Gigabyte GA-6VX7-1394 User Manual

Socket 370 processor motherboard
Hide thumbs Also See for GA-6VX7-1394:

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-6VX7-1394
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Mar. 16, 2001
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-6VX7-1394

  • Page 1 Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T. INC. limits are designed to provide reasonable Address: 18305 Valley Blvd., Suite#A...
  • Page 2: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6VX7-1394 is in conformity with...
  • Page 3 6VX7-1394 Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 5.0 First Edition R-50-01-010307...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6VX7-1394 Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.32 Block Diagram P.33 Suspend to RAM Installation P.34 Memory Installation P.40 Page Index for BIOS Setup P.41 Appendix P.69...
  • Page 8: Revision History

    6VX7-1394 Motherboard Revision History Revision Revision Note Date Initial release of the 6VX7-1394 motherboard user’s manual. Mar.2001 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6VX7-1394 motherboard Cable for IDE / floppy device Diskettes or CD (TUCD) for motherboard driver & utility 6VX7-1394 user’s manual...
  • Page 10 6VX7-1394 Motherboard Features Summary Form Factor 30.4 cm x 20.3 cm ATX SIZE form factor, 4 layers PCB. Socket 370 processor  Intel Pentium !!! 100/133MHz FSB, FC-PGA Intel Celeron 66MHz FSB, FC-PGA L2 cache in CPU(Depend on CPU) Chipset VT82C694X (VIA Apollo Pro 133A) VT82C686B Clock Generator...
  • Page 11 Features Summary Hardware Monitor CPU / System fan revolution detect CPU / System temperature detect System voltage detect (Vcore,+3V,+5V,+12V) CPU overheat shutdown detect PS/2 Connector PS/2 keyboard interface and PS/2 mouse interface BIOS Licensed AMI BIOS, 2M bit flash ROM Additional Features Supports Wake-on-LAN (WOL) Supports Internal / External modem wake up...
  • Page 12: 6Vx7-1394 Motherboard Layout

    6VX7-1394 Motherboard 6VX7-1394 Motherboard Layout JP15 JP30 PS/2 JP16 JP19 LED1 PGA 370 VT82C694X 6VX7-1394 BAT1 JP23 TSB4IL PCI1 USB2 PCI2 VT82C686B PCI3 TSBI2 LV23 PCI4 BIOS PCI5 JP22...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    6VX7-1394 Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors P.17 J13/J14/J15: I EEE 1394 Connector P.17 COM A / COM B / LPT Port P.17 USB Connector P.18 PS/2 Keyboard & PS/2 Mouse Connector P.18 JP16 (CPU Fan) P.19...
  • Page 14: Cpu Speed Setup

    6VX7-1394 Motherboard CPU Speed Setup The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the system bus speed (SW1) and change the DIP switch (SW2) selection to set up the CPU speed for 500MHz – 1GHz and faster processor. SW1: O : ON, X: OFF PCI CLK...
  • Page 15 CPU Speed Setup For Auto Jumper setting: Note: 1. If you use 66, 100, 133 MHz CPU, we recommend you to set up your system speed to “Auto” value. 2. We don’t recommend you to set up your system speed to 75,83,112, 124, 140,150 MHz because these frequencies are not the standard specifications for CPU, Chipset and most of the peripherals.
  • Page 16 6VX7-1394 Motherboard Celeron 533 / 66MHz FSB Celeron 566 / 66 MHz FSB Celeron 600 / 66 MHz FSB...
  • Page 17 CPU Speed Setup Celeron 633 / 66 MHz FSB Celeron 667 / 66 MHz FSB Celeron 700 / 66 MHz FSB...
  • Page 18 6VX7-1394 Motherboard Pentium ® !!! 500 / 100MHz FSB ® Pentium !!! 550 / 100MHz FSB Pentium ® !!! 600 / 100MHz FSB...
  • Page 19 CPU Speed Setup 10. Pentium ® !!! 650 / 100MHz FSB ® 11. Pentium !!! 700 / 100MHz FSB 12. Pentium !!! 750 / 100MHz FSB ®...
  • Page 20 6VX7-1394 Motherboard 13. Pentium !!! 800 / 100MHz FSB ® 14. Pentium !!! 850 / 100MHz FSB ® 15. Pentium ® !!! 533 / 133MHz FSB...
  • Page 21 CPU Speed Setup 16. Pentium ® !!! 600 / 133MHz FSB 17. Pentium ® !!! 667 / 133MHz FSB 18. Pentium ® !!! 733 / 133MHz FSB...
  • Page 22 6VX7-1394 Motherboard 19. Pentium !!! 800 / 133MHz FSB ® 20. Pentium !!! 866 / 133MHz FSB ® 21. Pentium !!! 933 / 133MHz FSB ®...
  • Page 23 CPU Speed Setup ® 22. Pentium !!! 1GHz / 133MHz FSB...
  • Page 24: Connectors

