Icom IC-F3020 Service Manual Addendum page 66

Nov. 2008
[PA UNIT]
REF PARTS
NO. NO.
C753 4030017460 S.CER ECJ0EB1E102K
C754 4030017460 S.CER ECJ0EB1E102K
C755 4030017420 S.CER ECJ0EC1H470J
C756 4030017420 S.CER ECJ0EC1H470J
C757 4030017460 S.CER ECJ0EB1E102K
C758 4030017420 S.CER ECJ0EC1H470J
C759 4030017460 S.CER ECJ0EB1E102K
C760 4030017460 S.CER ECJ0EB1E102K
C761 4030017460 S.CER ECJ0EB1E102K
C763 4030016790 S.CER ECJ0EB1C103K
C767 4030017460 S.CER ECJ0EB1E102K
C768 4030017520 S.CER ECJ0EC1H0R3B
C769 4030017520 S.CER ECJ0EC1H0R3B
C780 4030017460 S.CER ECJ0EB1E102K
C781 4030016930 S.CER ECJ0EB1A104K
C782 4030017460 S.CER ECJ0EB1E102K
C784 4030017420 S.CER ECJ0EC1H470J
C785 4030016790 S.CER ECJ0EB1C103K
C786 4550007600 S.TAN F920J106MPABMA
C787 4030017580 S.CER ECJ0EC1H060C
J701 6910017680 CON IMSA-9230B-1-04Z140-PT1
J702 6910017680 CON IMSA-9230B-1-04Z140-PT1
F701 5210000901 S.FUS 0467003.NR (0434003)
EP711 6910015370 S.BEA ACZ1005Y-102-T
EP712 6910012350 S.BEA MMZ1608Y 102BT
MP701 8410002531 S.HEA 2681 PA HEATSINK-1
[ANT UNIT]
REF PARTS
NO. NO.
L801 6200012780 S.COI 0.30-1.4-6TL 27.2N <COMO>
L802 6200012470 S.COI 0.30-1.7-7TL 45.3N <COMO>
R801 7030005080 S.RES ERJ2GEJ 823 X (82K)
C801 4030017460 S.CER ECJ0EB1E102K
C802 4030017380 S.CER ECJ0EC1H050B
C803 4030017410 S.CER ECJ0EC1H240J
C807 4030017620 S.CER ECJ0EC1H100C
MP801 8510017640 S.PLA 2927 ANT PLATE Y851
[CONNECT UNIT]
REF PARTS
NO. NO.
L901 6200006190 S.COI BLM21PG300SN1D(BLM21P300S) T
C901 4030017460 S.CER ECJ0EB1E102K
C902 4030017420 S.CER ECJ0EC1H470J
J901 6910015881 CON 9230B-1-02Z141-PT1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
B 26.8/16.4
B 29.2/12.5
B 16.7/12.9
B 15.8/12.9
T 16.7/13.5
T
B
B 21.2/19.9
T
T
B 16.7/14.5
T 29.4/15.8
B 34.2/16.8
B 15.7/22.6
B 16.7/24.2
B 14.7/23.7
B 19.5/20.7
B 21.2/23.7
T 17.7/21.1
T 26.2/20.1
B 12.7/20.2
T
B 14.6/14.4
T
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
DESCRIPTION M.
LOCATION
T
T
S.=Surface mount
H/V
16.3/1.6
7.8/10.3
7.2/9.9
8.1/14
9/14
19/7.2
H/V
4.2/12.3
3.6/8.6
9/13.5
9.6/7.4
5.5/8.6
1.8/14.1
3.4/14.1
H/V
8.7/6
5.6/6
5.6/7
11
