Motorola Solutions

WiNG 5.5

ACCESS POINT

SYSTEM REFERENCE GUIDE

Table of Contents

Summary of Contents for Motorola WiNG 5.5

Page 1 Motorola Solutions WiNG 5.5 ACCESS POINT SYSTEM REFERENCE GUIDE...
Page 3 MOTOROLA SOLUTIONS WING 5.5 ACCESS POINT SYSTEM REFERENCE GUIDE MN000160A01 Revision A October 2013...
Page 4 Motorola Solutions reserves the right to make changes to any software or product to improve reliability, function, or design. Motorola Solutions does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
Page 5: Table Of Contents
TABLE OF CONTENTS About this Guide Chapter 1, Overview 1.1 About the Motorola Solutions WiNG 5 Software ......................1-3 Chapter 2, Web User Interface Features 2.1 Accessing the Web UI ..............................2-2 2.1.1 Browser and System Requirements ........................2-2 2.1.2 Connecting to the Web UI ..........................2-2 2.2 Icon Glossary ................................2-4...
Page 6 WiNG 5.5 Access Point System Reference Guide 3.1.1.6 Wireless LAN Setup ..........................3-15 3.1.1.7 Summary And Commit Screen ........................3-19 3.1.1.8 Adopt to a controller ..........................3-20 3.1.2 Advanced Setup Wizard ...........................3-21 3.1.2.1 Network Topology Selection ........................3-24 3.1.2.2 LAN Configuration ...........................3-25 3.1.2.3 WAN Configuration ..........................3-27 3.1.2.4 Radio Configuration ..........................3-29...
Page 7 Table of Contents 5.2.6.4 IGMP Snooping ............................5-70 5.2.6.5 Quality of Service (QoS) ..........................5-72 5.2.6.6 Spanning Tree Configuration ........................5-74 5.2.6.7 Routing ..............................5-77 5.2.6.8 Dynamic Routing (OSPF) ..........................5-79 5.2.6.9 Forwarding Database ..........................5-86 5.2.6.10 Bridge VLAN ............................5-88 5.2.6.11 Cisco Discovery Protocol Configuration ....................5-93 5.2.6.12 Link Layer Discovery Protocol Configuration ..................5-94 5.2.6.13 Miscellaneous Network Configuration ....................5-95 5.2.6.14 Alias ..............................5-96...
Page 8 WiNG 5.5 Access Point System Reference Guide 5.4.5.6 Overriding the Virtual Router Redundancy Protocol (VRRP) Configuration ..........5-305 5.4.5.7 Profile Critical Resources ........................5-310 5.4.5.8 Overriding a Services Configuration .....................5-313 5.4.5.9 Overriding a Management Configuration .....................5-314 5.4.5.10 Overriding Mesh Point Configuration ....................5-318 5.4.5.11 Overriding an Advanced Configuration ....................5-328...
Page 9 Table of Contents Chapter 7, Network configuration 7.1 Policy Based Routing (PBR) ............................7-2 7.2 L2TP V3 Configuration ..............................7-8 7.3 AAA Policy ..................................7-12 7.4 AAA TACACS Policy ..............................7-22 7.5 Alias ....................................7-34 7.5.1 Network Basic Alias ............................7-34 7.5.2 Network Group Alias ............................7-37 7.5.3 Network Service Alias ............................7-40 7.6 Network Deployment Considerations ........................7-42 Chapter 8, Security Configuration...
Page 10 WiNG 5.5 Access Point System Reference Guide Chapter 11, Diagnostics 11.1 Fault Management ..............................11-2 11.2 Crash Files ................................11-6 11.3 Advanced ..................................11-7 11.3.1 UI Debugging ..............................11-7 11.3.1.1 Schema Browser ...........................11-8 11.3.2 View UI Logs ..............................11-9 11.3.3 View Sessions ...............................11-10 Chapter 12, Operations 12.1 Devices ..................................12-2...
Page 11 Table of Contents 13.2.3 Devices ................................13-19 13.2.4 AP Detection ..............................13-20 13.2.5 Wireless Clients ............................13-21 13.2.6 Device Upgrade .............................13-22 13.2.7 Wireless LANs ..............................13-24 13.2.8 Radios ................................13-25 13.2.8.1 Status ..............................13-25 13.2.8.2 RF Statistics ............................13-27 13.2.8.3 Traffic Statistics ..........................13-28 13.2.9 Mesh ................................13-29 13.2.10 Mesh Point ..............................13-30 13.2.11 SMART RF ..............................13-45 13.2.12 WIPS ................................13-50 13.2.12.1 WIPS Client Blacklist ........................13-50...
Page 12 WiNG 5.5 Access Point System Reference Guide 13.3.16 VRRP ................................13-95 13.3.17 Critical Resources ............................13-96 13.3.18 LDAP Agent Status .............................13-97 13.3.19 GRE Tunnels ..............................13-98 13.3.20 Dot1x ................................13-99 13.3.21 Network ..............................13-101 13.3.21.1 ARP Entries ............................13-101 13.3.21.2 Route Entries ...........................13-102 13.3.21.3 Bridge ..............................13-103 13.3.21.4 IGMP ..............................13-104...
Page 13 Table of Contents Appendix A, Customer Support Appendix B, Publicly Available Software B.1 General Information ..............................B-1 B.2 Open Source Software Used ............................B-2 B.3 OSS Licenses ................................B-11 B.3.1 Apache License, Version 2.0 ........................... B-11 B.3.2 The BSD License .............................. B-13 B.3.3 Creative Commons Attribution-ShareAlike License, version 3.0 ..............
Page 14 WiNG 5.5 Access Point System Reference Guide...
Page 15: About This Guide
NOTE: ES6510 is an Ethernet Switch managed by a wireless controller such as RFS4000/RFS6000/ RFS7000/NX9000/NX9500/NX9510. ES6510 does not have radios and does not provide WLAN support. This section is organized into the following: • Document Convention • Notational Conventions • Motorola Solutions Enterprise Mobility Support Center • Motorola Solutions End-User Software License Agreement...
Page 16: Notational Conventions
WiNG 5.5 Access Point System Reference Guide Document Convention The following conventions are used in this document to draw your attention to important information: NOTE: Indicates tips or special requirements. CAUTION: Indicates conditions that can cause equipment damage or data loss.
Page 17 • Software type and version number Motorola Solutions responds to calls by e-mail, telephone or fax within the time limits set forth in support agreements. If you purchased your Enterprise Mobility business product from a Motorola Solutions business partner, contact that business partner for support.
Page 18 (ii) means any modifications, enhancements, new versions and new releases of the software provided by Motorola Solutions; and (iii) may contain items of software owned by a third party supplier. The term “Software” does not include any third party software provided under separate license or third party software not licensable under the terms of this Agreement.
Page 19 5. OWNERSHIP AND TITLE 5.1 Motorola Solutions, its licensors, and its suppliers retain all of their proprietary rights in any form in and to the Software and Documentation, including, but not limited to, all rights in patents, patent applications, inventions, copyrights, trademarks, trade secrets, trade names, and other proprietary rights in or relating to the Software and Documentation.
Page 20 8.1 Unless otherwise specified in the applicable warranty statement, the Documentation or in any other media at the time of shipment of the Software by Motorola Solutions, and for the warranty period specified therein, for the first 120 days after initial shipment of the Software to the End-User Customer, Motorola Solutions warrants that the Software, when installed and/or used properly, will be free from reproducible defects that materially vary from its published specifications.
Page 21 11.4 Waiver. No waiver of a right or remedy of a Party will constitute a waiver of another right or remedy of that Party. 11.5 Assignments. Motorola Solutions may assign any of its rights or sub-contract any of its obligations under this End-User License Agreement or encumber or sell any of its rights in any Software, without prior notice to or consent of End-User Customer.
Page 22 WiNG 5.5 Access Point System Reference Guide...
Page 23: Chapter 1, Overview
CHAPTER 1 OVERVIEW Motorola Solutions’ family of WING 5.5 supported access points enable high performance with secure and resilient wireless voice and data services to remote locations with the scalability required to meet the needs of large distributed enterprises. AP6511, AP6521, AP6522, AP6532, AP6562, AP7131, AP7161, AP7181, AP8132, AP8232 access points and ES6510 model ethernet switch can now use WiNG 5 software as its onboard operating system.
Page 24 1 - 2 WiNG 5.5 Access Point System Reference Guide is optimized to prevent wired congestion and wireless congestion. Traffic flows dynamically, based on user and application, and finds alternate routes to work around network choke points. NOTE: This guide describes the installation and use of the WiNG 5 software designed specifically for AP6511, AP6521, AP6522, AP6532, AP6562, AP7131, AP7161, AP7181, AP8132, AP8232 access points and ES6510 model ethernet switch.
Page 25: About The Motorola Solutions Wing 5 Software
Deploying a new WiNG 5 access point managed network does not require the replacement of existing Motorola Solutions access points. WiNG 5 enables the simultaneous use of existing architectures from Motorola Solutions and other vendors, even if those other architectures are centralized models.
Page 26 1 - 4 WiNG 5.5 Access Point System Reference Guide...
Page 27: Chapter 2, Web User Interface Features
CHAPTER 2 WEB USER INTERFACE FEATURES The access point’s resident user interface contains a set of features specifically designed to enable either Virtual Controller AP, Standalone AP or Adopt to Controller functionality. In Virtual Controller AP mode, an access point can manage up to 24 other access points of the same model and share data amongst managed access points.
Page 28: Accessing The Web Ui
1 GB of RAM for the UI to display and function properly. The Web UI is based on Flex, and does not use Java as the underlying UI framework. Motorola Solutions recommends using a resolution of 1280 x 1024 pixels for using the GUI.
Page 29 2 - 3 Figure 2-1 Access Point Web UI Login screen 9. Enter the default username admin in the Username field. 10. Enter the default password motorola in the Password field. 11. Select the Login button to load the management interface.
Page 30: Icon Glossary
2 - 4 WiNG 5.5 Access Point System Reference Guide 2.2 Icon Glossary The access point interface utilizes a number of icons designed to interact with the system, gather information from managed devices and obtain status. This chapter is a compendium of the icons used, and is organized as follows: •...
Page 31: Dialog Box Icons
Web User Interface Features 2 - 5 Create new policy – Select this icon to create a new policy. Policies define different configuration parameters that can be applied to device configurations, and device profiles. Edit policy – Select this icon to edit an existing configuration item or policy. To edit a policy, select the policy and this icon.
Page 32: Status Icons
2 - 6 WiNG 5.5 Access Point System Reference Guide 2.2.4 Status Icons Icon Glossary These icons define device status, operations on the wireless controller, or any other action that requires a status being returned to the user. Fatal Error – States there is an error causing a managed device to stop functioning.
Page 33 Web User Interface Features 2 - 7 Radio QoS Policy – Indicates a QoS policy configuration has been impacted. AAA Policy – Indicates an Authentication, Authorization and Accounting (AAA) policy has been impacted. AAA policies define RADIUS authentication and accounting parameters. Association ACL –...
Page 34 2 - 8 WiNG 5.5 Access Point System Reference Guide Advanced WIPS Policy – States the conditions of an advanced WIPS policy have been invoked. WIPS prevents unauthorized access to the system by checking for and removing rogue access points and wireless clients.
Page 35: Configuration Objects
Web User Interface Features 2 - 9 Mesh QoS Policy – Indicates a mesh quality of service policy is being applied. This policy ensures that each mesh point in the network receives a fair share of overall bandwidth for its use. Virtual Controller APs –...
Page 36: Configuration Operation Icons
2 - 10 WiNG 5.5 Access Point System Reference Guide 2.2.7 Configuration Operation Icons Icon Glossary The following icons are used to define configuration operations: Revert – When selected, any unsaved changes are reverted back to their last saved configuration.
Page 37: Administrative Role Icons
Web User Interface Features 2 - 11 2.2.9 Administrative Role Icons Icon Glossary The following icons identify the different administrative roles allowed on the system: Superuser – Indicates superuser privileges. A superuser has complete access to all configuration aspects of the access point to which they are connected. System –...
Page 38 2 - 12 WiNG 5.5 Access Point System Reference Guide RF Domain - This icon indicates a RF Domain. RF Domains allow administrators to assign configuration data to multiple devices deployed in a common coverage area, such as in a floor, a building or a site. Each RF Domain also contains policies that can determine a Smart RF or WIPS configuration.
Page 39: Chapter 3, Quick Start
CHAPTER 3 QUICK START Access points can utilize an initial setup wizard to streamline the process of initially accessing the wireless network. The wizard defines the access point’s operational mode, deployment location, basic security, network and WLAN settings. For instructions on how to use the initial setup wizard, see Using the Initial Setup Wizard on page 3-2.
Page 40: Using The Initial Setup Wizard
3 - 2 WiNG 5.5 Access Point System Reference Guide 3.1 Using the Initial Setup Wizard Quick Start Once the access point is installed and powered on, complete the following steps to get the access point up and running and access management functions: 1.
Page 41 Quick Start 3 - 3 Figure 3-2 Initial Setup Wizard NOTE: The Initial Setup Wizard displays the same pages and content for each access point model supported. The only difference being the number of radios configurable by model, as an AP7131 model can support up to three radios, AP6522, AP6532, AP6562, AP8132, AP8232 and AP7161 models support two radios and AP6511 and AP6521 models support a single radio.
Page 42: Typical Setup Wizard
3 - 4 WiNG 5.5 Access Point System Reference Guide Figure 3-3 Initial Setup Wizard - Navigation Panel - Typical Setup Wizard A green check mark to the left of an item in the Navigation Panel defines the listed task as having its minimum required configuration parameters set correctly.
Page 43: Typical Setup Wizard
Quick Start 3 - 5 6. Select Save/Commit within each page to save the updates made to that page's configuration. Select Next to proceed to the next page listed in the Navigation Panel. Select Back to revert to the previous screen without saving your updates. NOTE: While you can navigate to any page in the navigation panel, you cannot complete the Initial Setup Wizard until each task in the Navigation Panel has a green check mark.
Page 44 Mode on page 3-9. NOTE: If designating the access point as a Standalone AP, Motorola Solutions recommends the access point’s UI be used exclusively to define its device configuration, and not the CLI. The CLI provides the ability to define more than one profile and the UI does not.
Page 45 Quick Start 3 - 7 • Adopted to Controller - Select this option when deploying the access point as a controller managed (Dependent mode) access point. Selecting this option closes the Initial AP Setup Wizard. An adopted access point obtains its configuration from a profile stored on its managing controller.
Page 46: Virtual Controller Ap Mode
3 - 8 WiNG 5.5 Access Point System Reference Guide 3.1.1.1 Virtual Controller AP Mode Using the Initial Setup Wizard When more than one access point is deployed, a single access point can function as a Virtual Controller AP. Up to 24 access points can be connected to, and managed by a single Virtual Controller AP of the same access point model.
Page 47: Standalone Mode
In the Standalone mode, the access point is not adopted to a wireless controller. Select this option to deploy this access point as an autonomous fat access point. CAUTION: If designating the access point as a Standalone AP, Motorola Solutions recommends the access point’s UI be used exclusively to define its device configuration, and not the CLI.
Page 48: Network Topology Selection
3 - 10 WiNG 5.5 Access Point System Reference Guide 3.1.1.3 Network Topology Selection Typical Setup Wizard Use the Network Topology screen to define how the access point manages network traffic. The available modes are: Figure 3-6 Initial Setup Wizard - Network Topology screen for Typical Setup Wizard •...
Page 49: Lan Configuration
Quick Start 3 - 11 3.1.1.4 LAN Configuration Typical Setup Wizard Use the LAN Configuration screen to set the access point's DHCP and LAN network address configuration. Figure 3-7 Initial Setup Wizard - LAN Configuration screen for Typical Setup Wizard 1.
Page 50 3 - 12 WiNG 5.5 Access Point System Reference Guide option is not selected, a primary and secondary DNS resource must be specified. DNS forwarding is useful when a request for a domain name is made but the DNS server, responsible for converting the name into its corresponding IP address, cannot locate the matching IP address.
Page 51: Wan Configuration
Quick Start 3 - 13 3.1.1.5 WAN Configuration Typical Setup Wizard NOTE: This option is only available when Router Mode is selected in the Network Topology screen. Use the WAN Setting screen to define network address settings for the WAN interface. The WAN interface connects the access point to a wired local area network or backhaul.
Page 52: Wireless Lan Setup
3 - 14 WiNG 5.5 Access Point System Reference Guide • Enable NAT on the WAN Interface – Select the option to enable Network Address Translation on the selected GE interface. 2. Select Next. The Typical Setup Wizard displays the...
Page 53 Quick Start 3 - 15 3.1.1.6 Wireless LAN Setup Typical Setup Wizard A Wireless Local Area Network (WLAN) is a data-communications system and local area network that flexibly extends the functionality of a wired LAN. A WLAN links two or more computers or devices using spread-spectrum or OFDM modulation based technology.
Page 54 3 - 16 WiNG 5.5 Access Point System Reference Guide • Captive Portal Authentication and No Encryption – Configures a network that uses a RADIUS server to authenticate users before allowing them on to the network. Once on the network, no encryption is used for the data being transmitted through the network.
Page 55 Quick Start 3 - 17 3.1.1.6.1 RADIUS Server Configuration Wireless LAN Setup Use the RADIUS Server Configuration screen to configure the users for the onboard RADIUS server. Use the screen to add, modify and remove RADIUS users. Figure 3-10 Initial Setup Wizard - RADIUS Server Configuration screen for Typical Setup Wizard Use the Add User button to add a new RADIUS user.
Page 56 3 - 18 WiNG 5.5 Access Point System Reference Guide Figure 3-11 Initial Setup Wizard - RADIUS Server Configuration - Add User screen for Typical Setup Wizard 1. Use the Add User dialog to provide user information to add to the RADIUS server user database.
Page 57: Summary And Commit Screen
Quick Start 3 - 19 3.1.1.7 Summary And Commit Screen Typical Setup Wizard The Summary And Commit screen displays a complete overview of the configurations made in the previous screens. There is no user intervention or additional settings required. The Summary and Commit screen is an additional means of validating the configuration before it is deployed.
Page 58: Adopt To A Controller
3 - 20 WiNG 5.5 Access Point System Reference Guide 3.1.1.8 Adopt to a controller Using the Initial Setup Wizard Adopted to Controller is the default behavior of the access point. When the access point is switched on for the first time, it looks for a wireless controller on the default subnet and that runs the same WiNG firmware version and automatically adopts to it.
Page 59: Advanced Setup Wizard
Quick Start 3 - 21 3.1.2 Advanced Setup Wizard Using the Initial Setup Wizard Advanced Setup is the recommended wizard for users who want more control on how the access point is configured beyond minimum default settings. This wizard provides additional radio and system information settings. The Advanced Setup wizard consists of the following: •...
Page 60 Standalone Mode on page 3-9. NOTE: If designating the access point as a Standalone AP, Motorola Solutions recommends the access point’s UI be used exclusively to define its device configuration, and not the CLI. The CLI provides the ability to define more than one profile and the UI does not.
Page 61 Quick Start 3 - 23 on page 3-35. 4. Select the Next button to start configuring the access point in the selected mode. If the Access Point Type is Virtual Controller AP or Standard AP, see Network Topology Selection on page 3-24.
Page 62: Network Topology Selection
3 - 24 WiNG 5.5 Access Point System Reference Guide 3.1.2.1 Network Topology Selection Advanced Setup Wizard Use the Network Topology screen to define how the access point manages network traffic. The available modes are: Figure 3-15 Initial Setup Wizard - Access Point Mode screen for Advanced Setup Wizard •...
Page 63: Lan Configuration
Quick Start 3 - 25 3.1.2.2 LAN Configuration Advanced Setup Wizard Use the LAN Configuration screen to configure the parameters required for setting a Local Area Network (LAN) on the access point. Figure 3-16 Initial Setup Wizard - LAN Configuration screen for Advanced Setup Wizard 1.
Page 64 3 - 26 WiNG 5.5 Access Point System Reference Guide • DNS Forwarding - Select this option to allow a DNS server to translate domain names into IP addresses. If this option is not selected, a primary and secondary DNS resource must be specified. DNS forwarding is useful when a request for a domain name is made but the DNS server, responsible for converting the name into its corresponding IP address, cannot locate the matching IP address.
Page 65: Wan Configuration
Quick Start 3 - 27 3.1.2.3 WAN Configuration Advanced Setup Wizard NOTE: This option is only available when Router Mode is selected in the Network Topology screen of the Advanced Setup Wizard. The Advanced Setup Wizard displays the WAN Setting screen to define DHCP and network address information for the WAN interface.
Page 66: Radio Configuration
3 - 28 WiNG 5.5 Access Point System Reference Guide • Enable NAT on the WAN Interface – Select the option to enable Network Address Translation on the selected GE interface. 2. Select Next. The Advanced Setup Wizard displays the Radio Configuration screen to set the access point's radios.
Page 67 Quick Start 3 - 29 3.1.2.4 Radio Configuration Advanced Setup Wizard Use the Radio Configuration screen to define radio support for the 2.4 GHz radio band, 5.0 GHz radio band or set the radio as a dedicated sensor. NOTE: The Radio Configuration screen displays separate configurable fields for each access point radio.
Page 68 3 - 30 WiNG 5.5 Access Point System Reference Guide 2.4 GHz or 5.0 GHz band. 1 dBm is the default setting. • Channel Mode - Select either Random, Best or Static. Select Random for use with a 802.11a/n radio. To comply with Dynamic Frequency Selection (DFS) requirements in the European Union, the 802.11a/n radio uses a randomly selected...
Page 69: Wireless Lan Setup
Quick Start 3 - 31 3.1.2.5 Wireless LAN Setup Advanced Setup Wizard A Wireless Local Area Network (WLAN) is a data-communications system and wireless local area network that flexibly extends the functionality of a wired LAN. A WLAN links two or more computers or devices using spread-spectrum or OFDM modulation based technology.
Page 70 3 - 32 WiNG 5.5 Access Point System Reference Guide users before allowing them on to the network. Once on the network, no encryption is used for the data transmitted through the network. Select this option to use a Web page (either internally or externally hosted) to authenticate users before access is granted to the network.
Page 71: System Information
Quick Start 3 - 33 3.1.2.6 System Information Advanced Setup Wizard Use the System Information screen to define the device’s location, contact information for an administrator, and the country where this access point is deployed. Figure 3-20 Initial Setup Wizard - System Information screen for the Advanced Setup Wizard •...
Page 72: Summary And Commit Screen
3 - 34 WiNG 5.5 Access Point System Reference Guide 3.1.2.7 Summary And Commit Screen Advanced Setup Wizard The Summary And Commit screen displays an overview of the updates made using the Advanced Setup Wizard. There is no user intervention or additional settings required. This screen is an additional means of validating the configuration before it is deployed.
Page 73: Adopt To A Controller
Quick Start 3 - 35 3.1.2.8 Adopt to a controller Advanced Setup Wizard When the access point is powered on for the first time, it looks for a wireless controller on the default subnet running the same firmware version and automatically adopts to it. When Adopted to Controller is selected, further configuration settings are displayed in the same screen.
Page 74 3 - 36 WiNG 5.5 Access Point System Reference Guide...
Page 75: Chapter 4, Dashboard
CHAPTER 4 DASHBOARD The dashboard allows network administrators to review and troubleshoot the operation of the devices comprising the access point managed network. Use the dashboard to review the current network topology, assess the network’s component health and diagnose problematic device behavior. By default, the Dashboard screen displays the System Dashboard, which is the top level in the device hierarchy.
Page 76: Dashboard Conventions
4 - 2 WiNG 5.5 Access Point System Reference Guide 4.1 Dashboard Dashboard The Dashboard screen displays device information organized by device association and inter-connectivity between an access point and connected wireless clients. To review dashboard information: 1. Select Dashboard. Expand the...
Page 77: Health
Dashboard 4 - 3 4.1.1.1 Health Dashboard Conventions Health tab displays performance and utilization data for the access point managed network. Figure 4-2 Dashboard - Health tab For more information see: • Device Details • Radio RF Quality Index • Radio Utilization Index •...
Page 78 4 - 4 WiNG 5.5 Access Point System Reference Guide Figure 4-3 Dashboard - Health tab - Device Details field Device Details field displays the name assigned to the selected access point, factory encoded MAC address, primary IP address, model type, RF Domain, software version, uptime, CPU and RAM information and system clock. Use this data to determine whether a software upgrade is warranted, or if the system clock needs adjustment.
Page 79 Dashboard 4 - 5 Periodically select Refresh (at the bottom of the screen) to update the RF quality data. 4.1.1.1.3 Radio Utilization Index Dashboard Conventions Radio Utilization Index displays how efficiently the RF medium is used by the access point. Traffic utilization is defined as the percentage of throughput relative to the maximum possible throughput.
Page 80 4 - 6 WiNG 5.5 Access Point System Reference Guide 1. The Client RF Quality Index displays the following: Worst 5 Lists the worst 5 performing client radios connected to the access point. The RF Quality Index measures the overall effectiveness of the RF environment as a percentage. Its a function of the connect rate in both directions, as well as the retry rate and the error rate.
Page 81: Inventory
Dashboard 4 - 7 4.1.1.2 Inventory Dashboard Conventions Inventory tab displays information relative to the devices managed by the selected access point. The Inventory screen affords a system administrator an overview of the number and state of managed devices. The screen contains links to display more granular data specific to a radio.
Page 82 4 - 8 WiNG 5.5 Access Point System Reference Guide 4.1.1.2.1 Radio Types Inventory Radio Types field displays the total number and types of radios managed by the selected access point. Figure 4-8 Dashboard - Inventory tab - Radio Types field...
Page 83 Dashboard 4 - 9 Figure 4-10 Dashboard - Inventory tab - Wireless Clients field Information within the Wireless Clients field is presented in two tables. The first table lists the total number of wireless clients managed by this access point. The second table lists an ordered ranking of radios based on their supported client count. Use this information to assess if an access point managed radio is optimally deployed in respect to its radio type and intended client support requirements.
Page 84: Network View
4 - 10 WiNG 5.5 Access Point System Reference Guide 4.2 Network View Dashboard Network View displays device topology association between a selected access point, its RF Domain and its connected clients. Access points and clients can be selected and viewed using various color schemes in respect to neighboring access points, connected devices and performance criteria.
Page 85: Network View Display Options
Dashboard 4 - 11 Figure 4-13 Network View - System Browser 4.2.1 Network View Display Options Network View 1. Select the blue Options link right under the Network View banner to display a menu for different device interaction display options. Figure 4-14 Network View - Display Options 2.
Page 86: Device Specific Information
4 - 12 WiNG 5.5 Access Point System Reference Guide and error rates. Quality results include: Red (Bad Quality), Orange (Poor Quality), Yellow (Fair Quality) and Green (Good Quality). • Vendor – Displays the device manufacturer. • Band – Select this option to filter based on the 2.4 or 5.0 GHz radio band of connected clients. Results include: Yellow (2.4 GHz radio band) and Blue (5.0 GHz radio band).
Page 87: Chapter 5, Device Configuration
CHAPTER 5 DEVICE CONFIGURATION Access points can either be assigned unique configurations to support a particular deployment objective or have an existing RF Domain or profile configuration modified (overridden) to support a requirement that deviates its configuration from the configuration shared by its peer access points. Refer to the following to set an access point’s sensor functionality, Virtual Controller AP designation, and license and certificate usage configuration: •...
Page 88: Rf Domain Configuration
5 - 2 WiNG 5.5 Access Point System Reference Guide 5.1 RF Domain Configuration Device Configuration An access point’s configuration consists of numerous elements including a RF Domain, WLAN and device specific settings. RF Domains are used to assign regulatory, location and relevant policies to access points of the same model. For example, an AP6532 RF Domain can only be applied to another AP6532 model.
Page 89 Device Configuration 5 - 3 4. Define the following Basic Configuration values for the access point RF Domain: Location Assign the physical location of the RF Domain. This name could be as specific as the floor of a building, or as generic as an entire site. The location defines the physical area where a common set of access point configurations are deployed and managed by the RF Domain policy.
Page 90: Rf Domain Sensor Configuration
In addition to dedicated Motorola Solutions AirDefense sensors, an access point radio can function as a sensor and upload information to a dedicated WIPS server (external to the access point). Unique WIPS server configurations can be used to ensure a WIPS server configuration is available to support the unique data protection needs of a RF Domain.
Page 91: Rf Domain Alias Configuration
Device Configuration 5 - 5 9. Select to save the changes to the AirDefense WIPS configuration, or select Reset to revert to the last saved configuration. 5.1.2 RF Domain Alias Configuration RF Domain Configuration With large deployments, the configuration of remote sites utilizes a set of shared attributes, of which a small set of attributes are unique for each location.
Page 92: Network Basic Alias
5 - 6 WiNG 5.5 Access Point System Reference Guide 5.1.2.1 Network Basic Alias RF Domain Configuration A basic alias is a set of configurations that consist of VLAN, Host, Network and Address Range alias configurations. VLAN configuration is a configuration for optimal VLAN re-use and management for local and remote deployments. A host alias configuration is for a particular host device’s IP address.
Page 93 Device Configuration 5 - 7 Use the VLAN Alias field to create unique aliases for VLANs that can be used at different deployments. For example, if a named VLAN is defined as 10 for the central network, and the VLAN is set at 26 at a remote location, the VLAN can be overridden at the deployment location with an alias.
Page 94 5 - 8 WiNG 5.5 Access Point System Reference Guide 8. Select + Add Row to define Network Alias settings: Use the Network Alias field to create aliases for IP networks that can be utilized at different deployments. For example, if a central network ACL defines a network as 192.168.10.0/24, and a remote location’s network range is 172.16.10.0/24,...
Page 95: Network Group Alias
Device Configuration 5 - 9 5.1.2.2 Network Group Alias RF Domain Configuration A network group alias is a set of configurations that consist of host and network configurations. Network configurations are complete networks in the form 192.168.10.0/24 or IP address range in the form 192.168.10.10-192.168.10.20. Host configuration is in the form of single IP address, 192.168.10.23.
Page 96 5 - 10 WiNG 5.5 Access Point System Reference Guide 5. Select Edit to modify the attributes of an existing policy or Delete to remove obsolete policies from the list of those available. Select to create a new Network Group Alias.
Page 97: Network Service Alias
Device Configuration 5 - 11 9. Select when completed to update the network group alias rules. Select Reset to revert the screen back to its last saved configuration. 5.1.2.3 Network Service Alias RF Domain Configuration A network service alias is a set of configurations that consist of protocol and port mappings. Both source and destination ports are configurable.
Page 98 5 - 12 WiNG 5.5 Access Point System Reference Guide Figure 5-7 RF Domain - Network Service Alias Add screen 6. If adding a new Network Service Alias, provide it a name up to 32 characters. NOTE: The Network Service Alias Name always starts with a dollar sign ($).
Page 99: System Profile Configuration
Device Configuration 5 - 13 5.2 System Profile Configuration Device Configuration An access point profile enables an administrator to assign a common set of configuration parameters and policies to access points of the same model. Profiles can be used to assign common or unique network, wireless and security parameters to across a large, multi segment, site.
Page 100: General Profile Configuration
5 - 14 WiNG 5.5 Access Point System Reference Guide 5.2.1 General Profile Configuration System Profile Configuration An access point profile requires unique clock synchronization settings as part of its general configuration. Network time protocol (NTP) manages time and/or network clock synchronization within the access point managed network.
