tekmarNet
Installation & Operation Manual
Introduction
The tekmarNet
®
2 Thermostat 527
provides operation for:
•
One Stage Heat
®
2 Thermostat 527
Features
•
Zone Synchronization
•
Zone Post Purge
•
Intelligent Setback (Timer 033)
•
One touch overrides (User Switch)
•
Auto Heating Cycle
•
tN2 Communication compatible
•
Room temperature limiting
•
Requires 2 wires
•
Pulse Width Modulation
•
CSA C US Approved for use in USA
and Canada
•
Outdoor Temperature Display
•
Air Group Member
•
Backlight
•
Freeze Protection
•
Equipment Exercising
•
Supports Radiant Floor Cooling
Note
•
tN2 Zone Manager, Expansion
Module, Wiring Center or House
Control required for operation
1 of 20
D527
Zoning
Replaces: 08/10
© 2011
D 527 - 12/11
12/11
