3Com Router 6040

Figure 1 Front panel of the 3Com Router 6040
(1)
1) Slot0 for the main control board
3) FIC Slot2
5) FIC Slot4
Figure 2 Rear panel of the 3Com Router 6040
(1)
(3) (4)
1) Fan module
3) ESD-preventive wrist strap port
5) PSU 2 (PWR2)
(2) (3)
(4) (5)
2) FIC Slot1
4) FIC Slot3
6) ESD-preventive wrist strap port
(5)
2) Grounding screw
4) PSU 1 (PWR1)
3Com Router 6040 13