Page 101: Profile Radio Power
Device Configuration 5 - 15 Version Use the spinner control to specify the version number used by this NTP server resource. The default setting is 0. 5. Use the RF Domain Manager field to configure how this access point behaves in standalone mode. Set the following parameters: Capable Select to enable this access point to act as a RF Domain Manager in a particular RF...
Page 102 5 - 16 WiNG 5.5 Access Point System Reference Guide Figure 5-9 Profile - Power screen 5. Use the Power Mode drop-down menu to set the Power Mode Configuration on this NOTE: Single radio model access points always operate using a full power configuration.
Page 103: Profile Adoption (Auto Provisioning) Configuration
Device Configuration 5 - 17 5.2.3 Profile Adoption (Auto Provisioning) Configuration System Profile Configuration Adoption is the process an access point uses to discover Virtual Controller APs available in the network, pick the most desirable Virtual Controller, establish an association with the Virtual Controller and optionally obtain an image upgrade, obtains its configuration and considers itself provisioned.
Page 104 5 - 18 WiNG 5.5 Access Point System Reference Guide Figure 5-10 Profile Adoption screen 5. Define the Preferred Group used as optimal group of Virtual Controller for adoption. The name of the preferred group cannot exceed 64 characters. 6. Select the...
Page 105: Profile Wired 802.1X Configuration
Device Configuration 5 - 19 Routing Level Use the spinner controller to set the routing level for the Virtual Controller link. The default setting is 1. IPSec Support Select to enable secure communication between the access point and wireless controllers. IPSec GW Use the drop-down menu to specify if the IPSec gateway resource is defined as a (non DNS) IP address or a hostname.
Page 106: Profile Interface Configuration
5 - 20 WiNG 5.5 Access Point System Reference Guide Dot1x Guest VLAN Select this option to globally enable 802.1x guest VLANs for the selected device. This Control setting is disabled by default. MAC Authentication Use the drop-down menu to select an AAA authentication policy for MAC address AAA Policy authentication.
Page 107: Ethernet Port Configuration
Device Configuration 5 - 21 5.2.5.1 Ethernet Port Configuration Profile Interface Configuration Displays the physical port reporting runtime data and statistics. The following ports are available depending on model: • AP6511 - fe1, fe2, fe3, fe4, up1 • AP6521 - GE1/POE (LAN) •...
Page 108 5 - 22 WiNG 5.5 Access Point System Reference Guide Type Displays the physical port type. Description Displays an administrator defined description for each listed port. Admin Status A green check mark defines the port as active and currently enabled with the profile. A red “X”...
Page 109 Device Configuration 5 - 23 Figure 5-13 Ethernet Ports - Basic Configuration screen 7. Set the following Ethernet port Properties: Description Enter a brief description for the port (64 characters maximum). The description should reflect the port’s intended function to differentiate it from others with similar configurations.
Page 110 5 - 24 WiNG 5.5 Access Point System Reference Guide 8. Define the following Cisco Discovery Protocol (CDP) and LLDP parameters to apply to the Ethernet port configuration: Cisco Discover Protocol Select this option to allow the Cisco discovery protocol for receiving data on this port. If...
Page 111 Device Configuration 5 - 25 Figure 5-14 Ethernet Ports - Security tab 13. Refer to the Access Control field. As part of the port’s security configuration, Inbound IP and MAC address firewall rules are required. Use the Inbound IP Firewall Rules Inbound MAC Firewall Rules drop-down menus to select the firewall rules to apply to this profile’s Ethernet port configuration.
Page 112 5 - 26 WiNG 5.5 Access Point System Reference Guide NOTE: Some vendor solutions with VRRP enabled send ARP packets with Ethernet SMAC as a physical MAC and inner ARP SMAC as VRRP MAC. If this configuration is enabled, a packet is allowed, despite a conflict existing.
Page 113 Device Configuration 5 - 27 Multiple Spanning Tree Protocol (MSTP) provides an extension to RSTP to optimize the usefulness of VLANs. MSTP allows for a separate spanning tree for each VLAN group, and blocks all but one of the possible alternate paths within each spanning tree topology.
Page 114 5 - 28 WiNG 5.5 Access Point System Reference Guide Enable PortFast BPDU MSTP BPDUs are messages exchanged when controllers gather information about the Filter network topology during STP scan. When enabled, PortFast enabled ports do not transmit or receive BPDU messages. 'Default' sets the PortFast BPDU Filter value to the bridge's BPDU filter value.
Page 115 Device Configuration 5 - 29 <=1000000000000 bits/sec >1000000000000 bits/sec 22. Select + Add Row as needed to include additional indexes. 23. Refer to the Spanning Tree Port Priority table. Define an Instance Index using the spinner control and then set the Priority. The lower the priority, the greater the likelihood of the port becoming a designated port.
Page 116: Virtual Interface Configuration
5 - 30 WiNG 5.5 Access Point System Reference Guide 5.2.5.2 Virtual Interface Configuration Profile Interface Configuration A Virtual Interface is required for layer 3 (IP) access to provide layer 3 service on a VLAN. The Virtual Interface defines which IP address is associated with each VLAN ID the access point is connected to.
Page 117 Device Configuration 5 - 31 VLAN Displays the numerical VLAN ID associated with each listed interface. IP Address Defines whether DHCP was used to obtain the primary IP address used by the Virtual Interface configuration. Once the configurations of existing Virtual Interfaces have been reviewed, determine whether a new interface requires creation, or an existing Virtual Interface requires edit or deletion.
Page 118 5 - 32 WiNG 5.5 Access Point System Reference Guide 9. Set the following network information from within the IP Addresses field: Enable Zero The access point can use Zero Config for IP assignments on an individual virtual interface Configuration basis.
Page 119: Port Channel Configuration
Device Configuration 5 - 33 Figure 5-18 Virtual Interfaces - Security tab 13. Use the Inbound IP Firewall Rules drop-down menu to select the firewall rule configuration to apply to this Virtual Interface. The firewall inspects and packet traffic to and from connected clients. If a firewall rule does not exist suiting the data protection needs of this Virtual Interface, select the Create icon to define a new firewall rule configuration or the Edit icon to modify an existing configuration.
Page 120 5 - 34 WiNG 5.5 Access Point System Reference Guide Figure 5-19 Profile Interfaces - Port Channels screen 1. Select the Configuration tab from the Web UI. 2. Select Devices. 3. Select System Profile from the options on left-hand side of the UI.
Page 121 Device Configuration 5 - 35 Figure 5-20 Port Channels - Basic Configuration tab 7. Set the following port channel Properties: Description Enter a brief description for the port channel (64 characters maximum). The description should reflect the port channel’s intended function. Admin Status Select the Enabled radio button to define this port channel as active to the controller profile it supports.
Page 122 5 - 36 WiNG 5.5 Access Point System Reference Guide 8. Use the Port Channel Load Balance drop-down menu within the Client Load Balancing field to define whether port channel load balancing is conducted using a Source/Destination IP or a Source/Destination MAC as criteria. Source/ Destination IP is the default setting.
Page 123 Device Configuration 5 - 37 Figure 5-21 Port Channels - Security tab 12. Refer to the Access Control field. As part of the port channel’s security configuration, Inbound IP and MAC address firewall rules are required. Use the Inbound IP Firewall Rules Inbound MAC Firewall Rules drop-down menus to select firewall rules to apply to this profile’s port channel configuration.
Page 124 5 - 38 WiNG 5.5 Access Point System Reference Guide 14. Select to save the changes to the security configuration. Select Reset to revert to the last saved configuration. 15. Select the Spanning Tree tab. Figure 5-22 Port Channels - Spanning Tree tab 16.
Page 125 Device Configuration 5 - 39 Link Type Select either the Point-to-Point or Shared radio button. Selecting Point-to-Point indicates the port should be treated as connected to a point-to-point link. Selecting Shared means this port should be treated as having a shared connection. A port connected to a hub is on a shared link, while one connected to a access point is a point- to-point link.
Page 126: Access Point Radio Configuration
5 - 40 WiNG 5.5 Access Point System Reference Guide 5.2.5.4 Access Point Radio Configuration Profile Interface Configuration An access point profile can have its radio configuration modified once its radios have successfully associated to the network. To define a access point radio configuration: 1.
Page 127 Device Configuration 5 - 41 RF Mode Displays whether each listed radio is operating in the 802.11a/n or 802.11b/g/n radio band. If the radio is a dedicated sensor, it will be listed as a sensor to define the radio as not providing typical WLAN support.
Page 128 5 - 42 WiNG 5.5 Access Point System Reference Guide Radio QoS Policy Use the drop-down menu to specify an existing QoS policy to apply to the access point radio in respect to its intended radio traffic. If there’s no existing suiting the radio’s intended operation, select the Create icon to define a new QoS policy that can be applied to this profile.
Page 129 Motorola Solutions recommends that only a professional installer set the antenna gain. The default value is 0.00.
Page 130 5 - 44 WiNG 5.5 Access Point System Reference Guide NOTE: AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232, AP7131, AP7181 and AP7161 model access points can support up to 256 client connections to a single access point radio. AP6511 and AP6521 model access points (both single radio models) can support up to 128 client connections to a single radio.
Page 131 Device Configuration 5 - 45 Short Preamble If using an 802.11bg radio, select this option for the radio to transmit using a short preamble. Short preambles improve throughput. However, some devices (SpectraLink phones) require long preambles. The default value is disabled. Guard Interval Use the drop-down menu to specify a Long or Any guard interval.
Page 132 5 - 46 WiNG 5.5 Access Point System Reference Guide 16. Select Create New MeshPoint to open a dialog where new Mesh Points are created. 17. Select the button located at the bottom right of the screen to save the changes to the WLAN Mapping. Select Reset to revert to the last saved configuration.
Page 133 Device Configuration 5 - 47 Figure 5-27 Access Point Radio - Advanced Settings tab 23. Refer to the Aggregate MAC Protocol Data Unit (A-MPDU) field to define how MAC service frames are aggregated by the access point radio. A-MPDU Modes Use the drop-down menu to define the A-MPDU mode supported.
Page 134 5 - 48 WiNG 5.5 Access Point System Reference Guide Forwarding Port Use the Forward Port spinner to configure the port on which to forward captured packets to the Ekahau Engine. MAC to be forwarded Use the text area to provide a MAC address that identifies that the packet is received from Ekahau tags.
Page 135 Device Configuration 5 - 49 31. Select the button located at the bottom right of the screen to save the changes to the Advanced Settings screen. Select Reset to revert to the last saved configuration. 5.2.5.4.1 MCS Data Rates Access Point Radio Configuration 802.11n MCS rates are defined as follows both with and without short guard intervals (SGI): Table 5.1 MCS-1Stream Number of...
Page 136 5 - 50 WiNG 5.5 Access Point System Reference Guide Table 5.3 MCS-3Stream Number of 20 MHz 20 MHz 40 MHz 40MHz MCS Index Streams No SGI With SGI No SGI With SGI 86.7 130.7 173.3 175.5 364.5 216.7 802.11ac MCS rates are defined as follows both with and without short guard intervals (SGI): Table 5.4 MCS-802.11ac (theoretical throughput for single spatial streams)
Page 137: Wan Backhaul Configuration
Device Configuration 5 - 51 5.2.5.5 WAN Backhaul Configuration Profile Interface Configuration A Wireless Wide Area Network (WWAN) card is a specialized network interface card that allows a network device to connect, transmit and receive data over a Cellular Wide Area Network. The AP7131N model access point has a PCI Express card slot that supports 3G WWAN cards.
Page 138 5 - 52 WiNG 5.5 Access Point System Reference Guide Figure 5-28 Profile Interface - WAN Backhaul screen 5. Refer to the WAN (3G) Backhaul configuration to specify the access point’s WAN card interface settings: WAN Interface Name Displays the WAN Interface name for the WAN 3G Backhaul card.
Page 139 Device Configuration 5 - 53 8. Configure the Inbound IP Firewall Rules. Use the drop-down menu to select a firewall (set of IP access connection rules) to apply to the PPPoE client connection. If a firewall rule does not exist suiting the data protection needs of the PPPoE client connection, select the Create icon to define a new rule configuration or the Edit icon to modify an existing rule.
Page 140: Pppoe Configuration
5 - 54 WiNG 5.5 Access Point System Reference Guide 5.2.5.6 PPPoE Configuration Profile Interface Configuration PPP over Ethernet (PPPoE) is a data-link protocol for dialup connections. PPPoE allows the access point to use a broadband modem (DSL, cable modem, etc.) for access to high-speed data and broadband networks. Most DSL providers are currently supporting (or deploying) the PPPoE protocol.
Page 141 Device Configuration 5 - 55 Figure 5-29 Profile Interface - PPPoE screen 5. Use the Basic Settings field to enable PPPoE and define a PPPoE client. Enable PPPoE Select Enable to support a high speed client mode point-to-point connection using the PPPoE protocol.
Page 142 5 - 56 WiNG 5.5 Access Point System Reference Guide 6. Define the following Authentication parameters for PPPoE client interoperation: Username Provide the 64 character maximum username used for authentication support by the PPPoE client. Password Provide the 64 character maximum password used for authentication by the PPPoE client.
Page 143: Profile Network Configuration
Device Configuration 5 - 57 5.2.6 Profile Network Configuration System Profile Configuration Setting an access point profile’s network configuration is a large task comprised of numerous administration activities. An access point profile network configuration process consists of the following: • DNS Configuration •...
Page 144: Dns Configuration
5 - 58 WiNG 5.5 Access Point System Reference Guide 5.2.6.1 DNS Configuration Profile Network Configuration Domain Naming System (DNS) is a hierarchical naming system for resources connected to the Internet or a private network. Primarily, DNS resources translate domain names into IP addresses. If one DNS server does not know how to translate a particular domain name, it asks another one until the correct IP address is returned.
Page 145: Arp
Device Configuration 5 - 59 8. Select to save the changes made to the DNS configuration. Select Reset to revert to the last saved configuration. 5.2.6.2 ARP Profile Network Configuration Address Resolution Protocol (ARP) is a protocol for mapping an IP address to a hardware MAC address recognized on the network.
Page 146 5 - 60 WiNG 5.5 Access Point System Reference Guide Device Type Specify the device type the ARP entry supports (Host, Router or DHCP Server). Host is the default setting. 7. Select the button located at the bottom right of the screen to save the changes to the ARP configuration. Select Reset to revert to the last saved configuration.
Page 147: L2Tpv3 Profile Configuration
Device Configuration 5 - 61 5.2.6.3 L2TPv3 Profile Configuration Profile Network Configuration L2TP V3 is an IETF standard used for transporting different types of layer 2 frames in an IP network (and access point profile). L2TP V3 defines control and encapsulation protocols for tunneling layer 2 frames between two IP nodes. Use L2TP V3 to create tunnels for transporting layer 2 frames.
Page 148 5 - 62 WiNG 5.5 Access Point System Reference Guide Figure 5-32 Network - L2TPv3 screen - General tab 5. Set the following General Settings for an L2TPv3 profile configuration: Host Name Define a 64 character maximum hostname to specify the name of the host that’s sent tunnel messages.
Page 149 Device Configuration 5 - 63 Figure 5-33 Network - L2TPv3 screen - T2TP tunnel tab 7. Review the following L2TPv3 tunnel configuration data: Name Displays the name of each listed L2TPv3 tunnel assigned upon creation. Local IP Address Lists the IP address assigned as the local tunnel end point address, not the interface IP address.
Page 150 5 - 64 WiNG 5.5 Access Point System Reference Guide 8. Either select to create a new L2TPv3 tunnel configuration, Edit to modify an existing tunnel configuration or Delete to remove a tunnel from those available to this profile. Figure 5-34 Network - L2TPv3 screen - Add T2TP Tunnel Configuration 9.
Page 151 Device Configuration 5 - 65 Set the maximum transmission unit (MTU). The MTU is the size (in bytes) of the largest protocol data unit the layer can pass between tunnel peers. Define a MTU between 128 - 1,460 bytes. The default setting is 1,460. A larger MTU means processing fewer packets for the same amount of data.
Page 152 5 - 66 WiNG 5.5 Access Point System Reference Guide Figure 5-35 Network - L2TPv3 screen - Add T2TP Peer Configuration 12. Define the following Peer parameters: Peer ID Define the primary peer ID used to set the primary and secondary peer for tunnel failover.
Page 153 Device Configuration 5 - 67 Pseudowire ID Define a psuedowire ID for this session. A pseudowire is an emulation of a layer 2 point-to-point connection over a packet-switching network (PSN). A pseudowire was developed out of the necessity to encapsulate and tunnel layer 2 protocols across a layer 3 network.
Page 154 5 - 68 WiNG 5.5 Access Point System Reference Guide Local Session ID Displays the numeric identifier assigned to each listed tunnel session. This is the pseudowire ID for the session. This pseudowire ID is sent in a session establishment message to the L2TP peer.
Page 155 Device Configuration 5 - 69 IP Address Specify the IP address used as a tunnel source IP address. If not specified, the tunnel source IP address is selected automatically based on the tunnel peer IP address. This address is applicable only for initiating the tunnel. When responding to incoming tunnel create requests, the tunnel would use the IP address received in the tunnel create request.
Page 156: Igmp Snooping
5 - 70 WiNG 5.5 Access Point System Reference Guide 5.2.6.4 IGMP Snooping Profile Network Configuration Internet Group Management Protocol (IGMP) is a protocol to establish and maintain multicast group memberships to interested members. Multicasting allows a networked computer to send content to multiple computers who have registered to receive the content.
Page 157 Device Configuration 5 - 71 6. Set the following for IGMP Querier configuration: Enable IGMP Querier Select this option to enable IGMP querier. IGMP snoop querier is used to keep host memberships alive. It is primarily used in a network where there is a multicast streaming server and hosts subscribed to the server and no IGMP querier present.
Page 158: Quality Of Service (Qos)
5 - 72 WiNG 5.5 Access Point System Reference Guide 5.2.6.5 Quality of Service (QoS) Profile Network Configuration The uses different Quality of Service (QoS) screens to define WLAN and device radio QoS configurations. The System Profiles > Network > QoS facility is separate from WLAN and radio QoS configurations, and is used to configure the priority of the different DSCP packet types.
Page 159 Device Configuration 5 - 73 802.1p Priority Assign a 802.1p priority as a 3-bit IP precedence value in the Type of Service field of the IP header used to set the priority. The valid values for this field are 0-7. Up to 64 entries are permitted.
Page 160: Spanning Tree Configuration
5 - 74 WiNG 5.5 Access Point System Reference Guide 5.2.6.6 Spanning Tree Configuration Profile Network Configuration The Multiple Spanning Tree Protocol (MSTP) provides an extension to RSTP to optimize the usefulness of VLANs. MSTP allows for a separate spanning tree for each VLAN group, and blocks all but one of the possible alternate paths within each spanning tree topology.
Page 161 Device Configuration 5 - 75 Figure 5-40 Network - Spanning Tree screen 5. Set the following MSTP Configuration parameters: MSTP Enable Select this option to enable MSTP for this profile. MSTP is disabled by default, so enable this setting if requiring different (groups) of VLANs with the profile supported network segment.
Page 162 5 - 76 WiNG 5.5 Access Point System Reference Guide Hello Time Set a BPDU hello interval from 1 - 10 seconds. BPDUs are exchanged regularly (every 2 seconds by default) and enable supported devices to keep track of network changes and start/stop port forwarding as required.
Page 163: Routing
Device Configuration 5 - 77 5.2.6.7 Routing Profile Network Configuration Routing is the process of selecting IP paths to send access point managed network traffic. Use the Routing screen to set destination IP and gateway addresses enabling assignment of static IP addresses for requesting clients without creating numerous host pools with manual bindings.
Page 164 5 - 78 WiNG 5.5 Access Point System Reference Guide 6. Select the Policy Based Routing policy to apply to this profile. Select the Create icon to create a policy based route or select the Edit icon to edit an existing policy after selecting it in the drop-down list.
Page 165: Dynamic Routing (Ospf)
Device Configuration 5 - 79 5.2.6.8 Dynamic Routing (OSPF) Profile Network Configuration Open Shortest Path First (OSPF) is a link-state interior gateway protocol (IGP). OSPF routes IP packets within a single routing domain (autonomous system), like an enterprise LAN. OSPF gathers link state information from neighbor routers and constructs a network topology.
Page 166 5 - 80 WiNG 5.5 Access Point System Reference Guide Figure 5-42 Network - OSPF Settings tab 5. Enable/disable OSPF and provide the following dynamic routing settings: Enable OSPF Select this option to enable OSPF for this access point. OSPF is disabled by default.
Page 167 Device Configuration 5 - 81 VRRP State Check Select this option to enable checking VRRP state. If the interface’s VRRP state is not Backup, then the interface is published via OSPF. 6. Set the following OSPF Overload Protection settings: Number of Routes Use the spinner controller to set the maximum number of OSPN routes permitted.
Page 168 5 - 82 WiNG 5.5 Access Point System Reference Guide Figure 5-43 Network - Area Settings tab 12. Review existing Area Settings configurations using: Area ID Displays either the IP address or integer representing the OSPF area. Authentication Type Lists the authentication schemes used to validate the credentials of dynamic route connections.
Page 169 Device Configuration 5 - 83 14. Set the OSPF Area configuration. Area ID Use the drop-down menu and specify either an IP address or Integer for the OSPF area. Authentication Type Select either None, simple-password or message-digest as credential validation scheme used with the OSPF dynamic route.
Page 170 5 - 84 WiNG 5.5 Access Point System Reference Guide 18. Select the button to define a new set of virtual interface basic settings, or Edit to update the settings of an existing virtual interface configuration. Figure 5-46 Network - OSPF Virtual Interfaces - Basic Configuration tab 19.
Page 171 Device Configuration 5 - 85 Figure 5-47 Network - OSPF Virtual Interface - Security tab 26. Use the Inbound IP Firewall Rules drop-down menu to select the IP access and deny rules to apply to the OSPF dynamic route. Either select an existing IP firewall policy or use the default set of IP firewall rules. The firewall inspects OSPF route traffic flows and detects potential attacks on the dynamic route not visible to traditional wired firewall appliances.
Page 172: Forwarding Database
5 - 86 WiNG 5.5 Access Point System Reference Guide 5.2.6.9 Forwarding Database Profile Network Configuration A Forwarding Database is used by a bridge to forward or filter packets. The bridge reads the packet’s destination MAC address and decides to either forward the packet or drop (filter) it. If it is determined the destination MAC is on a different network segment, it forwards the packet to the segment.
Page 173 Device Configuration 5 - 87 8. Define the target VLAN ID if the destination MAC is on a different network segment. 9. Provide an Interface Name used as the target destination interface for the target MAC address. 10. Select to save the changes. Select Reset to revert to the last saved configuration.
Page 174: Bridge Vlan
5 - 88 WiNG 5.5 Access Point System Reference Guide 5.2.6.10 Bridge VLAN Profile Network Configuration A Virtual LAN (VLAN) is separately administrated virtual network within the same physical managed network. VLANs are broadcast domains to allow control of broadcast, multicast, unicast and unknown unicast within a Layer 2 device.
Page 175 Device Configuration 5 - 89 Edge VLAN Mode Defines whether the VLAN is currently in edge VLAN mode. An edge VLAN is the VLAN where hosts are connected. For example, if VLAN 10 is defined with wireless clients and VLAN 20 is where the default gateway resides, VLAN 10 should be marked as an edge VLAN and VLAN 20 shouldn’t be marked as an edge VLAN.
Page 176 5 - 90 WiNG 5.5 Access Point System Reference Guide 8. Firewalls, generally, are configured for all interfaces on a device. When configured, firewalls generate flow tables that store information on the traffic allowed to traverse through the firewall. These flow tables occupy a large portion of the limited memory that could be used for other critical purposes.
Page 177 Device Configuration 5 - 91 Figure 5-51 Network - Bridge VLAN - IGMP Snooping screen 14. Define the following IGMP General parameters. Enable IGMP Snooping Select this option to enable IGMP snooping. If disabled, snooping on this bridge VLAN is disabled. This feature is enabled by default. If disabled, the settings under bridge configuration are overridden.
Page 178 5 - 92 WiNG 5.5 Access Point System Reference Guide 16. Set the following IGMP Querier parameters for the bridge VLAN configuration Enable IGMP Querier IGMP snoop querier is used to keep host memberships alive. It’s primarily used in a network where there’s a multicast streaming server, hosts subscribed to the server and...
Page 179: Cisco Discovery Protocol Configuration
Device Configuration 5 - 93 5.2.6.11 Cisco Discovery Protocol Configuration Profile Network Configuration The Cisco Discovery Protocol (CDP) is a proprietary Data Link Layer protocol implemented in Cisco networking equipment. It's primarily used to obtain IP addresses of neighboring devices and discover their platform information. CDP is also used to obtain information about the interfaces the access point uses.
Page 180: Link Layer Discovery Protocol Configuration
5 - 94 WiNG 5.5 Access Point System Reference Guide 5.2.6.12 Link Layer Discovery Protocol Configuration Profile Network Configuration The Link Layer Discovery Protocol (LLDP) provides a standard way for a controller or access point to advertise information about themselves to networked neighbors and store information they discover from their peers.
Page 181: Miscellaneous Network Configuration
Device Configuration 5 - 95 Extended Power via MDI Select this option to include LLPD-MED extended power via MDI discovery TLV in LLDP Discovery PDUs. This setting is disabled by default. 6. Select the button to save the changes to the LLDP configuration. Select Reset to revert to the last saved configuration.
Page 182: Alias
5 - 96 WiNG 5.5 Access Point System Reference Guide 5.2.6.14 Alias Profile Network Configuration With large deployments, the configuration of remote sites utilizes a set of shared attributes, of which a small set of attributes are unique for each location. For such deployments, maintaining separate configuration (WLANs, profiles, policies and ACLs) for each remote site is complex.
Page 183 Device Configuration 5 - 97 2. Select System Profiles. 3. Select Network to expand it and display its sub menus. 4. Select the Alias item, the Basic Alias screen displays. Figure 5-55 Network - Basic Alias Screen 5. Select + Add Row to define VLAN Alias settings:...
Page 184 5 - 98 WiNG 5.5 Access Point System Reference Guide • Wireless LANs 6. Select + Add Row to define Address Range Alias settings: Use the Address Range Alias field to create aliases for IP address ranges that can be utilized at different deployments.
Page 185 Device Configuration 5 - 99 Use the String Alias field to create aliases for strings that can be utilized at different deployments. For example, if the main domain at a remote location is called loc1.domain.com and at another deployment location it is called loc2.domain.com, the alias can be overridden at the remote location to suit the local (but remote) requirement.
Page 186 5 - 100 WiNG 5.5 Access Point System Reference Guide Figure 5-56 Network - Alias - Network Group Alias screen Name Displays the administrator assigned name of the Network Group Alias. Host Displays all host aliases configured in this network group alias. Displays a blank column if no host alias is defined.
Page 187 Device Configuration 5 - 101 Figure 5-57 Network - Alias - Network Group Alias Add screen 7. If adding a new Network Group Alias, provide it a name of up to 32 characters. NOTE: The Network Group Alias Name always starts with a dollar sign ($). 8.
Page 188 5 - 102 WiNG 5.5 Access Point System Reference Guide 5.2.6.14.3Network Service Alias Alias Network Service Alias is a set of configurations that consist of protocol and port mappings. Both source and destination ports are configurable. For each protocol, up to 2 source port ranges and up to 2 destination port ranges can be configured. A maximum of 4 protocol entries can be configured per Network Service Alias.
Page 189 Device Configuration 5 - 103 Figure 5-59 Network - Alias - Network Service Alias Add screen 7. If adding a new Network Service Alias, provide it a name up to 32 characters. NOTE: The Network Service Alias Name always starts with a dollar sign ($). 8.
Page 190: Profile Network Configuration And Deployment Considerations
5 - 104 WiNG 5.5 Access Point System Reference Guide 5.2.6.15 Profile Network Configuration and Deployment Considerations Profile Network Configuration Before defining a profile’s network configuration, refer to the following deployment guidelines to ensure the profile configuration is optimally effective: •...
Page 191: Profile Security Configuration
Device Configuration 5 - 105 5.2.7 Profile Security Configuration System Profile Configuration An access point profile can have its own firewall policy, wireless client role policy, WEP shared key authentication and NAT policy applied. For more information, refer to the following sections: •...
Page 192: Defining Profile Vpn Settings
5 - 106 WiNG 5.5 Access Point System Reference Guide 5.2.7.1 Defining Profile VPN Settings Profile Security Configuration IPSec VPN provides a secure tunnel between two networked peer access points or controllers. Administrators can define which packets are sent within the tunnel, and how they’re protected. When a tunnelled peer sees a sensitive packet, it creates a secure tunnel and sends the packet through the tunnel to its remote peer destination.
Page 193 Device Configuration 5 - 107 DPD Keep Alive Lists each policy’s IKE keep alive message interval defined for IKE VPN tunnel dead peer detection. IKE LifeTime Displays each policy’s lifetime for an IKE SA. The lifetime defines how long a connection (encryption/authentication keys) should last, from successful key negotiation to expiration.
Page 194 5 - 108 WiNG 5.5 Access Point System Reference Guide Mode If using IKEv1, use the drop-down menu to define the IKE mode as either Main or Aggressive. IPSEC has two modes in IKEv1 for key exchanges. Aggressive mode requires 3 messages be exchanged between the IPSEC peers to setup the SA, Main requires 6 messages.
Page 195 Device Configuration 5 - 109 11. Select either the IKEv1 IKEv2 radio button to enforce VPN key exchanges using either IKEv1 or IKEv2. 12. Refer to the following to determine whether a VPN Peer Configuration requires creation, modification or removal: Name Lists the 32 character maximum name assigned to each listed peer configuration.
Page 196 5 - 110 WiNG 5.5 Access Point System Reference Guide IP Type Enter either the IP address or FQDN hostname of the IPSec VPN peer used in the tunnel setup. If IKEv1 is used, this value is titled IP Type, if IKEv2 is used, this parameter is titled Select IP/Hostname.
Page 197 Device Configuration 5 - 111 Figure 5-64 Profile Security - VPN Transform Set tab 16. Review the following attributes of an existing Transform Set configurations: Transform Set Lists the 32 character maximum name assigned to each listed transform set upon creation.
Page 198 5 - 112 WiNG 5.5 Access Point System Reference Guide Figure 5-65 Profile Security - VPN Transform Set create/modify screen 18. Define the following settings for the new or modified Transform Set configuration: Transform Set If creating a new transform set, define a 32 character maximum name to differentiate this configuration from others with similar attributes.
Page 199 Device Configuration 5 - 113 Figure 5-66 Profile Security - VPN Crypto Map tab 21. Review the following Crypto Map configuration parameters to assess their relevance: Name Lists the 32 character maximum name assigned for each crypto map upon creation. This name cannot be modified as part of the edit process.
Page 200 5 - 114 WiNG 5.5 Access Point System Reference Guide Figure 5-67 Profile Security - VPN Crypto Map screen 24. Review the following before determining whether to add or modify a crypto map configuration: Sequence Each crypto map configuration uses a list of entries based on a sequence number. Specifying multiple sequence numbers within the same crypto map, provides the flexibility to connect to multiple peers from the same interface, based on the sequence number (from 1 - 1,000).
Page 201 Device Configuration 5 - 115 Figure 5-68 Profile Security - VPN Crypto Map Entry screen 26. Define the following parameters to set the crypto map configuration: Sequence Each crypto map configuration uses a list of entries based on a sequence number. Specifying multiple sequence numbers within the same crypto map extends connection flexibility to multiple peers on the same interface, based on this selected sequence number (from 1 - 1,000).
