Land Pride RC50 Series Brochure

RC50
SERIES
70 - 250 HP — 20'
The Commander series is available
in a 20' Cutter to maximize and take
command of your largest areas. Built
to handle 3" diameter material, cutting
a 20' swath will put a great deal
of work behind you in a hurry.
Roadsides, pastures, set-aside acres
and crop residue are perfect jobs for
the 20' Commander. Wing decks float
independently, and follow the contour
of the land leaving a nicely cut surface.
• 540 or 1000 RPM
• Self-leveling hitch reduces drawbar wear
• 3/16" Deck thickness
• 1/4" Sidewall thickness reduces
16
debris piercing possibilities
• 1/2" x 4" Blades with 6" blade overlap
• 3" Cutting capacity
• Replaceable skid shoes: one each wing,
two on center section
• 3/16" Round stump jumper
• Input driveline: Cat. 5 CV or Conventional, Star Profile
• 250 HP gearbox rating with rugged 2 3/8" output shaft
• 4 Plate slip-clutch protects drivelines and gearboxes
• Transport wing locks for safe, narrow transportation
• 4" x 8" Height adjusting cylinder
• Enclosed front to rear leveling rods
• 1" Solid hinge rods
• Rubber, chain or double chain guards
• Deck rings are available
• Laminated or aircraft tires
• Shredder and baffle kit available
20' FOldINg
SERIES
Available in:
5
year
Limited
Gearbox Warranty
*
HEAVY
DUTY
250
HORSEPOWER
Outer wing wheels can be single
or dual. Duals are ideal when
mowing in areas where one wing
needs to flex up hill. The outer
wheel rides up the embankment
and keeps the deck from gouging.
Wheel spindles are bolt-in to
allow easy change out.
