Shorthand Variable Text Commands (Cont.)
@TXT
Adds text to a but-
ton.
@UNI
Adds Unicode text
to a button.

Button String Commands

The table below lists string commands you can assign to buttons by using the touch panel editor.
Select the PROPERTIES option in the Edit bar, press the target button, and enter the string
command with the Touch Panel keyboard. The control system receives the string command
when you press a button.
Button String Commands
$ID
Sets the group ID
number on VPN
panels.
ViewPoint Wireless Touch Panels
Use the | character to display text on multiple lines.
Syntax:
"'@TXT',<variable text address>,'<text>'"
Variables:
variable text address = 1 - 255
text = Enter button text to appear on the button.
Example:
SEND_COMMAND TP,"'@TXT',2,'VCR|PLAY'"
Sets the VCR and PLAY text on variable button 2. The | character places VCR on a text
line above PLAY on the button.
Characters for Middle Eastern languages, such as Arabic, are not supported within the
Unicode fonts because they are bi-directional. Buttons with Unicode fonts can only be cre-
ated and edited using TPDesign3 Touch Panel Design Program.
Syntax:
"'@UNI',<variable text address>,'<text>'"
Variables:
variable text address = 1 - 255
text = Enter button text to appear on button.
Example:
SEND_COMMAND TP,"'@UNI',2,'Foreign Text'"
Sets the Foreign Text on variable button 2.
Syntax:
"$ID,<group ID>"
Variables:
group ID = 0 (Off) - 15
Example:
$ID 15
Sets the Group ID to 15.