Page 202 5 - 116 WiNG 5.5 Access Point System Reference Guide IP Firewall Rules Use the drop-down menu to select the access list (ACL) used to protect IPSec VPN traffic. New access/deny rules can be defined for the crypto map by selecting the Create icon, or an existing set of firewall rules can be modified by selecting the Edit icon.
Page 203 Device Configuration 5 - 117 Figure 5-69 Profile Security - Remote VPN Server tab (IKEv2 example) 29. Select either the IKEv1 IKEv2 radio button to enforce peer key exchanges over the remote VPN server using either IKEv1 or IKEv2. IKEv2 provides improvements from the original IKEv1 design (improved cryptographic mechanisms, NAT and firewall traversal, attack resistance etc.) and is recommended in most deployments.
Page 204 5 - 118 WiNG 5.5 Access Point System Reference Guide AAA Policy Select the AAA policy used with the remote VPN client. AAA policies define RADIUS authentication and accounting parameters. The access point can optionally use AAA server resources (when using RADIUS as the authentication method) to provide user database information and user authentication data.
Page 205 Device Configuration 5 - 119 Figure 5-70 Profile Security - Remote VPN Client tab 37. Refer to the following fields to define Remote VPN Client Configuration settings: Shutdown Select this option to disable the remote VPN client. The default is disabled. Transform Set Configure the transform set used to specify how traffic is protected within the crypto ACL defining the traffic that needs to be protected.
Page 206 5 - 120 WiNG 5.5 Access Point System Reference Guide Figure 5-71 Profile Security - Global VPN Settings tab 41. Refer to the following fields to define IPSec security, lifetime and authentication settings: df bit Select the DF bit handling technique used for the ESP encapsulating header. Options include clear, set and copy.
Page 207 Device Configuration 5 - 121 DPD Retries Use the spinner control to define the number of keep alive messages sent to an IPSec VPN client before the tunnel connection is defined as dead. The available range is from 1 - 100. The default number of messages is 5. NAT Keep Alive Define the interval (or frequency) of NAT keep alive messages for dead peer detection.
Page 208: Auto Ipsec Tunnel
5 - 122 WiNG 5.5 Access Point System Reference Guide 5.2.7.2 Auto IPSec Tunnel Profile Security Configuration IPSec tunnels are established to secure traffic, data and management traffic, from access points to remote wireless controllers. Secure tunnels must be established between access points and the wireless controller with minimum configuration pushed through DHCP option settings.
Page 209: Defining Profile Security Settings
WEP key to access the network using this profile. The access point, other proprietary routers, and Motorola Solutions clients use the key algorithm to convert an ASCII string to the same hexadecimal number. Clients without Motorola Solutions adapters need to use WEP keys manually configured as hexadecimal numbers.
Page 210: Setting The Certificate Revocation List (Crl) Configuration
5 - 124 WiNG 5.5 Access Point System Reference Guide 5.2.7.4 Setting the Certificate Revocation List (CRL) Configuration Profile Security Configuration A certificate revocation list (CRL) is a list of certificates that have been revoked or are no longer valid. A certificate can be revoked if the certificate authority (CA) had improperly issued a certificate, or if a private-key is compromised.
Page 211: Setting The Profile's Nat Configuration
Device Configuration 5 - 125 5.2.7.5 Setting the Profile’s NAT Configuration Profile Security Configuration Network Address Translation (NAT) is a technique to modify network address information within IP packet headers in transit across a traffic routing device. This enables mapping one IP address to another to protect network address credentials. With typical deployments, NAT is used as an IP masquerading technique to hide private IP addresses behind a single, public facing, IP address.
Page 212 5 - 126 WiNG 5.5 Access Point System Reference Guide NAT Pool tab displays by default. The NAT Pool tab lists those NAT policies created thus far. Any of these policies can be selected and applied to the access point profile.
Page 213 Device Configuration 5 - 127 Figure 5-77 Profile Security - Static NAT screen - Source tab 10. To map a source IP address from an internal network to a NAT IP address click the button. The following screen displays: Figure 5-78 Profile Security - Static NAT screen - New Source entry...
Page 214 5 - 128 WiNG 5.5 Access Point System Reference Guide 11. Define the following Source NAT parameters. Protocol Select the protocol for use with static translation. TCP, UDP and Any are the available options. Transmission Control Protocol (TCP) is a transport layer protocol used by applications requiring guaranteed delivery.
Page 215 Device Configuration 5 - 129 Figure 5-79 Profile Security - Static NAT screen - Destination tab 13. Select to create a new NAT destination configuration or Delete to permanently remove a NAT destination. Existing NAT destination configurations are not editable. Figure 5-80 NAT Destination - Add screen...
Page 216 5 - 130 WiNG 5.5 Access Point System Reference Guide 14. Set the following Destination configuration parameters: Static NAT creates a permanent, one-to-one mapping between an address on an internal network and a perimeter or external network. To share a Web server on a perimeter interface with the Internet, use static address translation to map the actual address to a registered IP address.
Page 217 Device Configuration 5 - 131 Figure 5-81 Profile Security - Dynamic NAT tab 17. Refer to the following to determine whether a new Dynamic NAT configuration requires creation, edit or deletion: Source List ACL Lists the ACL defining packet selection criteria for the NAT configuration. NAT is applied only on packets which match a rule defined in the access list.
Page 218 5 - 132 WiNG 5.5 Access Point System Reference Guide Figure 5-82 Profile Security - Source ACL List screen 19. Set the following to define the Dynamic NAT configuration: Source List ACL Use the drop-down menu to select an ACL name to define the packet selection criteria for NAT.
Page 219 Device Configuration 5 - 133 21. Select to save the changes made to the dynamic NAT configuration. Select Reset to revert to the last saved configuration.
Page 220: Setting The Profile's Bridge Nat Configuration
5 - 134 WiNG 5.5 Access Point System Reference Guide 5.2.7.6 Setting the Profile’s Bridge NAT Configuration Profile Security Configuration Use Bridge NAT to manage Internet traffic originating at a remote site. In addition to traditional NAT functionality, Bridge NAT provides a means of configuring NAT for bridged traffic through an access point.
Page 221 Device Configuration 5 - 135 5. Review the following Bridge NAT configurations to determine whether a new Bridge NAT configuration requires creation or an existing configuration modified or removed: Lists the ACL applying IP address access/deny permission rules to the Bridge NAT configuration. Interface Lists the communication medium (outgoing layer 3 interface) between source and destination points.
Page 222: Profile Security Configuration And Deployment Considerations
5 - 136 WiNG 5.5 Access Point System Reference Guide Figure 5-85 Profile Security - Source Dynamic NAT screen - Add Row field 10. Select to save the changes made within the Add Row Dynamic NAT screens. Select Reset to revert to the last saved configuration.
Page 223: Virtual Router Redundancy Protocol (Vrrp) Configuration
Device Configuration 5 - 137 5.2.8 Virtual Router Redundancy Protocol (VRRP) Configuration System Profile Configuration A default gateway is a critical resource for connectivity. However, it’s prone to a single point of failure. Thus, redundancy for the default gateway is required by the access point. If WAN backhaul is available on an AP7131, and a router failure occurs, then the access point should act as a router and forward traffic on to its WAN link.
Page 224 5 - 138 WiNG 5.5 Access Point System Reference Guide 5. Review the following VRRP configuration data to assess if a new VRRP configuration is required or if an existing VRRP configuration requires modification or removal: Virtual Router ID Lists a numerical index (from 1 - 254) used to differentiate VRRP configurations. The index is assigned when a VRRP configuration is initially defined.
Page 225 Device Configuration 5 - 139 (available publicly) refer to http://www.ietf.org/rfc/rfc3768.txt (version 2) and http://www.ietf.org/rfc/rfc5798.txt (version 7. From within the VRRP tab, select to create a new VRRP configuration or Edit to modify the attributes of an existing VRRP configuration. If necessary, existing VRRP configurations can be selected and permanently removed by selecting Delete.
Page 226 5 - 140 WiNG 5.5 Access Point System Reference Guide 9. Define the following VRRP General parameters: Description In addition to an ID assignment, a virtual router configuration can be assigned a textual description (up to 64 characters) to further distinguish it from others with a similar configuration.
Page 227: Profile Critical Resources
Device Configuration 5 - 141 Network Monitoring: Use this setting to decrement the configured priority (by the set value) when the Delta Priority monitored interface is down. When critical resource monitoring, the configured value is incremented by the value defined. 11.
Page 228 5 - 142 WiNG 5.5 Access Point System Reference Guide Figure 5-90 Critical Resources screen - Adding a Critical Resource 6. Use the Offline Resource Detection drop-down menu to define how critical resource event messages are generated. Options include Any and All. If selecting Any, an event is generated when the state of any single critical resource changes.
Page 229 Device Configuration 5 - 143 10. Select the Monitor Interval tab. Figure 5-91 Critical Resources screen - Monitor Interval tab 11. Set the duration between two successive pings from the access point to the critical resource. Define this value in seconds from 5 - 86,400.
Page 230: Profile Services Configuration
5 - 144 WiNG 5.5 Access Point System Reference Guide 5.2.10 Profile Services Configuration System Profile Configuration A profile can contain specific guest access (captive portal) server configurations. These guest network access permissions can be defined uniquely as profile requirements dictate.
Page 231: Profile Services Configuration And Deployment Considerations
Device Configuration 5 - 145 5.2.10.1 Profile Services Configuration and Deployment Considerations Profile Services Configuration Before defining a profile’s captive portal and DHCP configuration, refer to the following deployment guidelines to ensure the profile configuration is optimally effective: • A profile plan should consider the number of wireless clients allowed on the profile’s guest (captive portal) network and the services provided, or if the profile should support guest access at all.
Page 232: Profile Management Configuration
5 - 146 WiNG 5.5 Access Point System Reference Guide 5.2.11 Profile Management Configuration System Profile Configuration The access point has mechanisms to allow/deny management access to the network for separate interfaces and protocols (HTTP, HTTPS, Telnet, SSH or SNMP). These management access configurations can be applied strategically to profiles as resource permissions dictate.
Page 233 Device Configuration 5 - 147 Figure 5-93 Profile Management - Settings screen 5. Refer to the Message Logging field to define how the profile logs system events. It’s important to log individual events to discern an overall pattern that may be negatively impacting performance using the configuration defined for the access point’s profile.
Page 234 5 - 148 WiNG 5.5 Access Point System Reference Guide Remote Logging Host Use this table to define numerical (non DNS) IP addresses for up to three external resources where logged system events can be sent on behalf of the profile. Select Clear to remove an IP address.
Page 235 Device Configuration 5 - 149 Username for SMTP Server Specify the sender’s username on the outgoing SMTP server. Many SMTP servers require users to authenticate with a username and password before sending E-mail through the server. Password for SMTP Server Specify the sender’s username password on the outgoing SMTP server.
Page 236 5 - 150 WiNG 5.5 Access Point System Reference Guide 15. Use the parameters within the Automatic Adopted AP Firmware Upgrade field to define an automatic firmware configuration. Enable Controller Upgrade Select the access point model to upgrade to a newer firmware version using its of AP Firmware associated Virtual Controller AP’s most recent firmware file for that model.
Page 237: Upgrading Ap6532 Firmware From 5.1
3. Ping the AP6532 from the computer to ensure IP connectivity. 4. Open an SSH session on the computer and connect to the AP6532’s IP address. 5. Login with a username and password of admin/motorola. The CLI will prompt for a new password. Re-enter the password and confirm.
Page 238: Mesh Point Configuration
5 - 152 WiNG 5.5 Access Point System Reference Guide 5.2.12 Mesh Point Configuration System Profile Configuration The access point can be configured to be a part of a meshed network. A mesh network is one where each node in the network is be able to communicate with other nodes in the network and where the node can maintain more than one path to its peers.
Page 239 Device Configuration 5 - 153 Monitor Primary Port Displays if this mesh point monitors link status on the primary port. Link Path Method Displays the path selection method used to select the path to the root node. 6. Select the button to create a new Mesh Connex policy.
Page 240 Select the root selection method hysteresis (from 1 - 100dB) SNR delta range a candidate must sustain. The default setting is 1 dB. NOTE: With this release of Motorola Solutions WiNG software, an AP7161 model access point can be deployed as a Vehicle Mounted Modem (VMM) to provide wireless network access to a mobile vehicle (car, train, etc.).
Page 241 Device Configuration 5 - 155 Figure 5-98 Mesh Connex Auto Channel Selection screen 9. By default, the Dynamic Root Selection screen displays. This screen provides configuration for the 2.4 GHz and 5.0/4.9 GHz frequencies. Refer to the following for more information on the Auto Channel Selection Dynamic Root Selection screen.
Page 242 5 - 156 WiNG 5.5 Access Point System Reference Guide Off-channel Duration Configure the duration in the range of 20 - 250 milliseconds for the Off Channel Duration field. This is the duration the scan dwells on each channel when performing an off channel scan.
Page 243 Device Configuration 5 - 157 Refer to the following for more information on the Path Method SNR screen. These descriptions apply to both the 2.4 GHz and 5.0/4.9 GHz frequencies. Channel Width Configure the channel width that mesh point automatic channel scan should assign to the selected radio.
Page 244 5 - 158 WiNG 5.5 Access Point System Reference Guide Figure 5-100 Mesh Point Auto Channel Selection Path Method Root Path Metric screen...
Page 245: Vehicle Mounted Modem (Vmm) Deployment Consideration
Device Configuration 5 - 159 Refer to the following for more information on the Path Method Root Path Metric screen. These descriptions apply to both the 2.4 GHz and 5.0/4.9 GHz frequencies. Channel Width Configure the channel width that mesh point automatic channel scan should assign to the selected radio.
Page 246: Advanced Profile Configuration
5 - 160 WiNG 5.5 Access Point System Reference Guide • Disable Dynamic Chain Selection (radio setting). The default value is enabled. This setting is disabled from the Command Line Interface (CLI) using the command, or, in the UI (refer...
Page 247: Advanced Profile Client Load Balancing
Device Configuration 5 - 161 5.2.13.1 Advanced Profile Client Load Balancing Advanced Profile Configuration Use the screen to administer the client load across an access point’s radios. AP7131 models can have from 1-3 radios depending on the SKU. AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232, AP7131, AP7181 and AP7161 models have 2 radios, while AP6511 and AP6521 models have a single radio.
Page 248 5 - 162 WiNG 5.5 Access Point System Reference Guide Use notifications from Select this option to use roamed client notifications in the neighbor selection process. roamed clients This feature is enabled by default, allowing access points in the neighbor selection process to consider device roaming counts as selection criteria.
Page 249 Device Configuration 5 - 163 2.4 GHz load at which both When the Steering Strategy is set to Steer at 2.4 GHz, use the spinner control to set bands enabled a value (from 0 - 100%) at which the load on the 5.0 GHz radio is equally preferred to this 2.4 GHz radio load.
Page 250 5 - 164 WiNG 5.5 Access Point System Reference Guide Min. Value to Trigger 5GHz Use the spinner control to define a threshold (from 1 - 100) the access point uses Channel Balancing (when exceeded) to initiate channel load balancing in the 5GHz radio band. Set this value higher when wishing to keep radio traffic within their current channel designations.
Page 251: Configuring Mint Protocol
Device Configuration 5 - 165 5.2.13.2 Configuring MINT Protocol Advanced Profile Configuration MINT provides the means to secure access point profile communications at the transport layer. Using MINT, an access point can be configured to only communicate with other authorized (MINT enabled) access points of the same model. Virtual Controller AP managed access points can communicate with each other exclusively over a MINT security domain.
Page 252 5 - 166 WiNG 5.5 Access Point System Reference Guide 3. Define the following Device Heartbeat Settings in respect to devices supported by the profile: Designated IS Priority Use the spinner control to set a Designated IS Priority Adjustment setting from -255 Adjustment and 255.
Page 253 Device Configuration 5 - 167 Figure 5-104 Advanced Profile Configuration- MINT Protocol screen - Add IP MiNT Link field 11. Set the following Link IP parameters to complete the MINT network address configuration: Define the IP address used by peer access points for interoperation when supporting the MINT protocol.
Page 254 5 - 168 WiNG 5.5 Access Point System Reference Guide IPSec GW Define either an IP address or hostname for the IPSec gateway. 12. Select the VLAN tab to display the link IP VLAN information shared by the devices managed by the MINT configuration.
Page 255 Device Configuration 5 - 169 Figure 5-106 Advanced Profile Configuration - MINT Protocol screen - Add/edit VLAN field 14. Set the following parameters to add or modify MINT VLAN configuration: VLAN If adding a new VLAN, define a VLAN ID from 1 - 4,094 used by peers for interoperation when supporting the MINT protocol.
Page 256: Advanced Profile Miscellaneous Configuration
5 - 170 WiNG 5.5 Access Point System Reference Guide 5.2.13.3 Advanced Profile Miscellaneous Configuration Advanced Profile Configuration Refer to the advanced profile’s Miscellaneous menu item to set the profile’s NAS configuration. The profile database on the RADIUS server consists of user profiles for each connected network access server (NAS) port. Each profile is matched to a username representing a physical port.
Page 257: Environmental Sensor Configuration
Device Configuration 5 - 171 6. Set the appropriate Root Path Monitor Interval value. This setting configures the frequency at which the path to the root mesh point is monitored. 7. Set the Additional Port value for RADIUS Dynamic Authorization field.
Page 258 5 - 172 WiNG 5.5 Access Point System Reference Guide Figure 5-108 Profile - Environmental Sensor screen 5. Set the following Light Sensor settings for the AP8132’s sensor module:. Enable Light Sensor Select this option to enable the light sensor on the module. This setting is enabled by default.
Page 259 Device Configuration 5 - 173 Enable Motion Sensor Select this option to enable the module’s motion sensor. Results are reported back to the access point’s Environment screens within the Statistics node. This setting is enabled by default. Enable Humidity Sensor Select this option to enable the module’s humidity sensor.
Page 260: Managing Virtual Controllers
Virtual Controller AP of the same model. NOTE: If designating the access point as a Standalone AP, Motorola Solutions recommends the access point’s UI be used exclusively to define its device configuration, and not the CLI.
Page 261 Device Configuration 5 - 175 4. The Virtual Controller AP screen lists all peer access points within this Virtual Controller’s radio coverage area. Each listed access point is listed by its assigned System Name, MAC Address and Virtual Controller designation. Only Standalone APs of the same model can have their Virtual Controller AP designation changed.
Page 262: Overriding A Device Configuration
5 - 176 WiNG 5.5 Access Point System Reference Guide 5.4 Overriding a Device Configuration Device Configuration Devices within the access point managed network can have an override configuration defined and applied. New devices can also have an override configuration defined and applied once NOTE: The best way to administer a network populated by numerous access points is to configure them directly from the designated Virtual Controller AP.
Page 263 Device Configuration 5 - 177 Figure 5-111 Device Overrides - Basic Configuration screen 5. Set the following Configuration settings for the target device: System Name Provide the selected device a system name up to 64 characters in length. This is the device name that appears within the RF Domain or Profile the access point supports and is identified by.
Page 264: Certificate Management
5 - 178 WiNG 5.5 Access Point System Reference Guide Refer to the Device Time parameter to assess the device’s current time. If the device’s time has not been set, the device time is displayed as unavailable. Select Refresh to update the device’s system time.
Page 265 Device Configuration 5 - 179 Figure 5-112 Device Overrides - Certificates screen 6. Set the following Management Security certificate configurations: HTTPS Trustpoint Either use the default-trustpoint or select the Stored radio button to enable a drop-down menu where an existing certificate/trustpoint can be leveraged. To leverage an existing device certificate for use with this target device, select the Launch Manager button.
Page 266: Manage Certificates
5 - 180 WiNG 5.5 Access Point System Reference Guide For more information on the certification activities, refer to the following: • Manage Certificates • RSA Key Management • Certificate Creation • Generating a Certificate Signing Request 5.4.2.1 Manage Certificates...
Page 267 Device Configuration 5 - 181 2. Select a device from amongst those displayed to review its certificate information. Refer to Certificate Details to review the certificate’s properties, self-signed credentials, validity period and CA information. 3. To optionally import a certificate, select the Import button from the Certificate Management...
Page 268 5 - 182 WiNG 5.5 Access Point System Reference Guide 4. Define the following configuration parameters required for the Import of the trustpoint: Import Select the type of Trustpoint to import. The following Trustpoints can be imported: • Import – Select to import any trustpoint.
Page 269 Device Configuration 5 - 183 Host If using Advanced settings, provide the hostname of the server used to import the trustpoint. This option is not valid for cf, usb1, usb2, usb3 and usb4. Username/Password These fields are enabled if using ftp or sftp protocols. Specify the username and the password for that username to access the remote servers using these protocols.
Page 270 5 - 184 WiNG 5.5 Access Point System Reference Guide 9. Define the following configuration parameters to export a trustpoint: Trustpoint Name Enter the 32 character maximum name assigned to the target trustpoint. The trustpoint signing the certificate can be a certificate authority, corporation or individual.
Page 271 Device Configuration 5 - 185 1. Select the Launch Manager button from either the SSH RSA Key or RADIUS Server Certificate parameters (within the Certificate Management screen). 2. Select RSA Keys from the upper, left-hand side of the Certificate Management screen.
Page 272 Enter the 32 character maximum name assigned to the RSA key. Key Size Use the spinner control to set the size of the key (from 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting of 1024 to ensure optimum functionality.
Page 273 Device Configuration 5 - 187 Key Passphrase Define the key used by both the access point and the server (or repository) of the target RSA key. Select the Show option to expose the actual characters used in the passphrase. Leaving the Show option unselected displays the passphrase as a series of asterisks “*”. Provide the complete URL to the location of the RSA key.
Page 274 5 - 188 WiNG 5.5 Access Point System Reference Guide Figure 5-119 Certificate Management - Export RSA Key screen 12. Define the following configuration parameters required to export a RSA key: Key Name Enter the 32 character maximum name assigned to the RSA key.
Page 275 Device Configuration 5 - 189 IP Address If selecting Advanced, enter the IP address of the server used to export the RSA key. This option is not valid for cf, usb1, usb2, usb3 and usb4. Host If selecting Advanced, provide the hostname of the server used to export the RSA key. This option is not valid for cf, usb1, usb2, usb3 and usb4.
Page 276 RSA key. Use the spinner control to set the size of the key (from 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting (1024) to ensure optimum functionality. For more information on creating a new RSA key, see...
Page 277 Device Configuration 5 - 191 State (ST) Enter a State for the state or province name used in the certificate. This is a required field. City (L) Enter a City to represent the city name used in the certificate. This is a required field. Organization (O) Define an Organization for the organization used in the certificate.
Page 278 RSA key. Use the spinner control to set the size of the key (from 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting (1024) to ensure optimum functionality. For more information on creating a new RSA key, see...
Page 279: Rf Domain Overrides
Device Configuration 5 - 193 Organizational Unit (OU) Enter an Organizational Unit for the name of the organization unit used in the CSR. This is a required field. Common Name (CN) If there’s a Common Name (IP address) for the organizational unit issuing the certificate, enter it here.
Page 280 5 - 194 WiNG 5.5 Access Point System Reference Guide Figure 5-122 Device Overrides -RF Domain Overrides screen NOTE: A blue override icon (to the left of a parameter) defines the parameter as having an override applied. To remove a device’s override, go to the Basic Configuration screen’s Device Overrides field, and then select the Clear Overrides button.
Page 281: Wired 802.1X Overrides
Device Configuration 5 - 195 9. Select to save the changes and overrides made to the RF Domain configuration. Selecting Reset reverts the screen to its last saved configuration. 5.4.4 Wired 802.1X Overrides Overriding a Device Configuration 802.1X provides administrators secure, identity based access control as another data protection option to utilize with a device profile.
Page 282: Device Overrides
5 - 196 WiNG 5.5 Access Point System Reference Guide 5.4.5 Device Overrides Overriding a Device Configuration A profile enables an administrator to assign a common set of configuration parameters and policies to another access point of the same model. Profiles can be used to assign shared or unique network, wireless and security parameters to access points across a large, multi segment, site.
Page 283 Device Configuration 5 - 197 7. Select + Add Row below the Network Time Protocol (NTP) table to define (or override) the configurations of NTP server resources used it obtain system time. Set the following parameters to define the NTP configuration: AutoKey Select this option to enable an autokey configuration for the NTP resource.
Page 284: Radio Power Overrides
5 - 198 WiNG 5.5 Access Point System Reference Guide 5.4.5.1 Radio Power Overrides Device Overrides Use the Power screen to set or override one of two power modes (3af or Auto) for an access point. When Automatic is selected, the access point safely operates within available power.
Page 285 Device Configuration 5 - 199 Figure 5-125 Device Overrides - Power screen 7. Use the Power Mode drop-down menu to set or override the Power Mode Configuration on this AP. NOTE: Single radio model access point’s always operate using a full power configuration.
Page 286: Adoption Overrides
5 - 200 WiNG 5.5 Access Point System Reference Guide 5.4.5.2 Adoption Overrides Device Overrides Use the Adoption screen to define the configuration of a preferred Virtual Controller, wireless controller, or service platform resource used for access point adoption. A Virtual Controller can adopt up to 24 access points of the same model. The Virtual Controller must also share its VLAN to peer access points wishing to adopt to it.
Page 287 Device Configuration 5 - 201 Figure 5-126 Device Overrides - Adoption screen 7. Define a 64 character maximum Preferred Group. The preferred group is the controller group the access point would prefer to connect upon adoption. 8. Define the Hello Interval value for this device.
Page 288 5 - 202 WiNG 5.5 Access Point System Reference Guide IPSec Support Select to enable secure communication between the access point and the wireless controllers. IPSec GW Use the drop-down menu to specify if the IPSec Gateway resource is defined as a (non DNS) IP address or a hostname.
Page 289: Profile Interface Override Configuration
Device Configuration 5 - 203 5.4.5.3 Profile Interface Override Configuration Device Overrides An access point requires its Virtual Interface be configured for layer 3 (IP) access or layer 3 service on a VLAN. A virtual interface defines which IP address is associated with each connected VLAN ID. An interface configuration can have overrides applied to customize the configuration to a unique deployment objective.
Page 290 5 - 204 WiNG 5.5 Access Point System Reference Guide Figure 5-127 Device Overrides - Interface Ethernet Port screen 7. Refer to the following to review port status and assess whether an override is warranted: Name Displays the physical port name reporting runtime data and statistics. Supported ports vary depending on the supported models.
Page 291 Device Configuration 5 - 205 Overrides Click the Clear to clear overrides made to this interface. This field is blank if there are no overrides for this configuration. 8. To edit (or override) the configuration of an existing port, select it from amongst those displayed and select the Edit button.
Page 292 5 - 206 WiNG 5.5 Access Point System Reference Guide Duplex Select either half, full or automatic as the duplex option. Select Half duplex to send data over the port, then immediately receive data from the same direction in which the data was transmitted.
Page 293 Device Configuration 5 - 207 Allowed VLANs Selecting Trunk as the mode enables the Allowed VLANs parameter. Add VLANs that exclusively send packets over the listed port. 11. Optionally select the Port Channel Membership option and define (or override) a setting from 1 - 8 using the spinner control.
Page 294 5 - 208 WiNG 5.5 Access Point System Reference Guide Trust DHCP Responses Select this option to enable DHCP trust on this port. If enabled, only DHCP responses are trusted and forwarded on this port, and a DHCP server can be connected only to a DHCP trusted port.
Page 295 Device Configuration 5 - 209 20. Select the Spanning Tree tab. Figure 5-130 Ethernet Ports – Spanning Tree Configuration Spanning Tree Protocol (STP) (IEEE 802.1D standard) configures a meshed network for robustness by eliminating loops within the network and calculating and storing alternate paths to provide fault tolerance. STP calculation happens when a port comes up.
Page 296 5 - 210 WiNG 5.5 Access Point System Reference Guide messages conveys spanning tree information for each instance. Each instance can be assigned a number of configured VLANs. The frames assigned to these VLANs operate in this spanning tree instance whenever they are inside the MST region.
Page 297 Device Configuration 5 - 211 administration. A Virtual Interface is also used to map VLANs to IP address ranges. This mapping determines the destination networks for routing. To review existing Virtual Interface configurations and either create a new Virtual Interface configuration, modify (override) an existing configuration or delete an existing configuration: 1.
Page 298 5 - 212 WiNG 5.5 Access Point System Reference Guide Admin Status A green check mark defines the listed Virtual Interface configuration as active and enabled with its supported profile. A red “X” defines the Virtual Interface as currently disabled. The interface status can be modified when a new Virtual Interface is created or an existing one modified.
Page 299 Device Configuration 5 - 213 11. Define or override the following parameters from within the Properties field: Description Provide or edit a description (up to 64 characters) for the Virtual Interface that helps differentiate it from others with similar configurations. Admin Status Either select the Disabled or Enabled radio button to define this interface’s current status within the network.
Page 300 5 - 214 WiNG 5.5 Access Point System Reference Guide 15. Select the Security tab. The firewall inspects and packet traffic to and from connected clients. If a firewall rule does not exist suiting the data protection needs of this Virtual Interface, select the...
Page 301 Device Configuration 5 - 215 Figure 5-134 Device Overrides – Virtual Interfaces Dynamic Routing screen 19. Refer to the following to configure OSPF Settings. Priority Select this option to enable or disable OSPF priority settings. Use the spinner to configure a value from 0 - 255.
Page 302 5 - 216 WiNG 5.5 Access Point System Reference Guide 21. Refer the following to configure MD5 Authentication keys. Select the + Add Row button to add a row to the table. Key ID Set the unique MD5 Authentication key ID. The available key ID range is 1 - 255.
Page 303 Device Configuration 5 - 217 Admin Status A green check mark defines the listed port channel as active and currently enabled with the access point’s profile. A red “X” defines the port channel as currently disabled and not available for use. The interface status can be modified with the port channel configuration as required 7.
Page 304 5 - 218 WiNG 5.5 Access Point System Reference Guide Duplex Select either Half, Full or Automatic as the duplex option. Select Half duplex to send data over the port channel, then immediately receive data from the same direction in which the data was transmitted.
Page 305 Device Configuration 5 - 219 Figure 5-137 Device Overrides - Port Channels - Security tab 13. Refer to the Access Control field. As part of the port channel’s security configuration, Inbound IP and MAC address firewall rules are required. Use the Inbound IP Firewall Rules Inbound MAC Firewall Rules drop-down menus to select firewall rules to...
Page 306 5 - 220 WiNG 5.5 Access Point System Reference Guide Trust IP DSCP Select this option to enable IP DSCP values on this port channel. The default value is enabled. 15. Select to save the changes to the security configuration. Select Reset to revert to the last saved configuration.
Page 307 Device Configuration 5 - 221 18. Set the following MSTP Configuration parameters for the port channel: Enable as Edge Port Select this option to define this port as an edge port. Using an edge (private) port, you can isolate devices to prevent connectivity over this port channel. This setting is disabled by default.
Page 308 5 - 222 WiNG 5.5 Access Point System Reference Guide 22. Select + Add Row needed to include additional indexes. 23. Select to save the changes made to the Ethernet Port Spanning Tree configuration. Select Reset to revert to the last saved configuration.
Page 309 Device Configuration 5 - 223 7. Review the following radio configuration data to determine whether a radio configuration requires modification or override: Name Displays whether the reporting radio is the access point’s radio1, radio2 or radio3. AP7131 models can support up to 3 radios. AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232, AP7181 and AP7161 models support 2 radios and AP6511 and AP6521 models support a single radio.
