  • Page 1 DS6300 Reference Manual...
  • Page 2 DS6300 Reference Manual Ed.: 10/2012 © 2003 – 2012 Datalogic Automation S.r.l.  ALL RIGHTS RESERVED.  Protected to the fullest extent under U.S. and international laws. Copying, or altering of this document is prohibited without express written consent from Datalogic Automation S.r.l.

  • Page 3: Table Of Contents

    CONTENTS REFERENCES ......................vi Reference Documentation ................... vi Services and Support ....................vi Patents......................... vi COMPLIANCE......................vii Electrical Safety ......................vii Laser Safety.........................vii Power Supply......................viii CE Compliance......................ix FCC Compliance ......................ix GENERAL VIEW ......................x GUIDE TO INSTALLATION ..................xiv Point-to-Point Installation....................xiv Master/Slave Lonworks Installation ................xv INTRODUCTION ......................1 Product Description ......................
  • Page 4 9.2.1 Tilt Angle for Advanced Code Reconstruction ............81 Performance .......................82 9.3.1 Reading Conditions ....................82 Reading Diagrams ......................84 9.4.1 DS6300 Standard Model ....................84 9.4.2 DS6300 Oscillating Mirror Model ................88 9.4.3 DS6300 with GFX-60....................92 MAINTENANCE ......................94 10.1 Cleaning........................94 10.2 External Memory Backup &...
  • Page 5 TROUBLESHOOTING ....................96 TECHNICAL FEATURES................... 99 ALTERNATIVE LAYOUTS ..................101 Point-to-Point ......................101 ID-NET™ Gateway ....................103 Pass Through ......................104 RS232 Master/Slave....................105 Multiplexer ........................107 GLOSSARY......................108 INDEX........................110...

  • Page 6: References

    GFX-60 X-pattern mirror  Help On-Line in PDF format SERVICES AND SUPPORT Datalogic provides several services as well as technical support through its website. Log on to www.automation.datalogic.com and click on the links indicated for further information:  PRODUCTS Search through the links to arrive at your product page which describes specific Info, Features, Applications, Models, Accessories, and Downloads including the Genius™...

  • Page 7: Compliance

    LASER SAFETY The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of the DS6300 scanner. Standard Regulations This scanner utilizes a low-power laser diode. Although staring directly at the laser beam momentarily causes no known biological damage, avoid staring at the beam as one would with any very strong light source, such as the sun.

  • Page 8: Power Supply

    Laser Safety Label for Oscillating Mirror and Standard Models Warning and Device Class Label The identification label is applied onto the bottom part of the scanner (Figure A, 2): DATALOGIC AU TOMATION S.r.l. - Via Lavino 265 40050 Monte San Pietro (BO) ITALY MANUFACTURED VOLT Amp.

  • Page 9: Ce Compliance

    FCC COMPLIANCE Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.

  • Page 10: General View

    GENERAL VIEW DS6300 Figure A - DS6300 Laser Safety Label Service Cap Connector Panel Identification Label Display and Keypad Panel Warning and Device Class Label Laser Beam Output Window Focus Adjusting Screw...
  • Page 11 DS6300 Figure B - DS6300 Oscillating Mirror Version Laser Safety Label Laser Beam Output Window Figure C – Display and Keypad Panel Programming Keypad Power On LED LCD Display TX Data LED Phase On LED...
  • Page 12 Figure D – Connector Panel for Master/Slave Models Main/Aux. Interface 25-pin D-Sub male connector Lonworks 9-pin male connector Lonworks 9-pin female connector Figure E – Connector Panel for Ethernet Models Main/Aux. Interface 26-pin D-Sub male connector Ethernet 4-pin female connector Lonworks 9-pin female connector Figure F –...
  • Page 13 Figure G – Connector Panel for DeviceNet Models Main/Aux. Interface 26-pin D-Sub male connector DeviceNet 5-pin male connector Lonworks 9-pin female connector Figure H – Connector Panel for Profibus Models Main/Aux. Interface 26-pin D-Sub male connector Profibus 9-pin female connector (white) Lonworks 9-pin female connector xiii...

  • Page 14: Guide To Installation

    2.3 and par. 9.4. 3) Make electrical connections to your DS6300 scanner by: a) Connecting the DS6300 scanner to the CBX100/CBX500 by means of one of the CAB-Sxx (or CAB-F0x depending on the model) cables provided as an accessory (see par.

  • Page 15: Master/Slave Lonworks Installation

    9.4. 3) Make electrical connections to your DS6300 scanner by: a) Connecting the DS6300 Master scanner to the CBX100/CBX500 by means of one of the CAB-Sxx (or CAB-F0x depending on the model) cables provided as an accessory (see par. 1.7).
  • Page 16 8) Perform the External Memory Backup Procedure for system backup purposes (see par. 10.2). For backward compatibility you can perform the ASR Network Configuration procedure for system backup purposes (see par. 10.3.1). 9) Exit the configuration program and run your application. The installation is now complete.

  • Page 17: Introduction

    1 INTRODUCTION 1.1 PRODUCT DESCRIPTION The DS6300 is a high performance laser scanner in a complete range of industrial bar code readers offering an innovative and modular solution in terms of reading performance, connectivity and maintenance, in addition to a completely new hardware and software platform.

