DS6300
QUICK REFERENCE GUIDE
This manual illustrates Local Lonworks network applications. For other types of installations,
such as ID-NET™, Pass-Through, Multiplexer Layout, etc., refer to the DS6300 Reference
Manual available on the CD. For complete scanner configuration using the Genius™
configuration program refer to the Help On Line.
NOTE
821001890

Advertisement

Table of Contents
loading

Summary of Contents for Datalogic DS6300

  • Page 1 QUICK REFERENCE GUIDE This manual illustrates Local Lonworks network applications. For other types of installations, such as ID-NET™, Pass-Through, Multiplexer Layout, etc., refer to the DS6300 Reference Manual available on the CD. For complete scanner configuration using the Genius™ configuration program refer to the Help On Line.
  • Page 2: Services And Support

    - Material Return Authorization LEGAL NOTICES © 2003 - 2010 Datalogic Automation S.r.l.  ALL RIGHTS RESERVED.  Protected to the fullest extent under U.S. and international laws. Copying, or altering of this document is prohibited without express written consent from Datalogic Automation S.r.l.
  • Page 3 DS6300 QUICK GUIDE DS6300 GENERAL VIEW Standard Figure A Laser Beam Output Window Laser Safety Label Ethernet DeviceNet Figure B Laser Beam Output Window Laser Safety Label Profibus Figure D Lonworks 9-pin Male Connector Lonworks 9-pin Female Connector Serial Interface and I/O 25-pin (26-pin) male Connector...
  • Page 4 DS6300 QUICK GUIDE CONNECTIVITY Examples of the most common system layouts are shown in this section, for additional layouts refer to the Reference Manual. Local Lonworks Networks CAB-Sxx CBX100** CAB-610x BT-6000 Local Host Master I/O, AUX Slave 1 P.S.* BT-6000 PWR-120 P.S.
  • Page 5: Network Termination

    NETWORK TERMINATION When building a local Lonworks system the network must be properly terminated by positioning a BT-6000 terminator on the DS6300 master reader (BT-6000 female side) and on the last slave reader (BT-6000 male side). to Master to Slave...
  • Page 6: Electrical Connections

    The details of the connector pins are indicated in the following tables: The table below gives the pinout of the CBX100/CBX500 terminal block connectors. Use this pinout when the DS6300 reader is connected by means of the CBX100/CBX500: CBX100/500 Terminal Block Connectors...
  • Page 7 DS6300 QUICK GUIDE The DS6300 scanner provides a 25-pin (26-pin for Fieldbus models) male D-sub connector for connection to power supply, Host interface (Main and Aux), and input/output signals. 25-pin / 26-pin D-Sub Connector Pinout Name Function Chassis - internally connected to GND...
  • Page 8 The power supplied on pin V+ and V- is used only to propagate power to the section of the DeviceNet board directly connected to the Bus. It is completely isolated from the DS6300 power which must be supplied on pin 9, 13 and pin 23, 25 of the 26-pin Main/Aux connector.
  • Page 9: Technical Features

    DS6300 QUICK GUIDE APPENDIX TECHNICAL FEATURES ELECTRICAL FEATURES Supply Voltage 15 to 30 Vdc Power Consumption 1.0 to 0.5 A; 15 W typical 1.3 to 0.5 A; 20 W Max. (including startup current) Common Communication Interfaces Main Baud Rate RS232...
  • Page 10: Model Description

    113x180x104.5 (4.33x4.45x3.9) (4.45x7.08x4.11) Weight 1.5 kg (3.3 lb) 2.0 kg (4.4 lb) MODEL DESCRIPTION DS6300 - 10X - 0YY Decoder Model (Base) Optical Model (Head) 10 = Master/Slave 0 = Standard 11 = Profibus 5 = Oscillating Mirror 12 = Ethernet...
  • Page 11 Mounting bracket kit (5 pcs) for multisided stations 890001020 * DS6300 application software does not support any of the CBX500 Host Interface Module accessories nor the BM150 Display accessory. Use the CBX800 Gateway for Host Interface Applications, (Fieldbus and non...
  • Page 12 When the oscillating mirror is programmed to read barcode labels at very small angles, position the reader to assure at least 10° for the Skew angle (see DS6300 Reference Manual). This angle refers to the most inclined or external laser line, so that all other laser lines assure more than 10° Skew. This avoids the direct reflection of the laser light emitted by the reader.
  • Page 13 DS6300 QUICK GUIDE The mirror can be deflected up to 40°. Oscillation with respect to the output window median axis is asymmetrical (see figure below). 40° 0° Oscillating Mirror Maximum Aperture and Asymmetry By configuring the oscillating speed up to the maximum value of 19 Hz, raster emulation can be performed for reading fast moving objects.
  • Page 14: Mechanical Installation

