Tekmar tNt 540 Quick Setup Manual
Tekmar tNt 540 Quick Setup Manual

Tekmar tNt 540 Quick Setup Manual

Tekmarnet 4

Advertisement

Quick Links

tekmarNet
®
4 Thermostat 540
1.
Location
Exterior
Wall
3.
Install Mounting Base
Adaptor
Plate 007
Thermostat
Base
5.
Switch Settings
Switch Position Action
SETBACK Allow thermostat to respond to
ON
1
available schedule. Requires Timer 033.
OFF
OFF No setback schedule response.
SCENE Allow thermostat to respond to
ON
scenes. Requires User Switch 479.
2
OFF
OFF No scene response.
LOCK Locked to 'User' access level. Set
ON
to Lock when installation completed.
3
UNLOCK Unlock to access all settings.
OFF
Set to Unlock during installation.
ON
Not used
4
OFF
Not used
Quick Setup Guide
Interior
Wall
5 feet
1.5 m
Thermostat
Base
OR
Switch
Box
2.
Remove Mounting Base
4.
Wiring
Fan
G
Y
R
D
X
Cooling Equipment
Wall
tN4 Wiring Center
tN4 Zone Manager
6.
Close Thermostat
pivot
tab
1 of 2
Cooling
1 Stage
Cooling
1 Stage
Use at least 75°C conductors
Fan
For instructions see brochure
tN4
C
R
W
1
2
3
4
or
tN4
C
R
W
© 2011
Q 540
12/11
Zoning
Replaces: 08/10
tNt 540
One Stage Heat /
One Stage Cool / One Fan
Power:
24 V ±10% 50/60 Hz 1.8 VA
56 VA fully loaded
Relays:
24 V (ac) 2 A
ON
1 2 3 4
1
2
3
4
Switch
Setting
Location
Q 540 - 12/11