    6VX7-1394 Motherboard Connectors J13/J14/J15 : I EEE 1394 Connector Pin No. Definition TPB- TPB+ TPA- TPA+ COM A / COM B / LPT Port LPT Port COM A COM B...
  • Page 25: Usb Connector

    Connectors USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- 1 2 3 4 USB D1+ PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock...
  • Page 26: Jp16: Cpu Fan

    6VX7-1394 Motherboard JP16: CPU Fan Pin No. Definition +12V SENSE JP15: Power Fan Pin No. Definition +12V...
  • Page 27: Jp2: System Fan

    Connectors JP2: System Fan Pin No. Definition +12V SENSE ATX Power Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 28: Usb 2 Connector

    6VX7-1394 Motherboard USB 2 Connector Pin No. Definition 1,10 USB D2- USB D2+ USB D3+ USB D3- IR Connector PIN No. Definition VCC(+5V) IR data input IR data output...
  • Page 29: Floppy Port

    Connectors Floppy Port RED LINE IDE1 (Primary), IDE2(Secondary) Port RED LINE IDE 1 IDE 2...
  • Page 30: J3 (Ring Power On)

    6VX7-1394 Motherboard J3: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal J1: Wake On LAN Pin No. Definition +5V SB Signal...
  • Page 31: Jp5: Str Led Connector & Led1: Dimm Led

    Connectors JP5: STR LED Connector & LED1: DIMM LED STR LED Connector External DIMM LED Front USB Port (Optional) Pin No. Definition 1,4,5,10 3,7,9 USBP2+ USBP2-...
  • Page 32: J11: Sm Bus

    6VX7-1394 Motherboard J11: SM BUS Pin No. Definition SMB CLK SMB DATA CN4 : I EEE 1394 Connect (Optional) Pin No. Definition TPB- TPB+ TPA- TPA+...
  • Page 33: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J2: For 2X11 Pins Jumper P+ P− P− S P K GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode(−)
  • Page 34: Jp1: Clear Cmos Function (Optional)

    6VX7-1394 Motherboard JP1: Clear CMOS Function (Optional) Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS JP11: STR Enable Pin No. Definition Open STR Disabled (Default) Close STR Enabled...
  • Page 35: Jp19: Cyrix Cpu Turbo Function (Optional)

    Panel and Jumper Definition JP19: Cyrix CPU Turbo Function (Optional) Pin No. Definition Open Normal Close Cyrix 133MHz JP9: USB Device Wake up Selection Pin No. Definition 1-2 close Normal (Default) Enabled USB Device 2-3 close Wake up (If you want to use “USB KB Wakeup from S3~S5” function, you have to set the BIOS setting “USB KB Wakeup from S3~S5”...
  • Page 36: Jp23: Case Open

    6VX7-1394 Motherboard JP23: Case Open Pin No. Definition Signal JP22: BIOS Flash ROM Write Protect Pin No. Definition Close BIOS Write Disabled BIOS Write Enabled Open (Default) Please set Jumper JP22 to “Open” to enabled BIOS write function when you update new BIOS or new device.
  • Page 37: Jp30 (Over Voltage Cpu Speed Up) [Optional]

    Panel and Jumper Definition JP30: Over Voltage CPU Speed Up (Magic Booster) (Optional) (When JP30 set “7-8 Close”, CPU Voltage is rising 10%) Pin No. Definition 1-2 close 3-4 close 5-6 close 7-8 close 9-10 close Normal J12: Front Panel Jumper (Optional) Pin No.
  • Page 38: Bat1: Battery

