6VX

TABLE OF CONTENTS

1.
1.1. PREFACE ...................................................................................................... 1-1
1.2. KEY FEATHERS............................................................................................ 1-1
1.3. PERFORMANCE LIST .................................................................................. 1-2
1.4. BLOCK DIAGRAM......................................................................................... 1-3
1.5. INTRODUCE THE PENTIUM
1.6. WHAT IS AGP .............................................................................................. 1-6
2.
2.1. HARDWARE .................................................................................................. 2-1
2.2. SOFTWARE................................................................................................... 2-2
2.3. ENVIRONMENT ............................................................................................ 2-2
3.
3.1. UNPACKING.................................................................................................. 3-1
3.2. MAINBOARD LAYOUT ................................................................................. 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS.......................... 3-2
3.4. DRAM INSTALLATION ................................................................................. 3-5
3.5. CPU SPEED SETUP ..................................................................................... 3-5
3.6. CMOS RTC & ISA CFG CMOS SRAM......................................................... 3-6
3.7. SPEAKER CONNECTOR INSTALLATION .................................................. 3-7
3.9. POWER LED CONNECTOR INSTALLATION ............................................. 3-7
3.10. IDE & ATAPI DEVICE INSTALLATION ...................................................... 3-7
II PROCESSOR & AGP............................. 1-4
1

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GA-6VX

Summary of Contents for Gigabyte GA-6VX

  • Page 1: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE ...................... 1-1 1.2. KEY FEATHERS.................... 1-1 1.3. PERFORMANCE LIST .................. 1-2 1.4. BLOCK DIAGRAM..................1-3 1.5. INTRODUCE THE PENTIUM II PROCESSOR & AGP......1-4 1.6. WHAT IS AGP ....................1-6 SPECIFICATION 2.1. HARDWARE ....................2-1 2.2.
  • Page 2 Table of Contents 3.11. PERIPHERAL DEVICE INSTALLATION ............ 3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION........... 3-7 BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS................... 4-1 4.3. GETTING HELP..................... 4-2 4.3.1. Main Menu ..................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu....... 4-2 4.4.

  • Page 3: Introduction

    INTRODUCTION 1.1. PREFACE Welcome to use the 6VX motherboard. It is a Pentium II Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

  • Page 4: Performance List

    Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor...

  • Page 5: Block Diagram

    14.318MHz 1.4. BLOCK DIAGRAM SLOT 1 3.3V SDRAM DIMM Sockets Host Bus 66 / 66 / 100 MHz 100 MHz 33MHz 82C691 AGP Bus 66 / 66MHz 100 MHz 9148-58 33 MHz Ultra DMA/33 IDE Ports PCI Bus 33 MHz 48MHz 82C596 14.318MHz...

  • Page 6: Introduce The Pentium Ii Processor & Agp

    Introduction 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...
  • Page 7 Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...

  • Page 8: What Is Agp

    Introduction 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs.32-Bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.

  • Page 9: Specification

    SPECIFICATION 2.1. HARDWARE Pentium II processor 200 – 633 MHz. 242 pins 66 / 100MHz slot1 on board. 66/75/95/100/112/124/133 MHz system speed. SPEED 63/66/74/75/82/88 MHz AGP bus speed. (2X mode 133MHz) 31/33/37/41/44 MHz PCI-Bus speed. 8 MHz AT bus speed. 3 banks 168 pins DIMM module sockets on board.

  • Page 10: Software

    Specification Suspend mode support. GREEN FUNCTION IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. ATX Form Factor, 4 layers PCB. DIMENSION 2.2.

  • Page 11: Hardware Installation

    HARDWARE INSTALLATION 3.1. UNPACKING The main board package should contain the following: The 6VX main board. The Retention Mechanism & Attach Mount USER’ S MANUAL for main board. Cable set for IDE, Floppy devices. CD for main board Utility.(VIA Bas master IDE Driver, VIA VXD AGP Driver, VIA VIAREG Patch95 Driver, VIA Windows98 IRQ Routing) The main board contains sensitive electric components, which can be easily...

  • Page 12: Mainboard Layout

    Hardware Installation 3.2. MAINBOARD LAYOUT COM A COM B ISA 2 ISA 1 PS/2 BIOS PCI 5 PCI 4 PCI 3 PCI 2 PCI 1 Slot 1 82C691 Ring Pwr on BANK 0 BANK 1 82C596 BANK 2 BAT 1 IDE 2 FLOPPY IDE 1...
  • Page 13 JP7 : System Acceleration 1-2 short For 100MHz Turbo and other frequencies 2-3 short For 100MHz Normal Wake on LAN Connector Pin No. Function +5VSB CTRL-Signal IR: INFRARED Connector--Optional Pin No. Function IR DATA OUTPUT IR DATA INPUT POWER ¡ ] ¡ Ï ¡ ^ SB-LINK : For PCI Sound Card Connector (MNot support Creative SB- LINK PCI sound) Pin No.
  • Page 14 Hardware Installation J1 : 2*11PIN Jumper PWR P+P P HD SPKR PWR: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+) PIN 2 : cathode ( ) PIN 3 : cathode ( ) SPKR: Speaker Connector...

  • Page 15: Dram Installation

    GN: Green Function Switch Open : Normal operation Short : Entering Green Mode GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode ( ) 3.4. DRAM INSTALLATION The main board can be installed with 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 67~100 MHz for SDRAM when system bus speed is set to 66MHz.

  • Page 16: Cmos Rtc & Isa Cfg Cmos Sram

    Hardware Installation CLK RATIO X3.5 X4.5 X5.5 SDRAM JP3 M We don’ t recommend you to setup your system speed to 75, 95, 112, 124 or 133MHz because these frequencies are not the standard specifications for CPU, Chipset and most of the peripherals. Whether your system can run under 75, 95, 112, 124 or 133MHz properly will depend on your hardware configurations: CPU, SDRAM, Cards, etc.

  • Page 17: Speaker Connector Installation

    M Replace only with the same or equivalent type recommended by the manufacturer. M Dispose of used batteries according to the manufacturer’ s instructions. 3.7. SPEAKER CONNECTOR INSTALLATION There is a speaker in AT system for sound purpose. The 4 - Pins connector SPKR is used to connect speaker.
