2Select the desired Talkgroup ID (or name)
using [CH Up]/[CH Down], or [CH Up/Down].
▒ NOTE: When '65535' is selected as the
▒ Talkgroup ID, All Call is an open call to
▒ everyone on your system.
3Push and hold [PTT] to transmit the Talkgroup
call to the specific group, then speak into the
microphone.
• The Busy/Transmit indicator lights red.
• Depending on the pre-set value, the target
station does not open the squelch, and
communication is not established, if the
Talkgroup ID or NAC (Network Access Code)
is not matched. Ask your dealer for details.
• The Talkgroup ID (or name) is displayed for
2 sec when [PTT] is pushed. (Depending on
the pre-set value.) p
4 Release [PTT] to receive.
Receiving
1When a Talkgroup call is received;
• The Busy/Transmit lights green.
• The ringer sounds. (Depending on the pre-
setting.)
• The Talkgroup ID (or name) and calling The Talkgroup ID (or name) and calling
station ID (or name) are displayed for 2 sec.
(Depending on the pre-set value.)
"ALL CALL" is displayed instead of the Talkgroup ID
(or name) when All Call is received.
•Depending on the pre-set value, the transceiver
does not open the squelch, and communication is
not established if the Talkgroup ID or NAC not established, if the Talkgroup ID or NAC
(Network Access Code) is not matched.
Talkgoup ID
40
APCO P25 Mode Operation
)
The calling station
name ( or ID )
2Push and hold [PTT] and speak into the
microphone.
▒ NOTE: Only one station is permitted to speak at a
▒ time.
3Release [PTT] to receive a response.
▒ NOTE: When the Talkgroup ID is set to '65535,'
▒ any Talkgroup call can be received (if NAC is
▒ matched).
Talkgroup display on mode change
The Talkgroup ID (or name) is displayed for 2 sec on
the upper line of the LCD when the operating
channel or zone is changed. This function can be
turned OFF by your dealer.
Talkgroup display on PTT
The Talkgroup ID (or name) is displayed for 2 sec on
the upper line of the LCD when [PTT] is pushed.
This function can be turned OFF by your dealer.
■ Pager function
Transmitting
This function can be used as a "message pager" to
confirm the target station of a caller's identification,
even when the operator leaves the transceiver
temporarily unattended. If the target station is active
when receiving a signal, an acknowledgement
is automatically transmitted. The caller station can
verify whether a target station is active or not.
[Digital Button] or [Digital Page] key assignment is
necessary to transmit the pager signal. necessary to transmit the pager signal.
▒ Not available on Non-display model.
1Push [Digital Button] to enter the digital call type
selection mode.
▒ ✔ Quick access
▒ Push [Digital Page] to directly enter the Individual
▒ ID selection mode. In this case, skip step 2.
