Gigabyte GA-6VX7-1394 User Manual

Socket 370 processor motherboard
Hide thumbs Also See for GA-6VX7-1394:
Table of Contents

Advertisement

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-6VX7-1394
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Mar. 30, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which the
receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates, uses, and can radiate radio frequency
energy, and if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-6VX7-1394

  • Page 1 Product Name: Mother Board generates, uses, and can radiate radio frequency GA-6VX7-1394 Model Number: energy, and if not installed and used in Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6VX7-1394 is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6VX7-1394 Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 1.1 First Edition R-11-01-000328...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6VX7-1394 Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation Memory Installation Page Index for BIOS Setup Appendix P.30 P.31 P.32 P.38 P.39...
  • Page 8: Revision History

    6VX7-1394 Motherboard Revision History Revision Revision Note Initial release of the 6VX7-1394 motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6VX7-1394 motherboard Cable for IDE / floppy device Diskettes or CD (TUCD) for motherboard driver & utility Internal COM B Cable (Optional) Internal USB Cable (Optional) Cable for SCSI device 6VX7-1394 user’s manual...
  • Page 10: Summary Of Features

    6VX7-1394 Motherboard Summary Of Features Form Factor 30.4 cm x 20.3 cm ATX SIZE form factor, 4 layers PCB. Socket 370 processor 2nd cache in CPU(Depend on CPU) Chipset VT82C694X (VIA Apollo Pro 133A) VT82C686A Clock Generator ICS 9248DF-39 66/100/133 MHz system bus speeds (PCI 33MHz) 112/124/140/150 MHz system bus speeds (PCI 44MHz) (reserved) Memory...
  • Page 11 BIOS Licensed AMI BIOS, 2M bit flash ROM Additional Features Supports Wake-on-LAN (WOL) Supports Internal / External modem wake up Includes 3 fan power connectors Poly fuse for keyboard over-current protection Summary of Features...
  • Page 12: 6Vx7-1394 Motherboard Layout

    6VX7-1394 Motherboard 6VX7-1394 Motherboard Layout PS/2 JP19 JP16 PGA 370 VT82C694X 6VX7-1394 TSB4IL PCI1 PCI2 PCI3 TSBI2 LV23 PCI4 PCI5 JP15 JP30 LED1 BAT1 JP23 USB2 VT82C686A BIOS JP22 JP24...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors J13/J14/J15 : I EEE 1394 Connector COM A / COM B / LPT Port USB Connector PS/2 Keyboard & PS/2 Mouse Connector JP16 (CPU Fan) JP15 (Power Fan) JP2 (System Fan) ATX Power USB 2 Connector...
  • Page 14: Cpu Speed Setup

    6VX7-1394 Motherboard CPU Speed Setup The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the system bus speed (SW1) and change the DIP switch (SW2) selection to set up the CPU speed for 300 - 733MHz processor.
  • Page 15 For Auto Jumper setting: Note: 1. If you use 66, 100, 133 MHz CPU, we recommend you to set up your system speed to “Auto” value. 2. We don’t recommend you to set up your system speed to 75,83,112, 124, 140,150 MHz because these frequencies are not the standard specifications for CPU, Chipset and most of the peripherals.
  • Page 16 6VX7-1394 Motherboard Celeron 333 / 66MHz FSB Celeron 366 / 66MHz FSB Celeron 400 / 66MHz FSB...
  • Page 17 Celeron 433 / 66MHz FSB Celeron 466 / 66 MHz FSB Celeron 500 / 66 MHz FSB CPU Speed Setup...
  • Page 18 6VX7-1394 Motherboard Celeron 533 / 66 MHz FSB Celeron 566 / 66 MHz FSB 10. Cyrix Joshua 300 / 100 MHz FSB (Optional)
  • Page 19 11. Pentium ® !!! 500 / 100MHz FSB 12. Pentium ® !!! 550 / 100MHz FSB ® 13. Pentium !!! 600 / 100MHz FSB CPU Speed Setup...
  • Page 20 6VX7-1394 Motherboard 14. Pentium ® !!! 650 / 100MHz FSB 15. Pentium ® !!! 700 / 100MHz FSB 16. Pentium ® !!! 533 / 133MHz FSB...
  • Page 21 17. Pentium ® !!! 600 / 133MHz FSB 18. Pentium ® !!! 667 / 133MHz FSB 19. Pentium ® !!! 733 / 133MHz FSB CPU Speed Setup...
  • Page 22: Connectors