    DS6300 QUICK GUIDE MECHANICAL INSTALLATION The DS6300 reader can be positioned and installed in the best way possible as a result of the patented Step-A- Head feature. Thanks to the separation between Head and Base, you can modify the orientation of the decoder base, and therefore display-keypad and connector panels, while keeping the optic head in the correct reading position.
  • Page 15 16° Skew Positioning The DS6300 scanner is mounted on the ST-237 106° mounting bracket which guarantees a built-in Skew angle (S in the figure below) of 16° with respect to the frame plane (typically the Skew angle should be between 10° - 20°).
  • Page 16 DS6300 QUICK GUIDE Focus Adjustment The DS6300 provides a manual adjustment of the optics to optimize the reading performance by choosing the best focus between two extreme positions. The focus adjustment is continuous and not by step; thus, allowing an optimum adjustment around the selected position.
  • Page 17: Reading Conditions

    DS6300 QUICK GUIDE Use the ▲ (up arrow) and ▼ (down arrow) key to select the “Exit” item, then press the ENT (enter) key to confirm. The scanner exits the Main Menu and returns to its current operating mode. Focus Adjustment Screw The reader display shows the focus position only when the laser beam is activated.
  • Page 18 DS6300 QUICK GUIDE Minimum Code Height for ACR Reading (mm) 45° 30° Conveyor Speed (m/s) 0.25 0.30 0.33 Code 128 – Ean 128 0.38 Code Resolution (mm) 0.50 0.72 1.00 Table 3 Minimum Code Height for ACR Reading (mm) 45°...
  • Page 19: Reading Diagrams

    DS6300 QUICK GUIDE READING DIAGRAMS In the following reading diagrams (0,0) is the center of the laser beam output window. DS6300-100-0XX – Resolution: 0.20 mm/8 mils (in) (cm) Focus Position = 40 Focus Position = 0 CONDITIONS Code = Interleaved 2/5 or Code 39 PCS = 0.90...
  • Page 20 DS6300 QUICK GUIDE READING DIAGRAMS DS6300-100-0XX – Resolution: 0.38 mm/15 mils 36 38 42 44 (in) (cm) 95 100 105 110 Focus Position = 0 CONDITIONS Code = Interleaved 2/5 or Code 39 Focus Position = 100 PCS = 0.90 Pitch angle = 0°...
  • Page 21 DS6300 QUICK GUIDE READING DIAGRAMS DS6300-105-0XX (Oscillating Mirror) – Resolution: 0.20 mm/8 mils (in) (cm) Focus Focus Position = 0 Position = 40 CONDITIONS Code = Interleaved 2/5 or Code 39 PCS = 0.90 Pitch angle = 0° Skew angle = 10° - 20°...
  • Page 22 DS6300 QUICK GUIDE READING DIAGRAMS DS6300-105-0XX (Oscillating Mirror) – Resolution: 0.38 mm/15 mils 18 20 26 28 (in) 95 100 105 (cm) Focus Position = 0 CONDITIONS Code = Interleaved 2/5 or Code 39 Focus Position = 100 PCS = 0.90 Pitch angle = 0°...
  • Page 23: Laser Safety

    DS6300 QUICK GUIDE COMPLIANCE See the DS6300 Reference Manual for the Declaration of Conformity. LASER SAFETY Figure A Figure B Laser Beam Output Window Laser Safety Label Laser Beam Output Window Laser Safety Label The scanner is classified as a Class 2 laser product according to EN 60825-1 regulations and as a Class II laser product according to CDRH regulations.
  • Page 24: Power Supply

    FCC COMPLIANCE Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.
