problem Countermeasures Menus Is the correct menu selected? Choose the menu appropriate for the “ code to be read. page 118 Reading Has a finder pattern been detected? Reading accuracy can be improved by (This can be confirmed on the monitor adjusting the following items:...
  • Page 267 Section 9-1 Improving Reading • Try reading in Pattern mode (QR Code or Data Matrix). Before countermeasure After countermeasure Hollowing of Dots Try the following countermeasures when dots appear “hollowed,” i.e., the centers of dot images are white. Countermeasures • The influence of hollowing can be decreased by increasing the field of vision and thereby decreasing the size of the code image.
  • Page 268 Section 9-1 Improving Reading Direct Marking (White Code on Black Background) Try the following countermeasures for codes created using direct marking. Countermeasures • Use the smoothing function in 0. Image Adjust/Filtering. The smoothing function can be made even more effective by using 0. Image Adjust/Filtering Retry.
  • Page 269 Section 9-1 Improving Reading Lighting Try the following countermeasure when performing reading for a code created by direct marking with a laser on stainless steel. Countermeasure • Improve reading accuracy by using the optimum lighting for the reading object. Before countermeasure After countermeasure Ring lighting Coaxial lighting...

  • Page 270: Error Codes And Countermeasures

    Section 9-2 Error Codes and Countermeasures Error Codes and Countermeasures 9-2-1 Data Matrix Reading (Normal or Pattern Mode) Error Code Description Countermeasures E100 Finder pattern detec- No finder patterns were detected. tion error (No candi- • Make sure that the image is displayed on the monitor date finder patterns) correctly.
  • Page 271 Section 9-2 Error Codes and Countermeasures Error Code Description Countermeasures E123 Decode error Codes were restored to correct errors, but not decoded (Cell recognition error) correctly. Part of the codes may be stained or damaged. E150 Decode error The printing is in a special format and not defined for the (No definition error) V530-R150.

  • Page 272: Data Matrix Reading In Pattern Mode

    Section 9-2 Error Codes and Countermeasures 9-2-2 Data Matrix Reading in Pattern Mode Error Code Description Countermeasures E160 Timing pattern detec- No timing pattern was detected. tion error 1 (No finder • The timing pattern may be stained or damaged. Check patterns were detected the condition of the timing pattern.
  • Page 273 Section 9-2 Error Codes and Countermeasures Error Code Description Countermeasures E180 Decode error An L-shape finder pattern was detected but the data E181 could not be decoded. E182 • The data part of the code may be stained or damaged. Check the condition of the data part of the code.

  • Page 274: Qr Code Reading (Normal Or Pattern Mode)

    Section 9-2 Error Codes and Countermeasures 9-2-3 QR Code Reading (Normal or Pattern Mode) Error Code Description Countermeasures E000 No finder patterns No finder patterns were detected. detected • Make sure that the image is displayed on the monitor correctly. •...
  • Page 275 Section 9-2 Error Codes and Countermeasures Error Code Description Countermeasures E030 Pattern search NG As a result of the pattern search, 32 or more proposed finder patterns were found. Make sure the image is displayed on the monitor cor- rectly and check the registered mode. E200 Timeout error Decoding was not performed within the timeout time.

  • Page 276: Troubleshooting

    Section 9-3 Troubleshooting Troubleshooting Connection Errors The power indicator is not lit. • The power supply is not connected properly. • The supply voltage is not 24VDC+10%/–15%. The monitor is blank. • The power of the monitor is not ON. •...
  • Page 277 Section 9-3 Troubleshooting The images on the monitor are recognized but codes are hard to read. • Refer to the entry for the error code in 9-2 Error Codes and Countermeasures. Change the setting conditions and adjust the camera and lighting. •...
  • Page 278 Section 9-3 Troubleshooting The Unit operates well initially, but after a while there is no response from the V530-R150. • The reception buffer on the external device (e.g. computer) is full. Check that settings allow the data to be properly received.

  • Page 280: Ascii Codes

    Appendix A ASCII Codes Character Data (Hexa- Character Data (Hexa- Character Data (Hexa- Character Data (Hexa- decimal No.) decimal No.) decimal No.) decimal No.) ‘ ” & ’ – < >...

  • Page 282: Fcs Check Program Examples (Basic)

    Appendix B FCS Check Program Examples (BASIC) Calculation Examples for Sending FCS DATA$ Sample Data Line Data Length CODE$ Data Character Exclusive Operation 100 ’*****CALCULATE FCS***** 110 ’*FCSSET 120 L=LEN(DATA$) 130 A=0 140 FOR J=1 TO L 150 CODE$=MID$(DATA$,J,1) 160 A=ASC(CODE$)XOR A 170 NEXT J 180 FCS$=HEX$(A) 190 IF LEN(FCS$)=1 THEN FCS$=”0”+FCS$...