Page 310 5 - 224 WiNG 5.5 Access Point System Reference Guide Figure 5-140 Device Overrides - Access Point Radio Settings tab 9. The Radio Settings tab displays by default. 10. Define or override the following radio configuration Properties: Description Provide or edit a description (1 - 64 characters in length) for the radio that helps differentiate it from others with similar configurations.
Page 311 Motorola Solutions recommends only a professional installer set the antenna gain. The default value is 0.00.
Page 312 5 - 226 WiNG 5.5 Access Point System Reference Guide Enable Antenna Diversity Select this option for the radio to dynamically change the number of transmit chains. This option is enabled by default. Wireless Client Power Select this option to enable a spinner control for client radio power transmissions in dBm.
Page 313 Device Configuration 5 - 227 12. Set or override the following profile WLAN Properties for the selected access point radio. Beacon Interval Set the interval between radio beacons in milliseconds (either 50, 100 or 200). A beacon is a packet broadcast by adopted radios to keep the network synchronized. Included in a beacon is information such as the WLAN service area, the radio address, the broadcast destination addresses, a time stamp, and indicators about traffic and delivery such as a DTIM.
Page 314 5 - 228 WiNG 5.5 Access Point System Reference Guide Guard Interval Use the drop-down menu to specify a Long or Any guard interval. The guard interval is the space between symbols (characters) being transmitted. The guard interval eliminates inter-symbol interference (ISI). ISI occurs when echoes or reflections from one symbol interfere with another symbol.
Page 315 Device Configuration 5 - 229 Figure 5-142 Device Overrides - Access Point Radio - Mesh tab 17. Use the Mesh Legacy screen to define or override how mesh connections are established and the number of links available amongst access points within the Mesh network. 18.
Page 316 5 - 230 WiNG 5.5 Access Point System Reference Guide Figure 5-143 Device Overrides - Access Point Radio Advanced Settings tab 22. Refer to the Aggregate MAC Protocol Data Unit (A-MPDU) field to define or override how MAC service frames are aggregated by the access point radio.
Page 317 Device Configuration 5 - 231 25. Set or override the following profile Ekahau Properties for the selected access point radio. Forwarding host Provide the IP address of the host to which Ekahau packets are forwarded to. Forwarding Port Use the spinner to provide the Ekahau forwarding port number. MAC to be Enter the MAC address that is incorporated in the Ekahau packets that are forwarded.
Page 318 5 - 232 WiNG 5.5 Access Point System Reference Guide including twisted pair or fiber optic lines or satellite transmission. It uses a variation of High Speed Data Link Control (HDLC) for packet encapsulation. For a list of supported 3G cards, see WAN Backhaul Configuration on page 5-51.
Page 319 Device Configuration 5 - 233 Reset WAN Card If the WAN card becomes unresponsive or is experiencing other errors click the Reset WAN Card button to power cycle and reboot the WAN card. Enable WAN (3G) Select this option to enable 3G WAN card support on the device. A supported 3G card must be connected to the device for this feature to work.
Page 320 5 - 234 WiNG 5.5 Access Point System Reference Guide NOTE: PPPoE is supported on AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232, AP7131, AP7181 and AP7161 models and is not available on AP6511 and AP6521 model access points. When PPPoE client operation is enabled, it discovers an available server and establishes a PPPoE link for traffic slow. When a wired WAN connection failure is detected, traffic flows through the WWAN interface in fail-over mode (if the WWAN network is configured and available).
Page 321 Device Configuration 5 - 235 Figure 5-145 Device Overrides - PPPoE screen 6. Use the Basic Settings field to enable PPPoE and define a PPPoE client: Enable PPPoE Select Enable PPPoE to support a high speed client mode point-to-point connection using the PPPoE protocol.
Page 322 5 - 236 WiNG 5.5 Access Point System Reference Guide 7. Define the following Authentication parameters for PPPoE client interoperation: Username Provide the 64 character maximum username used for authentication support by the PPPoE client. Password Provide the 64 character maximum password used for authentication by the PPPoE client.
Page 323: Overriding The Network Configuration
Device Configuration 5 - 237 5.4.5.4 Overriding the Network Configuration Device Overrides Setting a network configuration is a large task comprised of numerous administration activities. Each of the configuration activities described can have an override applied to the original configuration. Applying an override differentiates the device from the profile’s configuration and requires careful administration to ensure this one device still supports the deployment requirements within the network.
Page 324 5 - 238 WiNG 5.5 Access Point System Reference Guide Figure 5-146 Device Overrides - Network DNS screen NOTE: A blue override icon (to the left of a parameter) defines the parameter as having an override applied. To remove an override, go to the Basic Configuration screen’s Device...
Page 325 Device Configuration 5 - 239 as needed, but removes the device configuration from the managed profile that may be shared with other similar device models. When an incoming packet destined for a host arrives at the access point, the access point’s gateway uses ARP to find a physical host or MAC address that matches the IP address.
Page 326 5 - 240 WiNG 5.5 Access Point System Reference Guide Device Type Specify the device type the ARP entry supports (either Host, Router or DHCP Server). Host is the default setting. 7. Select the OK button to save the changes and overrides to the ARP configuration. Select Reset to revert to the last saved configuration.
Page 327 Device Configuration 5 - 241 5. Select L2TP NOTE: A blue override icon (to the left of a parameter) defines the parameter as having an override applied. To remove an override, go to the Basic Configuration screen’s Device Overrides field and select Clear Overrides.
Page 328 5 - 242 WiNG 5.5 Access Point System Reference Guide Figure 5-149 Device Overrides - Network - L2TPv3 screen, T2TP tunnel tab 8. Set the following for an L2TPv3 profile configuration: Name Displays the name of each listed L2TPv3 tunnel assigned upon creation.
Page 329 Device Configuration 5 - 243 Figure 5-150 Device Overrides - Network - L2TPv3 screen, Add T2TP Tunnel Configuration 10. If creating a new tunnel configuration, assign it a 31 character maximum Name. 11. Define the following Settings required for the L2TP tunnel configuration: Local IP Address Enter the IP address assigned as the local tunnel end point address, not the interface IP address.
Page 330 5 - 244 WiNG 5.5 Access Point System Reference Guide Use Tunnel Policy Select the L2TPv3 tunnel policy. The policy consists of user defined values for protocol specific parameters which can be used with different tunnels. If none is available a new policy can be created or an existing one can be modified.
Page 331 Device Configuration 5 - 245 14. Define the following Peer parameters: Peer ID Define the primary peer ID used to set the primary and secondary peer for tunnel failover. If the peer is not specified, tunnel establishment does not occur. However, if a peer tries to establish a tunnel with this access point, it creates the tunnel if the hostname and/or router ID matches.
Page 332 5 - 246 WiNG 5.5 Access Point System Reference Guide Figure 5-152 Device Overrides - Network - L2TPv3 screen, Manual Session tab 21. Refer to the following manual session configurations to determine whether one should be created or modified: IP Address Lists the IP address assigned as the local tunnel end point address, not the interface IP address.
Page 333 Device Configuration 5 - 247 Figure 5-153 Device Overrides - Network - L2TPv3 screen, Add T2TP Peer Configuration 23. Set the following session parameters: Name Define a 31 character maximum name of this tunnel session. After a successful tunnel connection and establishment, the session is created. Each session name represents a single data stream.
Page 334 5 - 248 WiNG 5.5 Access Point System Reference Guide Encapsulation Select either IP or UDP as the peer encapsulation protocol. The default setting is IP. UDP uses a simple transmission model without implicit handshakes. UDP Port If UDP encapsulation is selected, use the spinner control to define the UDP encapsulation port.
Page 335 Device Configuration 5 - 249 Figure 5-154 Device Overrides - Network - IGMP Snooping Screen 6. Set the following parameters to configure general IGMP Snooping values. Enable IGMP Snooping Select the box to enable IGMP Snooping on the access point. This feature is enabled by default.
Page 336 5 - 250 WiNG 5.5 Access Point System Reference Guide Maximum Response Time Specify the maximum time (from 1 - 25 seconds) before sending a responding report. When no reports are received from a radio, radio information is removed from the IGMP snooping table.
Page 337 Device Configuration 5 - 251 Figure 5-155 Device Overrides - Network QoS screen 6. Set or override the following parameters for the IP DSCP mappings for untagged frames: DSCP Lists the DSCP value as a 6-bit parameter in the header of every IP packet used for packet classification.
Page 338 5 - 252 WiNG 5.5 Access Point System Reference Guide If there’s just one VLAN in the access point managed network, a single spanning tree works fine. However, if the network contains more than one VLAN, the network topology defined by single STP would work, but it’s possible to make better use of the alternate paths available by using an alternate spanning tree for different VLANs or groups of VLANs.
Page 339 Device Configuration 5 - 253 Figure 5-156 Device Overrides - Network - Spanning Tree screen 6. Set the following MSTP Configuration parameters: MSTP Enable Select this option to enable MSTP for this profile. MSTP is disabled by default, so if requiring different (groups) of VLANs with the profile supported network segment.
Page 340 5 - 254 WiNG 5.5 Access Point System Reference Guide Forward Delay Set the forward delay time from 4 - 30 seconds. When a device is first attached to a port, it does not immediately start to forward data. It first processes BPDUs and determines the network topology.
Page 341 Device Configuration 5 - 255 3. Select a target device from the device browser in the lower, left-hand, side of the UI. 4. Select Network to expand its sub menu options. 5. Select Routing. Figure 5-157 Device Overrides - Network - Network Routing screen 6.
Page 342 5 - 256 WiNG 5.5 Access Point System Reference Guide Enable Routing Failure When selected, all default gateways are monitored for activity. The system will failover to a live gateway if the current gateway becomes unusable. This feature is enabled by default.
Page 343 Device Configuration 5 - 257 5. Select OSPF. Figure 5-158 Device Overrides - Network - OSPF Settings screen 6. Enable/disable OSPF and provide the following dynamic routing settings: Enable OSPF Select this option to enable OSPF for this access point. OSPF is disabled by default. Router ID Select this option to define a router ID (numeric IP address) for this access point.
Page 344 5 - 258 WiNG 5.5 Access Point System Reference Guide VRRP Mode Check Select this option to enable checking VRRP state. If the interface’s VRRP state is not Backup, then the interface is published via OSPF. 7. Set the following OSPF Overload Protection settings: Number of Routes Use the spinner controller to set the maximum number of OSPN routes permitted.
Page 345 Device Configuration 5 - 259 Figure 5-159 Device Overrides - Network - OSPF Area Settings screen 17. Review existing Area Settings configurations using: Area ID Displays either the IP address or integer representing the OSPF area. Authentication Type Lists the authentication schemes used to validate the credentials of dynamic route connections.
Page 346 5 - 260 WiNG 5.5 Access Point System Reference Guide Figure 5-160 Device Overrides - Network - OSPF Area Configuration screen 19. Set the OSPF Area configuration. Area ID Use the drop-down menu and specify either an IP address or Integer for the OSPF area.
Page 347 Device Configuration 5 - 261 Figure 5-161 Device Overrides - Network - OSPF Interface Settings screen 22. Review existing Interface Settings using: Name Displays the name defined for the interface configuration. Type Displays the type of interface. Description Lists each interface’s 32 character maximum description. Admin Status Displays whether Admin Status privileges have been enabled or disabled for the OSPF route’s virtual interface connection.
Page 348 5 - 262 WiNG 5.5 Access Point System Reference Guide Figure 5-162 Device Overrides - Network - OSPF Virtual Interface - Basic Configuration screen 24. Within the Properties field, enter a 32 character maximum Description to help differentiate the virtual interface configuration used with this OSPF route.
Page 349 Device Configuration 5 - 263 • Outside - Packets passing through the NAT on the way back to the LAN are searched against the records kept by the NAT engine. There the destination IP address is changed back to the specific internal private class IP address in order to reach the LAN over the network.
Page 350 5 - 264 WiNG 5.5 Access Point System Reference Guide Figure 5-164 OSPF Virtual Interface - Dynamic Routing screen 36. Refer to the following to configure OSPF Settings. Priority Select to enable or disable OSPF priority settings. Use the spinner to configure a value in the range 0-255.
Page 351 Device Configuration 5 - 265 37. Configure the OSPF Authentication Type settings by selecting from the drop-down list. The available options are None, Null, simple-password and message-digest. 38. Refer the following to configure MD5 Authentication keys. Click the + Add Row button to add a row to the table.
Page 352 5 - 266 WiNG 5.5 Access Point System Reference Guide Figure 5-165 Device Overrides - Network Forwarding Database screen 6. Define or override a Bridge Aging Time from 0, 10-1,000,000 seconds. The aging time defines the length of time an entry will remain in the a bridge’s forwarding table before being deleted due to lack of activity.
Page 353 Device Configuration 5 - 267 Administrators often need to route traffic to interoperate between different VLANs. Bridging VLANs are only for non-routable traffic, like tagged VLAN frames destined to some other device which will untag it. When a data frame is received on a port, the VLAN bridge determines the associated VLAN based on the port of reception.
Page 354 5 - 268 WiNG 5.5 Access Point System Reference Guide Edge VLAN Mode Defines whether the VLAN is currently in edge VLAN mode. An edge VLAN is the VLAN where hosts are connected. For example, if VLAN 10 is defined with wireless clients and VLAN 20 is where the default gateway resides, VLAN 10 should be marked as an edge VLAN and VLAN 20 shouldn’t be marked as an edge VLAN.
Page 355 Device Configuration 5 - 269 9. If creating a new Bridge VLAN, provide a Description (up to 64 characters) unique to the VLAN’s specific configuration to help differentiate it from other VLANs with similar configurations. 10. Select the Per VLAN Firewall option to enable firewall on this interface.
Page 356 5 - 270 WiNG 5.5 Access Point System Reference Guide Edge VLAN Mode Select this option to enable edge VLAN mode. When selected, the IP address in the VLAN is not used for normal operations, as its now designated to isolate devices and prevent connectivity.
Page 357 Device Configuration 5 - 271 18. Set the following parameters for IGMP Querier configuration: Enable IGMP Querier Select this option to enable IGMP querier. IGMP snoop querier is used to keep host memberships alive. It is primarily used in a network where there is a multicast streaming server and hosts subscribed to the server and no IGMP querier present.
Page 358 5 - 272 WiNG 5.5 Access Point System Reference Guide Figure 5-169 Cisco Discovery Protocol (CDP) screen 6. Enable/disable CDP and set the following timer settings: Enable CDP Select this option to enable CDP and allow for network address discovery of Cisco supported devices and operating system version.
Page 359 Device Configuration 5 - 273 3. Select a target device from the device browser in the lower, left-hand, side of the UI. 4. Select Network to expand its sub menu options. 5. Select Link Layer Discovery Protocol. Figure 5-170 Link Layer Discovery Protocol (LLDP) screen 6.
Page 360 5 - 274 WiNG 5.5 Access Point System Reference Guide To include a hostnames in DHCP request: 1. Select Devices from the Configuration tab. 2. Select Device Overrides from the Device menu to expand it into sub menu options. 3. Select a target device from the device browser in the lower, left-hand side of the UI.
Page 361 Device Configuration 5 - 275 5.4.5.4.14Overriding Alias Configuration Overriding the Network Configuration With large deployments, the configuration of remote sites utilizes a set of shared attributes, of which a small set of attributes are unique for each location. For such deployments, maintaining separate configuration (WLANs, profiles, policies and ACLs) for each remote site is complex.
Page 362 5 - 276 WiNG 5.5 Access Point System Reference Guide 2. Select Device Overrides from the Device menu to expand it into sub menu options. 3. Select a target device from the device browser in the lower, left-hand side of the UI.
Page 363 Device Configuration 5 - 277 • Switchport • Wireless LANs 7. Select + Add Row to define Host Alias settings. Use the Host Alias field to create aliases for hosts that can be utilized at different deployments. For example, if a central network DNS server is set a static IP address, and a remote location’s local DNS server is defined, this host can be overridden at the remote location.
Page 364 5 - 278 WiNG 5.5 Access Point System Reference Guide 10. Select + Add Row to define String Alias settings. Use the String Alias field to create aliases for strings that can be utilized at different deployments. For example, if the main domain at a remote location is called loc1.domain.com and at another deployment location it is called...
Page 365 Device Configuration 5 - 279 Figure 5-173 Network - Alias - Network Group Alias screen Name Displays the administrator assigned name of the Network Group Alias. Host Displays all host aliases configured in this network group alias. Displays a blank column if no host alias is defined.
Page 366 5 - 280 WiNG 5.5 Access Point System Reference Guide Figure 5-174 Network - Alias - Network Group Alias Add screen 8. If adding a new Network Group Alias, provide it a name of up to 32 characters. NOTE: The Network Group Alias Name always starts with a dollar sign ($).
Page 367 Device Configuration 5 - 281 5.4.5.4.17Network Service Alias Overriding Alias Configuration Network Service Alias is a set of configurations that consist of protocol and port mappings. Both source and destination ports are configurable. For each protocol, up to 2 source port ranges and up to 2 destination port ranges can be configured. A maximum of 4 protocol entries can be configured per Network Service Alias.
Page 368: Overriding A Security Configuration
5 - 282 WiNG 5.5 Access Point System Reference Guide Figure 5-176 Network - Alias - Network Service Alias Add screen 8. If adding a new Network Service Alias, provide it a name up to 32 characters. NOTE: The Network Service Alias Name always starts with a dollar sign ($).
Page 369 Device Configuration 5 - 283 device’s deployed environment. However, in doing so this device must now be managed separately from the profile configuration shared by other identical models within the network. For more information on applying an override to an existing device profile, refer to the following sections: •...
Page 370 5 - 284 WiNG 5.5 Access Point System Reference Guide 5.4.5.5.2 Quick Setup Wizard Overriding General Security Settings The Quick Setup Wizard creates a VPN connection with minimum manual configuration. Default values are retained for most of the parameters. Figure 5-178 VPN Quick Setup Wizard 1.
Page 371 Device Configuration 5 - 285 Select Interface Configure the interface for creating the tunnel. The following options are available: • VLAN – Configures the tunnel over a Virtual LAN interface. Use the spinner to configure the VLAN number. • WWLAN – Configures the tunnel over the WWLAN interface. •...
Page 372 5 - 286 WiNG 5.5 Access Point System Reference Guide Figure 5-179 VPN Step-By-Step Wizard - Step 1 3. Define the following: Tunnel Name Provide a name for the tunnel in the Tunnel Name field. Tunnel Type Select the tunnel type being created. Two types of tunnels can be created. Site to Site is used to create a tunnel between two remote sites as indicated in the image.
Page 373 Device Configuration 5 - 287 Figure 5-180 VPN Step-By-Step Wizard - Step 2 5. In Step 2 screen, configure the following parameters: Peer Select the type of peer for this device when forming a tunnel. Peer information can be either IP Address or Host Name.
Page 374 5 - 288 WiNG 5.5 Access Point System Reference Guide 6. Click the Add Peer button to add the Tunnel peer information into the Peer(s) table. This table lists all the peers configured for the VPN Tunnel. 7. Click the Next button to go to the next configuration screen.
Page 375 Device Configuration 5 - 289 Mode This field is enabled when Create New Policy is selected in Transform Set field. The mode indicates how packets are transported through the tunnel. • Tunnel – Use this mode when the tunnel is between two routers or servers. •...
Page 376 5 - 290 WiNG 5.5 Access Point System Reference Guide 3. Select a target device from the device browser in the lower, left-hand, side of the UI. 4. Select Security to expand its sub menu options. 5. Select Auto IPSec Tunnel to configure its parameters.
Page 377 Select this option to require devices using this profile to use a WEP key to access the Authentication network using this profile. Clients without Motorola Solutions adapters need to use WEP keys manually configured as hexadecimal numbers. This option is disabled by default.
Page 378 5 - 292 WiNG 5.5 Access Point System Reference Guide 5.4.5.5.6 Overriding a Certificate Revocation List (CRL) Configuration Overriding a Security Configuration A certificate revocation list (CRL) is a list of certificates that have been revoked or are no longer valid. A certificate can be revoked if the certificate authority (CA) had improperly issued a certificate, or if a private-key is compromised.
Page 379 Device Configuration 5 - 293 9. Use the spinner control within the Hours field to specify an interval (in hours) after which the access point copies a CRL file from an external server and associates it with a trustpoint. 10. Select to save the changes and overrides made within the Certificate Revocation screen.
Page 380 5 - 294 WiNG 5.5 Access Point System Reference Guide Figure 5-186 Device Overrides - NAT Pool screen 6. The Pool tab displays by default. The NAT Pool screen lists those NAT policies created thus far. Any of these policies can be selected and applied to a profile.
Page 381 Device Configuration 5 - 295 8. If adding a new NAT policy or editing the configuration of an existing policy, define the following parameters: Name If adding a new NAT policy, provide a name to help distinguish it from others with similar configurations.
Page 382 5 - 296 WiNG 5.5 Access Point System Reference Guide Figure 5-189 Device Overrides - Add NAT Source screen 12. Define the following Source NAT parameters: Protocol Select the protocol for use with static translation. TCP, UDP and Any are the available options.
Page 383 Device Configuration 5 - 297 NAT Port Enter the port number of the matching packet to the specified value. This option is valid only if the direction specified is destination. Network Select Inside or Outside NAT as the network direction. The default setting is Inside. Select Inside to create a permanent, one-to-one mapping between an address on an internal network and a perimeter or external network.
Page 384 5 - 298 WiNG 5.5 Access Point System Reference Guide Figure 5-191 Device Overrides - Add Destination NAT screen 15. Set or override the following Destination configuration parameters: 16. Static NAT creates a permanent, one-to-one mapping between an address on an internal network and a perimeter or external network.
Page 385 Device Configuration 5 - 299 Network Select Inside or Outside NAT as the network direction. Inside is the default setting. Select Inside to create a permanent, one-to-one mapping between an address on an internal network and a perimeter or external network. To share a Web server on a perimeter interface with the Internet, use static address translation to map the actual address to a registered IP address.
Page 386 5 - 300 WiNG 5.5 Access Point System Reference Guide Network Displays Inside or Outside NAT as the network direction for the dynamic NAT configuration. Interface Lists the VLAN (from 1 - 4094) used as the communication medium between the source and destination points within the NAT configuration.
Page 387 Device Configuration 5 - 301 Interface Select the VLAN (from 1 - 4094) or WWAN used as the communication medium between the source and destination points within the NAT configuration. Ensure the VLAN selected adequately supports the intended network traffic within the NAT supported configuration. Overload Type Define the overload type utilized when Several internal addresses are NATed to only one or a few external addresses.
Page 388 5 - 302 WiNG 5.5 Access Point System Reference Guide Figure 5-194 Profile Override - Security - Bridge NAT screen 5. Review the following Bridge NAT configurations to determine whether a new Bridge NAT configuration requires creation or an existing configuration overridden or removed: Lists the ACL applying IP address access/deny permission rules to the Bridge NAT configuration.
Page 389 Device Configuration 5 - 303 Figure 5-195 Profile Security - Dynamic NAT screen 7. Select the whose IP rules are applied to this policy based forwarding rule. A new ACL can be defined by selecting the Create icon, or an existing set of IP ACL rules can be modified by selecting the Edit icon.
Page 390 5 - 304 WiNG 5.5 Access Point System Reference Guide Figure 5-196 Profile Security - Source Dynamic NAT screen - Add Row field 11. Select to save the changes made within the Add Row Dynamic NAT screens. Select Reset to revert to the last...
Page 391: Overriding The Virtual Router Redundancy Protocol (Vrrp) Configuration
Device Configuration 5 - 305 5.4.5.6 Overriding the Virtual Router Redundancy Protocol (VRRP) Configuration System Profile Configuration A default gateway is a critical resource for connectivity. However, it’s prone to a single point of failure. Thus, redundancy for the default gateway is required by the access point. If WAN backhaul is available on an AP7131, and a router failure occurs, then the access point should act as a router and forward traffic on to its WAN link.
Page 392 5 - 306 WiNG 5.5 Access Point System Reference Guide Figure 5-197 Device Overrides - VRRP screen - VRRP tab 5. Review the following VRRP configuration data to assess if a new VRRP configuration is required or if an existing VRRP...
Page 393 Device Configuration 5 - 307 Figure 5-198 Device Overrides - VRRP screen - Version tab VRRP version 3 (RFC 5798) and 2 (RFC 3768) are selectable to set the router redundancy. Version 3 supports sub-second (centisecond) VRRP failover and support services over virtual IP. For more information on the VRRP protocol specifications (available publicly) refer to http://www.ietf.org/rfc/rfc3768.txt (version 2) and...
Page 394 5 - 308 WiNG 5.5 Access Point System Reference Guide Figure 5-199 Device Overrides - VRRP screen 8. If creating a new VRRP configuration, assign a Virtual Router ID from 1 - 255. In addition to functioning as numerical identifier, the ID identifies the access point’s virtual router a packet is reporting status for.
Page 395 Device Configuration 5 - 309 Virtual IP Addresses Provide up to 8 IP addresses representing the Ethernet switches, routers or security appliances defined as virtual router resources to the AP7131 access point. Advertisement Interval Select either seconds, milliseconds or centiseconds as the unit used to define VRRP Unit advertisements.
Page 396: Profile Critical Resources
5 - 310 WiNG 5.5 Access Point System Reference Guide 5.4.5.7 Profile Critical Resources System Profile Configuration Critical resources are device IP addresses or interface destinations on the network interoperated as critical to the health of the network. The critical resource feature allows for the continuous monitoring of these addresses. A critical resource, if not available, can result in the network suffering performance degradation.
Page 397 Device Configuration 5 - 311 Figure 5-201 Device Overrides - Critical Resources screen - Adding a Critical Resource 6. Use the Offline Resource Detection drop-down menu to define how critical resource event messages are generated. Options include Any and All. If selecting Any, an event is generated when the state of any single critical resource changes. If selecting All, an event is generated when the state of all monitored critical resources change.
Page 398 5 - 312 WiNG 5.5 Access Point System Reference Guide 10. Select the Monitor Interval tab. Figure 5-202 Device Overrides - Critical Resources screen - Monitor Interval tab 11. Set the duration between two successive pings from the access point to critical resource. Define this value in seconds from 5 - 86,400.
Page 399: Overriding A Services Configuration
Device Configuration 5 - 313 5.4.5.8 Overriding a Services Configuration Device Overrides A profile can contain specific guest access (captive portal), DHCP server and RADIUS server configurations. These access, IP assignment and user authorization resources can be defined uniquely as profile requirements dictate. To define or override a profile’s services configuration: 1.
Page 400: Overriding A Management Configuration
5 - 314 WiNG 5.5 Access Point System Reference Guide Either select an existing captive portal policy, use the default captive portal policy or select the Create link to create a new captive portal configuration that can be applied to a profile. For more information, see...
Page 401 Device Configuration 5 - 315 Figure 5-204 Device Overrides - Management Settings screen 5. Refer to the Message Logging field to define how the profile logs system events. It’s important to log individual events to discern an overall pattern that may be negatively impacting performance. Enable Message Logging Select this option to enable the profile to log system events to a user defined log file or a syslog server.
Page 402 5 - 316 WiNG 5.5 Access Point System Reference Guide Console Logging Level Event severity coincides with the console logging level defined for the profile. Assign a numeric identifier to log events based on criticality. Severity levels include 0 - Emergency, 1 - Alert, 2 - Critical, 3 - Errors, 4 - Warning, 5 - Notice, 6 - Info and 7 - Debug.
Page 403 Device Configuration 5 - 317 12. Select to save the changes and overrides made to the profile’s Management Settings. Select Reset to revert to the last saved configuration. 13. Select the Firmware tab from the Management menu. Figure 5-205 Device Overrides - Management Firmware screen 14.
Page 404: Overriding Mesh Point Configuration
5 - 318 WiNG 5.5 Access Point System Reference Guide Figure 5-206 Device Overrides - Management Heartbeat screen 18. Select the Service Watchdog option to implement heartbeat messages to ensure other associated devices are up and running and capable of effectively interoperating. The Service Watchdog is enabled by default.
Page 405 Device Configuration 5 - 319 Figure 5-207 Device Overrides - Mesh Point screen 5. Select to create a new mesh point configuration or Edit to override an existing one. Select Delete to delete a mesh point configuration after selecting it.
Page 406 5 - 320 WiNG 5.5 Access Point System Reference Guide Figure 5-208 Device Overrides - Add Mesh Point screen 6. Refer to the following to configure Mesh Point general parameters: Mesh Connex Policy Provide a name for the Mesh Connex Policy. Use the Create icon to create a new Mesh Connex Policy.
Page 407 Select the preferred Interface for this mesh point. Select None to set no preferences. The other interface choices are 2.4 GHz and 5 GHz. NOTE: With this release of Motorola Solutions WiNG software, an AP7161 model access point can be deployed as a Vehicle Mounted Modem (VMM) to provide wireless network access to a mobile vehicle (car, train, etc.).
Page 408 5 - 322 WiNG 5.5 Access Point System Reference Guide 8. Click the Auto Channel Selection tab to configure the parameters for the Mesh Connex Auto Channel Selection policy. The following screen displays: Figure 5-209 Mesh Point Auto Channel Selection screen 9.
Page 409 Device Configuration 5 - 323 Priority Meshpoint Configure the mesh point to be monitored for automatic channel scan. This is the mesh point that given priority over other available mesh points. When configured, a mesh is created with this mesh point. When not configured, a mesh point is automatically selected.
Page 410 5 - 324 WiNG 5.5 Access Point System Reference Guide Refer to the following for more information on the Path Method SNR screen. These descriptions apply to both the 2.4 GHz and 5.0/4.9 GHz frequencies. Channel Width Configure the channel width that mesh point automatic channel scan should assign to the selected radio.
Page 411 Device Configuration 5 - 325 Figure 5-211 Mesh Point Auto Channel Selection Path Method Root Path Metric screen...
Page 412 5 - 326 WiNG 5.5 Access Point System Reference Guide 12. Refer to the following for more information on the Path Method Root Path Metric screen. These descriptions apply to both the 2.4 GHz and 5.0/4.9 GHz frequencies. Channel Width Configure the channel width that mesh point automatic channel scan should assign to the selected radio.
Page 413 Device Configuration 5 - 327 • Use Opportunistic as the rate selection settings for the AP7161 radio The default is Standard. For more information on defining this settings, see Radio Override Configuration. • Disable Dynamic Chain Selection (radio setting). The default value is enabled. This setting is disabled from the Command Line Interface (CLI) using the command, or, in the UI (refer Radio Override...
Page 414: Overriding An Advanced Configuration
5 - 328 WiNG 5.5 Access Point System Reference Guide 5.4.5.11 Overriding an Advanced Configuration Device Overrides Advanced device settings sets or overrides a profile’s MiNT and/or NAS configurations. MINT secures controller profile communications at the transport layer. Using MINT, a device can be configured to only communicate with other authorized (MINT enabled) devices.
Page 415 Device Configuration 5 - 329 Figure 5-212 Device Overrides - Client Load Balancing 6. Use the drop-down to set a value for strategy. Options include Prefer 5GHz, Prefer 2.4 GHz, and distribute-by-ratio. The default value is Prefer 5GHz. 7. Refer to the following Neighbor Selection Strategies fields to configure or override it: Using probes from...
