INTRODUCTION
This service manual describes the latest service information for
the IC-T2H/E-T FM TRANSCEIVER at the time of publication.
MODEL VERSION
IC-T2H
C.S. America/-1
IC-T2E-T
To upgrade quality, all electrical or mechanical parts and inter-
nal circuits are subject to change without notice or obligation.
DANGER
NEVER
connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. Such a connection
could cause a fire hazard and/or electric shock.
DO NOT
expose the transceiver to rain, snow or any liq-
uids.
DO NOT
reverse the polarities of the power supply when
connecting the transceiver.
DO NOT
apply an RF signal of more than 20 dBm (100
mW) to the antenna connector.
transceiver's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1140006560 S.IC HD6433875A45H IC-T2H
8810009560 Screw B0 2 × 6 ZK
Addresses are provided on the inside back cover for your
convenience.
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 40 dB or 50 dB attenuator between the transceiver and a deviation meter or spectrum analyser when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transciver.
SYMBOL
U.S.A. USA
Europe EUR
U.K. UK
Italy ITA
Asia SEA
CSA/-1
Taiwan TWN
Asia-1 ANI
Thailand THA
This could damage the
MAIN UNIT 1 piece
IC-T2H CHASSIS 6 pieces
REPAIR NOTES