  • Page 18: Applications

    DS6300 REFERENCE MANUAL 1.2 APPLICATIONS The DS6300 barcode reader is specifically designed for industrial applications and for all cases requiring high reading performance such as:  code reconstruction  reading of codes covered by plastic film  reading of codes with a wide depth of field ...

  • Page 19: Model Description

    It is suggested to use this parameter for example when the conveyor is stopped for a lengthy period. 1.3 MODEL DESCRIPTION The DS6300 scanner is available in versions that differ in regard to the following characteristics:  Optical Model (Head) ...
  • Page 20 DS6300 REFERENCE MANUAL to the most inclined or external laser line, so that all other laser lines assure more than 10° Skew. This avoids the direct reflection of the laser light emitted by the reader. Figure 1 – Oscillating Mirror Skew Angle Otherwise, the scanner can be mounted at an angle of inclination of 17.5°...
  • Page 21 INTRODUCTION By configuring the oscillating speed up to the maximum value of 19 Hz, raster emulation can be performed for reading fast moving objects. Max. Aperture 40° 6-10 30° 11-15 20° 16-19 10° By limiting the raster width to the minimum necessary, the number of scans on the reading surface is increased.

  • Page 22: Indicators

    DS6300 REFERENCE MANUAL 1.5 INDICATORS The DS6300 has three LEDs on the Display and Keypad panel. The indicators have the following functions: POWER ON (red) Indicates the scanner is turned on. PHASE ON (yellow) Indicates the external presence sensor is active.

  • Page 23: Test Mode

    4) Use the ▲ (up arrow) and ▼ (down arrow) key to select the “Exit” item, then press the ENT (enter) key to confirm. The scanner exits the Main Menu and returns to its current operating mode. 1.7 ACCESSORIES The following accessories are available on request for DS6300: Name Description Part Number...
  • Page 24 (5 pcs) for multisided stations 890001020 * DS6300 application software does not support any of the CBX500 Host Interface Module accessories nor the BM150 Display accessory. Use the CBX800 Gateway for Host Interface Applications, (Fieldbus and non...

  • Page 25: Installation

    DS6300 reader to other devices in the system (i.e. CBX100 etc.). NOTE 2.1 PACKAGE CONTENTS Verify that the DS6300 reader and all the parts supplied with the equipment are present and intact when opening the packaging; the list of parts includes: ...

  • Page 26: Mechanical Mounting

    2.2 MECHANICAL MOUNTING 2.2.1 Mounting the Scanner The DS6300 reader can be positioned and installed in the best way possible as a result of the patented Step-a-Head™ feature. Thanks to the separation between Head and Base, you can modify the orientation of the decoder base, and therefore display-keypad and connector panels, while keeping the optic head in the correct reading position.
  • Page 27 The following diagrams give the overall dimensions of the reader standard model, oscillating mirror model and mounting brackets. They may be used for their installation. 16.5 0.65 3.34 2.99 inch 4.33 Figure 8 - DS6300 Overall Dimensions 1.65 0.86 0.15 106° 1.96 73.2 2.83 2.88...
  • Page 28 DS6300 REFERENCE MANUAL 16.5 0.65 3.35 2.72 2.20 4.48 inch 7.08 Figure 10 - DS6300 Oscillating Mirror Model Overall Dimensions 1.65 0.86 0.15 Ø4.1 0.16 0.43 1.96 0.43 0.55 2.83 0.55 3.93 inch Figure 11 – ST-210 Mounting Bracket Overall Dimensions...

  • Page 29: Mounting The Scanner With Accessories

    INSTALLATION 2.2.2 Mounting the Scanner with Accessories The following accessories allow installing the DS6300 reader in the most suitable position for your network layout: ST-237 mounting bracket; ST-210 mounting bracket; FBK-6000 fast bracket. The ST-237 is a 106° mounting bracket to be mounted on the reader as displayed in the image below: Figure 12 –...
  • Page 30 The FBK-6000 is a fast bracket kit allowing a quick and easy mounting of the scanner on the ST-237 bracket. First, it is necessary to fix the FBK-6000 to the DS6300 scanner by means of the mounting screws: Figure 14 – Mounting the FBK-6000 on the Scanner Then, attach the assembly to the mounting bracket by slipping the hook into the bracket hole.

  • Page 31: Mounting The Scanner With Gfx-60

    INSTALLATION 2.2.3 Mounting the Scanner with GFX-60 The GFX-60 is an accessory X-pattern mirror for the DS6300 Series Scanners. The following procedure describes how to mount the GFX-60. 1. Unscrew the upper cover of the scan head, which houses the scanner output window.
  • Page 32 ACR™ 4 conditions (see par. 9.3.1). Figure 16 – Omni-Directional Reading Position The DS6300 with the GFX-60 can be mounted over a conveyor in different positions. The following picture illustrates the suggested position offering the best compromise between width and height of the reading area: Figure 17 –...

  • Page 33: Positioning The Scanner

    INSTALLATION 2.3 POSITIONING THE SCANNER The DS6300 reader is able to decode moving barcode labels at a variety of angles, however significant angular distortion may degrade reading performance. When mounting DS6300 take into consideration these three ideal label position angles: Pitch 0°, Skew 10°...

