Hanging the Printer on a Wall

To hang the printer on the wall, follow the steps below.
CAUTION:
To fix the printer securely, install the wall hanging bracket on a wall made of wood, concrete, or
metal. The thickness of the wall should be 10 mm {0.4"} or more.
Be sure to use metallic screws.
The screws on the wall side must have a pull-out strength of 150 N (15.3 kgf) or more.
1. Install 2 screws (screw diameter: 4 mm {0.16"}, head diameter: 7 to 9 mm {0.28 to
0.35"}) in the wall at an interval of 80 mm {3.15"}. Make sure the length of the screw's
body in the wall is 10 mm {0.39"} or more, and the length outside the wall is 3 to 4 mm
{0.12 to 0.16"}.
2. Remove the installed 2 screws from the printer, as shown in the illustration below.
3. Install the wall hanging bracket on the printer, and fix it using the screws removed in
Step 2.
10 TM-T82 User's Manual
7~ 9 mm
80 mm
Screws
3~ 4 mm
4 mm
10 mm or more
Wall hanging
bracket
