Page 1: Instruction Manual
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at Instruction Manual Bedienungsanleitung Manuel d’utilisation ™ Manuale di Istruzioni Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at... -
Page 2: Additional Safety Precautions And Warnings
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. -
Page 3: Table Of Contents
Introduction Designed for 3D aerobatics even in relatively small indoor spaces, the UMX Extra 300 3D utilizes micro light film over laser cut foam with carbon reinforcement to create an ultra lightweight aerobatic performer. Designed by ETOC Champion Seth Arnold, the UMX Extra 300 3D has been totally optimized to deliver extreme 3D performance for any experienced pilot. -
Page 4: Battery Warnings
• By handling, charging or using the included Li-Po battery you assume all risks associated with lithium batteries. If you do not agree with these conditions, return your complete UMX Extra 300 3D model in new, unused condition to the place of purchase immediately. • DO NOT USE A Ni-Cd OR Ni-MH CHARGER. Failure to charge the battery with a compatible charger may cause fire resulting in personal injury and/or property damage. -
Page 5: Charging The Battery
Charging the Battery Your UMX Extra 300 3D comes with a 1S 3.7V Li-Po Battery Charger and 150mAh 1-Cell 3.7V 12C Li-Po battery. It is important that you only charge with the included charger, or the E-flite Celectra™ 4-port Charger (EFLC1004). Refer ® to battery warnings. We recommend you charge the battery pack first. You will need the flight battery to confirm proper aircraft operation in future steps. -
Page 6: Transmitter And Receiver Binding
Spektrum DSM2 aircraft transmitter can bind to the Spektrum AR6400L receiver. Due to the ® aerobatic capabilities of the UMX Extra 300 3D, we recommend using a transmitter with adjustable exponential and dual rates. Please visit www.bindnfly.com for a complete list of compatible transmitters. -
Page 7: Control Direction Test
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at Control Direction Test You should bind your aircraft and transmitter before doing these tests. Move the controls on the transmitter to make sure aircraft control surfaces move correctly and in the proper direction. Control Centering Before first flights, or in the event of an accident, make sure the flight control surfaces are centered. -
Page 8: Dual Rates And Expo
Flying Note: Always fully lower the throttle when the aircraft lands For the initial flights the UMX Extra 300 3D should to prevent damage to the ESC. be flown in a gymnasium or large open space. Note: Crash damage is not If flown outdoors, fly only in an open yard or covered under warranty. -
Page 9: Installation Of Side Force Generator (Sfg)
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at Installation of Side Force Generator (SFG) SFGs help with knife-edge flying. They add side 3. Put channel in SFG on wing. force in all attitudes which greatly increases rudder 4. Turn SFG carefully so rear support goes in slot in authority making a variety of 3D aerobatics pos- SFG (see illustration). sible. However, installation is optional. 5. Attach SFG to wing and carbon supports using 1. Turn SFG so it is near flat in relation to the wing. foam-safe CA. 2. Lower part of SFG with pre-cut slot must go 6. Attach an SFG on other wing using instructions under carbon wing supports. -
Page 10: Replacement Parts
Description EFLU1053 Gearbox with Propeller Shaft: UMX Extra 300 3D Landing Gear with Mounts: UMX Extra 300 3D EFLU1055 EFLU1056 Hardware Set: UMX Extra 300 3D Wing Bracing with Mounts: UMX Extra 300 3D EFLU1057 EFLU1070 Replacement Airframe: UMX Extra 300 3D EFL9051 Propeller with Spinner (2): 130mm x 70mm EFL9052 Motor: UMX 4Site/Extra 300 3D... -
Page 11: Troubleshooting Guide
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at Troubleshooting Guide Problem Possible Cause Solution Aircraft will not respond Throttle not at idle and/or throttle trim Reset controls with throttle stick and throttle to throttle but responds to too high trim at lowest setting other controls Throttle channel is reversed Reverse throttle channel on transmitter... -
Page 12: Warranty And Repair Policy
Modellbau Lindinger GmbH e-Mail: office@lindinger.at www.lindinger.at Warranty and Repair Policy Warranty Period WARRANTY SERVICES Exclusive Warranty- Horizon Hobby, Inc., (Horizon) war- Questions, Assistance, and Repairs ranties that the Products purchased (the “Product”) will Your local hobby store and/or place of purchase cannot be free from defects in materials and workmanship at the provide warranty support or repair. -
Page 13: Contact Information
Compliance Information for the European Union Declaration of Conformity (in accordance with ISO/IEC 17050-1) No. HH2010083003 Product(s): EFL UMX Extra 300 3D BNF Item Number(s): EFLU1080 Equipment class: The object of declaration described above is in conformity with the requirements of the specifications listed below, following the provisions of the European R&TTE directive 1999/5/EC:... - Page 14 The Spektrum trademark is used with permission of Bachmann Industries, Inc. E-flite, Bind-N-Fly, Hangar 9, JR, UMX, DSM2 and Celectra are trademarks or registered trademarks of Horizon Hobby, Inc. Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan.
