Basic Operation
Selecting Your Desired Temperature
(adjusting the setpoints)
AUTO OR PROGRAM MODE
Pressing the UP or DOWN button in Auto or Program
mode will adjust both the heat and cool set temperatures
simultaneously.
76
70
C
OOL
AUTO
68
H
EAT
Fan Operation
Pressing the FAN button will run the fan in
low, medium, or high speed continuously
(see below and page 20).
When only the Fan icon is displayed, the fan
is in the Auto mode and will run only when
necessary to heat or cool (see below and
page 20).
Press Press
FAN FAN
Low Speed Medium Speed
Fan Fan
Note: If the thermostat is placed in the Off mode, the fan
will de-energize (see page 5).
Adjust the desired
set temperature with the
buttons.
Press
FAN
Press
FAN
High Speed
Fan
Page 9
Press
FAN
Auto
Fan