  • Page 34: 16° Skew Positioning

    Figure 20 - "Tilt" Angle 2.3.1 16° Skew Positioning The DS6300 scanner is mounted on the ST-237 106° mounting bracket (see Figure 9) which guarantees a built-in Skew angle (S in the figure below) of 16° with respect to the frame plane (typically the Skew angle should be between 10°...

  • Page 35: 45° Skew Positioning

    INSTALLATION 2.3.2 45° Skew Positioning The DS6300 scanner is mounted on the ST-210 90° mounting bracket (see Figure 11). By adjusting the mounting bracket guides, reach 45° for the Skew angle (S in the figure below) to avoid the direct reflection of the laser light emitted by the scanner: 45°...

  • Page 36: Cbx Electrical Connections

    CBX connection box by using the dedicated cables (CAB-Sxx). DS6300 Fieldbus models can connect their 26-pin male D-sub connector for connection to the power supply, serial interface and input/output signals to a CBX connection box by using the dedicated cables (CAB-F0x).
  • Page 37 CBX ELECTRICAL CONNECTIONS The table below gives the pinout of the CBX100/500 terminal block connectors. Use this pinout when the DS6300 reader is connected by means of the CBX100/500: CBX100/500 Terminal Block Connectors Group Name Function Power Supply Input Voltage +...

  • Page 38: Power Supply

    DS6300 scanners have power ground GND (25/26-pin connector pin 23, 25, 26) as well as the cable Shield (25/26-pin connector pin 1) internally connected to the chassis. It is recommended to connect the device chassis to earth ground (Earth) by setting the appropriate jumper in the CBX connection box.

  • Page 39: Rs232 Interface

    The RTS and CTS signals control data transmission and synchronize the connected devices. If the RTS/CTS handshaking protocol is enabled, the DS6300 activates the RTS output to indicate a message is to be transmitted. The receiving unit activates the CTS input to enable...

  • Page 40: Rs485 Full-Duplex Interface

    DS6300 REFERENCE MANUAL 3.2.2 RS485 Full-Duplex Interface The RS485 full-duplex (5 wires + shield) interface is used for non-polled communication protocols in point-to-point connections over longer distances (max 1200 m / 3940 ft) than those acceptable for RS232 communications or in electrically noisy environments.

  • Page 41: Rs485 Half-Duplex Interface

    The RS485 half-duplex (3 wires + shield) interface is used for polled communication protocols. It can be used for Multidrop connections with a Datalogic Multiplexer, (see par. "Multiplexer" in Appendix A) exploiting a proprietary protocol based on polled mode called MUX32 protocol, where a master device polls slave devices to collect data.
  • Page 42 RS485 HD Termination Resistor. PG-6000 Earth Figure 29 - DS6300 Multidrop Connection to a Multiplexer * When using CBX500, the Main interface multidrop network signals: Shield, SGND, RTX+and RTX- are repeated on terminal connector row 4 to facilitate system cabling.

  • Page 43: Auxiliary Rs232 Interface

    CBX ELECTRICAL CONNECTIONS 3.3 AUXILIARY RS232 INTERFACE The auxiliary serial interface is used exclusively for RS232 point-to-point connections. It is principally used for scanner configuration from a laptop PC but is also available for LOCAL ECHO to a monitoring PC or for Pass through layouts. This interface is active when the Data Tx parameter is enabled.

  • Page 44: Inputs

    DS6300 REFERENCE MANUAL 3.4 INPUTS There are four optocoupled polarity insensitive inputs available on the scanner: Input 1 (External Trigger/PS), Input 2 (Encoder), Input 3 and 4 generic inputs. The electrical features of the inputs are: Maximum voltage: 30 Vdc...
  • Page 45 (Vdc and GND). INPUT 1 (EXTERNAL TRIGGER/PS) CONNECTIONS USING DS6300 POWER ( brown) MEP-593 PH-1 Ph oto cell (PNP) (b lack) (b lue) Figure 32 – MEP-593 PH-1 (PNP) External Trigger/PS Using DS6300 Power Power to In put Photocell Signal Photoce ll...
  • Page 46 DS6300 REFERENCE MANUAL INPUT 2 (ENCODER) CONNECTIONS USING DS6300 POWER ( red) (white) ( black) OEK-1 Encoder (PN P) Figure 36 - OEK-1 Encoder PNP Using DS6300 Power Power to Input Inp ut Device Signa l In put Device (Encoder) Input Device...
  • Page 47 INPUT 3 - 4 CONNECTIONS USING DS6300 POWER (CBX500 Only) Power to Input Device Input Device Input Input Device Signal Reference Figure 40 - PNP Input 3 - 4 Using DS6300 Power Power to Input Input Device Signal Input Device Input Device Reference...

  • Page 48: Code Verifier

    DS6300 REFERENCE MANUAL 3.4.1 Code Verifier If the DS6300 is used as a Code Verifier, the verifier code can be configured in software through the Genius™ configuration program. However it is also possible to use one of the inputs to trigger when the scanner should store a code read as the verifier code.
  • Page 49 OUTPUT 1 and 2 CONNECTIONS USING DS6300 POWER Output Device Power to Output Outpu t Device Signal Output D evice Reference Figure 44 - Open Emitter Output Using DS6300 Power Output Device Power to Outpu t Device Output D evice Reference Output Signal...
  • Page 50 Figure 46 - Open Emitter Output Using External Power Output Device Output Signal Output Device Groun d Reference Figure 47 - Open Collector Output Using External Power OUTPUT 3 CONNECTIONS USING DS6300 POWER (CBX500 Only) Power to Output Device Output Device Output Output Device Signal...