    6VX7-1394 Motherboard Connectors J13/J14/J15 : I EEE 1394 Connector COM A / COM B / LPT Port Pin No. Definition TPB- TPB+ TPA- TPA+ LPT PORT COM A COM B...
  • Page 23: Usb Connector

    USB Connector PS/2 Keyboard & PS/2 Mouse Connector Connectors Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ 1 2 3 4 PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock...
  • Page 24: Jp16: Cpu Fan

    6VX7-1394 Motherboard JP16: CPU Fan JP15: Power Fan Pin No. Definition +12V SENSE Pin No. Definition +12V...
  • Page 25: Jp2: System Fan

    JP2: System Fan ATX Power Pin No. Definition +12V SENSE Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Connectors...
  • Page 26: Usb 2 Connector

    6VX7-1394 Motherboard USB 2 Connector IR Connector Pin No. Definition USB DT2- USB DT2+ USB DT3+ USB DT3- PIN No. Definition VCC(+5V) IR data input IR data output...
  • Page 27: Floppy Port

    Connectors Floppy Port RED LINE IDE1 (Primary), IDE2(Secondary) Port RED LINE IDE 1 IDE 2...
  • Page 28: J3 (Ring Power On)

    6VX7-1394 Motherboard J3: Ring Power On (Internal Modem Card Wake Up) J1: Wake On LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 29: Front Usb Port [Optional]

    JP5: STR LED Connector & LED1: DIMM LED Front USB Port (Optional) Connectors STR LED Connector External DIMM LED Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 30: J11: Sm Bus

    6VX7-1394 Motherboard J11: SM BUS Pin No. Definition SMB CLK SMB DATA...
  • Page 31: Panel And Jumper Definition

    6VX7-1394 Motherboard Panel And Jumper Definition J2: For 2X11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P−P−(Power LED) PW (Soft Power Connector) P+ P − P − S P K Open: Normal Operation Close: Entering Green Mode...
  • Page 32: Jp1 (Clear Cmos Function)

    6VX7-1394 Motherboard JP1: Clear CMOS Function(Optional) JP11: STR Enable Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS Pin No. Definition Open STR Disabled (Default) Close STR Enabled...
  • Page 33: Jp19: Cyrix Cpu Turbo Function (Optional)

    JP19: Cyrix CPU Turbo Function (Optional) JP9: USB Device Wake up Selection (Optional) (If you want to use “USB KB Wakeup from S3~S5” function, you have to set the BIOS setting “USB KB Wakeup from S3~S5” enabled, and the jumper “JP9” enabled). *(Power on the computer and as soon as memory counting starts, press <Del>.
  • Page 34: Jp23: Case Open

    6VX7-1394 Motherboard JP23: Case Open JP22: BIOS Flash ROM Write Protect (Optional) Pin No. Definition Signal Pin No. Definition Close BIOS Write Disabled BIOS Write Enabled Open (Default) Please set Jumper JP22 to “Open” to enabled BIOS write function when you update new BIOS or new device.
  • Page 35: Jp30: Over Voltage Cpu Speed Up (Optional)

    JP30: Over Voltage CPU Speed Up (Optional) J12: Front Panel Jumper (Optional) Panel and Jumper Definition Pin No. Definition 1-2 close 3-4 close 5-6 close 7-8 close 9-10 close Normal Pin No. Definition HD LED+ GN LED+ HD LED- PWR LED+ RESET SW Soft ON/OFF 10,12...
  • Page 36: Jp24: Recovery/Normal

