About Alarm Actions

You can define up to 700 alarms for the Switch. The
actions that you can define for each alarm are
shown in Table 5-3:
Table 5-3 Alarm Actions
Action High Threshold
No action.
Notify only. Send Trap.
Notify and Send Trap. Block broad-
blip port. cast and multicast traffic
on the port for 5 sec-
onds.
Notify and Send Trap. Turn port off.
disable port.
Notify and
enable port.
Blip port. Block broadcast and mul-
ticast traffic on the port
for 5 seconds.
Disable port. Turn port off.
Enable port.
Notify and move Send Trap. If port is the
resilient port. main port of a resilient
link pair then move to
standby.
Notify and Send Trap. Block broad-
blip device. cast and multicast traffic
on all ports for 5 seconds.
Notify and Send trap. Turn all ports
disable device. on device off.
Notify and
enable device.
Blip device. Block broadcast and mul-
ticast traffic on all ports
for 5 seconds.
Disable device. Turn all ports on device
off.
Re-enable
device.
RMON 5-27
Low Threshold
Send Trap. Turn port
on.
Turn port on.
Send Trap. Turn ports
back to original state.
Turn ports back to
original state.