  • Page 51: User Interface - Host

    CBX ELECTRICAL CONNECTIONS OUTPUT 3 CONNECTIONS USING EXTERNAL POWER (CBX500 Only) Output Signal External Device Power or Ground Reference Figure 50 - Ouput 3 Using External Power The command signals are filtered and generate a delay of about 50 µs for Output 1 and 2 and 1 ms for Output 3.

  • Page 52: Custom Cable Electrical Connections

    Laptop PC. CAUTION DS6300 scanners are equipped with a 25-pin male D-sub connector (Master/Slave models) or a 26-pin male D-sub connector (Fieldbus models) for connection to the host computer, power supply and input/output signals. These signals can be wired using a custom cable according to the application needs.
  • Page 53 CUSTOM CABLE ELECTRICAL CONNECTIONS The details of the connector pins are indicated in the following table: Figure 51 - 25-pin Connector Figure 52 - 26-pin Connector DS6300 25/26-pin D-sub Connector Pinout Name Function Chassis - internally connected to GND CHASSIS...

  • Page 54: Power Supply

    DS6300 scanners have power ground GND (25/26-pin connector pin 23, 25, 26) as well as the cable Shield (25/26-pin connector pin 1) internally connected to the chassis.

  • Page 55: Rs232 Interface

    The RTS and CTS signals control data transmission and synchronize the connected devices. If the RTS/CTS handshaking protocol is enabled, the DS6300 activates the RTS output to indicate a message is to be transmitted. The receiving unit activates the CTS input to enable...

  • Page 56: Rs485 Full-Duplex Interface

    DS6300 REFERENCE MANUAL 4.2.2 RS485 Full-Duplex Interface The RS485 full-duplex (5 wires + shield) interface is used for non-polled communication protocols in point-to-point connections over longer distances than those acceptable for RS232 communications or in electrically noisy environments. The overall maximum cable length should not exceed 1200 m (3940 ft).

  • Page 57: Rs485 Half-Duplex Interface

    The RS485 half-duplex (3 wires + shield) interface can be used for polled communication protocols. It can be used for Multidrop connections with a Datalogic Multiplexer, (see par. "Multiplexer" in Appendix A) exploiting a proprietary protocol based on polled mode called MUX32 protocol, where a master device polls slave devices to collect data.
  • Page 58 DS6300 REFERENCE MANUAL Figure 59 – DS6300 Multidrop Connection to a Multiplexer...

  • Page 59: Auxiliary Interface

    Figure 60 - RS232 Auxiliary Interface Connections 4.4 INPUTS There are four optocoupled polarity insensitive inputs available on the 25/26-pin connector of the DS6300 scanner: Input 1 (External Trigger/PS), Input 2 (Encoder), Input 3 and 4 generic inputs: The electrical features of these inputs are:...
  • Page 60 9 (Vdc) and 23 (GND) of the 25/26-pin I/O connector. In this case, however, the device is no longer electrically isolated. The voltage available on the 25/26-pin I/O connector, is physically the same as used to power the scanner. INPUT 1 - 2 CONNECTIONS USING DS6300 POWER DS6300 EXTERNAL TRIGGER/ENCODER...
  • Page 61 Figure 64 - NPN Command Input Connection Using External Power Terminal pins I34B are common to both inputs 3 and 4 and therefore these inputs cannot be driven by opposite polarity devices. NOTE INPUT 3 - 4 CONNECTIONS USING DS6300 POWER DS6300 EXTERNAL DEVICE I34B...

  • Page 62: Code Verifier

    Figure 66 - I3/I4 PNP Input Command using External Power 4.4.1 Code Verifier If the DS6300 is used as a Code Verifier, the verifier code can be configured in software through the Genius™ configuration program. However it is also possible to use one of the inputs to trigger when the scanner should store a code read as the verifier code.
  • Page 63 Output 3 can be assigned to the same events and it has the advantage of being polarity insensitive. By default it is not assigned to any event. DS6300 USER INTERFACE Vext 30 Vdc max Figure 67 –...

  • Page 64: User Interface

    The following wiring diagram shows a simple test cable including power, external (push-button) trigger and PC RS232 COM port connections. 25-pin D-sub female 9-pin D-sub female TXAUX RXAUX DS6300 EXT TRIG A EXT TRIG B Power Supply VS (15 – 30 VDC) Power GND Trigger Test Cable for DS6300...

  • Page 65: Lonworks Connections

    The use of these system circuits is not required in all the operating modes. Anyway, for correct system functioning it is suggested to use Datalogic cables and accessories and follow the description of the typical layouts (see chapter 7 for details).

