SECTION 1
GENERAL
• Frequency coverage
• Mode
• Current drain
(at 9.6 V DC)
• Frequency stability
• Usable temperature range
• Antenna connector
• No. of memory channels
• Acceptable power supply
• Frequency resolution
• Dimensions (Projections not included) : 58(W) × 140.5(H) × 32.3(D) mm; 2
• Weight
(with BP-199)
TRANSMITTER
• Output power
(9.6 V DC)
• Modulation system
• Max. frequency deviation
• Spurious emissions
• External microphone connector
RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
(12 dB SINAD)
• Squelch sensitivity
(threshold)
• Selectivity
• Spurious and image refection ratio
(except 2nd IF image frequency)
• Audio output power
(at 9.6 V DC)
• External speaker connector
All stated specifications are subject to change without notice or obligation.
SPECIFICATIONS
:
Version
U.S.A.
140.000–150.000 MHz*
Europe, U.K.
144.000–146.000 MHz
Thailand
Italy, Asia,
136.000–174.000 MHz*
ANI, C.S.A.
Taiwan
145.000–146.000 MHz
Guaranteed frequency range:
: FM (F2, F3)
: Transmit at 6.0 W
at 5.0 W
at 1.0 W
Receive max. audio
power saved
standby
: ±10 ppm
(0˚C to +50˚C; 32˚F to 122˚F)
: –10˚C to 60˚C; 14˚F to 140˚F
: BNC (50 Ω)
: 43 ch (40 regulator, 2 scan edges and 1 call)
: 9.6 V DC (supplied Ni-Cd cells; negative ground)
: 5 kHz and 12.5 kHz
: 420 g; 14.8 oz
: 6 W typical
(high)
5 W typical
(high)
0.7 W typical
(low)
: Variable reactance frequency modulation
: ±5 kHz
: Less than –60 dB
: 3-conductor 2.5 (d) mm (
: Double conversion superheterodyne
: 1st 30.85 MHz
2nd 450 kHz
: Less than 0.18 µV (–122 dBm)
: Less than 0.18 µV (–122 dBm)
: More than 15 kHz/–6 dB
Less than 30 kHz/–60 dB
: 60 dB (typical)
(typical at 10% distortion with an 8 Ω load)
: 500 mW
: 3-conductor 3.5 (d) mm (
Transmit
136.000–174.000 MHz*
144.000–146.000 MHz
136.000–174.000 MHz*
145.000–146.000 MHz
*
144–148 MHz
1.6 A (typical)
1.5 A (typical) [Thailand]
0.7 A (typical)
210 mA (typical)
25 mA (typical)
80 mA (typical)
(W) × 5
9 ⁄
32
[Thailand] only
⁄ ") ⁄ 2 kΩ
1
10
⁄ ") ⁄ 8 Ω
1
8
1 - 1
Receive
(H) × 1
17 ⁄ 9 ⁄ (D) inch
32 32
