1999 Mustang Workshop Manual
SECTION 303-01B: Engine — 4.6L (2V)
REMOVAL
Engine
Special Tool(s)
Spreader Bar
303-D089 (D93P-6001-A3)
Lifting Bracket Set, Engine
303-D074 (D91P-6001-A)
Removal
1. Place the gearshift lever in the neutral position.
2. Remove the hood ground strap.
3. Remove the hood.
4. Drain the cooling system. For additional information, refer to
5. Recover the A/C system. For additional information, refer to
6. Remove the degas bottle. For additional information, refer to
7. Remove the air cleaner and outlet pipe. For additional information, refer to
8. Disconnect the fuel tube spring lock couplings. For additional information, refer to
9. Disconnect the upper radiator hose from the water outlet adapter.
10. Disconnect the throttle and speed control cables, and remove the return spring.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSXB/~MUS~LEN/20...
Section
303-03.
Section
412-00.
Section
303-03.
Section
303-12.
Section
310-00.
Page 1 of 8
1999 Mustang Workshop Manual
Procedure revision date: 04/19/2002
10/24/2009

Advertisement

loading

Related Manuals for Ford Mustang 1999

Summary of Contents for Ford Mustang 1999

  • Page 1 1999 Mustang Workshop Manual Page 1 of 8 SECTION 303-01B: Engine — 4.6L (2V) 1999 Mustang Workshop Manual REMOVAL Procedure revision date: 04/19/2002 Engine Special Tool(s) Spreader Bar 303-D089 (D93P-6001-A3) Lifting Bracket Set, Engine 303-D074 (D91P-6001-A) Removal 1. Place the gearshift lever in the neutral position. 2.
  • Page 2 1999 Mustang Workshop Manual Page 2 of 8 11. Remove the bolts and position the cables and bracket out of the way. 12. Disconnect the climate control vacuum supply hoses. 13. Disconnect the two heater water hoses. 14. Disconnect the wiring harness connectors. 15.
  • Page 3 1999 Mustang Workshop Manual Page 3 of 8 17. Disconnect the evaporative emissions (EVAP) return tube. 18. Disconnect the A/C suction tube from the accumulator. 19. Disconnect and remove the A/C suction tube. 20. Disconnect the A/C tube and position the tube aside. 21.
  • Page 4 1999 Mustang Workshop Manual Page 4 of 8 22. NOTE: Drain power steering fluid into a suitable container. Disconnect the power steering hose from the reservoir. 23. Slide the access cover up. 24. Remove the nut and the battery leads. 25.
  • Page 5 1999 Mustang Workshop Manual Page 5 of 8 28. Install the LH lifting bracket. 29. Remove the transmission. For additional information, refer to Section 308-03A (T5OD), Section 308-03B (TR3650) or Section 307-01 for automatic transmissions. 30. Drain the engine oil. Install the drain plug when finished.
  • Page 6 1999 Mustang Workshop Manual Page 6 of 8 34. Remove the nut and the engine ground cable. 35. Remove the bolt and the body ground. 36. Disconnect the lower radiator hose from the oil filter adapter. 37. Disconnect and remove the lower radiator hose. 38.
  • Page 7 1999 Mustang Workshop Manual Page 7 of 8 40. Remove the degas bottle support bracket. 41. Install the bolts for the RH lifting bracket. 42. NOTE: RH shown, LH similar. Remove the engine mount nuts. 43. Remove the transmission wiring harness. 1.
  • Page 8 1999 Mustang Workshop Manual Page 8 of 8 http://www.fordtechservice.dealerconnection.com/pubs/content/~WSXB/~MUS~LEN/20... 10/24/2009...
