Mode Indicators - Page 5-8
Selects the operational mode of the equipment.
HEAT - Indicates the heating mode.
COOL - Indicates the cooling mode.
AUTO - Indicates the system will automatically
changeover between heat and cool modes
as the temperature varies.
OFF - Indicates heating and cooling are turned off.
2
Room Temperature Display
Indicates current room temperature.
3
Desired Set Temperature - Page 9
Indicates desired room temperature(s).
Setup icon - Pages 10-14
4
Indicates the thermostat is in the advanced setup
mode.
4
O
UTSIDE
Page 3
