Rack-mounting

The air is as free from dust as possible.
The unit is installed in a clean, air conditioned environment.
No more than four Switch units are placed on top of one another, if
the units are free-standing.
The Switch 4300 is 1.5U and will fit in most standard 19-inch racks.
CAUTION: Disconnect all cables from the Switch before continuing.
Remove all self adhesive pads from the underside of the Switch if they
have been fitted.
To rack-mount your Switch:
1 Place the Switch the right way up on a hard flat surface, with the front
facing towards you.
2 Locate a mounting bracket over the mounting holes on one side of the
Switch, as shown in
Figure 3 Fitting a bracket for rack-mounting
3 Insert the three screws and tighten with a suitable screwdriver.
You must use the screws supplied with the mounting brackets. Damage
caused to the unit by using incorrect screws invalidates your warranty.
Figure 3.
Rack-mounting 21