  • Page 66: Network Termination

    5.1 NETWORK TERMINATION When building a Lonworks system the network must be properly terminated by positioning the BT-6000 Lonworks terminator in the DS6300 master reader and in the last DS6300 slave reader. Each side of the terminator provides a different connector; thus, it can be inserted either into...
  • Page 67 LONWORKS CONNECTIONS The following diagram represents the connection between a DS6300 working as master and a DS6300 working as a slave reader. The cable shield for LON A/B is connected to pin1 - CHASSIS. Master Slave VS_I/O REF_I/O LON A...
  • Page 68 DS6300 REFERENCE MANUAL The diagram below represents the termination of a DS6300 (Master/Slave model) working as master by means of the BT-6000. Master BT-6000 Female Side VS_I/O LON A LON B GN D REF_I/O = male connector = female connector Figure 73 –...

  • Page 69: Fieldbus Connections

    FIELDBUS CONNECTIONS 6 FIELDBUS CONNECTIONS 6.1 ETHERNET INTERFACE This connector is only available for DS6300 Ethernet models and allows the Ethernet connection between the host and the reader. Figure 76 –DS6300 M12 4-pin D-Coded Female Ethernet Connector This interface and the connector pinout (see the following table) are IEEE 802.3 10 BaseT and IEEE 802.3u 100 Base Tx compliant.

  • Page 70: Ethernet Interface (Older Models)

    DS6300 REFERENCE MANUAL 6.2 ETHERNET INTERFACE (OLDER MODELS) The RJ45 connector is only available for older DS6300 Ethernet models and allows the Ethernet connection between the host and the reader. Figure 78 – DS6300 RJ45 Female Modular Connector This interface and the connector pinout (see the following table) are IEEE 802.3 10 BaseT and IEEE 802.3u 100 Base Tx compliant.
  • Page 71 LAN. It can also be connected directly to a host PC. The following is an example of a connection to a LAN through a Hub using a straight through cable: HUB / SWITCH DS6300 T X+ T X- n. c.

  • Page 72: Devicenet Interface

    When using DeviceNet, the Main serial interface is disabled and must not be physically connected. NOTE The 5-pin male connector is only available in the DS6300 DeviceNet model and allows connection between the host and the reader: Figure 81 - DeviceNet 5-pin Male Connector...

  • Page 73: Profibus Interface

    FIELDBUS CONNECTIONS 6.4 PROFIBUS INTERFACE The 9-pin Profibus female connector (white) is only available in the DS6300 Profibus model and allows connection between the host and the reader: Figure 82 - Profibus 9-pin Female Connector DS6300 9-pin Profibus connector pinout...

  • Page 74: Typical Layouts

    7.1 LOCAL LONWORKS NETWORK A local Lonworks network allows logically connecting a DS6300 master reader with up to 31 DS6300 slaves. Actually, the maximum number of readers to be employed in the network depends on the system operating conditions;...

  • Page 75: Small Synchronized Network

    NOTE 7.1.1 Small Synchronized Network When building a small local Lonworks network (less than 10 scanners), the DS6300 master reader must be connected to a local host computer or a CBX connection box by means of a cable connected to the 25/26-pin D-sub male connector.
  • Page 76  the master is connected to the CBX100 through the CAB-F0x, and provides power to the PS and Encoder.  The Master DS8100A is terminated with the BTK-8102 and the last slave DS6300 is terminated with the BT-6000. CAB-610x BT-6000...

  • Page 77: Multidata Network

    TYPICAL LAYOUTS 7.1.2 Multidata Network In this layout, one master and up to 7 DS6300 slave readers have their own P.S. and therefore multiple reading phases. Each P.S. is connected through a CBX100, which in turn is connected to its relative scanner through a CAB-Sxx cable.

  • Page 78: Fieldbus Networks

    The master is connected to the CBX100 through the CAB-F0x, and provides power to the PS and Encoder.  Since the master DS6300 is a Fieldbus model, it is internally terminated. The last slave DS6300 is terminated with the BT-6000. ...
  • Page 79 TYPICAL LAYOUTS To interface DS6300 scanners to other Host types (Fieldbus and non- Fieldbus), use the CBX800 Gateway with Host Interface Modules. The Master scanner in this case is a standard Master/Slave Serial model which requires the BT-6000 terminator. NOTE...

  • Page 80: Software Configuration

    DS6300 REFERENCE MANUAL 8 SOFTWARE CONFIGURATION 8.1 GENIUS™ INSTALLATION ™ Genius is a new Datalogic scanner configuration tool providing several important advantages:  Wizard approach for new users;  Multi-language version;  Defined configuration directly stored in the reader; ...

  • Page 81: Test Operating Mode

    Sending the configuration to the scanner. Figure 89 - Genius™ Wizard Closing Window Test Operating Mode This operating mode is not available when DS6300 works as slave. NOTE Figure 90 - Test Mode Selection This operating mode causes the reader to be continuously activated allowing verification of its reading features and its reading position with respect to the barcode.

  • Page 82: On Line Operating Mode

    This operating mode causes the reader to be connected to an external Presence Sensor using I1A and I1B (External Trigger/PS) inputs. During the active phase of the presence sensor, the DS6300 reader tries to acquire and correctly decode the code.

