Icom IC-T2H Service Manual page 15

[MAIN UNIT]
REF ORDER
NO. NO.
R70 7030003480 S.RESISTOR
R71 7030003290 S.RESISTOR
R76 7030003480 S.RESISTOR
R77 7030003400 S.RESISTOR
R79 7030003440 S.RESISTOR
R80 7030003670 S.RESISTOR
R81 7030003400 S.RESISTOR
R82 7030003450 S.RESISTOR
R83 7030003400 S.RESISTOR
R84 7030003390 S.RESISTOR
R85 7030003440 S.RESISTOR
R86 7030003670 S.RESISTOR
R87 7030003460 S.RESISTOR
R88 7030003720 S.RESISTOR
R89 7030003600 S.RESISTOR
R90 7510000890 S.THERMISTOR NTCCF2012 3NH 153KC-T
R91 7030003580 S.RESISTOR
R92 7310002760 S.TRIMMER
R93 7030003570 S.RESISTOR
R94 7030003770 S.RESISTOR
R95 7030003750 S.RESISTOR
R96 7030003640 S.RESISTOR
R97 7030003710 S.RESISTOR
R98 7030003710 S.RESISTOR
R99 7030003540 S.RESISTOR
R100 7030003470 S.RESISTOR
R101 7030003800 S.RESISTOR
R102 7030003200 S.RESISTOR
R103 7030003570 S.RESISTOR
R104 7030003680 S.RESISTOR
R105 7030003320 S.RESISTOR
R106 7030003570 S.RESISTOR
R107 7030003710 S.RESISTOR
R108 7030003750 S.RESISTOR
R109 7030003560 S.RESISTOR
R112 7030003800 S.RESISTOR
R114 7030003640 S.RESISTOR
R115 7030003690 S.RESISTOR
R116 7030003440 S.RESISTOR
R117 7030003460 S.RESISTOR
R118 7030003560 S.RESISTOR
R119 7310002600 S.TRIMMER
R120 7030003580 S.RESISTOR
R121 7030003440 S.RESISTOR
R122 7030003470 S.RESISTOR
R123 7030003520 S.RESISTOR
R125 7030003720 S.RESISTOR
R126 7030003570 S.RESISTOR
R127 7030003200 S.RESISTOR
R128 7030003200 S.RESISTOR
R130 7030003680 S.RESISTOR
R131 7030003400 S.RESISTOR
R132 7030000340 S.RESISTOR
R133 7030003440 S.RESISTOR
R134 7030003520 S.RESISTOR
R137 7030003520 S.RESISTOR
R139 7030003520 S.RESISTOR
R141 7030003520 S.RESISTOR
R144 7030003620 S.RESISTOR
R146 7030003680 S.RESISTOR
R147 7030003720 S.RESISTOR
R148 7030003680 S.RESISTOR
R149 7030003560 S.RESISTOR
R151 7030003640 S.RESISTOR
R155 7030003400 S.RESISTOR
R156 7030000170 S.RESISTOR
R157 7030000170 S.RESISTOR
R158 7030003520 S.RESISTOR
R159 7030003680 S.RESISTOR
R160 7030000270 S.RESISTOR
R161 7030007330 S.RESISTOR
R162 7030003440 S.RESISTOR
R163 7030003580 S.RESISTOR
R166 7030003680 S.RESISTOR
R167 7030003680 S.RESISTOR
R168 7030003560 S.RESISTOR
R169 7030003550 S.RESISTOR
R174 7030003580 S.RESISTOR
R176 7030003530 S.RESISTOR
R178 7030003520 S.RESISTOR
R181 7030005870 S.RESISTOR
R182 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
DESCRIPTION
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
RV-152 (RH03A3AJ4X0HA) 223
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
RV-110 (RH03A3AS4X0AA) 473
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 470 Ω (471)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 18 Ω (180)
MCR10EZHJ 18 Ω (180)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
MCR10EZHJ 120 Ω (121)
ERJ1WRSJR15U (0.15 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
RR0816R-104-D (100 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R183 7030003380 S.RESISTOR
R186 7030003640 S.RESISTOR
