3Push [Digital Button] again to enter the Short 3Push [Digital Button] again to enter the Short
Message selection mode.
*A pre-programmed Short Message is displayed.
4Push [CH Up] or [CH Down], or rotate
[CH Up/Down] to select the desired Short
Message. While in the Trunking mode, the
following steps 5and 6 are not necessary.
Go to step 7.
5Push [Digital Button] (or [Digital Message]) again 5Push [Digital Button] (or [Digital Message]) again
to enter the Individual ID selection mode.
• A pre-programmed ID name is displayed.
• When the ID name is not programmed,
the ID code is displayed.
6Push [CH Up] or [CH Down], or rotate
[CH Up/Down] to select the desired ID (or name).
• Push and hold [Digital Button] (or [Digital
Message]) for 1 sec to cancel and return to Message]) for 1 sec to cancel and return to
normal operation.
• The ID can be edited with the 10-keypad*.
(Depending on the pre-set value.)
* 10-key model only.
7Push [PTT] to transmit the Short Message to the
target station.
• The Busy/Transmit lights red. y/
• "PLEASE WAIT" is displayed.
8Release [PTT].
• "ACK RECEIVED" is displayed after receiving an
acknowledgement from the target station, and
then the transceiver returns to normal operation.
• "NO ACKNOWLDG" is displayed when an
acknowledgement is not received, and then the
transceiver returns to normal operation.
46
APCO P25 Mode Operation
g
Receiving Receiving
▒ Not available on Non-display model.
1When a Short Message is received;
• The Busy/Transmit lights green.
• The ringer sounds. (Depending on the pre-set
value.)
• The calling station ID name (or code) and the
Short Message blinks. g
2An acknowledgement is automatically transmitted. k l d
2A
• The Busy/Transmit lights red.
3Push any key (except for [ ]) to stop the display
from blinking and return to normal operation.
■ Status Query function
Transmitting Transmitting
A Status Query function allows you to send a signal
that requests the last transmitted Status Message
to the target station. The target station transceiver
automatically responds after receiving a Status
Query signal.
[Digital Button] key assignment is necessary to
transmit the Status Query.
▒ Not available on Non-display model.
1Push [Digital Button] to enter the digital call type
selection mode.
2Push [CH Up] or [CH Down], or rotate
[CH Up/Down] to select "STATUS QUERY."
3Push [Digital Button] again to enter the Individual
ID selection mode.
• A pre-programmed ID name is displayed. • A pre programmed ID name is displayed
• When the ID name is not programmed,
the ID code is displayed.
The received message
The calling station ID name
i i ll i d