Page 416 5 - 330 WiNG 5.5 Access Point System Reference Guide Balance 5 GHz Channel Select this option to balance the access point’s 5 GHz radio load across the channels Loads supported within the country of deployment. This can prevent congestion on the 5 GHz radio if a channel is over utilized.
Page 417 Device Configuration 5 - 331 12. Refer to the following AP Load Balancing fields to configure or override them: Min Value to Trigger Use the spinner control to set the access point radio threshold value (from 0 - 100%) used Load Balancing to initiate load balancing across other access point radios.
Page 418 5 - 332 WiNG 5.5 Access Point System Reference Guide Max confirmed Use the spinner to set the maximum number of learned neighbors stored at this device. Neighbors Minimum signal Use the spinner to set the minimum signal strength of neighbor devices that are learnt strength for smart-rf through Smart RF before being recognized as neighbors.
Page 419 Device Configuration 5 - 333 19. Define or override the following MINT Link Settings: MLCP IP Select this option to enable MINT Link Creation Protocol (MLCP) by IP Address. MINT Link Creation Protocol is used to create one UDP/IP link from the device to a neighbor. That neighboring device can be another AP.
Page 420 5 - 334 WiNG 5.5 Access Point System Reference Guide Figure 5-215 Device Overrides - Advanced Profile MINT screen - IP (Add) 25. Set the following Link IP parameters to complete the MINT network address configuration: Define or override the IP address used by peer access points for interoperation when supporting the MINT protocol.
Page 421 Device Configuration 5 - 335 Adjacency Hold Time Set or override a hold time interval in either Seconds (2 - 600) or Minutes (1 - 10) for the transmission of hello packets. The default interval is 46 seconds. IPSec Secure Select this option to use a secure link for IPSec traffic.
Page 422 5 - 336 WiNG 5.5 Access Point System Reference Guide Figure 5-217 Device Overrides - Advanced Profile MINT screen - Add VLAN screen 28. Set the following VLAN parameters to complete the MINT configuration: VLAN Define a VLAN ID from 1 - 4,094 used by peer controllers for interoperation when supporting the MINT protocol.
Page 423 Device Configuration 5 - 337 Figure 5-218 Device Overrides - Miscellaneous screen 31. Set a NAS-Identifier Attribute up to 253 characters in length. This is the RADIUS NAS-Identifier attribute that typically identifies where a RADIUS message originates 32. Set a NAS-Port-Id Attribute up to 253 characters in length.
Page 424: Overriding Environmental Sensor Configuration
5 - 338 WiNG 5.5 Access Point System Reference Guide 5.4.5.12 Overriding Environmental Sensor Configuration Overriding a Device Configuration NOTE: This feature is available on the AP8132 model only. An AP8132 sensor module is a USB environmental sensor extension to an AP8132 model access point. It provides a variety of sensing mechanisms, allowing the monitoring and reporting of the AP8132's radio coverage area.
Page 425 Device Configuration 5 - 339 Low Limit of Light Set the low threshold limit (from 0 - 1,000 lux) to determine whether the lighting is off in Threshold the AP8132’s deployment location. The default is 100. High Limit of Light Set the upper threshold limit (from 100 - 10,000 lux) to determine whether the lighting is Threshold on in the AP8132’s deployment location.
Page 426: Managing An Event Policy
5 - 340 WiNG 5.5 Access Point System Reference Guide 5.5 Managing an Event Policy Device Configuration Event Policies enable an administrator to create specific notification mechanisms using one, some or all of the SNMP, syslog, controller forwarding or E-mail notification options available to the controller. Each listed event can have customized notification settings defined and saved as part of an event policy.
Page 427: Chapter 6, Wireless Configuration
CHAPTER 6 WIRELESS CONFIGURATION A Wireless Local Area Network (WLAN) is a data-communications system and wireless local area network that flexibly extends the functionality of a wired LAN. A WLAN links two or more computers or devices using spread-spectrum or OFDM modulation based technology.
Page 428 6 - 2 WiNG 5.5 Access Point System Reference Guide Figure 6-1 Configuration > Wireless menu...
Page 429: Wireless Lans
Wireless Configuration 6 - 3 6.1 Wireless LANs Wireless Configuration To review the attributes of existing WLANs and, if necessary, modify their configurations: 1. Select the Configuration tab from the Web UI. 2. Select Wireless. 3. Select Wireless LANs to display a high level display of existing WLANs. Figure 6-2 Wireless LANs screen 4.
Page 430 6 - 4 WiNG 5.5 Access Point System Reference Guide DHCP Option 82 Displays if DHCP Option 82 is enabled or not. DHCP option 82 provides additional information on the physical attachment of a client Authentication Type Displays the name of the authentication scheme used by each listed WLAN to secure client transmissions.
Page 431: Basic Wlan Configuration
Wireless Configuration 6 - 5 6.1.1 Basic WLAN Configuration Wireless LANs When creating or modifying a WLAN, the Basic Configuration screen is the first screen that displays as part of the WLAN configuration screen flow. Use this screen to enable a WLAN, and define its SSID, client behavior and VLAN assignments. 1.
Page 432 6 - 6 WiNG 5.5 Access Point System Reference Guide Description Provide a textual description for the WLAN to help differentiate it from others with similar configurations. A description can be up to 64 characters. WLAN Status Select the Enabled radio button to ensure this WLAN is active and available to clients on the radios where it has been mapped.
Page 433: Wlan Basic Configuration Deployment Considerations
Wireless Configuration 6 - 7 6.1.1.1 WLAN Basic Configuration Deployment Considerations Basic WLAN Configuration Before defining a WLAN’s basic configuration, refer to the following deployment guidelines to ensure the configuration is optimally effective: • Deploy separate VLAN for providing secure WLAN access. •...
Page 434: Configuring Wlan Security
6 - 8 WiNG 5.5 Access Point System Reference Guide 6.1.2 Configuring WLAN Security Wireless LANs Assign WLANs unique security configurations supporting authentication, captive portal (hotspot), self registration or encryption schemes as data protection requirements dictate. Figure 6-4 WLAN Security screen Authentication ensures only known and trusted users or devices access an access point managed WLAN.
Page 435: Eap, Eap-Psk And Eap Mac
Wireless Configuration 6 - 9 • MAC Authentication • PSK / None Secure guest access to the network is referred to as captive portal. A captive portal is guest access policy for providing temporary and restrictive access to the access point managed wireless network. Existing captive portal policies can be applied to a WLAN to provide secure guest access.
Page 436: Mac Authentication
• If using an external RADIUS server for EAP authentication, Motorola Solutions recommends the round trip delay over the WAN does not exceed 150 ms. Excessive delay over a WAN can cause authentication and roaming issues and impact wireless client performance.
Page 437 Wireless Configuration 6 - 11 MAC authentication enables device-level authentication by permitting WLAN access based on device MAC address. MAC authentication is typically used to augment WLAN security options that do not use authentication (such as static WEP, WPA-PSK and WPA2-PSK). MAC authentication can also be used to assign VLAN memberships, Firewall policies and time and date access restrictions.
Page 438: Psk / None
6 - 12 WiNG 5.5 Access Point System Reference Guide 6.1.2.3 PSK / None Configuring WLAN Security Open-system authentication can be referred to as no authentication, since no actual authentication and user credential validation takes place. When selecting PSK/None, a client requests (and is granted) authentication with no credential exchange.
Page 439: Mac Registration
Wireless Configuration 6 - 13 4. Select the button to create an additional WLAN, or select an existing WLAN and Edit to modify its properties. 5. Select Security. 6. Refer to the Passpoint field within the WLAN Policy security screen. 7.
Page 440: Wpa/Wpa2-Tkip
6 - 14 WiNG 5.5 Access Point System Reference Guide 1. Select the Configuration tab from the Web UI. 2. Select Wireless. 3. Select Wireless LANs to display a high level display of existing WLANs. 4. Select the button to create an additional WLAN, or select an existing WLAN and Edit to modify its properties.
Page 441 When using WPA2, a wireless client can use 2 keys: one unicast key, for its own traffic to and from an access point, and one broadcast key, the common key for all clients in that subnet. Motorola Solutions recommends rotating these keys so a potential hacker would not have enough data using a single key to attack the deployed encryption scheme.
Page 442 6 - 16 WiNG 5.5 Access Point System Reference Guide 9. Define the Fast Roaming configuration used only with 802.1x EAP-WPA/WPA2 authentication. NOTE: Fast Roaming is available only when the authentication is EAP or EAP-PSK and the selected encryption is either WPA/WPA2-TKIP or WPA-CCMP.
Page 443: Wpa2-Ccmp
Wireless Configuration 6 - 17 11. Select when completed to update the WLAN’s WPA/WPA2-TKIP encryption configuration. Select Reset to revert the screen back to its last saved configuration. NOTE: WPA-TKIP is not supported on radios configured to exclusively use 802.11n. WPA-TKIP Deployment Considerations Before defining a WPA-TKIP supported configuration on a WLAN, refer to the following deployment guidelines to ensure the configuration is optimally effective:...
Page 444 When using WPA2-CCMP, a wireless client can use 2 keys: one unicast key, for its own traffic to and from an access point, and one broadcast key, the common key for clients in that subnet. Motorola Solutions recommends rotating these keys so a potential hacker would not have enough data using a single key to attack the deployed encryption scheme.
Page 445 WPA2-TKIP information elements. Enabling this option allows backwards compatibility for clients that support WPA-TKIP and WPA2-TKIP, but do not support WPA2-CCMP. Motorola Solutions recommends enabling this feature if WPA-TKIP or WPA2-TKIP supported clients operate...
Page 446: Wep 64
Before defining a WPA2-CCMP supported configuration on a WLAN, refer to the following deployment guidelines to ensure the configuration is optimally effective: • Motorola Solutions recommends WPA2-CCMP be configured for all new (non visitor) WLANs requiring encryption, as it’s supported by the majority of the hardware and client vendors using Motorola Solutions wireless networking equipment.
Page 447 The wireless controller, other proprietary routers, and Motorola Solutions clients use the algorithm to convert an ASCII string to the same hexadecimal number. Clients without Motorola Solutions adapters need to use WEP keys manually configured as hexadecimal numbers.
Page 448: Wep 128 And Keyguard
• Motorola Solutions recommends additional layers of security (beyond WEP 64) be enabled to minimize the likelihood of data loss and security breaches. WEP enabled WLANs should be mapped to an isolated VLAN with Firewall policies restricting access to hosts and suspicious network applications.
Page 449 The access point, other proprietary routers, and Motorola Solutions clients use the algorithm to convert an ASCII string to the same hexadecimal number. Clients without Motorola Solutions adapters need to use WEP keys manually configured as hexadecimal numbers.
Page 450: Configuring Wlan Firewall Support
• Motorola Solutions recommends additional layers of security (beyond WEP) be enabled to minimize the likelihood of data loss and security breaches. WEP enabled WLANs should be mapped to an isolated VLAN with Firewall policies restricting access to hosts and suspicious network applications.
Page 451 Wireless Configuration 6 - 25 Figure 6-9 WLAN Security - WLAN Firewall screen 6. Select an existing Inbound IP Firewall Rules Outbound IP Firewall Rules using the drop-down menu. If no rules exist, select the Create icon to create a new firewall rule configuration. Select the Edit icon to modify the configuration of a selected firewall.
Page 452 6 - 26 WiNG 5.5 Access Point System Reference Guide Figure 6-10 WLAN Security - IP Firewall Rules screen 8. IP Firewall rule configurations can either be modified as a collective group of variables or selected and updated individually as their filtering attributes require a more refined update.
Page 453 Wireless Configuration 6 - 27 Figure 6-12 WLAN Security - IP Firewall Rules - IP Firewall Rules Add Criteria screen NOTE: Only those selected IP ACL filter attributes display. Each value can have its current settings adjusted by selecting that IP ACL’s column to display a pop-up to adjust that one value.
Page 454 6 - 28 WiNG 5.5 Access Point System Reference Guide Network Service Alias The service alias is a set of configurations consisting of protocol and port mappings. Both source and destination ports are configurable. Set an alphanumeric service alias (beginning with a $ character and containing one special character) and include the protocol as relevant.
Page 455 Wireless Configuration 6 - 29 Precedence column sets the priority of a IP Firewall rule within its rule set. Click on this column and drag the rule to its appropriate place in the ruleset to set its precedence. 10. Click the button to save all changes made to the IP Firewall Rules dialog.
Page 456 6 - 30 WiNG 5.5 Access Point System Reference Guide Source and Destination Enter both Source and Destination MAC addresses. The access point uses the source IP address, destination MAC address as basic matching criteria. Provide a subnet mask if using a mask.
Page 457 Wireless Configuration 6 - 31 Validate ARP Header Select this radio button to check for a source MAC mismatch in the ARP header and Mismatch Ethernet header. This setting is enabled by default. DHCP Trust Select this radio button to enable DHCP trust on this WLAN. This setting is disabled by default.
Page 458: Configuring Client Settings
6 - 32 WiNG 5.5 Access Point System Reference Guide 6.1.4 Configuring Client Settings Wireless LANs Each WLAN can maintain its own client setting configuration. These settings include wireless client inactivity timeouts and broadcast configurations. AP7131, AP6562, AP6532, AP6522, AP6522M, AP8132, AP8232, AP7181 and AP7161 model access points can support up to 256 clients per access point.
Page 459 Wireless Configuration 6 - 33 6. Define the following Client Settings for the WLAN: Enable Select this option to allow client to client communication within this WLAN. The default Client-to-Client is enabled, meaning clients are allowed to exchange packets with other clients. Disabling Communication this setting does not necessarily prevent clients on other WLANs from sending packets to this WLAN, but as long as this setting is disabled on the other WLAN, clients are not...
Page 460: Configuring Wlan Accounting Settings
Motorola Solutions Client Extensions for the WLAN: Move Operations Select the option to enable the use of Motorola Solutions Fast Roaming (HFSR) for clients on this WLAN. This feature applies only to certain Motorola Solutions client devices. This feature is disabled by default.
Page 461 Wireless Configuration 6 - 35 Figure 6-15 WLAN Accounting screen 6. Set the following Syslog Accounting information: Enable System Log Select this option for the access point to generate accounting records in standard syslog Accounting format (RFC 3164). The feature is disabled by default. Syslog Host Specify the IP address (or hostname) of the external syslog host where accounting records are routed.
Page 462: Configuring Service Monitoring Settings
Before defining a AAA configuration on a WLAN, refer to the following deployment guidelines to ensure the configuration is optimally effective: • When using RADIUS authentication, Motorola Solutions recommends the WAN port round trip delay not exceed 150 ms. Excessive delay over a WAN can cause authentication and roaming issues. When excessive delays exist, a distributed RADIUS service should be used.
Page 463 Wireless Configuration 6 - 37 Figure 6-16 WLAN – Service Monitoring screen 6. Refer the following for more information on Service Monitoring fields. AAA Server Monitoring Select to enable monitoring the configured RADIUS server. Configure a RADIUS server through an AAA Policy. See AAA Policy on page 7-12 for more information.
Page 464: Configuring Client Load Balancing
6 - 38 WiNG 5.5 Access Point System Reference Guide 6.1.7 Configuring Client Load Balancing Wireless LANs Client load balance settings can be defined generically for both the 2.4 GHz and 5.0 GHz bands, and specifically for either of the 2.4 GHz or 5.0 GHz bands.
Page 465 Wireless Configuration 6 - 39 7. Set the following Load Balancing Settings (2.4 GHz): Single Band Clients Select this option to enable single band client associations on the 2.4 GHz frequency, even if load balancing is available. The default setting is enabled. Max Probe Requests Enter a value (from 0 - 10,000) for the maximum number of probe requests for client associations on the 2.4 GHz frequency.
Page 466: Configuring Advanced Wlan Settings
6 - 40 WiNG 5.5 Access Point System Reference Guide 6.1.8 Configuring Advanced WLAN Settings Wireless LANs To configure advanced RADIUS configuration and radio rate settings for a WLAN: 1. Select the Configuration tab from the Web UI. 2. Select Wireless.
Page 467 Wireless Configuration 6 - 41 Figure 6-19 Advanced WLAN - Rate Settings 2.4 GHz-WLAN screen 8. For 2.4 GHz WLAN radio transmission rate settings, define the minimum Basic and Supported rates in the 802.11b Rates, 802.11g Rates 802.11n Rates sections. These rates are applicable to client traffic associated with this WLAN only. If supporting 802.11n, select a Supported MCS index.
Page 468 6 - 42 WiNG 5.5 Access Point System Reference Guide Figure 6-20 Advanced WLAN - Rate Settings 5 GHz-WLAN screen 9. For 5.0 GHz WLAN radio transmission rate settings, define the minimum Basic and Supported rates in the 802.11a Rates, 802.11n Rates...
Page 469 Wireless Configuration 6 - 43 Table 6.2 MCS-2Stream Number of 20 MHz 20 MHz 40 MHz 40MHz MCS Index Streams No SGI With SGI No SGI With SGI 14.4 28.9 43.4 57.8 86.7 115.6 144.4 Table 6.3 MCS-3Stream Number of 20 MHz 20 MHz 40 MHz...
Page 470 6 - 44 WiNG 5.5 Access Point System Reference Guide Table 6.4 MCS-802.11ac (theoretical throughput for single spatial streams) 20 MHz 20 MHz 40 MHz 40MHz 80 MHz 80MHz MCS Index No SGI With SGI No SGI With SGI No SGI With SGI 58.5...
Page 471: Configuring Auto Shutdown Settings
Wireless Configuration 6 - 45 6.1.9 Configuring Auto Shutdown Settings Wireless LANs Auto shutdown provides a mechanism to regulate the availability of a WLAN based on time. WLANs can be enabled or disabled depending on the day of the week and time of day. A WLAN can be made available during a particular time of the day to prevent misuse and reduce the vulnerability of the wireless network.
Page 472 6 - 46 WiNG 5.5 Access Point System Reference Guide Figure 6-21 WLAN - Auto Shutdown screen 6. Refer to the following to configure Auto Shutdown parameters: Shutdown on Mesh Point Select to enable the WLAN to shutdown if the access point’s connection to the mesh Loss network is lost.
Page 473 Wireless Configuration 6 - 47 End Time Configure the time when the WLAN is unavailable. End time is configured as HH:MM AM/ 9. Select when completed to update this WLAN’s Advanced settings. Select Reset to revert to the last saved configuration.
Page 474: Wlan Qos Policy
6 - 48 WiNG 5.5 Access Point System Reference Guide 6.2 WLAN QoS Policy Wireless Configuration QoS provides a data traffic prioritization scheme that reduces congestion from excessive traffic. If there is enough bandwidth for all users and applications (unlikely because excessive bandwidth comes at a very high cost), then applying QoS has very little value.
Page 475 Wireless Configuration 6 - 49 4. Refer to the following read-only information to determine whether an existing policy can be used as is, an existing policy requires edit or a new policy requires creation: WLAN QoS Policy Displays the name assigned to each listed WLAN QoS. The policy name cannot be edited. Wireless Client Lists each policy’s Wireless Client Classification as defined for this WLAN's intended Classification...
Page 476: Configuring Qos Wmm Settings
6 - 50 WiNG 5.5 Access Point System Reference Guide 5. Either select the button to define a new WLAN QoS policy, or select an existing WLAN QoS policy and Edit configuration. Existing QoS policies can also be selected and deleted as needed.
Page 477 Wireless Configuration 6 - 51 Figure 6-23 WLAN - WLAN QoS Policy screen - WMM tab 5. Configure the following Settings in respect to the WLAN’s intended WMM radio traffic and user requirements: Wireless Client Use the drop-down menu to select the Wireless Client Classification for this WLAN's Classification intended traffic.
Page 478 Select this option if Voice traffic is prioritized on the WLAN. This gives priority to voice Prioritization and voice management packets and is supported only on certain legacy Motorola Solutions VOIP phones. This feature is disabled by default. Enable SVP Prioritization Enabling Spectralink Voice Prioritization (SVP) allows the access point to identify and prioritize traffic from Spectralink/Polycomm phones.
Page 479 Wireless Configuration 6 - 53 ECW Min ECW Min is combined with ECW Max to create the contention value in the form of a numerical range. From this range, a random number is selected for the back off mechanism. Lower values are used for higher priority traffic. The available range is from 0-15.
Page 480: Configuring A Wlan's Qos Rate Limit Settings
AP6511 and AP6521 model access points do not support rate limiting on an individual client basis. Before defining rate limit thresholds for WLAN upstream and downstream traffic, Motorola Solutions recommends you define the normal number of ARP, broadcast, multicast and unknown unicast packets that typically transmit and receive from each supported WMM access category.
Page 481 Wireless Configuration 6 - 55 Figure 6-24 WLAN - WLAN QoS Policy screen - Rate Limit tab 6. Configure the following intended Upstream Rate Limit parameters for the selected WLAN: Enable Select this radio button to enable rate limiting for data transmitted from access point radios to associated clients on this WLAN.
Page 482 6 - 56 WiNG 5.5 Access Point System Reference Guide Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the upstream packet transmission will result in congestion for the WLAN’s wireless client destinations.
Page 483 Wireless Configuration 6 - 57 Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the downstream packet transmission will result in congestion for the WLANs wireless client destinations. By trending the typical number of ARP, broadcast, multicast and unknown unicast packets over a period of time, the average rate for each access category can be obtained.
Page 484 6 - 58 WiNG 5.5 Access Point System Reference Guide Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the upstream packet transmission will result in congestion for wireless client traffic. By trending the typical number of ARP, broadcast, multicast and unknown unicast packets over a period of time, the average rate for each access category can be obtained.
Page 485: Configuring Multimedia Optimizations
Wireless Configuration 6 - 59 Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the downstream packet transmission will result in congestion for wireless client traffic. By trending the typical number of ARP, broadcast, multicast and unknown unicast packets over a period of time, the average rate for each access category can be obtained.
Page 486 6 - 60 WiNG 5.5 Access Point System Reference Guide Figure 6-25 WLAN - WLAN QoS Policy Screen - Multimedia Optimizations 6. Configure the following parameters in respect to the intended Multicast Mask: Multicast Mask Primary Configure the primary multicast mask for each listed QoS policy. Normally all multicast and broadcast packets are buffered until the periodic DTIM interval (indicated in the 802.11 beacon frame), when clients in power save mode wake to check for frames.
Page 487: Wlan Qos Deployment Considerations
Wireless Configuration 6 - 61 Automatically Detect Select this option to convert multicast packets to unicast to provide better overall airtime Multicast Streams utilization and performance. The administrator can either have the system automatically detect multicast streams and convert all detected multicast streams to unicast, or specify which multicast streams are converted to unicast.
Page 488: Radio Qos Policy
QoS policy’s intended wireless client base. Motorola Solutions access point radios and wireless clients support several Quality of Service (QoS) techniques enabling real- time applications (such as voice and video) to co-exist simultaneously with lower priority background applications (such as web, E-mail and file transfers).
Page 489: Configuring A Radio's Qos Policy
Wireless Configuration 6 - 63 Wireless network administrators can also assign weights to each WLAN in relation to user priority levels. The lower the weight, the lower the priority. Use a weighted round robin technique to achieve different QoS levels across WLANs. Optionally rate-limit bandwidth for WLAN sessions.
Page 490 6 - 64 WiNG 5.5 Access Point System Reference Guide Implicit TPSEC A green check mark defines the policy as requiring wireless clients to send their traffic specifications to an access point before they can transmit or receive data. If enabled, this setting applies to just this radio’s QoS policy.
Page 491 Wireless Configuration 6 - 65 6. Set the following Voice Access settings for the radio QoS policy: Transmit Ops Use the slider to set the maximum duration a device can transmit after obtaining a transmit opportunity. When resources are shared between a Voice over IP (VoIP) call and a low priority file transfer, bandwidth is normally exploited by the file transfer, thus reducing call quality or even causing the call to disconnect.
Page 492 6 - 66 WiNG 5.5 Access Point System Reference Guide ECW Min ECW Min is combined with ECW Max to create a contention value in the form of a numerical range. From this range, a random number is selected for the back off mechanism.
Page 493 Wireless Configuration 6 - 67 Figure 6-28 Radio QoS Policy screen - Admission Control tab 12. Select the Enable admission control for firewall detected traffic (e.g, SIP) option to apply radio QoS settings to traffic detected by the access point’s firewall. This feature is enabled by default. 13.
Page 494 6 - 68 WiNG 5.5 Access Point System Reference Guide Reserved for Roam Set the roam utilization (in the form of a percentage of the radio’s bandwidth) allotted to admission control for voice supported clients who have roamed to a different access point radio.
Page 495 Wireless Configuration 6 - 69 Reserved for Roam Set the roam utilization (in the form of a percentage of the radio’s bandwidth) allotted to admission control for video supported clients who have roamed to a different managed radio. The available percentage range is from 0 - 150%, with 150% accounting for over- subscription.
Page 496 6 - 70 WiNG 5.5 Access Point System Reference Guide Figure 6-29 Radio QoS Policy screen - Multimedia Optimizations tab 19. Set the following Accelerated Multicast settings: Maximum number of Specify the maximum number of wireless clients (from 0 - 256) allowed to use accelerated wireless clients allowed multicast.
Page 497 Wireless Configuration 6 - 71 • When a preconfigured interval has elapsed since the last frame, not necessarily the final frame, - of a set of frames to be aggregated - was received. In this enhancement to the standard frame aggregation, the time delay for aggregation is set individually for each traffic class.
Page 498 • WMM enabled clients can co-exist with non-WMM clients on the same WLAN. Non-WMM clients are always assigned a best effort access category. • Motorola Solutions recommends default WMM values be used for all deployments. Changing these values can lead to unexpected traffic blockages, and the blockages might be difficult to diagnose.
Page 499: Association Acl
Wireless Configuration 6 - 73 6.4 Association ACL Wireless Configuration An Association ACL is a policy-based Access Control List (ACL) that either prevents or allows wireless clients from connecting to a WLAN. An Association ACL allows an administrator to grant or restrict client access by specifying a wireless client MAC address or range of MAC addresses to either include or exclude from connectivity.
Page 500 6 - 74 WiNG 5.5 Access Point System Reference Guide Figure 6-31 Association ACL screen 5. Select the + Add Row button to add an association ACL template. 6. If creating a new Association ACL, provide a name specific to its function. Avoid naming it after a WLAN it may support.
Page 501: Association Acl Deployment Considerations
• Motorola Solutions recommends using the Association ACL screen strategically to name and configure ACL policies meeting the requirements of the particular WLANs they may map to. However, be careful not to name ACLs after specific WLANs, as individual ACL policies can be used by more than one WLAN.
Page 502: Smart Rf
WLAN to better maintain wireless client performance and site coverage during dynamic RF environment changes, which typically require manual reconfiguration to resolve. Motorola Solutions recommends you keep in mind that if a Smart RF managed radio is operating in WLAN mode on a channel requiring DFS, it will switch channels if radar is detected.
Page 503 Wireless Configuration 6 - 77 2. Select Wireless. 3. Select Smart RF. Basic Configuration screen displays by default. 4. Select the Activate SMART RF Policy option to enable the parameters on the screen for configuration. The configuration cannot be applied to the access point profile unless this settings is selected and remains enabled. Figure 6-32 SMART RF - Basic Configuration screen 5.
Page 504 6 - 78 WiNG 5.5 Access Point System Reference Guide 6. Refer to the Calibration Assignment field to define whether Smart RF Calibration and radio grouping is conducted by the floor the access point is deployed on or building in its entirety. Both options are disabled by default.
Page 505 Wireless Configuration 6 - 79 2.4 GHz Minimum Power Use the spinner control to select a 1 - 20 dBm minimum power level Smart RF can assign a radio in the 2.4 GHz band. The default setting is 4 dBm. 2.4 GHz Maximum Power Use the spinner control to select a 1 - 20 dBm maximum power level Smart RF can assign a radio in the 2.4 GHz band.
Page 506 6 - 80 WiNG 5.5 Access Point System Reference Guide Figure 6-34 SMART RF - Scanning Configuration screen NOTE: The monitoring and scanning parameters within the Scanning Configuration screen are only enabled when Custom is selected as the Sensitivity setting from the Basic Configuration screen.
Page 507 Wireless Configuration 6 - 81 End Time This value sets the ending time of day(s) the overrides will be disabled. Use the spinner controls to select the hour and minute, in 12h time format. Then use the radio button to choose AM or PM.
Page 508 6 - 82 WiNG 5.5 Access Point System Reference Guide Figure 6-35 SMART RF Recovery Configuration screen - Neighbor Recovery tab Power Hold Time Defines the minimum time between two radio power changes during neighbor recovery. Set the time in either Seconds (0 - 3,600), Minutes (0 - 60) or Hours (0 - 1). The default setting is 0 seconds.
Page 509 Wireless Configuration 6 - 83 22. Set the following Dynamic Sample Recovery parameters: Dynamic Sample Select this option to enable dynamic sampling. Dynamic sampling enables an Enabled administrator to define how Smart RF adjustments are triggered by locking retry and threshold values.
Page 510 6 - 84 WiNG 5.5 Access Point System Reference Guide Channel Hold Time Defines the minimum time between channel changes during neighbor recovery. Set the time in either Seconds (0 - 86,400), Minutes (0 - 1,440) or Hours (0 - 24) or Days (0 - 1). The default setting is 30 minutes.
Page 511 Wireless Configuration 6 - 85 28. Set the following Coverage Hole Recovery for 5.0 GHz 2.4 GHz parameters: Client Threshold Use the spinner to set a client threshold from 1 - 255. This is the minimum number of clients a radio should have associated for coverage hole recovery to trigger. AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232 and AP71XX model access points can support up to 256 clients per access point or radio.
Page 512: Smart Rf Configuration And Deployment Considerations
Administrators need to determine the root cause of RF deterioration and fix it. Smart RF history/events can assist. Motorola Solutions recommends that if a Smart RF managed radio is operating in WLAN mode on a channel requiring DFS, it will switch channels if radar is detected.
Page 513: Meshconnex Policy
Wireless Configuration 6 - 87 6.6 MeshConnex Policy Wireless Configuration MeshConnex is a mesh networking technology comparable to the 802.11s mesh networking specification. MeshConnex meshing uses a hybrid proactive/on-demand path selection protocol, similar to Ad hoc On Demand Distance Vector (AODV) routing protocols.
Page 514 6 - 88 WiNG 5.5 Access Point System Reference Guide Mesh ID Displays the IDs of all mesh identifiers for the configured mesh points. Mesh Point Status Specifies the status of each configured mesh point, either Enabled or Disabled. Descriptions Displays any descriptive text entered for each of the configured mesh points.
Page 515 Wireless Configuration 6 - 89 Mesh Point Status To enable this mesh point, select the Enabled radio button. To disable the mesh point select the Disabled button. The default value is enabled. Mesh QoS Policy Use the drop-down menu to specify the mesh QoS policy to use on this mesh point. This value is mandatory.
Page 516 6 - 90 WiNG 5.5 Access Point System Reference Guide Figure 6-40 MeshConnex - Security screen 9. Refer to the Select Authentication field to define an authentication method for the mesh policy. Security Mode Select a security authentication mode for the mesh-point. Select none to set no authentication for the mesh point.
Page 517 Wireless Configuration 6 - 91 14. Set the following Radio Rates for both the 2.4 and 5.0 GHz radio bands: 2.4 GHz Mesh Point Choose the Select button to configure radio rates for the 2.4 GHz band. Define both minimum Basic and optimal Supported rates as required for the 802.11b rates, 802.11g rates and 802.11n rates supported by the 2.4 GHz band.