  • Page 284: Data Capacity Tables

    Appendix C Data Capacity Tables QR Code QR Code (Model 2) The relation between matrix size (number of cells) and data capacity is shown in the table below. In this example, the matrix size is 29 ™ 29 cells. 7 cells 15 cells 7 cells 7 cells...

  • Page 285: Data Matrix

    Appendix C Data Capacity Tables Data Matrix Data Matrix (ECC200) The relation between matrix size (number of cells) and data capacity is shown in the table below. In this example, the matrix size is 12 ™ 12 cells. 12 cells 12 cells Matrix size Maximum data capacity...
  • Page 286 Appendix C Data Capacity Tables Matrix size Maximum data capacity Num. Cap. Alpha Num. Cap. ™ ™ Data Matrix (ECC100-140) The relation between matrix size (number of cells) and data capacity is shown in the table below. The following diagram shows an ECC100 data matrix (matrix size: 15 ™ 15.) 15 cells 15 cells •...
  • Page 287 Appendix C Data Capacity Tables • ECC050 Matrix size Maximum data capacity Num. Cap. Alpha Num. Cap. ™ ™ ™ ™ ™ ™ ™ ™ • ECC080 Matrix size Maximum data capacity Num. Cap. Alpha Num. Cap. ™ ™ ™ ™...
  • Page 288 Appendix C Data Capacity Tables • ECC140 Matrix size Maximum data capacity Num. Cap. Alpha Num. Cap. ™ ™ ™ ™ ™...

  • Page 290: Glossary

    Appendix D Glossary This glossary focuses on terms related to QR Codes and Data Matrix codes which are matrix-type 2-dimensional codes. There may be some parts of this glossary that do not apply to other types of 2-dimensional codes. Data Matrix Data Matrix codes were developed by I.D.
  • Page 291 Appendix D Glossary Pixel Pixels are the points that make up images. The monitor screen is 512 pixels high and 484 pixels wide which means that the screen contains approximately 250,000 pixels. Adjust the field of vision so that the number of pixels per cell is at least 5. The number of pixels per cell can be measured in 2.
  • Page 292 Appendix D Glossary Cell These squares are the units that make up matrix-type 2-dimensional codes. Whether these cells are black or white determines the information carried by the code. Timing Pattern These patterns are used to determine symbol density and horizontal and vertical dimen- sions and thereby obtain a frame of reference for 2-dimensional codes.
  • Page 293 Appendix D Glossary Resolution The resolution is a measure of the detail with which images are displayed. The V530- R150 can display images (via a monitor) using approximately 250,000 pixels (512 ™ 484). This means that if the field of vision is 512 mm ™ 484 mm, the resolution will be 1 (mm/pixel).

  • Page 294: Version Information

    Appendix E Version Information Data Compatibility The software version for this V530-R150E-3/EP-3 is “Ver. 3.00.” Scene data and system data for the V530-R150E-2/EP-2 (version 2.@@) cannot be used. Changes from Version 2.@@ to Version 3.00 The following table lists functions in the V530-R150E-3/EP-3 (Version 3.00) that are dif- ferent from the V530-R150E-2/EP-2 (Version 2.@@).
  • Page 295 Added a footer code to the The ETX footer code was added to allow communications with “ RS-232C communications OMRON NT-series Programmable Terminals specifications page 194 The data output format in The output format can be customized. For example, just part of the...

  • Page 296: Index

    Index Numerics Delete Monitor Display Increment the Scene Number +1 2-dimensional code Load Image Data Load Scene Data Load System and Scene Data Monitor Display applications One Shot Reading overview One Shot Reading (1:1 connection) ASCII codes One Shot Reading (1:N connection) Polling (1:1 connection) Polling (1:N connection) Polling with Digit Position...
  • Page 297 Index for reading mounting connections display errors See also images Host Link mode Normal mode overview errors RS-232C error codes connector error method Console troubleshooting keys Extension Tube specifications/dimensions continuous mode timing continuous reading Controller calculation mounting/removing program examples specifications/dimensions features copying finder pattern...
  • Page 298 Index See also commands input specifications nomenclature input terminals Normal communications inspections See also modes installation number of retries xiii precautions oblique lighting Judge Coincidence one shot mode timing operations keys output format See also Console keys outputs output format output specifications output terminals lens...
  • Page 299 Index Pattern mode storing menu tree reading errors tact time quitting terminal blocks communications errors reading terminals checking DO terminals conditions input terminals level trigger OK/NG terminal moving objects output terminals performing precautions Reading Accuracy through images reading data timing reflected lighting Trigger inputs ring lighting...

  • Page 300: Revision History

    Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. Z155-E1-01 Revision code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.

This manual is also suitable for:

V530-r150ep-3

Table of Contents