    6VX7-1394 Motherboard BAT1: Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 39: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •...
  • Page 40: Block Diagram

    6VX7-1394 Motherboard Block Diagram 14.318MHz AGP 2X/4X PGA 370 CPU 3.3V DIMM DIMM Sockets Host Bus AGP Bus VT82C694X ICS 9248DF-39 33 MHz PCI Bus 33 MHz ISA Bus 24MHz 48MHz IDE Bus 14.318MHz VT82C686B Ultra DMA33/ATA66 COM Ports /ATA100IDE Ports Floppy IEEE 1394 PS/2 KB/Mouse...
  • Page 41: Suspend To Ram Installation

    Suspend to RAM Installation Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 42 6VX7-1394 Motherboard Step 2: (If you want to use STR Function, please set jumper JP11 Closed.) Pin No. Definition Open STR Disabled (Default) Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter ACPI Sleep BIOS Setup.
  • Page 43 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” Choose the “Stand by”...
  • Page 44 6VX7-1394 Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 45 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. D. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 46 6VX7-1394 Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant. Jumper JP5 is provided to connect to the STR LED in your system chassis.
  • Page 47: Memory Installation

    Memory Installation Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 48: Page Index For Bios Setup

    6VX7-1394 Motherboard Page Index for BIOS Setup Page The Main Menu P.43 Standard CMOS Setup P.45 BIOS Features Setup P.48 Chipset Features Setup P.50 Power Management Setup P.53 PNP/ PCI Configuration P.56 Load BIOS Defaults P.58 Load Setup Defaults P.59 Integrated Peripherals P.60 Hardware Monitor Setup...
  • Page 49: Entering Setup

    BIOS Setup BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 50: Getting Help

    6VX7-1394 Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 51 BIOS Setup • • • • Chipset Features Setup This setup page includes all the items of chipset special features. • • • • Power Management Setup This setup page includes all the items of Green function features. • • • • PnP/PCI Configurations This setup page includes all the configurations of PCI &...
  • Page 52: Standard Cmos Setup

    6VX7-1394 Motherboard Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 53 BIOS Setup • • • • Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. • • • • IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 54 6VX7-1394 Motherboard • • • • Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 55: Bios Features Setup

    BIOS Setup BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device :Floppy 2nd Boot Device :IDE-0 3rd Boot Device :CDROM S.M.A.R.T for Hard Disks :Disabled BootUp Num-Lock Floppy Drive Seek :Disabled Password Check...
  • Page 56 6VX7-1394 Motherboard • • • • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. • • • • Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks.
  • Page 57: Chipset Features Setup

    BIOS Setup Chipset Features Setup AMIBIOS SETUP –CHIPSET FEATURE CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *** DRAM Timing *** Top Performance :Disabled SDRAM Timing by SPD :Disabled SDRAM CAS# Latency DRAM Frequency :Auto C2P Concurrency & Master :Enabled DRAM Integrity Mode :Disabled...
  • Page 58 6VX7-1394 Motherboard • • • • C2P Concurrency & Master Enabled Enabled C2P Concurrency & Master. (Default Value) Disabled Disabled C2P Concurrency & Master. • • • • DRAM Integrity Mode For 72 bit ECC type DIMM Modle. Disabled Normal Setting. (Default Value) •...
  • Page 59 BIOS Setup • • • • South Bridge Subsystem ID Disabled Disable it if you have to install VIA 4 in 1 SP4.22 or before. (Default Value) Enabled Enable south bridge subsystem ID function. • • • • USB Controller USB Port 0&1 USB Controller for USB Port 0&1.
  • Page 60 6VX7-1394 Motherboard Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep type :S1/POS PME Event Wake up :Enabled USB KB Wakeup From S3~S5 :Disabled RTC Alarm Power On :Disabled Video Power Down Mode :Stand By RTC Alarm Date...
  • Page 61 BIOS Setup • • • • Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min.
  • Page 62 6VX7-1394 Motherboard • • • • Modem Ring on/Wake on LAN Disabled Disabled Modem Ring on/Wake on LAN. Enabled Enabled Modem Ring on/Wake on LAN. (Default Value) • • • • PME Event Wake up Disabled Disabled PME Event Wake up function. Enabled Enabled PME Event Wake up function.
  • Page 63 BIOS Setup PnP/PCI Configurations AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Reset Configuration Data VGA Boot From :AGP PCI VGA Palette Snoop :Disabled DMA Channel 0 :PnP DMA Channel 1 :PnP DMA Channel 3...
  • Page 64 6VX7-1394 Motherboard • • • • DMA Channel (0,1,3,5,6,7) The resource is used by PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA). • • • • IRQ (3,4,5,7, 9,10,11,14,15) PCI/PnP The resource is used by PCI/PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA).
  • Page 65: Power Management Setup