  • Page 83: Genius™ Network Setup Through Master

    SOFTWARE CONFIGURATION 8.2.2 Genius™ Network Setup Through Master Network Setup allows configuring your Local Lonworks Network through the Master using Genius™. Three different procedures are available to define the number of network slave scanners, their label and address according to two main conditions: Condition Available Procedure Feature...
  • Page 84 DS6300 REFERENCE MANUAL The following dialog box appears asking whether to send the configuration to the Local Device or not: 2. Click the "Yes" button, then click on the icon available on the Toolbar to make the “Devices” area appear next to the Parameter Explorer window. By repeatedly clicking the icon this area will be displayed or hidden.
  • Page 85 SOFTWARE CONFIGURATION 3. Then, proceed with the network setup by using one of the icons available on the Tool Bar according to the procedure to follow: Net-Autoset procedure Network Wizard procedure Express Network Setup procedure Net-Autoset This procedure is to be used when all scanner addresses and labels are unknown (typically when configuring the network for the first time or whenever a network reconfiguration is required).

  • Page 86: Network Wizard

    DS6300 REFERENCE MANUAL Network Wizard Before performing this procedure, a Lonworks address must be assigned to each slave scanner. The most practical method is through the Net-Autoset procedure. See par. 8.2.3 for alternative address assignment methods. Once all addresses have been assigned, the Network Wizard is to be used when one or more scanner addresses and labels need to be modified.
  • Page 87 SOFTWARE CONFIGURATION 2. If desired, select a slave scanner within the "Current Devices" area and click on the icon (or select the "Show Device" option from the right-click menu) to make the dialog box appear as follows: The "Show Device" option is particularly useful after the Net-Autoset procedure or whenever it is necessary to know which address is assigned to a specific slave scanner.

  • Page 88: Alternative Slave Address Assignment

    DS6300 REFERENCE MANUAL 8.2.3 Alternative Slave Address Assignment As alternatives to Network Setup through the Master, each Slave scanner can be assigned an address through the following methods:  address setting through the Local Device Network Settings item in the Device Menu with the slave scanner connected to Genius™...

  • Page 89: Genius™ Shortcuts For Network Configuration

    SOFTWARE CONFIGURATION 8.3.1 Genius™ Shortcuts for Network Configuration Once the Network Setup is structured in Genius and the Master is configured, there are a few shortcuts that Genius offers to quickly configure the slaves. By right-clicking on a device in the "Devices" area a shortcut menu appears which allows you ...
  • Page 90 DS6300 REFERENCE MANUAL It is possible to Paste, Send or Load configurations simultaneously to a selected number of devices by clicking the relative device check box and executing the desired command. These same functions can be selected from the Edit menu as well.

  • Page 91: Parameter Default Values

    SOFTWARE CONFIGURATION 8.4 PARAMETER DEFAULT VALUES The following table contains the list of the factory default settings for the DS6300. Genius™ also allows checking the parameter default values by selecting the "Compare parameters" option available in the Tools menu and comparing the current scanner configuration to the default one.
  • Page 92 DS6300 REFERENCE MANUAL Parameter Default Setting Reading Parameters Beam Shutter Disabled Overflow Start Ratio Overflow Stop Ratio Reading Mode Reconstruction Reading Condition Standard Reconstruction Parameters Enabled Stacked Code Disabled (unchecked) Extended Min Match Position Tolerance Duration Tolerance Min Start/Stop Number...
  • Page 93 SOFTWARE CONFIGURATION Parameter Default Setting Parameters Auxiliary Serial Port Search for CBX BM100 at Device Startup Enabled (checked) Data Tx Enabled (checked) Heartbeat Disable Pass Through Disabled (unchecked) Parameters Baud Rate 115200 Parity None Data Bits Stop Bits Digital I/O Setting Digital Input Lines Setting Debouncing For Input 1, 3 and 4 Debouncing For Input 2...
  • Page 94 DS6300 REFERENCE MANUAL Parameter Default Setting Diagnostics PackTrack Debug Message Tx Disabled (unchecked) Enable Checked Conveyor Info Not Available Refresh Time 2 sec Statistics Enabled (checked) Energy Saving Energy Saving Configuration Disabled (unchecked) User Information Section End User Name Empty...

  • Page 95: Reading Features

    9 READING FEATURES 9.1 FOCUS ADJUSTMENT The DS6300 provides a manual adjustment of the optics to optimize the reading performance by choosing the best focus between two extreme positions. The focus adjustment is continuous and not by step; thus, allowing an optimum adjustment around the selected position.
  • Page 96 DS6300 REFERENCE MANUAL Display Visualization The first line of the display shows the read code and Good Read percentage. Possible suspending commas at the end of the code mean that the code is too long to be displayed. The second line of the display indicates the value of the focus position according to the table below.

  • Page 97: Advanced Code Reconstruction (Acr™ 4)

    With just a set of partial scans on the label (obtained using the motion of the label itself), the DS6300 is able to “reconstruct” the barcode. A typical set of partial scans is shown in the figure below: Code Direction Figure 100 –...

  • Page 98: Performance

    25 C ambient temperature depending on the conditions listed under each diagram. If standard models do not satisfy specific requirements, contact your nearest Datalogic distributor, supplying code samples, to obtain complete information on the reading possibilities.
  • Page 99 READING FEATURES Minimum Code Height for ACR Reading (mm) 45° 30° Conveyor Speed (m/s) 0.25 0.30 Code 39 0.33 Code Resolution 0.38 (mm) 0.50 0.72 1.00 Ratio 3:1; Interdigit = Module Size Table 2 Minimum Code Height for ACR Reading (mm) 45°...