Page 518 6 - 92 WiNG 5.5 Access Point System Reference Guide Figure 6-42 Advanced Rate Settings 5 GHz screen 15. Define both minimum Basic and optimal Supported rates as required for the 802.11b rates, 802.11g rates and 802.11n rates supported by the 2.4 GHz band and 802.11a and 802.11n rates supported by the 5.0 GHz radio band. These are the rates wireless client traffic is supported within this mesh point.
Page 519: Mesh Qos Policy
Wireless Configuration 6 - 93 6.7 Mesh QoS Policy Wireless Configuration Mesh QoS provides a data traffic prioritization scheme that reduces congestion from excessive traffic. If there is enough bandwidth for all users and applications (unlikely because excessive bandwidth comes at a very high cost), then applying QoS has very little value.
Page 520 Before defining rate limit thresholds for mesh point transmit and receive traffic, Motorola Solutions recommends you define the normal number of ARP, broadcast, multicast and unknown unicast packets that typically transmit and receive from each supported WMM access category.
Page 521 Wireless Configuration 6 - 95 Figure 6-44 Mesh QoS Policy - Rate Limit screen 6. Configure the following parameters in respect to the intended From Air Upstream Rate Limit, or traffic from the controller to associated access point radios and their associated neighbor: Mesh Tx Rate Limit Select this option to enable rate limiting for all data received from any mesh point in the mesh.
Page 522 6 - 96 WiNG 5.5 Access Point System Reference Guide Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the transmit packet transmission will result in congestion for the mesh point’s client destinations.
Page 523 Wireless Configuration 6 - 97 Maximum Burst Size Set a maximum burst size from 2 - 1024 kbytes. The smaller the burst, the less likely the receive packet transmission will result in congestion for the mesh point’s wireless client destinations. By trending the typical number of ARP, broadcast, multicast and unknown unicast packets over a period of time, the average rate for each access category can be obtained.
Page 524 6 - 98 WiNG 5.5 Access Point System Reference Guide 11. Set the following Neighbor Receive Random Early Detection Threshold settings for each access category: Background Traffic Set a percentage value for background traffic in the transmit direction. This is a percentage of the maximum burst size for low priority traffic.
Page 525 Wireless Configuration 6 - 99 Voice Traffic Set a percentage value for voice traffic in the receive direction. This is a percentage of the maximum burst size for voice traffic. Voice traffic exceeding the defined threshold is dropped by the client and a log message is generated. The default threshold is 0%.0% means no early random drops will occur.
Page 526: Passpoint Policy
6 - 100 WiNG 5.5 Access Point System Reference Guide 6.8 Passpoint Policy Wireless Configuration A Passpoint Policy provides a mechanism by which devices can select the correct network by querying for information from the available networks and then deciding which network to associate with. A Passpoint policy is associated to a WLAN to enable the WLAN to provide hotspot services.
Page 527 Wireless Configuration 6 - 101 5. Select the button to define a new Passpoint policy, or select an existing Passpoint policy and select Edit to modify its existing configuration. Existing Passpoint policies can be selected and deleted as needed. Figure 6-47 Passpoint Policy - Add new policy 6.
Page 528 6 - 102 WiNG 5.5 Access Point System Reference Guide...
Page 529: Chapter 7, Network Configuration
CHAPTER 7 NETWORK CONFIGURATION The access point allows packet routing customizations and additional route resources. For more information on the network configuration options available to the access point, refer to the following: • Policy Based Routing (PBR) • L2TP V3 Configuration •...
Page 530: Policy Based Routing (Pbr)
7 - 2 WiNG 5.5 Access Point System Reference Guide 7.1 Policy Based Routing (PBR) Network configuration Define a policy based routing (PBR) configuration to direct packets to selective paths. PBR can optionally mark traffic for preferential services (QoS). PBR minimally provides the following: •...
Page 531 Network configuration 7 - 3 • Default next hop - If a packet subjected to PBR does not have an explicit route to the destination, the configured default next hop is used. This can be either the IP address of the next hop or the outgoing interface. Only one default next hop can be defined.
Page 532 7 - 4 WiNG 5.5 Access Point System Reference Guide 5. If creating a new PBR policy assign it a Policy Name up to 32 characters to distinguish this route map configuration from others with similar attributes. Select Continue to proceed to the Policy Name screen where route map configurations can be added, modified or removed.
Page 533 Network configuration 7 - 5 Figure 7-3 Policy Based Routing screen - Add a Route Map 8. Use the spinner control to set a numeric precedence (priority) for this route-map. An incoming packet is matched against the route-map with the highest precedence (lowest numerical value). 9.
Page 534 7 - 6 WiNG 5.5 Access Point System Reference Guide Incoming Interface Select this option to enable radio buttons used to define the interfaces required to receive route-map packets. Use the drop-down menu to define either the access point’s wwan1 or pppoe1 interface.
Page 535 Network configuration 7 - 7 Figure 7-4 Policy Based Routing screen - General tab 13. Set the following General PBR configuration settings: Logging Select this option to log events generated by route-map configuration rule enforcement. This setting is disabled by default. Local PBR Select this option to implement policy based routing for this access point’s packet traffic.
Page 536: L2Tp V3 Configuration
7 - 8 WiNG 5.5 Access Point System Reference Guide 7.2 L2TP V3 Configuration Network configuration L2TP V3 is an IETF standard used for transporting different types of layer 2 frames in an IP network. L2TP V3 defines control and encapsulation protocols for tunneling layer 2 frames between two IP nodes.
Page 537 Network configuration 7 - 9 Figure 7-5 L2TP V3 Policy screen The L2TP V3 screen lists the policy configurations defined thus far. 2. Refer to the following to discern whether a new L2TP V3 policy requires creation or modification: Name Lists the 31 character maximum name assigned to each listed L2TP V3 policy upon creation.
Page 538 7 - 10 WiNG 5.5 Access Point System Reference Guide Force L2 Path Recovery Indicates if L2 Path Recovery is enabled to learn servers, gateways and other network devices behind a L2TPV3 tunnel. 3. Select to create a new L2TP V3 policy,...
Page 539 Network configuration 7 - 11 Reconnect Attempts Use the spinner control to set a value (from 0 - 250) representing the maximum number of reconnection attempts initiated to reestablish the tunnel. The default interval is 0. Reconnect Interval Define an interval in either Seconds (1 - 3,600), Minutes (1 -60) or Hours (1) between two successive reconnection attempts.
Page 540: Aaa Policy
7 - 12 WiNG 5.5 Access Point System Reference Guide 7.3 AAA Policy Network configuration Authentication, Authorization, and Accounting (AAA) is the mechanism network administrators use to define access control within the access point managed network. The access point can optionally use an external RADIUS and LDAP Servers (AAA Servers) to provide user database information and user authentication data.
Page 541 Network configuration 7 - 13 Figure 7-7 Authentication, Authorization, and Accounting (AAA) screen 4. Refer to the following information listed for each existing AAA policy: AAA Policy Displays the name assigned to the AAA policy when it was initially created. The name cannot be edited within a listed profile.
Page 542 7 - 14 WiNG 5.5 Access Point System Reference Guide Figure 7-8 AAA Policy - RADIUS Authentication tab 6. Refer to the following configured RADIUS Authentication details: Server Id Displays the numerical server index (1-6) for the accounting server when added to the list available to the access point.
Page 543 Network configuration 7 - 15 NAI Routing Enable Displays NAI routing status. AAA servers identify clients using the NAI. The NAI is a character string in the format of an E-mail address as either user or user@ but it need not be a valid E-mail address or a fully qualified domain name.
Page 544 7 - 16 WiNG 5.5 Access Point System Reference Guide 8. Define the following settings to add or modify AAA RADIUS authentication server configuration: Server Id Define the numerical server index (1-6) for the authentication server to differentiate it from others available to the access point’s AAA policy.
Page 545 Network configuration 7 - 17 Strip Realm Select this option to remove information from the packet when NAI routing is enabled. 10. Select the RADIUS Accounting tab. Figure 7-10 AAA Policy - RADIUS Accounting tab 11. Refer to the following configured RADIUS Accounting profile details: Server ID Displays the numerical server index (1-6) for the accounting server when added to the list available to the access point.
Page 546 7 - 18 WiNG 5.5 Access Point System Reference Guide NAI Routing Enable Displays the NAI routing status. AAA servers identify clients using the NAI. The NAI is a character string in the format of an E-mail address as either user or user@ but it need not be a valid E-mail address or a fully qualified domain name.
Page 547 Network configuration 7 - 19 Host Specify the IP address or hostname of the RADIUS authentication server. Port Define or edit the port on which the RADIUS server listens to traffic within the access point managed network. The port range is 1 - 65,535. The default port is 1813. Server Type Select the type of AAA server as either Host, onboard-self or onboard-controller.
Page 548 7 - 20 WiNG 5.5 Access Point System Reference Guide Figure 7-12 AAA-Policy - Settings screen 15. Set the following RADIUS server configuration parameters: Protocol for MAC, Set the authentication protocol when the server is used for any non-EAP authentication.
Page 549 Network configuration 7 - 21 Attributes Lists whether the format specified applies only to the user name/password in mac-auth or for all attributes that include a MAC address, such as calling-station-id or called- station-id. Server Pooling Mode Controls how requests are transmitted across RADIUS servers. Failover implies traversing the list of servers if any server is unresponsive.
Page 550: Aaa Tacacs Policy
7 - 22 WiNG 5.5 Access Point System Reference Guide 7.4 AAA TACACS Policy Network configuration Terminal Access Controller Access - Control System+ (TACACS+) is a protocol created by CISCO Systems which provides access control to network devices such as routers, network access servers and other networked computing devices through one or more centralized servers.
Page 551 Network configuration 7 - 23 Figure 7-13 Authentication, Authorization, and Accounting (AAA) TACACS screen 4. Refer to the following information for each existing AAA TACACS policy: AAA TACACS Policy Displays the name assigned to the AAA TACACS policy when it was initially created. The name cannot be edited within a listed profile.
Page 552 7 - 24 WiNG 5.5 Access Point System Reference Guide Figure 7-14 AAA TACACS Policy - New Policy screen 6. Provide a name for the AAA TACACS policy in the AAA TACACS Policy field. The name can be up to 32 characters long.
Page 553 Network configuration 7 - 25 Figure 7-15 AAA TACACS Policy - Authentication tab 7. Refer to the following AAA TACACS policy authentication details. Server Id Displays the numerical server index (1-2) for the authentication server when added to the list available to the access point. Host Displays the IP address or hostname of the AAA TACACS authentication server.
Page 554 7 - 26 WiNG 5.5 Access Point System Reference Guide Figure 7-16 AAA TACACS Policy - New Authentication Server NOTE: Only 2 AAA TACACS Authentication servers can be configured at a time. 9. Define the following settings to add or modify AAA TACACS authentication server configuration:...
Page 555 Network configuration 7 - 27 Figure 7-17 AAA TACACS Policy - Accounting tab 12. Refer to the following AAA TACACS policy accounting details. Server Id Displays the numerical server index (1-2) for the accounting server when added to the list available to the access point.
Page 556 7 - 28 WiNG 5.5 Access Point System Reference Guide Figure 7-18 AAA TACACS Policy - New Accounting Server NOTE: Only 2 AAA TACACS accounting servers can be configured at a time. 14. Define the following settings to add or modify AAA TACACS accounting server configuration:...
Page 557 Network configuration 7 - 29 Figure 7-19 AAA TACACS Policy - Authorization tab 17. Refer to the following AAA TACACS policy authorization details. Server Id Displays the numerical server index (1-2) for the authorization server when added to the list available to the access point. Host Displays the IP address or hostname of the AAA TACACS authorization server.
Page 558 7 - 30 WiNG 5.5 Access Point System Reference Guide Figure 7-20 AAA TACACS Policy - New Authorization Server NOTE: Only 2 AAA TACACS authorization servers can be configured at a time. 19. Define the following to add or modify AAA TACACS authorization server configuration:...
Page 559 Network configuration 7 - 31 Figure 7-21 AAA TACACS Policy - Settings tab 22. Set the following AAA TACACS Accounting server configuration parameters: Accounting Access Specify the access methods for which accounting must be performed. From the drop-down Method select one of: •...
Page 560 7 - 32 WiNG 5.5 Access Point System Reference Guide Server Preference Specifies how an accounting server is selected from the server pool for sending accounting requests. Select one of the following: • NONE – No preference in selection of server used for accounting.
Page 561 Network configuration 7 - 33 Allow Privileged Select this option to enable privileged commands executed without command Commands authorization. Privileged commands can alter/change the authorization server configuration. 25. Set the following AAA TACACS Service Protocol Settings parameters: Service Name Configure a shell service for user authorization. Service Protocol Configure a protocol for user authentication using the service in the Service Name field.
Page 562: Alias
7 - 34 WiNG 5.5 Access Point System Reference Guide 7.5 Alias Network configuration With large deployments, the configuration of remote sites utilizes a set of shared attributes, of which a small set of attributes are unique for each location. For such deployments, maintaining separate configuration (WLANs, profiles, policies and ACLs) for each remote site is complex.
Page 563 Network configuration 7 - 35 To edit or delete a basic alias configuration: 1. Select Configuration tab from the web user interface. 2. Select Network. 3. Select the Alias item, the Basic Alias screen displays. Figure 7-22 Network - Basic Alias Screen 4.
Page 564 7 - 36 WiNG 5.5 Access Point System Reference Guide • Switchport • Wireless LANs 5. Select + Add Row to define Address Range Alias settings: Use the Address Range Alias field to create aliases for IP address ranges that can be utilized at different deployments.
Page 565: Network Group Alias
Network configuration 7 - 37 8. Select + Add Row to define String Alias settings: Use the String Alias field to create aliases for strings that can be utilized at different deployments. For example, if the main domain at a remote location is called loc1.domain.com and at another deployment location it is called loc2.domain.com, the alias can be overriden at the remote location to suit the local (but remote) requirement.
Page 566 7 - 38 WiNG 5.5 Access Point System Reference Guide Figure 7-23 Network - Alias - Network Group Alias screen Name Displays the administrator assigned name of the Network Group Alias. Host Displays all host aliases configured in this network group alias. Displays a blank column if no host alias is defined.
Page 567 Network configuration 7 - 39 Figure 7-24 Network - Alias - Network Group Alias Add screen 6. If adding a new Network Group Alias, provide it a name of up to 32 characters. NOTE: The Network Group Alias Name always starts with a dollar sign ($). 7.
Page 568: Network Service Alias
7 - 40 WiNG 5.5 Access Point System Reference Guide 7.5.3 Network Service Alias Alias A network service alias is a set of configurations that consist of protocol and port mappings. Both source and destination ports are configurable. For each protocol, up to 2 source port ranges and up to 2 destination port ranges can be configured. A maximum of 4 protocol entries can be configured per network service alias.
Page 569 Network configuration 7 - 41 Figure 7-26 Network - Alias - Network Service Alias Add screen 6. If adding a new Network Service Alias, provide it a name up to 32 characters. NOTE: The Network Service Alias Name always starts with a dollar sign ($). 7.
Page 570: Network Deployment Considerations
7 - 42 WiNG 5.5 Access Point System Reference Guide 7.6 Network Deployment Considerations Before defining an access point network configuration, refer to the following deployment guidelines to ensure the configuration is optimally effective: • In respect to L2TP V3, data transfers on the pseudowire can start as soon as session establishment corresponding to the pseudowire is complete.
Page 571: Chapter 8, Security Configuration
CHAPTER 8 SECURITY CONFIGURATION When taking precautions to secure wireless traffic from a client to an access point, the network administrator should not lose sight of the security solution in it's entirety, since the network’s chain is as weak as its weakest link. An access point managed wireless network provides seamless data protection and user validation to protect and secure data at each vulnerable point in the network.
Page 572: Wireless Firewall
With Motorola Solutions’ access points, firewalls are configured to protect against unauthenticated logins from outside the network. This helps prevent hackers from accessing wireless clients within the network. Well designed firewalls block traffic from outside the network, but permit authorized users to communicate freely outside the network.
Page 573 Security Configuration 8 - 3 Figure 8-1 Wireless Firewall screen - Denial of Service tab A denial of service (DoS) attack is an attempt to make a computer or network resource unavailable to its intended users. Although the means to carry out a DoS attack will vary, it generally consists of a concerted effort of one or more persons attempting to prevent a device, site or service from functioning temporarily or indefinitely.
Page 574 8 - 4 WiNG 5.5 Access Point System Reference Guide Action If a DoS filter is enabled, chose an action from the drop-down menu to determine how the firewall treats the associated DoS attack. Options include: • Log and Drop - An entry for the associated DoS attack is added to the log and then the packets are dropped.
Page 575 Security Configuration 8 - 5 Router Advertisement In this attack, the attacker uses ICMP to redirect the network router function to some other host. If that host can not provide router services, a DoS of network communications occurs as routing stops. This can also be modified to single out a specific system, so that only that system is subject to attack (because only that system sees the 'false' router).
Page 576 8 - 6 WiNG 5.5 Access Point System Reference Guide TCP Intercept A SYN-flooding attack occurs when a hacker floods a server with a barrage of requests for connection. Because these messages have unreachable return addresses, the connections cannot be established.
Page 577 Security Configuration 8 - 7 Twinge The Twinge DoS attack sends ICMP packets and cycles through using all ICMP types and codes. This can crash some Windows systems. UDP Short Header Enables the UDP Short Header denial of service check in the firewall. WINNUKE The WINNUKE DoS attack sends a large amount of data to UDP port 137 to crash the Net BIOS service on windows and can also result on high CPU utilization on the target machine.
Page 578 8 - 8 WiNG 5.5 Access Point System Reference Guide The firewall maintains a facility to control packet storms. Storms are packet bombardments that exceed the high threshold configured for an interface. During a storm, packets are throttled until the rate falls below the configured rate, severely impacting performance for the interface.
Page 579 Security Configuration 8 - 9 Figure 8-3 Wireless Firewall screen - Advanced Settings tab 14. Refer to the Firewall Status radio buttons to define the firewall as either Enabled or Disabled. The firewall is enabled by default. If disabling the firewall, a confirmation prompt displays stating NAT, wireless hotspot, proxy ARP, deny-static-wireless-client and deny-wireless-client sending not permitted traffic excessively will be disabled.
Page 580 8 - 10 WiNG 5.5 Access Point System Reference Guide 16. Refer to the General field to enable or disable the following firewall parameters: Enable Proxy ARP Select the radio button to allow the Firewall Policy to use Proxy ARP responses for this policy on behalf of another device.
Page 581 Security Configuration 8 - 11 17. The firewall policy allows traffic filtering at the application layer using the Application Layer Gateway feature. The Application Layer Gateway provides filters for the following common protocols: FTP ALG Select the Enable box to allow FTP traffic through the firewall using its default ports. This feature is enabled by default.
Page 582 8 - 12 WiNG 5.5 Access Point System Reference Guide ICMP Define a flow timeout value in either Seconds (1 - 32,400), Minutes (1 - 540) or Hours (1 - 9). The default setting is 30 seconds. Define a flow timeout value in either Seconds (15 - 32,400), Minutes (1 - 540) or Hours (1 - 9).
Page 583: Configuring Ip Firewall Rules
Security Configuration 8 - 13 8.2 Configuring IP Firewall Rules Security Configuration Access points use IP based firewalls like Access Control Lists (ACLs) to filter/mark packets based on the IP address from which they arrive, as opposed to filtering packets on Layer 2 ports. IP based firewall rules are specific to source and destination IP addresses and the unique rules and precedence orders assigned.
Page 584 8 - 14 WiNG 5.5 Access Point System Reference Guide Figure 8-5 IP Firewall Rules screen - Adding a new rule 6. If adding a new rule, enter a name up to 32 characters. 7. Select to add a new firewall rule.
Page 585 Security Configuration 8 - 15 Figure 8-7 WLAN Security - IP Firewall Rules - IP Firewall Rules Add Criteria screen NOTE: Only those selected IP ACL filter attributes display. Each value can have its current settings adjusted by selecting that IP ACL’s column to display a pop-up to adjust that one value.
Page 586 8 - 16 WiNG 5.5 Access Point System Reference Guide Network Service Alias The service alias is a set of configurations consisting of protocol and port mappings. Both source and destination ports are configurable. Set an alphanumeric service alias (beginning with a $ character and containing one special character) and include the protocol as relevant.
Page 587 Security Configuration 8 - 17 10. Select as needed to add additional IP Firewall Rule configurations. Select the Remove icon as required to remove selected IP Firewall Rules. 11. Select when completed to update the IP Firewall rules. Select Reset to revert back to the last saved configuration.
Page 588: Device Fingerprinting
8 - 18 WiNG 5.5 Access Point System Reference Guide 8.3 Device Fingerprinting Security Configuration With the increase in popularity of Bring Your Own Devices (BYOD) for use in the corporate environment, there is an increase in the number of possible vectors of attacks on the network. BYOD devices are inherently unsafe as the organization does not have control on the level of security on these devices.
Page 589 Security Configuration 8 - 19 4. Select to create a new client identity policy. Client identity policies configure the signatures used to identify clients and then use these signatures to classify and assign permissions to them. A set of pre-defined client identities are included. Click Edit to modify the attributes of a selected policy or...
Page 590 8 - 20 WiNG 5.5 Access Point System Reference Guide Figure 8-10 Security - Device Fingerprinting - New Client Identity - Pre-defined Identity screen 6. To create a custom client identity, select Custom and provide a name in the adjacent field and click the button at the bottom of the screen.
Page 591 Security Configuration 8 - 21 Figure 8-11 Security - Device Fingerprinting - Client Signature screen 9. Provide the following information for each device signature: Index Use the spinner control to assign an index for this signature. A maximum of 16 signatures can be created in each Client Identity.
Page 592 8 - 22 WiNG 5.5 Access Point System Reference Guide Match Type Use the drop-down menu to select how the signatures are matched. The available options are: • Exact – The complete signature string completely matches the string specified in the Option Value field.
Page 593 Security Configuration 8 - 23 a different signature from Android devices. This unique signature can then be used to classify the devices and assign permissions and restrictions on each device class. 12. Select to create a new Client Identity Group policy. Client Identity Group policies configure the signatures used to identify clients and then use these signatures to classify and assign permissions to them.
Page 594 8 - 24 WiNG 5.5 Access Point System Reference Guide Figure 8-14 Security - Device Fingerprinting - Client Identity Group - New Client Identity Group 15. From the drop-down, select the Client Identity Policy to include in this group. Use the buttons next to the drop-down to manage and create new Client Identity policies.
Page 595: Configuring Mac Firewall Rules
Security Configuration 8 - 25 8.4 Configuring MAC Firewall Rules Security Configuration Access points can use MAC based firewalls like Access Control Lists (ACLs) to filter/mark packets based on the IP from which they arrive, as opposed to filtering packets on Layer 2 ports. Optionally filter Layer 2 traffic on a physical Layer 2 interface using MAC addresses.
Page 596 8 - 26 WiNG 5.5 Access Point System Reference Guide Figure 8-16 MAC Firewall Rules screen - Adding a new rule 6. If adding a new MAC Firewall Rule, provide a name up to 32 characters in length. 7. Define the following parameters for the MAC Firewall Rule: Allow Every MAC firewall rule is made up of matching criteria rules.
Page 597 Security Configuration 8 - 27 Precedence Use the spinner control to specify a precedence for this MAC firewall rule from 1 - 5000. Rules with lower precedence are always applied first to packets. VLAN ID Enter a VLAN ID representative of the shared SSID each user employs to interoperate within the network (once authenticated by the RADIUS server).
Page 598: Wireless Ips (Wips)
8 - 28 WiNG 5.5 Access Point System Reference Guide 8.5 Wireless IPS (WIPS) Security Configuration The access point supports Wireless Intrusion Protection Systems (WIPS) to provide continuous protection against wireless threats and act as an additional layer of security complementing wireless VPNs and encryption and authentication policies. An access point supports WIPS through the use of dedicated sensor devices designed to actively detect and locate unauthorized AP devices.
Page 599 Security Configuration 8 - 29 Figure 8-17 Wireless IPS screen - Settings tab 4. Select the Activate Wireless IPS Policy option on the upper left-hand side of the screen to enable the screen’s parameters for configuration. Ensure this option stays selected to apply the configuration to the access point profile. 5.
Page 600 8 - 30 WiNG 5.5 Access Point System Reference Guide 9. Select to update the settings. Select Reset to revert to the last saved configuration. The WIPS policy can be invoked at any point in the configuration process by selecting...
Page 601 Security Configuration 8 - 31 Enable Displays whether tracking is enabled for each event. Use the drop-down menu to enable/ disable events as required. A green checkmark defines the event as enabled for tracking against its threshold values. A red “X” defines the event as disabled and not tracked by the WIPS policy.
Page 602 8 - 32 WiNG 5.5 Access Point System Reference Guide MU Anomaly events are suspicious events by wireless clients that can compromise the security and stability of the network. Use the MU Anomaly screen to set the intervals clients can be filtered upon the generation of each event.
Page 603 Security Configuration 8 - 33 Figure 8-20 Wireless IPS screen - WIPS Events - AP Anomaly tab AP Anomaly events are suspicious frames sent by neighboring APs. Use the AP Anomaly tab to enable or disable an event. 17. Enable or disable the following AP Anomaly Events: Name...
Page 604 8 - 34 WiNG 5.5 Access Point System Reference Guide Figure 8-21 Wireless IPS screen - WIPS Signatures tab 20. The WIPS Signatures tab displays the following read-only configuration data: Name Lists the name assigned to each signature when it was created. A signature name cannot be modified as part of the edit process.
Page 605 Security Configuration 8 - 35 Figure 8-22 WIPS Signature Configuration screen 22. If adding a new WIPS signature, define a Name to distinguish it from others with similar configurations. The name cannot exceed 64 characters. 23. Set the following network address information for a new or modified WIPS Signature: Enable Signature Select the radio button to enable the WIPS signature for use with the profile.
Page 606 8 - 36 WiNG 5.5 Access Point System Reference Guide 24. Refer to Thresholds field to set the thresholds used as filtering criteria. Wireless Client Specify the threshold limit per client that, when exceeded, signals the event. The Threshold configurable range is from 1 - 65,535.
Page 607: Device Categorization
Security Configuration 8 - 37 8.6 Device Categorization Security Configuration A proper classification and categorization of access points and clients can help suppress unnecessary unauthorized access point alarms, and allow an administrator to focus on alarms on devices actually behaving in a suspicious manner. An intruder with a device erroneously authorized could potentially perform activities that harm your organization.
Page 608 8 - 38 WiNG 5.5 Access Point System Reference Guide Figure 8-24 Device Categorization screen - Marked Devices 5. If creating a new Device Categorization filter, provide it a Name (up to 32 characters). Select to save the name and enable the remaining device categorization parameters.
Page 609: Security Deployment Considerations
• Is the detected access point properly configured according to your organization’s security policies? • Motorola Solutions recommends trusted and known access points be added to an sanctioned AP list. This will minimize the number of unsanctioned AP alarms received.
Page 610 8 - 40 WiNG 5.5 Access Point System Reference Guide...
Page 611: Chapter 9, Services Configuration
CHAPTER 9 SERVICES CONFIGURATION Motorola Solutions WING software supports services providing captive portal access, leased DHCP IP address assignments to requesting clients and local RADIUS client authentication. For more information, refer to the following: • Configuring Captive Portal Policies •...
Page 612: Configuring Captive Portal Policies
9 - 2 WiNG 5.5 Access Point System Reference Guide 9.1 Configuring Captive Portal Policies Services Configuration A captive portal is an access policy that provides temporary and restrictive access to the access point managed wireless network. A captive portal policy provides secure authenticated access using a standard Web browser. Captive portals provide authenticated access by capturing and re-directing a wireless user's Web browser session to a captive portal login page where the user must enter valid credentials to access the wireless network.
Page 613 0 is the default value. Connection Mode Lists each policy’s connection mode as either HTTP or HTTPS. Motorola Solutions recommends the use of HTTPS, as it offers client transmissions a measure of data protection HTTP cannot provide.
Page 614 9 - 4 WiNG 5.5 Access Point System Reference Guide AAA Policy Lists each AAA policy used to authorize client guest access requests. The security provisions provide a way to configure advanced AAA policies that can be applied to captive portal policies supporting authentication. When a captive portal policy is created or modified, a AAA policy must be defined and applied to authorize, authenticate and account user requests.
Page 615 Services Configuration 9 - 5 Figure 9-2 Captive Portal Policy screen - Basic Configuration tab...
Page 616 External (Centralized) server resource. Connection Mode Select either HTTP or HTTPS to define the connection medium. Motorola Solutions recommends the use of HTTPS, as it offers additional data protection HTTP cannot provide. The default value however is HTTP.
Page 617 Services Configuration 9 - 7 Terms and Conditions Select this option (with any access type) to include terms that must be adhered to for page captive portal access. These terms are included in the Terms and Conditions page when No authentication required is selected as the access type, otherwise the terms appear in the Login page.
Page 618 9 - 8 WiNG 5.5 Access Point System Reference Guide Figure 9-3 Captive Portal DNS Whitelist screen b. Provide a numerical IP address or Hostname within the DNS Entry parameter for each destination IP address or host in the whitelist.
Page 619 Services Configuration 9 - 9 Syslog Host When syslog accounting is enabled, use the drop-down menu to determine whether an IP address or a host name is used as a syslog host. The IP address or hostname of an external server resource is required to route captive portal syslog events to that destination.
Page 620 9 - 10 WiNG 5.5 Access Point System Reference Guide Figure 9-4 Captive Portal Policy screen - Web Page tab The Login screen prompts for a username and password to access the captive portal and proceed to either the Terms and Conditions page (if used) or the Welcome page.
Page 621 Services Configuration 9 - 11 Title Text Set the title text displayed on the Login, Terms and Conditions, Welcome and Fail pages when wireless clients access each page. The text should be in the form of a page title describing the respective function of each page and should be unique to each login, terms, welcome and fail function.
Page 622 9 - 12 WiNG 5.5 Access Point System Reference Guide Figure 9-5 Captive Portal Policy screen - Web Page tab - Externally Hosted Web Page screen 20. Set the following URL destinations for externally hosted captive portal pages: Login URL Define the complete URL for the location of the Login page.
Page 623 Services Configuration 9 - 13 22. Select Advanced to use a custom directory of Web pages copied to and from the access point for captive portal support. Figure 9-6 Captive Portal Policy screen - Web Page tab - Advanced Web Page screen 23.
Page 624: Setting The Dns Whitelist Configuration
9 - 14 WiNG 5.5 Access Point System Reference Guide 9.2 Setting the DNS Whitelist Configuration Services Configuration A DNS whitelist is used in conjunction with a captive portal to provide captive portal services to wireless clients. Use the DNS whitelist parameter to create a set of allowed destination IP addresses within the captive portal.
Page 625: Setting The Dhcp Server Configuration
Services Configuration 9 - 15 9.3 Setting the DHCP Server Configuration Services Configuration Dynamic Host Configuration Protocol (DHCP) allows hosts on an IP network to request and be assigned IP addresses as well as discover information about the network where they reside. Each subnet can be configured with its own address pool. Whenever a DHCP client requests an IP address, the DHCP server assigns an IP address from that subnet’s address pool.
Page 626 9 - 16 WiNG 5.5 Access Point System Reference Guide Figure 9-8 DHCP Server Policy screen - DHCP Pool tab 4. Select the Activate DHCP Server Policy option to optimally display the screen and enable the ability Add or Edit a new policy.