R191 7030003590 S.RESISTOR
R192 7030003590 S.RESISTOR
R195 7030003590 S.RESISTOR
R196 7030003560 S.RESISTOR
R197 7030003780 S.RESISTOR
R199 7030003520 S.RESISTOR
R200 7030003440 S.RESISTOR
R202 7030003640 S.RESISTOR
R203 7030003640 S.RESISTOR
R204 7030003580 S.RESISTOR
R205 7030003580 S.RESISTOR
R207 7030003440 S.RESISTOR
R208 7030003650 S.RESISTOR
R209 7030003770 S.RESISTOR
R210 7030003440 S.RESISTOR
R213 7030003560 S.RESISTOR
R214 7030003570 S.RESISTOR
R215 7030005520 S.RESISTOR
R216 7030005630 S.RESISTOR
R217 7030003560 S.RESISTOR
R218 7030003630 S.RESISTOR
R219 7030003660 S.RESISTOR
R220 7030003720 S.RESISTOR
R221 7030003740 S.RESISTOR
R224 7030003640 S.RESISTOR
R226 7410000950 S.ARRAY
R227 7030003440 S.RESISTOR
R229 7030003560 S.RESISTOR
R230 7030003600 S.RESISTOR
R231 7030003640 S.RESISTOR
R234 7030003670 S.RESISTOR
R235 7030003680 S.RESISTOR
R236 7030003440 S.RESISTOR
R237 7410000750 S.ARRAY
R238 7030003220 S.RESISTOR
R239 7030003440 S.RESISTOR
R240 7030003320 S.RESISTOR
7030003400 S.RESISTOR
R242 7030003600 S.RESISTOR
R243 7030003680 S.RESISTOR
R245 7030003600 S.RESISTOR
R246 7030003640 S.RESISTOR
R247 7030003670 S.RESISTOR
R248 7030003710 S.RESISTOR
R249 7030003740 S.RESISTOR
R252 7410000770 S.ARRAY
R253 7410000950 S.ARRAY
R254 7410000770 S.ARRAY
R255 7410000950 S.ARRAY
R256 7410000950 S.ARRAY
R257 7410000770 S.ARRAY
R258 7030003780 S.RESISTOR
R259 7030003680 S.RESISTOR
R260 7030003440 S.RESISTOR
R261 7030003440 S.RESISTOR
R262 7030003580 S.RESISTOR
R263 7030003720 S.RESISTOR
R264 7030005520 S.RESISTOR
R266 7030003340 S.RESISTOR
R267 7030003540 S.RESISTOR
R268 7030003570 S.RESISTOR
R269 7030003600 S.RESISTOR
R272 7030003520 S.RESISTOR
R279 7030003680 S.RESISTOR
R280 7030003250 S.RESISTOR
R281 7030003440 S.RESISTOR
R282 7030003440 S.RESISTOR
R283 7030003440 S.RESISTOR
R284 7030003440 S.RESISTOR
R285 7030003440 S.RESISTOR
R286 7030003440 S.RESISTOR
R287 7030003440 S.RESISTOR
R289 7030003440 S.RESISTOR
R290 7030003440 S.RESISTOR
R291 7030003680 S.RESISTOR
R292 7030003290 S.RESISTOR
R294 7030003560 S.RESISTOR
6 - 2
DESCRIPTION
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
RR0816R-334-D (330 kΩ)
RR0816R-154-D (150 kΩ)
ERJ3GEYJ 103 V (10 kΩ) [ANI] only
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
EXB-V8V 102JV
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EXB-V4V 104JV (100 kΩ)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
[SEA], [THA], [CSA/CSA-1], [TWN], [ANI]
ERJ3GEYJ 471 V (470 Ω)
[EUR], [UK], [ITA], [USA]
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
EXB-V4V 102JV (1 kΩ)
EXB-V8V 102JV
EXB-V4V 102JV (1 kΩ)
EXB-V8V 102JV
EXB-V8V 102JV
EXB-V4V 102JV (1 kΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
RR0816R-334-D (330 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 270 V (27 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
[ANI] only
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 103 V (10 kΩ)
S.=Surface mount