  • Page 100: Reading Diagrams

    DS6300 REFERENCE MANUAL 9.4 READING DIAGRAMS 9.4.1 DS6300 Standard Model DS6300-100-0XX - Resolution: 0.20 mm/8 mils (in) (cm) Focus Position = 40 Focus Position = 0 CONDITIONS Code = Interleaved 2/5 or Code 39 PCS = 0.90 Pitch angle = 0°...
  • Page 101 READING FEATURES DS6300-100-0XX - Resolution: 0.30 mm/12 mils 32 34 (in) (cm) 20 25 Focus Position = 0 Focus Position = 40 Focus Position = 60 (in) (cm) Figure 104 - Standard Model 0.30 mm / 12 mils Reading Diagram...
  • Page 102 DS6300 REFERENCE MANUAL DS6300-100-0XX - Resolution: 0.38 mm/15 mils 36 38 42 44 (in) (cm) 95 100 105 110 Focus Position = 0 Focus Position = 100 Focus Position = 60 (in) (cm) Figure 105 - Standard Model 0.38 mm / 15 mils Reading Diagram...
  • Page 103 READING FEATURES DS6300-100-0XX - Resolution: 0.50 mm/20 mils 48 52 56 (in) (cm) 110 120 130 140 Focus Position = 100 Focus Position = 60 Focus Position = 0 (in) (cm) Figure 106 - Standard Model 0.50 mm / 20 mils Reading Diagram...

  • Page 104: Ds6300 Oscillating Mirror Model

    DS6300 REFERENCE MANUAL 9.4.2 DS6300 Oscillating Mirror Model DS6300-105-0XX (oscillating mirror) - Resolution: 0.20 mm/8 mils (in) (cm) Focus Focus Position = 0 Position = 40 (in) (cm) Figure 107 – Oscillating Mirror Model 0.20 mm / 8 mils Reading Diagram...
  • Page 105 READING FEATURES DS6300-105-0XX (oscillating mirror) - Resolution: 0.30 mm/12 mils 32 34 (in) (cm) Focus Position = 0 Focus Position = 40 Focus Position = 60 (in) (cm) Figure 108 - Oscillating Mirror Model 0.30 mm / 12 mils Reading Diagram...
  • Page 106 DS6300 REFERENCE MANUAL DS6300-105-0XX (oscillating mirror) - Resolution: 0.38 mm/15 mils 18 20 26 28 (in) (cm) 95 100 105 Focus Position = 0 Focus Position = 100 Focus Position = 60 (in) (cm) Figure 109 - Oscillating Mirror Model 0.38 mm / 15 mils Reading Diagram...
  • Page 107 READING FEATURES DS6300-105-0XX (oscillating mirror) - Resolution: 0.50 mm/20 mils 48 52 56 (in) (cm) 20 30 110 120 130 140 Focus Position = 100 Focus Position = 60 Focus Position = 0 (in) (cm) Figure 110 - Oscillating Mirror Model 0.50 mm / 20 mils Reading Diagram...

  • Page 108: Ds6300 With Gfx-60

    DS6300 REFERENCE MANUAL 9.4.3 DS6300 with GFX-60 DS6300 with GFX-60 - Resolution: 0.20 mm/8 mils Figure 111 – GFX-60 0.20 mm / 8 mils Reading Diagram Note: 0 value on the X axis is measured from the nose of the GFX-60...
  • Page 109 READING FEATURES DS6300 with GFX-60 - Resolution: 0.50 mm/20 mils Figure 113 - GFX-60 0.50 mm / 20 mils Reading Diagram Note: 0 value on the X axis is measured from the nose of the GFX-60 0 value on the Y axis is measured from the conveyor plane focus position = 100 DS6300 with GFX-60 - Resolution: 1.00 mm/40 mils...

  • Page 110: Maintenance

    Repeat the operation frequently in particularly dirty environments. Use soft material and alcohol to clean the window and avoid any abrasive substances. Clean the window of the DS6300 when the scanner is turned off or at least when the laser beam is not active.

  • Page 111: Asr Network Configuration

    MAINTENANCE The ASR procedure restores only a part of the system parameters: common slave parameters (Code Selection and Reconstruction). The Master must be prepared at the time of installation in order for this procedure to work correctly. 10.3.1 ASR Network Configuration 1.

  • Page 112: Troubleshooting

    DS6300 REFERENCE MANUAL 11 TROUBLESHOOTING Before contacting your local Datalogic office or Datalogic Partner or ARC, it is suggested to save the device configuration to a *.ddc file by means of the Genius™ software configuration program and check the device exact model and serial number.
  • Page 113 TROUBLESHOOTING TROUBLESHOOTING GUIDE Problem Suggestion On Line Mode and Serial On Line  Genius™ software configuration Mode: program select the OPERATING MODES folder and check the “Reading Phase the reader does not respond correctly to Timeout” parameterization. the expected external signal end. ...
  • Page 114 DS6300 REFERENCE MANUAL TROUBLESHOOTING GUIDE Problem Suggestion How do I obtain my units’ serial  The device serial number is printed on a label numbers? that is affixed above the connector panel of the reader.  The serial number is also displayed when connecting the device through the Genius™...