Page 627 Services Configuration 9 - 17 6. Select to create a new DHCP pool, Edit to modify an existing pool or Delete to remove a pool. Figure 9-9 DHCP Pools screen - Basic Settings tab If adding or editing a DHCP pool, the DHCP Pool screen displays the Basic Settings tab by default.
Page 628 9 - 18 WiNG 5.5 Access Point System Reference Guide Lease Time DHCP leases provide addresses for defined times to various clients. If a client does not use the leased address for the defined time, that IP address can be re-assigned to another DHCP supported client.
Page 629 Services Configuration 9 - 19 Figure 9-10 DHCP Pools screen - Static Bindings tab 11. Review existing DHCP pool static bindings to determine if a static binding can be used as is, a new one requires creation or edit, or if one requires deletion: Client Identifier Type Lists whether the reporting client is using a Hardware Address or Client Identifier as its identifier type.
Page 630 9 - 20 WiNG 5.5 Access Point System Reference Guide Figure 9-11 Static Bindings Add screen 13. Define the following General parameters required to complete the creation of the static binding configuration: Client Identifier Type Use the drop-down menu whether the DHCP client is using a Hardware Address or Client Identifier as its identifier type with a DHCP server.
Page 631 Services Configuration 9 - 21 Client Name Provide the name of the client requesting DHCP Server support. Enable Unicast Unicast packets are sent from one location to another location (there is just one sender, and one receiver). Select this option to forward unicast messages to just a single device within this network pool.
Page 632 9 - 22 WiNG 5.5 Access Point System Reference Guide Figure 9-12 DHCP Pools screen - Advanced tab 22. The addition or edit of the network pool’s advanced settings requires the following General parameters be set: Boot File Enter the name of the boot file used with this pool. Boot files (Boot Protocol) can be used to boot remote systems over the network.
Page 633: Defining Dhcp Server Global Settings
Services Configuration 9 - 23 NetBIOS Servers Specify a numerical IP address of a single or group of NetBIOS WINS servers available to DHCP supported wireless clients. Select Alias to use a network alias with the NetBIOS server configuration. For more information see Alias on page 7-34.
Page 634 9 - 24 WiNG 5.5 Access Point System Reference Guide Figure 9-13 DHCP Server Policy screen - Global Settings tab 2. Set the following parameters within the Configuration field: Ignore BOOTP Requests Select the check box to ignore BOOTP requests. BOOTP requests boot remote systems within the network.
Page 635: Dhcp Class Policy Configuration
Services Configuration 9 - 25 9.3.3 DHCP Class Policy Configuration Setting the DHCP Server Configuration The DHCP server assigns IP addresses to DHCP enabled wireless clients based on user class option names. Clients with a defined set of user class option names are identified by their user class name. The DHCP server can assign IP addresses from as many IP address ranges as defined by the administrator.
Page 636 9 - 26 WiNG 5.5 Access Point System Reference Guide Figure 9-15 DHCP Class - Name Add screen 3. If adding a new DHCP Class Name, assign a name representative of the device class supported. The DHCP user class name should not exceed 32 characters.
Page 637: Setting The Radius Configuration
Services Configuration 9 - 27 9.4 Setting the RADIUS Configuration Services Configuration Remote Authentication Dial-In User Service (RADIUS) is a client/server protocol and software enabling remote access servers to authenticate users and authorize their access to the access point managed network. RADIUS is a distributed client/server system that secures networks against unauthorized access.
Page 638 9 - 28 WiNG 5.5 Access Point System Reference Guide • The ability to rate limit traffic To review existing RADIUS groups and add, modify or delete group configurations: 1. Select Configuration tab from the web user interface. 2. Select Services.
Page 639 Services Configuration 9 - 29 Role If a group is listed as a management group, it may also have a unique role assigned. Available roles include: • monitor - Read-only access • helpdesk - Helpdesk/support access • network-admin - Wired and wireless access •...
Page 640: Creating Radius Groups
9 - 30 WiNG 5.5 Access Point System Reference Guide 9.4.1.1 Creating RADIUS Groups Creating RADIUS Groups To create a RADIUS group: 1. Select Configuration tab from the web user interface. 2. Select Services. 3. Select and expand the RADIUS menu.
Page 641 Services Configuration 9 - 31 VLAN Select this option (and use the slider) to assign a specific VLAN to this RADIUS user group. Ensure Dynamic VLAN assignment (Single VLAN) is enabled for the WLAN for the VLAN to work properly. For more information, see Basic WLAN Configuration on page 6-5.
Page 642: Defining User Pools
9 - 32 WiNG 5.5 Access Point System Reference Guide 8. Click the to save the changes. Select Reset to revert to the last saved configuration. 9.4.2 Defining User Pools Setting the RADIUS Configuration A user pool defines policies for individual user access to the access point’s internal RADIUS resources. User or pools provide a convenient means of providing user access to RADIUS resources based on the pool’s unique permissions (either temporary...
Page 643 Services Configuration 9 - 33 Figure 9-19 RADIUS User Pool Add screen 6. Refer to the following User Pool configurations to discern when specific user IDs have access to the access point’s RADIUS resources: User Id Displays the unique alphanumeric string identifying this user. This is ID assigned to the user when created and cannot be modified with the rest of the configuration.
Page 644 9 - 34 WiNG 5.5 Access Point System Reference Guide Expiry Date Lists the month, day and year the listed user Id can no longer access the internal RADIUS server. Expiry Time Lists the time the listed user Id losses access internal RADIUS server resources. The time is only relevant to the range defined by the start and expiry date.
Page 645: Configuring The Radius Server
Services Configuration 9 - 35 Email Id Set the E-mail ID for this user. Telephone Configure the telephone number for this user. 9. Set the following Time settings for the new user: Start Date Configure the month, day and year the listed user can access the access point’s internal RADIUS server resources.
Page 646 9 - 36 WiNG 5.5 Access Point System Reference Guide Figure 9-21 RADIUS Server Policy screen - Server Policy tab RADIUS Server Policy screen displays with the Server Policy tab displayed by default. 4. Select the Activate RADIUS Server Policy button to enable the parameters within the screen for configuration.
Page 647 Services Configuration 9 - 37 5. Define the following Settings required in the creation or modification of the server policy: RADIUS User Pools Select the user pools to apply to this server policy. Up to 32 can be applied. If a pool requires creation, select the Create link.
Page 648 9 - 38 WiNG 5.5 Access Point System Reference Guide Authentication Type Use the drop-down menu to select the EAP authentication scheme for local and LDAP authentication. The following EAP authentication types are supported: • All – Enables all authentication schemes.
Page 649 Services Configuration 9 - 39 8. Set the following Session Resumption/Fast Reauthentication settings to define how server policy sessions are re-established once terminated and require cached data to resume: Enable Session Resumption Select the check box to control volume and the duration cached data is maintained by the server policy upon the termination of a server policy session.
Page 650 9 - 40 WiNG 5.5 Access Point System Reference Guide 11. Select the + Add Row button to add a table entry for a new client’s IP address, mask and shared secret. To delete a client entry, select the Delete icon on the right-hand side of the table entry.
Page 651 Services Configuration 9 - 41 17. Enter the Proxy Retry Delay as a value in seconds (from 5 - 10 seconds). This is the interval the RADIUS server waits before making an additional connection attempt. The default delay interval is 5 seconds. 18.
Page 652 9 - 42 WiNG 5.5 Access Point System Reference Guide Figure 9-24 RADIUS Server Policy screen - LDAP tab 27. Refer to the following to determine whether an LDAP server can be used as is, a server configuration requires creation or...
Page 653 Services Configuration 9 - 43 Figure 9-25 LDAP Server Add screen 29. Set the following Network address information required for the connection to the external LDAP server resource: Redundancy Define whether this LDAP server is a primary or secondary server resource. Primary servers are always queried for the first connection attempt.
Page 654 9 - 44 WiNG 5.5 Access Point System Reference Guide Base DN Specify a distinguished name (DN) that establishes the base object for the search. The base object is the point in the LDAP tree at which to start searching. LDAP...
Page 655: Services Deployment Considerations
• Motorola Solutions recommends each RADIUS client use a different shared secret password. If a shared secret is compromised, only the one client poses a risk as opposed all the additional clients that potentially share that secret password.
Page 656 9 - 46 WiNG 5.5 Access Point System Reference Guide...
Page 657: Chapter 10 Management Access
ACL (in routers or other firewalls), where administrators specify and customize specific IPs to access specific interfaces. Motorola Solutions recommends disabling unused and insecure management interfaces as required within different access profiles. Disabling un-used management services can dramatically reduce an attack footprint and free resources too.
Page 658: Creating Administrators And Roles
10 - 2 WiNG 5.5 Access Point System Reference Guide 10.1 Creating Administrators and Roles Management Access Use the Administrators screen to review existing administrators, their access medium and their administrative role within the access point managed network. New administrators can be added and existing administrative configurations modified or deleted as required.
Page 659 Management Access 10 - 3 Figure 10-2 Administrators screen 5. If adding a new administrator, enter the name in the User Name field. This is a mandatory field, and cannot exceed 32 characters. Optimally assign a name representative of the user’s intended access type and role. 6.
Page 660 10 - 4 WiNG 5.5 Access Point System Reference Guide Security Select this option to set the administrative rights for a security administrator allowing the configuration of all security parameters. Monitor Select this option to assign permissions without administrative rights. The Monitor option provides read-only permissions.
Page 661: Setting The Access Control Configuration
(HTTP, HTTPS, Telnet, SSH or SNMP). Access options can be either enabled or disabled as required. Motorola Solutions recommends disabling unused interfaces to reduce security holes. The Access Control tab is not meant to function as an ACL (in routers or other firewalls), where you can specify and customize specific IPs to access specific interfaces.
Page 662 10 - 6 WiNG 5.5 Access Point System Reference Guide 4. Set the following parameters required for Telnet access: Enable Telnet Select the check box to enable Telnet device access. Telnet provides a command line interface to a remote host over TCP. Telnet provides no encryption, but it does provide a measure of authentication.
Page 663 Management Access 10 - 7 8. Set the following General parameters: Idle Session Timeout Specify an inactivity timeout for management connects (in seconds) between 1 - 4,320. The default setting is 12.0 Message of the Day Enter message of the day text (no longer than 255 characters) displayed at login for clients connecting via Telnet or SSH.
Page 664: Setting The Authentication Configuration
10 - 8 WiNG 5.5 Access Point System Reference Guide 10.3 Setting the Authentication Configuration Management Access As part of the access point’s Management Policy, define how client authentication requests are validated using either an external or internal authentication resource: To configure an authentication resource: 1.
Page 665 Management Access 10 - 9 6. Set the following AAA TACACS configuration parameters Authentication Select to enable TACACS authentication on login. Accounting Select to enable TACACS accounting on login. Fallback Select to enable fallback to use local authentication if TACACS authentication fails. Authorization Select to enable TACACS authorization on login.
Page 666: Setting The Snmp Configuration
10 - 10 WiNG 5.5 Access Point System Reference Guide 10.4 Setting the SNMP Configuration Management Access The access point can use Simple Network Management Protocol (SNMP) to interact with wireless devices. SNMP is an application layer protocol that facilitates the exchange of management information. SNMP enabled devices listen on port 162 (by default) for SNMP packets from their management server.
Page 667 Management Access 10 - 11 3. Enable or disable SNMPv2 and SNMPv3. Enable SNMPv1 Select the check box to enable SNMPv1 support. SNMPv1 provides device management using a hierarchical set of variables. SNMPv1 uses Get, GetNext, and Set operations for data management. SNMPv1 is enabled by default. Enable SNMPv2 Select the check box to enable SNMPv2 support.
Page 668: Snmp Trap Configuration
10 - 12 WiNG 5.5 Access Point System Reference Guide 10.5 SNMP Trap Configuration Management Access An access point can use SNMP trap receivers for fault notifications. SNMP traps are unsolicited notifications triggered by thresholds (or actions) on devices, and are therefore an important fault management tool.
Page 669: Management Access Deployment Considerations
• By default, SNMPv2 community strings on most devices are set to public for the read-only community string and private for the read-write community string. Legacy Motorola Solutions devices may use other community strings by default. • Motorola Solutions recommends SNMPv3 be used for device management, as it provides both encryption, and authentication.
Page 670 10 - 14 WiNG 5.5 Access Point System Reference Guide...
Page 671: Chapter 11 Diagnostics
CHAPTER 11 DIAGNOSTICS An access point’s resident diagnostic capabilities enable administrators to understand how devices are performing and troubleshoot issues impacting network performance. Performance and diagnostic information is collected and measured for anomalies causing a key processes to potentially fail. Numerous tools are available within the Diagnostics menu.
Page 672: Fault Management
11 - 2 WiNG 5.5 Access Point System Reference Guide 11.1 Fault Management Diagnostics Fault management enables users administering multiple sites to assess device performance and issues effecting the network. Use the Fault Management screens to view and administrate errors generated by an access point or a connected wireless client.
Page 673 Diagnostics 11 - 3 Module Select the module from which events are tracked. When a single module is selected, events from other modules are not tracked. Remember this when interested in events generated by a particular module. Individual modules can be selected (such as TEST, LOG, FSM etc.) or all modules can be tracked by selecting All Modules.
Page 674 11 - 4 WiNG 5.5 Access Point System Reference Guide Module Displays the module used to track the event. Events detected by other modules are not tracked. Message Displays error or status messages for each event listed. Severity Displays the severity of the event as defined for tracking from the Configuration screen.
Page 675 Diagnostics 11 - 5 12. Select Fetch Historical Events from the lower, right-hand, side of the UI to populate the table with either device or RF Domain events. The following event data is fetched and displayed: Timestamp Displays the timestamp (time zone specific) each listed event occurred. Module Displays the module tracking the listed event.
Page 676: Crash Files
11 - 6 WiNG 5.5 Access Point System Reference Guide 11.2 Crash Files Diagnostics Use Crash Files to assess critical access point failures and malfunctions. Use crash files to troubleshoot issues specific to the device on which a crash event was generated. These are issues impacting the core (distribution layer).
Page 677: Advanced
Diagnostics 11 - 7 11.3 Advanced Diagnostics Use Advanced diagnostics to review and troubleshoot potential issues with the access point’s User Interface (UI). The UI Diagnostics screen contains tools to effectively identify and correct access point UI issues. Diagnostics can also be performed at the device level for connected clients.
Page 678: Schema Browser
11 - 8 WiNG 5.5 Access Point System Reference Guide Real Time NETCONF Messages area lists an XML representation of any message generated by the system. The main display area of the screen is updated in real time. Refer to the...
Page 679: View Ui Logs
Diagnostics 11 - 9 5. Select the Statistics tab to assess performance data and statistics for a target device. Use Statistics data to assess whether the device is optimally configured in respect to its intended deployment objective. Often the roles of radio supported devices and wireless clients change as additional devices and radios are added to the access point managed network.
Page 680: View Sessions
11 - 10 WiNG 5.5 Access Point System Reference Guide Figure 11-8 View UI Logs - Error Logs tab The Sequence (order of occurrence), Date/Time, Type, Category and Message items display for each log option selected. 11.3.3 View Sessions Advanced View Sessions screen displays a list of all sessions associated with this device.
Page 681 Diagnostics 11 - 11 Figure 11-9 Advanced - View Sessions screen 4. Refer to the following table for more information on the fields displayed in this screen: Cookie Displays the number of cookies created by this session. From Displays the IP address of the device/process initiating this session. Role Displays the role assigned to the user name as displayed in the User column.
Page 682 11 - 12 WiNG 5.5 Access Point System Reference Guide...
Page 683: Chapter 12 Operations
Self Monitoring At Run Time RF Management (Smart RF) is a Motorola Solutions innovation designed to simplify RF configurations for new deployments, while (over time) providing on-going deployment optimization and radio performance improvements.
Page 684: Devices
Motorola Solutions periodically releases updated device firmware and configuration files to the Motorola Solutions Support Web site. If an access point’s (or its associated device’s) firmware is older than the version on the Web site, Motorola Solutions recommends updating to the latest firmware version for full functionality and utilization. Additionally, selected devices can either have a primary or secondary firmware image applied or fallback to a selected firmware image if an error were to occur in the update process.
Page 685: Managing Running Configuration
Operations 12 - 3 Figure 12-2 Device Browser - Options for an AP7131 Refer to the drop-down menu on the lower, left-hand side, of the UI. The following tasks and displays are available in respect to device firmware for the selected device: Show Running Config Select this option to display the running configuration of the selected device.
Page 686 12 - 4 WiNG 5.5 Access Point System Reference Guide Figure 12-3 Device Browser 2. Select the down arrow next to the device to view a set of operations that can be performed on the selected device. Figure 12-4 Device Browser - Options for a device 3.
Page 687 Operations 12 - 5 Figure 12-5 Operations - Manage Running Configuration 4. Use the Export Config field to configure the parameters required to export the running configuration to an external server. Refer to the following to configure the export parameters: Protocol Select the protocol used for exporting the running configuration.
Page 688: Managing Startup Configuration
12 - 6 WiNG 5.5 Access Point System Reference Guide Host Enter IP address or the hostname of the server used to export the running configuration to. This option is not valid for local, cf, usb1, usb2, usb3 and usb4.
Page 689 Operations 12 - 7 Figure 12-8 Operations - Manage Startup Configuration 4. Use the Import/Export Config field to configure the parameters required to export or import the startup configuration to or from an external server. Refer to the following to configure the remote server parameters: Protocol Select the protocol used for exporting or importing the startup configuration.
Page 690 12 - 8 WiNG 5.5 Access Point System Reference Guide Port Use the spinner control or manually enter the value to define the port used by the protocol for exporting or importing the startup configuration. This option is not valid for cf, usb1, usb2, usb3 and usb4.
Page 691: Managing Crash Dump Files
Crash files are generated when the device encounters a critical error that impairs the performance of the device. When a critical error arises, information about the state of the device at that moment is written to a text file. This file is used by Motorola Solutions Support Center to debug the issue and provide a solution to correct the error condition.
Page 692: Rebooting The Device
12 - 10 WiNG 5.5 Access Point System Reference Guide 4. Refer to the following for more information on the Clear Crash Info screen. File Name Displays the full path to the crash file Size Displays the size of the crash information file in kilobytes.
Page 693: Locating A Device
Operations 12 - 11 Figure 12-14 Device - Reload screen 4. Refer the following for more information on this screen: Force Reload Select this option to force this device to reload. Use this option for devices that are unresponsive and do not reload normally. Delay Use the spinner to configure a delay in seconds before the device is reloaded.
Page 694: Upgrading Device Firmware
12 - 12 WiNG 5.5 Access Point System Reference Guide Figure 12-15 Device Browser 2. Select the down arrow next to the device to view a set of operations that can be performed on the selected device. Figure 12-16 Device Browser - Options for a device 3.
Page 695 Operations 12 - 13 Figure 12-18 Device Browser - Options for a device 3. Select the Firmware Upgrade button to upgrade the device’s firmware. Figure 12-19 Firmware Upgrade screen 4. Provide the following information to accurately define the location of the target device’s firmware file: Protocol Select the protocol used for updating the firmware.
Page 696: Viewing Device Summary Information
12 - 14 WiNG 5.5 Access Point System Reference Guide Path/File Specify the path to the firmware file. Enter the complete relative path to the file on the server. User Name Define the user name used to access either a FTP or SFTP server.
Page 697 Operations 12 - 15 Figure 12-21 Device Details screen 4. Refer to the following to determine whether a firmware image needs requires an update: Firmware Version Displays the Primary and Secondary firmware image version currently utilized by the selected access point. Build Date Displays the date the Primary and Secondary firmware image was built for the selected device.
Page 698: Adopted Device Upgrades
12 - 16 WiNG 5.5 Access Point System Reference Guide 12.1.6 Adopted Device Upgrades Devices To configure an access point upgrade: NOTE: AP upgrades can only be performed by access points in Virtual Controller AP mode, and cannot be initiated by Standalone APs. Additionally, upgrades can only be performed on access points of the same model as the Virtual Controller AP.
Page 699 Operations 12 - 17 Figure 12-23 Devices - Adopted AP Upgrade screen NOTE: If selecting the Device Upgrade screen from the RF Domain level of the UI, there is an additional Upgrade from Controller option to the right of the Device Type List drop-down menu.
Page 700 12 - 18 WiNG 5.5 Access Point System Reference Guide Schedule Reboot Time To reboot a target access point immediately, select Now. To schedule the reboot to take place at a specified time in the future, enter a date and time. This feature is helpful when wishing to upgrade an access point’s firmware, but wish to keep in...
Page 701 Operations 12 - 19 Figure 12-24 AP Upgrade screen - AP Image File 9. Select the Device Image File tab and refer to the following configuration parameters: Device Image Type Select the access point model to specify which model should be available to upgrade. Upgrades can only be made to the same access point model.
Page 702 12 - 20 WiNG 5.5 Access Point System Reference Guide Protocol Select the protocol to retrieve the image files. Available options include: • tftp - Select this option to specify a file location using Trivial File Transfer Protocol. A port and IP address or hostname are required. A path is optional.
Page 703 Operations 12 - 21 Figure 12-25 AP Upgrade screen - Upgrade Status screen 12. Refer to the following fields to understand the status of the number of device being updated: Number of devices currently Lists the number of firmware upgrades currently in-progress and downloading for being upgraded selected devices.
Page 704 12 - 22 WiNG 5.5 Access Point System Reference Guide MAC Address Lists the factory encoded MAC address of a device either currently upgrading or in the queue of scheduled upgrades. Result Lists the state of an upgrade operation (downloading, waiting for a reboot etc.).
Page 705: File Management
Operations 12 - 23 Result Displays the current upgrade status for each listed access point. Possible states include: • Waiting • Downloading • Updating Scheduled • Reboot • Rebooting Done • Cancelled • Done • No Reboot Time Displays the time when the device was upgraded. Retries Displays the number of retries, if any, during the upgrade.
Page 706 12 - 24 WiNG 5.5 Access Point System Reference Guide Figure 12-27 Device Summary screen 4. Click File Management. The following screen displays:...
Page 707 Operations 12 - 25 Figure 12-28 Devices - File Management screen 5. The pane on the left of the screen displays the directory tree for the selected device. Use this tree to navigate around the device’s directory structure. When a directory is selected, all files in that directory is listed in the pane on the right.
Page 708 12 - 26 WiNG 5.5 Access Point System Reference Guide Figure 12-29 Devices - File Management screen 6. Refer to the following for more information: File Name Displays the name of the file. Size (Kb) Displays the size of the file in kilobytes.
Page 709 Operations 12 - 27 Click Proceed to delete the directory. All files in the selected directory also get deleted. Click Abort to exit without deleting the directory. 9. Click Transfer File to transfer files between the device and a remote server. The following window displays: Figure 12-31 File Management - File Transfer Dialog Use this dialog to transfer files between the device and a remote location.
Page 710 12 - 28 WiNG 5.5 Access Point System Reference Guide Protocol If Advanced is selected, choose the protocol for file management. Available options include: • tftp • ftp • sftp • http • cf • usb1 • usb2 • usb3 •...
Page 711: Adopted Device Restart
Operations 12 - 29 11. Select to begin the file transfer. Selecting Cancel reverts the screen to its last saved configuration. 12. To delete a file, select the file to be deleted and click Delete File button. The file is deleted immediately. 12.1.8 Adopted Device Restart Devices Use the Adopted Device Restart screen to restart one or more of the access points adopted by this AP.
Page 712: Captive Portal
12 - 30 WiNG 5.5 Access Point System Reference Guide Figure 12-33 Devices - Adopted Device Restart screen 5. From the list of adopted devices, select the access point from the list and select Reload. 6. Select Refresh to refresh the list of adopted access points on the screen.
Page 713 Operations 12 - 31 2. Select Devices. 3. Use the navigation pane on the left to navigate to the device to manage the files on and select it. Figure 12-34 Device Summary screen 4. Select Captive Portal Pages. The following screen displays: NOTE: If selecting the Captive Portal Pages screen from the RF Domain level of the...
Page 714 12 - 32 WiNG 5.5 Access Point System Reference Guide Figure 12-35 Devices Captive Portal Pages - AP Upload List screen 5. Use the Captive Portal List drop-down list to select the captive portal configuration to upload to the adopted access points.
Page 715 Operations 12 - 33 Figure 12-36 Devices Captive Portal Pages - CP Page Image File screen 10. Use the Captive Portal List drop-down list to select the captive portal configuration to upload to the adopted access points. 11. Set the following file transfer configuration parameters of the required file transfer activity: Protocol If Advanced is selected, choose the protocol for file management.
Page 716 12 - 34 WiNG 5.5 Access Point System Reference Guide IP Address If Advanced is selected, specify the IP address of the server used to transfer files. This option is not valid for cf, usb1, usb2, usb3 and usb4. If IP address of the server is provided, a Hostname is not required.
Page 717: Re-Elect Controller
Operations 12 - 35 15. Refer to the Status tab to view the history of captive portal pages upload. Hostname Displays the hostname of the target device. Displays the factory assigned MAC address of the target device. State Displays the target device’s state. Progress Displays the progress of the upload to the target device.
Page 718 12 - 36 WiNG 5.5 Access Point System Reference Guide Figure 12-38 Re-elect Controller screen 4. Refer to the Available APs column, and use the > button to move the selected access point into the list of Selected APs available for RF Domain Manager candidacy. Use the >>...
Page 719: Certificates
Operations 12 - 37 12.2 Certificates Operations A certificate links identity information with a public key enclosed in the certificate. A certificate authority (CA) is a network authority that issues and manages security credentials and public keys for message encryption. The CA signs all digital certificates it issues with its own private key. The corresponding public key is contained within the certificate and is called a CA certificate.
Page 720 12 - 38 WiNG 5.5 Access Point System Reference Guide Figure 12-39 Certificate Management -Trustpoints screen Trustpoints screen displays for the selected MAC address. 3. Refer to the Certificate Details to review certificate properties, self-signed credentials, validity period and CA information.
Page 721 Operations 12 - 39 Figure 12-40 Certificate Management - Import New Trustpoint screen...
Page 722 12 - 40 WiNG 5.5 Access Point System Reference Guide 5. Define the following configuration parameters required for the Import of the Trustpoint: Import Select the type of Trustpoint to import. The following Trustpoints can be imported: • Import – Select to import any trustpoint.
Page 723 Operations 12 - 41 Hostname If using Advanced settings, provide the hostname of the server used to import the trustpoint. This option is not valid for cf and usb1 - 4. Username/Password These fields are enabled if using ftp or sftp protocols. Specify the username and the password for that username to access the remote servers using these protocols.
Page 724: Rsa Key Management
12 - 42 WiNG 5.5 Access Point System Reference Guide 9. Define the following configuration parameters required for the Export of the trustpoint: Trustpoint Name Enter the 32 character maximum name assigned to the target trustpoint. The trustpoint signing the certificate can be a certificate authority, corporation or individual.
Page 725 Operations 12 - 43 1. Select Operations. 2. Select Certificates. 3. Select Keys. Figure 12-42 Certificate Management - RSA Keys screen Each key can have its size and character syntax displayed. Once reviewed, optionally generate a new RSA key, import a key from a selected device, export a key to a remote location or delete a key from a selected device.
Page 726 Enter the 32 character maximum name assigned to the RSA key. Key Size Use the spinner control to set the size of the key (between 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting of 1024 to ensure optimum functionality.
Page 727 Operations 12 - 45 7. Define the following configuration parameters required for the import of the RSA key: Key Name Enter the 32 character maximum name assigned to identify the RSA key. Key Passphrase Define the key used by the server (or repository) of the target RSA key. Select the Show textbox to expose the actual characters used in the passphrase.
Page 728 12 - 46 WiNG 5.5 Access Point System Reference Guide Figure 12-45 Certificate Management - Export RSA Key screen 11. Define the following configuration parameters required for the Export of the RSA key: Key Name Enter the 32 character maximum name assigned to the RSA key.
Page 729: Certificate Creation
Operations 12 - 47 IP Address If using Advanced settings, enter IP address of the server used to export the RSA key. This option is not valid for cf and usb1 - 4. Hostname If using Advanced settings, provide the hostname of the server used to export the RSA key.
Page 730 RSA key. Use the spinner control to set the size of the key (between 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting of 1024 to ensure optimum functionality. For more information on creating a new RSA key, RSA Key Management on page 12-42.
Page 731: Generating A Certificate Signing Request (Csr)
Operations 12 - 49 State (ST) Enter a State/Prov. for the state or province name used in the certificate. This is a required field. City (L) Enter a City to represent the city name used in the certificate. This is a required field. Organization (O) Define an Organization for the organization used in the certificate.
Page 732 Create or use an existing key by selecting the appropriate radio button. Use the spinner control to set the size of the key (between 1,024 - 2,048 bits). Motorola Solutions recommends leaving this value at the default setting of 1024 to ensure optimum functionality.
Page 733 Operations 12 - 51 Organizational Unit (OU) Enter an Org. Unit for the name of the organization unit used in the CSR. This is a required field. Common Name (CN) If there’s a common name (IP address) for the organizational unit issuing the certificate, enter it here.
Page 734: Smart Rf
12 - 52 WiNG 5.5 Access Point System Reference Guide 12.3 Smart RF Operations Self Monitoring At Run Time RF Management (Smart RF) is a Motorola Solutions innovation designed to simplify RF configurations for new deployments, while (over time) providing on-going deployment optimization and radio performance improvements.
Page 735 Operations 12 - 53 3. Refer to the following to determine whether Smart RF calibrations or interactive calibration is required: Hostname Displays the user friendly hostname assigned to each access point within the RF Domain. This value cannot be modified as a part of calibration activity. AP MAC Address Displays the hardware encoded MAC address assigned to each access point within the RF Domain.
Page 736 12 - 54 WiNG 5.5 Access Point System Reference Guide 4. Select the Refresh button to (as required) to update the contents of the Smart RF screen and the attributes of the devices within the RF Domain. CAUTION: Smart RF is not able to detect a voice call in progress, and will switch to a different channel resulting in voice call reconnections.
Page 737: Operations Deployment Considerations
Before defining the access point’s configuration using the Operations menu, refer to the following deployment guidelines to ensure the configuration is optimally effective: • If an access point’s (or its associated device’s) firmware is older than the version on the support site, Motorola Solutions recommends updating to the latest firmware version for full functionality and utilization.
Page 738 12 - 56 WiNG 5.5 Access Point System Reference Guide...
Page 739: Chapter 13 Statistics
CHAPTER 13 STATISTICS This chapter describes statistics displayed by the graphical user interface (GUI). Statistics are available for access point and their managed devices. A Smart RF statistical history is available to assess adjustments made to device configurations to compensate for detected coverage holes or device failures.
Page 740: System Statistics
13 - 2 WiNG 5.5 Access Point System Reference Guide 13.1 System Statistics Statistics System screen displays information supporting managed devices. Use this information to asses the overall state of the devices comprising the system. Systems data is organized as follows: •...
Page 741 Statistics 13 - 3 Figure 13-1 System - Health screen 4. The Devices table displays the total number of devices in the network. The pie chart is a proportional view of how many devices are functional and currently online. Green indicates online devices and red offline devices detected within the network.
Page 742: Inventory
13 - 4 WiNG 5.5 Access Point System Reference Guide 8. Use the RF Quality table to isolate poorly performing radio devices within specific RF Domains. This information is a starting point to improving the overall quality of the network.The RF Quality area displays the RF Domain performance.