    BIOS Setup Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD Load BIOS Defaults (Y/N)? N PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...
  • Page 66: Load Setup Defaults

    6VX7-1394 Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION Load SETUP Defaults (Y/N)? N...
  • Page 67: Integrated Peripherals

    BIOS Setup Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE :Both OnBoard FDC :Auto OnBoard Serial Port 1 :Auto OnBoard Serial Port 2 :Auto Serial Port 2 Mode :Normal Duplex Mode :N/A OnBoard Parallel Port :Auto...
  • Page 68 6VX7-1394 Motherboard • • • • OnBoard Serial Port 2 Auto BIOS will automatically setup the port 2 address. (Default Value) 3F8/COM1 Enable Onboard Serial port 2 and address is 3F8. 2F8/COM2 Enable Onboard Serial port 2 and address is 2F8. 3E8/COM3 Enable Onboard Serial port 2 and address is 3E8.
  • Page 69 BIOS Setup • • • • Parallel Port IRQ Set Parallel Port IRQ is 7. Auto Set Auto to parallel Port IRQ DMA Channel. (Default Value) Set Parallel Port IRQ is 5. • • • • OnBoard AC’97 Audio Auto Set AC’97 Audio to Auto (Default Value).
  • Page 70: Hardware Monitor

    6VX7-1394 Motherboard Hardware Monitor AMIBIOS SETUP –HARDWARE MONITOR ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. :Disabled Current CPU Temp. :36°C/96°F Current System Temp. :28°C/82°F Case Status :Closed Current CPU Fan Speed :5487 RPM Current System Fan Speed :0 RPM Vcore...
  • Page 71 BIOS Setup • • • • Current CPU Temp. (° ° ° ° C / ° ° ° ° F) Detect CPU Temperature automatically. • • • • Current System Temp. (° ° ° ° C / ° ° ° ° F) Detect System Temperature automatically.
  • Page 72: Hardware Monitor Setup

    6VX7-1394 Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP...
  • Page 73: Ide Hdd Auto Detection

    BIOS Setup IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Thu Feb 24, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave...
  • Page 74: Save To Cmos And Exit

    6VX7-1394 Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...
  • Page 75: Exit Without Saving

    BIOS Setup Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION Quit without saving (Y/N) ? N...
  • Page 76: Appendix

    6VX7-1394 Motherboard Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 77 Appendix 7.Click “Next”. 6.Click “Next”. 8.Click “Next”. (10) 9.Click “Finish” to restart computer.
  • Page 78 6VX7-1394 Motherboard Appendix B: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Click “Tool” . Click “@BIOS Writer v1.05” Click “ ” . Click Here. Methods and steps : I.
  • Page 79 Appendix II. Update BIOS through Internet : Do not click "Internet Update" icon b. Click "Update New BIOS" c. Please select "All Files" in dialog box while opening the old file. d. Please search for BIOS unzip file, downloading from internet or any other methods (such as: 6vx7-1394.F1).
  • Page 80 6VX7-1394 Motherboard Or else you can select flash BIOS in DOS mode. Please check your BIOS vendor (AMI or AWARD), your motherboard name and PCB version on the motherboard. Format a bootable system floppy diskette by the command “format a:/s” in command mode.
  • Page 81 Appendix Appendix C: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communication Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface...
  • Page 82 6VX7-1394 Motherboard Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID...
