D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 Li-Ion battery packs to
be charged simultaneously. The following items are addition-
ally required.
• Six AD-106 charger adapters
• An optional AC adapter or the DC power cable (OPC-656)
Battery
pack
AC adapter
(Purchased
separately)
IMPORTANT!
Ensure the tabs on
DC power cable
the battery pack are
(OPC-656)
correctly
(Connect with the
with the guide rails
DC power supply;
inside the charger.
13.8 V/at least 7 A)
Transceiver
Turn power OFF
AD-106 charger
adapters are installed
in each slot.
Tabs
aligned
Guide rails
BATTERY CHARGING