    6VX7-1394 Motherboard JP24: Recovery/Normal BAT1: Battery Pin No. Definition Close Recovery Open Normal Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 37: Performance List

    Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •...
  • Page 38: Block Diagram

    6VX7-1394 Motherboard Block Diagram AGP 2X/4X PGA 370 CPU AGP Bus VT82C694X Ultra DMA 33/ATA66 IDE Ports PCI Bus ISA Bus IDE Bus VT82C686A IEEE 1394 Port Slot USB Port 14.318MHz 3.3V DIMM DIMM Sockets Host Bus ICS 9248DF-39 33 MHz 33 MHz 24MHz 48MHz...
  • Page 39: Suspend To Ram Installation

    Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 40 6VX7-1394 Motherboard Step 2: (If you want to use STR Function, please set jumper JP11 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ Type : S3 / STR”.
  • Page 41 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” Choose the “Stand by”...
  • Page 42 6VX7-1394 Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 43 C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are six ways to “wake up”...
  • Page 44 6VX7-1394 Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B. Your SDRAM must be PC-100 compliant. 2.
  • Page 45: Memory Installation

    Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 46: Page Index For Bios Setup

    6VX7-1394 Motherboard Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Setup Supervisor Password / User Password IDE HDD Auto Detection Save to CMOS and Exit Exit Without Saving...
  • Page 47: Entering Setup

    BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 48: Getting Help

    6VX7-1394 Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 49 • Chipset Features Setup This setup page includes all the items of chipset special features. • Power Management Setup This setup page includes all the items of Green function features. • PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. •...
  • Page 50: Standard Cmos Setup

    6VX7-1394 Motherboard Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 51 • Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. • IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 52: Boot Sector Virus Protection

    6VX7-1394 Motherboard • Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 53: Bios Features Setup

    BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device :Floppy 2nd Boot Device :IDE-0 3rd Boot Device :CDROM S.M.A.R.T for Hard Disks :Disabled BootUp Num-Lock Floppy Drive Seek :Disabled Password Check :Setup...
  • Page 54: Password Check

    6VX7-1394 Motherboard • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. • Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.
  • Page 55: Top Performance

    Chipset Features Setup AMIBIOS SETUP –CHIPSET FEATURE CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *** DRAM Timing *** Top Performance :Disabled SDRAM Timing by SPD :Disabled SDRAM CAS# Latency DRAM Frequency :Auto C2P Concurrency & Master :Enabled DRAM Integrity Mode :Disabled...
  • Page 56: Dram Integrity Mode

    6VX7-1394 Motherboard • C2P Concurrency & Master Enabled Enabled C2P Concurrency & Master. (Default Value) Disabled Disabled C2P Concurrency & Master. • DRAM Integrity Mode For 72 bit ECC type DIMM Modle. Disabled Normal Setting. (Default Value) • AGP Mode Set AGP Mode is 4X.
  • Page 57: Usb Legacy Support

    • USB Legacy Support Keyboard Set USB Legacy Support Keyboard. Keyb+Mouse Set USB Legacy Support Keyboard +Mouse. Disabled USB Legacy Support Function. (Default Value) Disabled BIOS Setup...
  • Page 58: Video Power Down Mode

    6VX7-1394 Motherboard Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep type :S1/POS USB KB Wakeup From S3~S5 :Disabled Video Power Down Mode :Stand By Hard Disk Power Down Mode :Stand By Suspend Time Out(Minute) :Disabled...
  • Page 59: Modem Use Irq

    • Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
  • Page 60 6VX7-1394 Motherboard • Modem Ring on/Wake on LAN Disabled Disabled Modem Ring on/Wake on LAN. Enabled Enabled Modem Ring on/Wake on LAN. (Default Value) • PME Event Wake up Disabled Disabled PME Event Wake up function. Enabled Enabled PME Event Wake up function. (Default Value) •...
  • Page 61: Reset Configuration Data