  • Page 115: Technical Features

    TECHNICAL FEATURES 12 TECHNICAL FEATURES ELECTRICAL FEATURES Supply Voltage 15 to 30 Vdc Power Consumption 15 W typical 1.3 to 0.5 A max. (including startup current) Common Communication Main Baud Rate RS232 Interfaces RS485 full-duplex 1200 to 115200 RS485 half-duplex Auxiliary RS232 1200 to 115200...
  • Page 116 DS6300 REFERENCE MANUAL SOFTWARE FEATURES Readable Codes Interleaved 2/5 Code 39 Standard Codabar Code 128 GS1-128 (ex EAN 128) Code 93 (standard and full ASCII) EAN/UPC (including Add-on 2 and Add-on 5) GS1 DataBar (including Limited and Expanded) Code Selection...

  • Page 117: Aalternative Layouts

    When On-Line operating mode is used, the reader is activated by an External Trigger/PS (photoelectric sensor) when the object enters its reading zone. In the following case, the signal is passed to the DS6300 through the CBX100/CBX500, which also passes power to the system from the power supply (i.e. PWR-120).
  • Page 118 In this case no External Trigger is used and the CBX100/CBX500 only passes power to the reader. The DS6300 Fieldbus models (Ethernet, DeviceNet or Profibus) are connected to a remote Host. It can be activated by a signal generated by the remote Host or always be active if working in Automatic operating mode.

  • Page 119: Id-Net™ Gateway

    ALTERNATIVE LAYOUTS ID-NET™ GATEWAY The CBX800 Gateway can be used to integrate a DS6300 reader into a high speed ID- NET™ network consisting of different scanners not provided with a Lonworks interface. In this case the DS6300 uses its main RS232/RS485 interface to communicate with the CBX800.

  • Page 120: Pass Through

    DS6300 REFERENCE MANUAL PASS THROUGH When Pass Through is activated on the Auxiliary interface, the DS6300 reader can be integrated in a network consisting of different scanners not provided with a Lonworks interface. This connection mode allows two or more devices to be connected to a single external serial interface.

  • Page 121: Rs232 Master/Slave

    Figure 119 – Pass Through Connection for Fieldbus Models RS232 MASTER/SLAVE The RS232 master/slave connection is used to integrate a DS6300 reader in a network consisting of different scanners not provided with a Lonworks interface. The Slave scanners use RS232 only on the main and auxiliary interfaces. Each slave scanner transmits the messages received by the auxiliary interface onto the main interface.
  • Page 122 DS6300 Master Local Host  Main Serial Interface (RS232 only)  Auxiliary Serial Interface (RS232)  Input 1 (External Trigger/PS for On-Line Mode) Figure 120 – RS232 Master/Slave for DS6300 Master/Slave Models Power DS4800 CBX100 Slave 1 CAB-F0x DS4800 Fieldbus...

  • Page 123: Multiplexer

    ALTERNATIVE LAYOUTS MULTIPLEXER The Multiplexer connection is used to integrate a DS6300 slave reader in a Multidrop network consisting of different scanners not provided with a Lonworks interface. Each scanner connected Multiplexer (MX4000) with RS485 half-duplex main interface. CBX100 DS6300...

  • Page 124: Glossary

    This organization (a service of the Food and Drug Administration) is responsible for the safety regulations governing acceptable limitations on electronic radiation from laser devices. Datalogic devices are in compliance with the CDRH regulations. EEPROM Electrically Erasable Programmable Read-Only Memory. An on-board non-volatile memory chip.
  • Page 125 Multidrop Line A single communications circuit that interconnects many stations, each of which contains terminal devices. See RS485. Parameter A value that you specify to a program. Typically parameters are set to configure a device to have particular operating characteristics. Position The position of a scanner or light source in relation to the target of a receiving element.

  • Page 126: Index

    INDEX Accessories, 7 Laser Safety, vii ACR™ 4, 81 LEDs, 6 Alternative Layouts, 101 Local Lonworks Network Layouts, 58 Auxiliary RS232 Interface, 27, 43 Lonworks Connections, 49 Lonworks Interface, 50 CBX Electrical Connections, 20 CE Compliance, ix Main Serial Interface, 22, 38 Cleaning, 94 Master/Slave Connector Panel, xii Code Verifier, 32, 46...
  • Page 127 Reading Diagrams, 84 Scanner Assignment using Keypad, 6 DS6300 with GFX-60, 92 Scanner Replacement, 94 Oscillating Mirror Models, 88 Services and Support, vi Standard Models, 84 Skew Angle, 17 Reading Features, 79 Software Configuration, 64 Reference Documentation, vi RS232 Interface, 23, 39...
  • Page 128 40050 Monte San Pietro Bologna - Italy www.automation.datalogic.com declares that the DS6300; Laser Scanner and all its models are in conformity with the requirements of the European Council Directives listed below: 2004 / 108 / EC EMC Directive 2006/95/EC Low Voltage Directive...
  • Page 129 www.automation.datalogic.com...

Table of Contents
