4Push [CH Up] or [CH Down], or rotate
[CH Up/Down] to select the desired ID (or name.) [CH Up/Down] to select the desired ID (or name.)
• Push and hold [Digital Button] for 1 sec to
cancel and return to normal operation.
• The ID can be edited with the 10-keypad*.
(Depending on the pre-set value.)
* 10-key model only.
5Push [PTT] to transmit the status query signal to
the target station.
• The Busy/Transmit indicator lights red.
• "PLEASE WAIT" is displayed.
6 Release [PTT].
• "STATUS QUERY" and the last transmitted
Status Message by the target station blinks.
• "NO ACKNOWLDG" is displayed when an
acknowledgement is not received, and then the
t transceiver returns to normal operation. i t t
Receiving
▒ Not available on Non-display model.
➥ When a status transmitted Status Message is
automatically transmitted.
• The Busy/Transmit indicator lights green
while receiving, and lights red while
transmitting an acknowledgement or the
Status Message.
• The function display does not change while
transmitting.
■ Phone call
Transmitting Transmitting
The transceiver can make a phone call that is
similar to standard phone calls. A transceiver and a
PSTN (Public Switched Telephone Network) can
access each other.
If no phone number is pre-programmed, the Phone
call function is not available.
[Digital Button] or [Phone] key assignment is
necessary to transmit the Phone call. t t it th Ph
▒ Not available on Non-display model.
APCO P25 Mode Operation
l ti
ll
1Push [Digital Button] to enter the digital call type
selection mode.
▒ ✔ Quick access
▒ Push [Phone] to enter the phone number
▒ selection mode directly. In this case, skip step 2.
▒ Go to step 3.
2Push [CH Up] or [CH Down], or rotate [CH
Up/Down] to select "PHONE." Up/Down] to select PHONE.
3Push [Digital Button] again to enter the phone
number selection mode.
• A pre-programmed phone number and text are
displayed.
4Push [CH Up] or [CH Down], or rotate
[CH Up/Down] to select the desired phone number.
• Push and hold [Digital Button] (or [Phone]) for 1
sec to cancel and return to normal operation.
• The phone digits (0 to 9, M and #) can be edited
with the 10-keypad*. (Depending on the pre-set
value.)
*10-key model only.
▒ To edit the Phone number with the 10-keypad:
▒ Input the phone number directly with the 10-
▒ keypad. ▒ keypad.
▒• Push [Digital Button] (or [Phone]) to clear a
▒ code.
▒
▒
▒
▒
▒
▒ ▒
▒