    PnP/PCI Configurations AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Reset Configuration Data VGA Boot From :AGP PCI VGA Palette Snoop :Disabled DMA Channel 0 :PnP DMA Channel 1 :PnP DMA Channel 3 :PnP...
  • Page 62 6VX7-1394 Motherboard • DMA Channel (0,1,3,5,6,7) The resource is used by PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA). • IRQ (3,4,5,7, 9,10,11,14,15) PCI/PnP The resource is used by PCI/PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA).
  • Page 63: Power Management Setup

    Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load BIOS Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit ↑↓→←...
  • Page 64: Load Setup Defaults

    6VX7-1394 Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load SETUP Defaults (Y/N)? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit ↑↓→←...
  • Page 65: Integrated Peripherals

    Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE :Both OnBoard FDC :Auto OnBoard Serial Port 1 :Auto OnBoard Serial Port 2 :Auto Serial Port 2 Mode :Normal Duplex Mode :N/A OnBoard Parallel Port :Auto Parallel Port Mode...
  • Page 66: Onboard Serial Port 2

    6VX7-1394 Motherboard • OnBoard Serial Port 2 Auto BIOS will automatically setup the port 2 address. (Default Value) 3F8/COM1 Enable Onboard Serial port 2 and address is 3F8. 2F8/COM2 Enable Onboard Serial port 2 and address is 2F8. 3E8/COM3 Enable Onboard Serial port 2 and address is 3E8. 2E8/COM4 Enable Onboard Serial port 2 and address is 2E8.
  • Page 67 BIOS Setup...
  • Page 68: Parallel Port Irq

    6VX7-1394 Motherboard • Parallel Port IRQ Set Parallel Port IRQ is 7. Auto Set Auto to parallel Port IRQ DMA Channel. (Default Value) Set Parallel Port IRQ is 5. • OnBoard AC’97 Audio Auto Set AC’97 Audio to Auto (Default Value). Disabled Disabled AC’97 Audio.
  • Page 69 Hardware Monitor AMIBIOS SETUP –HARDWARE MONITOR ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. :65°C/149°F Current CPU Temp. :36°C/96°F Current System Temp. :28°C/82°F Case Status :Closed Current CPU Fan Speed :5487 RPM Current System Fan Speed :0 RPM Vcore :2.075V...
  • Page 70 6VX7-1394 Motherboard • Current CPU Temp. (°C / °F) Detect CPU Temperature automatically. • Current System Tem. (°C / °F) Detect System Temperature automatically. • Case Status If the case is closed, “Case Status” will show “Closed”. If the case have been opened, “Case Opened” will show “Open”. •...
  • Page 71: Hardware Monitor Setup

    Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 72: Ide Hdd Auto Detection

    6VX7-1394 Motherboard IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Thu Feb 24, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed...
  • Page 73: Save To Cmos And Exit

    Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION SAVE to CMOS and EXIT(Y/N)? Y LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit ↑↓→←...
  • Page 74: Exit Without Saving

    6VX7-1394 Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.21 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Quit without saving (Y/N) ? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit ↑↓→←...
  • Page 76: Appendix

    6VX7-1394 Motherboard Appendix Appendix A: VIA Series VT82C686A Chipsets Driver Installation A. VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 77 6.Click “Next”. 8.Click “Next”. (11) Appendix 7.Click “Next”. 9.Click “Next”. (10) 10.Click “Finish” to Restart Computer. (12)
  • Page 78 6VX7-1394 Motherboard B. Hardware Monitor: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Hardware Monitor” item. 2.Click 4.Click “Next” to Finish. 3.Click “Next”.
  • Page 79 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing>. Once the process is finished, reboot the system. Note: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file. Appendix...
  • Page 80 6VX7-1394 Motherboard Appendix C: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting...
