1
6
2
7
1
10
9
Table Top
Follow this diagram to attach the
fence to the table.
PROFENCE PARTS LIST
1 Aluminum Fence
2 Adjustable MDF Fence Faces
3 Bit Safety Guard
4 Dust Port
5 3/8-16 T-Knobs
6 5/16-18 x 1 1 ⁄ " T-Bolts
4
7 1" Round Knobs
8 Knob Spacer
9 3/8-16 x 2 1 ⁄ " Hex Bolts
2
10 3/8" Nylon Washer
8
10
9
3
5
8
4
7
2
5
9
Quantity
1
2
1
1
2
6
6
2
2
2
3