Page 743: Adopted Devices
Statistics 13 - 5 Figure 13-2 System - Inventory screen 4. The Devices table displays an exploded pie chart depicting controller, service platform and access point device type distribution by model. Use this information to assess whether these are the correct models for the original deployment objective.
Page 744 13 - 6 WiNG 5.5 Access Point System Reference Guide To view adopted AP statistics: 1. Select the Statistics menu from the Web UI. 2. Select the System node from the left navigation pane. 3. Select Adopted Devices from the left-hand side of the UI.
Page 745: Pending Adoptions
Statistics 13 - 7 13.1.4 Pending Adoptions System Statistics The Pending Devices screen displays those devices detected within the network coverage area, but have yet to be adopted. Review these devices to assess whether they could provide radio coverage to wireless clients needing support. To view pending AP adoptions to the controller or service platform: 1.
Page 746: Offline Devices
13 - 8 WiNG 5.5 Access Point System Reference Guide Add to Devices Select a listed AP and select the Add to Devices button to begin the adoption process for this detected AP. Refresh Click the Refresh button to update the list of pending adoptions.
Page 747: Device Upgrade
Statistics 13 - 9 Area Lists the administrator assigned deployment area where the offline device has been detected. Floor Lists the administrator assigned deployment floor where the offline device has been detected. Connected To Lists the offline’s device’s connected controller, service platform or peer model access point. Last Update Displays the date and time stamp of the last time the device was detected within the network.
Page 748: Licenses
13 - 10 WiNG 5.5 Access Point System Reference Guide Device Hostname List the administrator assigned hostname of the device receiving an update. History ID Displays a unique timestamp for the upgrade event. Last Update Status Displays the initiation, completion or error status of each listed upgrade operation.
Page 749 Statistics 13 - 11 Figure 13-7 System - Licenses screen 4. The Local Licenses table provides the following information: Cluster/Hostname Lists the administrator assigned cluster hostname whose license count and utilization is tallied in this Local Licenses table. AP Licenses Installed Lists the number of access point connections available to this device under the terms of the current license.
Page 750 13 - 12 WiNG 5.5 Access Point System Reference Guide Lent AAP Licenses Displays the number of Adaptive Access Point licenses lent (from this device) to a cluster member to compensate for an access point licenses deficiency. Total AAP Licenses Displays the total number of Adaptive Access Point connection licenses currently available to this device.
Page 751 Statistics 13 - 13 Refer to the following license utilization data: Cluster/Hostname Lists the administrator assigned cluster hostname whose license count and utilization is listed and tallied for access points. AP Licenses Installed Lists the number of access point connections available to this peer access point under the terms of the current license.
Page 752: Rf Domain Statistics
13 - 14 WiNG 5.5 Access Point System Reference Guide 13.2 RF Domain Statistics Statistics RF Domain screens display status for a selected RF domain. This includes the RF Domain health and device inventory, wireless clients and Smart RF functionality. RF Domains allow administrators to assign regional, regulatory and RF configuration to devices deployed in a common coverage area such as on a building floor, or site.
Page 753 Statistics 13 - 15 Figure 13-8 RF Domain - Health screen 4. The Domain field displays the name of the RF Domain manager. The RF Domain manager is the focal point for the radio system and acts as a central registry of applications, hardware and capabilities. It also serves as a mount point for all the different pieces of the hardware system file.
Page 754 13 - 16 WiNG 5.5 Access Point System Reference Guide Radio ID Lists each radio’s administrator defined hostname and its radio designation (radio 1, radio 2 or radio 3). Radio Type Displays the radio type as either 5 GHz or 2.4 GHz.
Page 755: Inventory
Statistics 13 - 17 13.The Traffic Statistics statistics table displays the following information for transmitted and received packets: Total Bytes Displays the total bytes of data transmitted and received within the access point RF Domain. Total Packets Lists the total number of data packets transmitted and received within the access point RF Domain.
Page 756 13 - 18 WiNG 5.5 Access Point System Reference Guide Figure 13-9 RF Domain - Inventory screen 4. The Device Types table displays the total members in the RF Domain. The exploded pie chart depicts the distribution of RF Domain members by controller and access point model type.
Page 757: Devices
Statistics 13 - 19 8. Refer to the WLANs table to review RF Domain WLAN, radio and client utilization. Use this information to help determine whether the WLANs within this RF Domain have an optimal radio and client utilization. 9. The Clients by Band bar graph displays the total number of RF Domain member clients by their IEEE 802.11 radio type.
Page 758: Ap Detection
13 - 20 WiNG 5.5 Access Point System Reference Guide Radio Count Displays the number of radios on each listed device. AP7131N models can support from 1-3 radios depending on the hardware SKU. AP6532, AP6522, AP6562, AP71xx, AP8132 and AP8232 models have two radios. AP6511 and AP6521 models have one radio. An ES6510 is a controller or service platform-manageable Ethernet Switch, with no embedded device radios.
Page 759: Wireless Clients
Statistics 13 - 21 RSSI Displays the Received Signal Strength Indicator (RSSI) of the detected access point. Use this variable to help determine whether a device connection would improve network coverage or add noise. Reported by Displays the MAC address of the RF Domain member reporting the access point. Clear All Select Clear All to reset the statistics counters to zero and begin a new data collection.
Page 760: Device Upgrade
13 - 22 WiNG 5.5 Access Point System Reference Guide Hostname Displays the unique administrator assigned hostname when the client’s configuration was originally set. Role Lists the role assigned to each controller, service platform or access point managed client. Client Identity Lists the client’s operating system vendor identity (Android, Windows etc.)
Page 761 Statistics 13 - 23 Figure 13-13 RF Domain - Device Upgrade screen Device Upgrade screen displays the following for RF Domain member devices: Upgraded By Device Lists the name of the device performing an update on behalf of a peer device. Type Displays the model of the device receiving an update.
Page 762: Wireless Lans
13 - 24 WiNG 5.5 Access Point System Reference Guide 13.2.7 Wireless LANs RF Domain Statistics The Wireless LANs screen displays the name, network identification and radio quality information for the WLANs currently being utilized by RF Domain members. To view wireless LAN statistics for RF Domain members: 1.
Page 763: Radios
Statistics 13 - 25 Rx User Data Rate Displays the average data rate per user for packets received on each listed RF Domain member WLAN. Disconnect All Select the Disconnect All Clients button to terminate each listed client’s WLAN membership Clients from this RF Domain.
Page 764 13 - 26 WiNG 5.5 Access Point System Reference Guide Radio Type Defines whether the radio is operating within the 2.4 or 5 GHz radio band. Displays the user assigned name of the RF Domain member access point to which the radio Access Point resides.
Page 765: Rf Statistics
Statistics 13 - 27 13.2.8.2 RF Statistics To view the RF Domain radio statistics: 1. Select the Statistics menu from the Web UI. 2. Select a RF Domain from under the System node on the top, left-hand side, of the screen. 3.
Page 766: Traffic Statistics
13 - 28 WiNG 5.5 Access Point System Reference Guide Refresh Select the Refresh button to update the statistics counters to their latest values. 13.2.8.3 Traffic Statistics Traffic Statistics screen displays transmit and receive data as well as data rate and packet drop and error information for RF Domain member radios.
Page 767: Mesh
Statistics 13 - 29 Tx Dropped Displays the total number of transmitted packets which have been dropped by each RF Domain member access point radio. This includes all user data as well as any management overhead packets that were dropped. Rx Errors Displays the total number of received packets which contained errors for each RF Domain member access point radio.
Page 768: Mesh Point
13 - 30 WiNG 5.5 Access Point System Reference Guide Portal Radio MAC Displays the hardware encoded MAC address for each radio in the RF Domain mesh network. Connect Time Displays the total connection time for each listed client in the RF Domain mesh network.
Page 769 Statistics 13 - 31 Figure 13-20 RF Domain - Mesh Point MCX Logical View screen Concentric Hierarchical buttons define how the mesh point is displayed in the MCX Logical View screen. In the Concentric mode, the mesh is displayed as a concentric arrangement of devices with the root mesh at the centre and the other mesh device arranged around it.
Page 770 13 - 32 WiNG 5.5 Access Point System Reference Guide Figure 13-21 RF Domain - Mesh Point Device Type screen Root field displays the Mesh ID and MAC Address of the configured root mesh points in the RF Domain. 8. The Non Root field displays the Mesh ID and MAC Address of all configured non-root mesh points in the RF Domain.
Page 771 Statistics 13 - 33 Meshpoint Identifier The MP identifier is used to distinguish between other mesh points both on the same device and on other devices. This is used by a user to setup the preferred root configuration. Interface ID The IFID uniquely identifies an interface associated with the MPID.
Page 772 13 - 34 WiNG 5.5 Access Point System Reference Guide Sequence The sequence number also known as the destination sequence number. It is updated whenever a mesh point receives new information about the sequence number from RREQ, RREP, or RERR messages that may be received related to that destination.
Page 773 Statistics 13 - 35 Neighbor MP ID The MAC Address that the device uses to define the mesh point in the device that the neighbor is a part of. It is used to distinguish the device that is the neighbor. Neighbor IFID The MAC Address used by the interface on the neighbor device to communicate with this device.
Page 774 13 - 36 WiNG 5.5 Access Point System Reference Guide Rank The rank is the level of importance and is used for automatic resource management. 8 – The current next hop to the recommended root. 7 – Any secondary next hop to the recommended root to has a good potential route metric.
Page 775 Statistics 13 - 37 Proxy Address Displays the MAC Address of the proxy used in the mesh point. Displays the age of the proxy connection for each of the mesh points in the RF Domain. Proxy Owner The owner’s (MPID) is used to distinguish the neighbor device. Persistence Displays the persistence (duration) of the proxy connection for each of the mesh points in the RF Domain.
Page 776 13 - 38 WiNG 5.5 Access Point System Reference Guide Hostname Displays the administrator assigned hostname for each configured mesh point in the RF Domain. Configured as Root A root mesh point is defined as a mesh point connected to the WAN, providing a wired backhaul to the network (Yes/No).
Page 777 Statistics 13 - 39 Path tab displays the following: Mesh Point Name Displays the name of each configured mesh point in the RF Domain. Destination Addr The destination is the endpoint of mesh path. It may be a MAC address or a mesh point ID. Destination The MAC Address used by the interface on the neighbor device to communicate with this device.
Page 778 13 - 40 WiNG 5.5 Access Point System Reference Guide Bound Indicates whether the root is bound or unbound. Metric Displays the computed path metric between the neighbor and their root mesh point. Interface Bias This field lists any bias applied because of preferred root Interface Index.
Page 779 Statistics 13 - 41 Mesh Root Hops The number of devices between the neighbor and its root mesh point. If the neighbor is a root mesh point, this value will be 0. If the neighbor is not a root mesh point but it has a neighbor that is a root mesh point, this value will be 1.
Page 780 13 - 42 WiNG 5.5 Access Point System Reference Guide State Displays the Link State for each mesh point: • Init - indicates the link has not been established or has expired. • Enabled - indicates the link is available for communication.
Page 781 Statistics 13 - 43 Figure 13-23 RF Domain - Mesh Point Device Data Transmit screen Review the following transmit and receive statistics for Mesh nodes: Data Bytes (Bytes): Displays the total amount of data, in Bytes, that has been transmitted by mesh points in Transmitted Bytes the RF Domain.
Page 782 13 - 44 WiNG 5.5 Access Point System Reference Guide Data Rates (bps): Displays the average data rate, in kbps, for all data transmitted by mesh points in the RF Transmit Data Rate Domain. Data Rates (bps): Receive Displays the average data rate, in kbps, for all data received by mesh points in the RF Data Rate Domain.
Page 783: Smart Rf
Statistics 13 - 45 13.2.11 SMART RF RF Domain Statistics When invoked by an administrator, Self-Monitoring At Run Time (Smart RF) instructs access point radios to change to a specific channel and begin beaconing using the maximum available transmit power. Within a well-planned deployment, any RF Domain member access point radio should be reachable by at least one other radio.
Page 784 13 - 46 WiNG 5.5 Access Point System Reference Guide 6. Review the Top 10 interference table to assess RF Domain member WLANs whose radios are contributing the highest levels of detected interference within the RF Domain. WLAN Name Lists the WLANs whose member device radios are contributing to the highest levels of interference detected within the RF Domain.
Page 785 Statistics 13 - 47 9. Select Refresh to update the Summary to its latest RF Domain Smart RF information. 10.Select Details from the RF Domain menu. Refer to the General field to review assess the radio's factory encoded hardware MAC address, the radio index assigned by the administrator, the 802.11 radio type, its current operational state, the radio's AP hostname assigned by an administrator, its current operating channel and power.
Page 786 13 - 48 WiNG 5.5 Access Point System Reference Guide Figure 13-26 RFDomain - Smart RF Energy Graph 12.Select Smart RF History to review the descriptions and types of Smart RF events impacting RF Domain member devices. Figure 13-27 RF Domain - Smart RF History screen...
Page 787 Statistics 13 - 49 Type Lists a high-level description of the Smart RF activity initiated for a RF Domain member device. Description Provides a more detailed description of the Smart RF event in respect to the actual Smart RF calibration or adjustment made to compensate for detected coverage holes and interference.
Page 788: Wips
13 - 50 WiNG 5.5 Access Point System Reference Guide 13.2.12 WIPS RF Domain Statistics Refer to the Wireless Intrusion Protection Software (WIPS) screens to review a client blacklist and events reported by a RF Domain member access point. For more information, see: •...
Page 789: Wips Events
Statistics 13 - 51 Refresh Select the Refresh button to update the statistics counters to their latest values. 13.2.12.2 WIPS Events WIPS Refer to the WIPS Events screen to assess WIPS events detected by RF Domain member access point radios and reported to the controller or service platform.
Page 790: Captive Portal
13 - 52 WiNG 5.5 Access Point System Reference Guide 13.2.13 Captive Portal RF Domain Statistics A captive portal is guest access policy for providing guests temporary and restrictive access to the controller or service platform managed wireless network. Captive portal authentication is used primarily for guest or visitor access to the network, but is increasingly being used to provide authenticated access to private network resources when 802.1X EAP is not a viable option.
Page 791 Statistics 13 - 53 VLAN Displays the name of the VLAN the client would use as a virtual interface for captive portal operation with the access point. Remaining Time Displays the time after which a connected client is disconnected from the captive portal. Refresh Select the Refresh button to update the statistics counters to their latest values.
Page 792: Access Point Statistics
13 - 54 WiNG 5.5 Access Point System Reference Guide 13.3 Access Point Statistics Statistics The Access Point statistics screens displays controller or service platform connected access point performance, health, version, client support, radio, mesh, interface, DHCP, firewall, WIPS, sensor, captive portal, NTP and load information. Access point statistics consists of the following: •...
Page 793: Health
Statistics 13 - 55 13.3.1 Health Access Point Statistics The Health screen displays a selected access point’s hardware version and software version. Use this information to fine tune the performance of an access point. This screen should also be the starting point for troubleshooting an access point since it’s designed to present a high level display of access point performance efficiency.
Page 794 13 - 56 WiNG 5.5 Access Point System Reference Guide RF Domain Name Displays the access point’s RF Domain membership. Unlike a controller or service platform, an access point can only belong to one RF Domain based on its model. The domain name appears as a link that can be selected to show RF Domain utilization in greater detail.
Page 795: Device
Statistics 13 - 57 13.3.2 Device Access Point Statistics The Device screen displays basic information about the selected access point. Use this screen to gather version information, such as the installed firmware image version, the boot image and upgrade status. To view the device statistics: 1.
Page 796 13 - 58 WiNG 5.5 Access Point System Reference Guide Next Boot Designates this version as the version used the next time the access point is booted. System Resources field displays the following: Available Memory Displays the available memory (in MB) available on the access point.
Page 797 Statistics 13 - 59 IP Domain Lookup Lists the current state of an IP lookup operation. state IP Name Servers field displays the following: Name Server Displays the names of the servers designated to provide DNS resources to this access point. Type Displays the type of server for each server listed.
Page 798: Device Upgrade
13 - 60 WiNG 5.5 Access Point System Reference Guide Refresh Select Refresh to update the statistics counters to their latest values. 13.3.3 Device Upgrade Access Point Statistics The Device Upgrade screen displays information about devices receiving updates and the devices used to provision them. Use this screen to gather version data, install firmware images, boot an image and upgrade status.
Page 799: Adoption
Statistics 13 - 61 Refresh Select the Refresh button to update the screen’s statistics counters to their latest values. 13.3.4 Adoption Access Point Statistics Access point adoption stats are available for both currently adopted and access points pending adoption. Historical data can be also be fetched for adopted access points.
Page 800: Ap Adoption History
13 - 62 WiNG 5.5 Access Point System Reference Guide Type Lists the each listed access point type adopted by this access point. RF Domain Name Displays each access point’s RF Domain membership. An access point can only share RF Domain membership with other access points of the same model.
Page 801: Ap Self Adoption History
Statistics 13 - 63 AP MAC Address Displays the MAC address of each access point this access point has attempted to adopt. Reason Displays the reason code for each event listed. Event Time Displays day, date and time for each access point adoption attempt. Refresh Select the Refresh button to update the screen’s statistics counters to their latest values.
Page 802: Pending Adoptions
13 - 64 WiNG 5.5 Access Point System Reference Guide 13.3.4.4 Pending Adoptions Adoption The Pending Adoptions screen displays a list of devices yet to be adopted to this peer access point, or access points in the process of adoption.
Page 803: Ap Detection
Statistics 13 - 65 13.3.5 AP Detection Access Point Statistics The AP Detection screen displays potentially hostile access points, their SSIDs, reporting AP, and so on. Continuously revalidating the credentials of detected devices reduces the possibility of an access point hacking into the network. To view the AP detection statistics: 1.
Page 804: Wireless Clients
13 - 66 WiNG 5.5 Access Point System Reference Guide RSSI Lists a relative signal strength indication (RSSI) for a detected (and perhaps unsanctioned) access point. Last Seen Displays the time (in seconds) the unsanctioned access point was last seen on the network.
Page 805: Wireless Lans
Statistics 13 - 67 Role Lists the client’s defined role within the access point managed network. Client Identity Displays the unique identity of the listed client as it appears to its adopting access point. Vendor Displays the name of the client vendor (manufacturer). Band Displays the 802.11 radio band on which the listed wireless client operates.
Page 806 13 - 68 WiNG 5.5 Access Point System Reference Guide Figure 13-40 Access Point - Wireless LANs screen Wireless LANs screen displays the following: WLAN Name Displays the name of the WLAN the Access Point is currently using for client transmissions.
Page 807: Policy Based Routing
Statistics 13 - 69 13.3.8 Policy Based Routing Access Point Statistics The Policy Based Routing statistics screen displays statistics for selective path packet redirection. PBR can optionally mark traffic for preferential services (QoS). PBR is applied to incoming routed packets, and a route-map is created containing a set of filters and associated actions.
Page 808: Radios
13 - 70 WiNG 5.5 Access Point System Reference Guide Secondary Next Displays whether the secondary hop is applied to incoming routed packets (UP/UNREACHABLE). Hop State Default Next Hop If a packet subjected to PBR does not have an explicit route to the destination, the configured default next hop is used.
Page 809: Status
Statistics 13 - 71 13.3.9.1 Status Radios Use the Status screen to review access point radio stats in detail. Use the screen to assess radio type, operational state, operating channel and current power to assess whether the radio is optimally configured. To view access point radio statistics: 1.
Page 810: Rf Statistics
13 - 72 WiNG 5.5 Access Point System Reference Guide 13.3.9.2 RF Statistics Use the RF Statistics screen to review access point radio transmit and receive statistics, error rate and RF quality. To view access point radio RF statistics: 1. Select the Statistics menu from the Web UI.
Page 811: Traffic Statistics
Statistics 13 - 73 Traffic Index Displays the traffic utilization index of the radio. This is expressed as an integer value. 0 – 20 indicates very low utilization, and 60 and above indicate high utilization. Quality Index Displays an integer that indicates overall RF performance. The RF quality indices are: •...
Page 812: Mesh
13 - 74 WiNG 5.5 Access Point System Reference Guide Tx Packets Displays the total number of packets transmitted by each listed radio. This includes all user data as well as any management overhead packets. Rx Packets Displays the total number of packets received by each listed radio. This includes all user data as well as any management overhead packets.
Page 813: Interfaces
Statistics 13 - 75 Mesh screen describes the following: Client Displays the system assigned name of each member of the mesh network. Client Radio MAC Displays the MAC address of each client radio in the mesh network. Portal Mesh points connected to an external network and forward traffic in and out are mesh portals.
Page 814: General Interface Details
13 - 76 WiNG 5.5 Access Point System Reference Guide • General Interface Details • Network Graph 13.3.11.1 General Interface Details Interfaces The General tab provides information on a selected access point interface such as its MAC address, type and TX/RX statistics.
Page 815 Statistics 13 - 77 Traffic table displays the following: Good Octets Sent Displays the number of octets (bytes) with no errors sent by the interface. Good Octets Received Displays the number of octets (bytes) with no errors received by the interface. Good Packets Sent Displays the number of good packets transmitted.
Page 816: Network Graph
13 - 78 WiNG 5.5 Access Point System Reference Guide Receive Errors table displays the following: Rx Frame Errors Displays the number of frame errors received at the interface. A frame error occurs when data is received, but not in an expected format.
Page 817: Rtls
Statistics 13 - 79 To view a detailed graph for an interface, select an interface and drop it on to the graph. The graph displays Port Statistics as the Y-axis and the Polling Interval as the X-axis. Use the Polling Interval from-down menu to define the increment data is displayed on the graph.
Page 818 13 - 80 WiNG 5.5 Access Point System Reference Guide Figure 13-48 Access Point - RTLS screen The Access Point RTLS screen displays the following for Aeroscout tags: Engine IP Lists the IP address of the Aeroscout locationing engine. Engine Port Displays the port number of the Aeroscout engine.
Page 819: Pppoe
Statistics 13 - 81 The Access Point RTLS screen displays the following for Ekahau tags: Tag Reports Displays the number of tag reports received from locationing equipped radio devices supporting RTLS. Refresh Select the Refresh button to update the screen’s statistics counters to their latest values. 13.3.13 PPPoE Access Point Statistics The PPPoE statistics screen displays stats derived from the AP’s access to high-speed data and broadband networks.
Page 820: Ospf
13 - 82 WiNG 5.5 Access Point System Reference Guide Authentication Type Lists authentication type used by the PPPoE client whose credentials must be shared by its peer access point. Supported authentication options include None, PAP, CHAP, MSCHAP, and MSCHAP-v2.
Page 821: Ospf Summary
Statistics 13 - 83 13.3.14.1 OSPF Summary OSPF To view OSPF summary statistics: 1. Select the Statistics menu from the Web UI. 2. Select System from the navigation pane (on the left-hand side of the screen), expand the default node and select an access point for statistical observation.
Page 822 13 - 84 WiNG 5.5 Access Point System Reference Guide ABR/ASBR Lists Autonomous System Boundary Router (ASBR) data relevant to OSPF routing, including the ASBR, ABR and ABR type. An Area Border Router (ABR) is a router that connects one or more areas to the main backbone network.
Page 823: Ospf Neighbors
Statistics 13 - 85 13.3.14.2 OSPF Neighbors OSPF OSPF establishes neighbor relationships to exchange routing updates with other routers. An access point supporting OSPF sends hello packets to discover neighbors and elect a designated router. The hello packet includes link state information and list of neighbors.
Page 824: Ospf Area Details
13 - 86 WiNG 5.5 Access Point System Reference Guide Request Count Lists the connection request count (hello packets) to connect to the router interface, discover neighbors and elect a designated router. Retransmit Count Lists the connection retransmission count attempted in order to connect to the router interface, discover neighbors and elect a designated router.
Page 825 Statistics 13 - 87 Figure 13-52 Access Point - OSPF Area Details tab Area Details tab describes the following: OSPF Area ID Displays either the integer (numeric ID) or IP address assigned to the OSPF area as a unique identifier. OSPF INF Lists the interface ID (virtual interface for dynamic OSPF routes) supporting each listed OSPF area Auth Type...
Page 826: Ospf Route Statistics
13 - 88 WiNG 5.5 Access Point System Reference Guide NSSA LSA Routers in a Not-so-stubby-area (NSSA) do not receive external LSAs from Area Border Routers, but are allowed to send external routing information for redistribution. They use type 7 LSAs to tell the ABRs about these external routes, which the Area Border Router then translates to type 5 external LSAs and floods as normal to the rest of the OSPF network.
Page 827 Statistics 13 - 89 Figure 13-53 Access Point - OSPF External Routes tab External routes are external to area, originate from other routing protocols (or different OSPF processes) and are inserted into OSPF using redistribution. A stub area is configured not to carry external routes. Each external route can be tagged by the advertising router, enabling the passing of additional information between routers.
Page 828 13 - 90 WiNG 5.5 Access Point System Reference Guide Figure 13-54 Access Point - OSPF Network Routes tab Network routes support more than two routers, with the capability of addressing a single physical message to all attached routers (broadcast). Neighboring routers are discovered dynamically using OSPF hello messages. This use of the hello protocol takes advantage of broadcast capability.
Page 829: Ospf Interface
Statistics 13 - 91 8. Select the Refresh button (within any of the four OSPF Routes tabs) to update the statistics counters to their latest values. 13.3.14.5 OSPF Interface OSPF An OSPF interface is the connection between a router and one of its attached networks. An interface has state information associated with it, which is obtained from the underlying lower level protocols and the routing protocol itself.
Page 830: Ospf State
13 - 92 WiNG 5.5 Access Point System Reference Guide OSPF Enabled Lists whether OSPF has been enabled for each listed interface. OSPF is disabled by default. UP/DOWN Displays whether the OSPF interface (the dynamic route) is currently up or down for each listed interface.
Page 831: L2Tpv3 Tunnels
Statistics 13 - 93 OSPF ignore Displays the timeout that, when exceeded, prohibits the access point from detecting changes to state monitor the OSPF link state. timeout OSPF max ignore Displays whether an OSPF state timeout is being ignored and not utilized in the transmission of state count state update requests amongst neighbors within the OSPF topology.
Page 832 13 - 94 WiNG 5.5 Access Point System Reference Guide The Access Point L2TPv3 Tunnels screen displays the following: Displays the name of each listed L2TPv3 tunnel assigned upon creation. Each listed tunnel Tunnel Name name can be selected as a link to display session data specific to that tunnel. The Sessions screen displays cookie size information as well as psuedowire information specific to the selected tunnel.
Page 833: Vrrp
Statistics 13 - 95 13.3.16 VRRP Access Point Statistics The VRRP statistics screen displays Virtual Router Redundancy Protocol (VRRP) configuration statistics supporting router redundancy in a wireless network requiring high availability. To review a selected access point’s VRRP statistics: 1. Select the Statistics menu from the Web UI.
Page 834: Critical Resources
13 - 96 WiNG 5.5 Access Point System Reference Guide Interface Name Displays the interfaces selected on the access point to supply VRRP redundancy failover support. Version Display VRRP version 3 (RFC 5798) or 2 (RFC 3768) as selected to set the router redundancy.
Page 835: Ldap Agent Status
Statistics 13 - 97 4. Refer to the General field to assess the Monitor Interval used to poll for updates from critical resources and the Source IP For Port-Limited Monitoring of critical resources. The access point Critical Resource screen displays the following: Critical Resource Lists the name of the critical resource monitored by the access point.
Page 836: Gre Tunnels
13 - 98 WiNG 5.5 Access Point System Reference Guide Figure 13-61 Access Point - LDAP Agent Status screen LDAP Agent Status screen displays the following: LDAP Agent Primary Lists the primary IP address of a remote LDAP server resource used by the access point to validate PEAP-MS-CHAP v2 authentication requests.
Page 837: Dot1X
Statistics 13 - 99 Figure 13-62 Access Point - GRE Tunnels screen The access point GRE Tunnels screen displays the following: GRE State Displays the current operational state of the GRE tunnel. Peer IP Address Displays the IP address of the peer device on the remote end of the GRE tunnel. Tunnel Id Displays the session ID of an established GRE tunnel.
Page 838 13 - 100 WiNG 5.5 Access Point System Reference Guide 2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF Domain and select one of its connected access points. 3. Select Dot1x from the left-hand side of the UI.
Page 839: Network
Statistics 13 - 101 BESM Lists whether an authentication request is pending on the listed port. Client MAC Lists the MAC address of requesting clients seeking authentication over the listed port. Guest VLAN Lists the guest VLAN utilized for the listed port. This is the VLAN traffic is bridged on if the port is unauthorized and guest VLAN globally enabled.
Page 840: Route Entries
13 - 102 WiNG 5.5 Access Point System Reference Guide correlation between each MAC address and its corresponding IP address. ARP provides the protocol rules for making this correlation and providing address conversion in both directions. To view an access point’s ARP statistics: 1.
Page 841: Bridge
Statistics 13 - 103 3. Select Network and expand the menu to reveal its sub menu items. 4. Select Route Entries. Figure 13-65 Access Point - Network Route Entries screen Route Entries screen supports the following: Destination Displays the IP address of the destination route address. FLAGS The flag signifies the condition of the direct or indirect route.
Page 842: Igmp
13 - 104 WiNG 5.5 Access Point System Reference Guide • Permits access to other networks • Times out old logins The Bridging screen also provides information about the Multicast Router (MRouter), which is a router program that distinguishes between multicast and unicast packets and how they should be distributed along the Multicast Internet. Using an appropriate algorithm, a multicast router instructs a switching device what to do with the multicast packet.
Page 843 Statistics 13 - 105 On the wired side of the network, the access point floods all the wired interfaces. This feature reduces unnecessary flooding of multicast traffic in the network To view a network’s IGMP configuration: 1. Select the Statistics menu from the Web UI.
Page 844: Dhcp Options
13 - 106 WiNG 5.5 Access Point System Reference Guide MiNT IDs Lists MiNT IDs for each listed VLAN. MiNT provides the means to secure access point profile communications at the transport layer. Using MiNT, an access point can be configured to only communicate with other authorized (MiNT enabled) access point of the same model.
Page 845 Statistics 13 - 107 DHCP Options screen displays the following: Server Information Displays the DHCP server hostname used on behalf of the access point. Image File Displays the image file name. BOOTP or the bootstrap protocol can be used to boot diskless clients.
Page 846: Cisco Discovery Protocol
13 - 108 WiNG 5.5 Access Point System Reference Guide 13.3.21.6 Cisco Discovery Protocol Network The Cisco Discovery Protocol (CDP) is a proprietary Data Link Layer network protocol implemented in Cisco networking equipment and used to share information about network devices.
Page 847: Link Layer Discovery Protocol
Statistics 13 - 109 13.3.21.7 Link Layer Discovery Protocol Network The Link Layer Discovery Protocol (LLDP) or IEEE 802.1AB is a vendor-neutral Data Link Layer protocol used by network devices for advertising of (announcing) their identity, capabilities, and interconnections on a IEEE 802 LAN network. The protocol is formally referred to by the IEEE as Station and Media Access Control Connectivity Discovery.
Page 848: Dhcp Server
13 - 110 WiNG 5.5 Access Point System Reference Guide 13.3.22 DHCP Server Access Point Statistics Access points contain an internal Dynamic Host Configuration Protocol (DHCP) server. DHCP can provide IP addresses automatically. DHCP is a protocol that includes mechanisms for IP address allocation and delivery of host-specific configuration parameters (IP address, network mask gateway etc.) from a DHCP server to a host.
Page 849 Statistics 13 - 111 Status table defines the following: Interfaces Displays the access point interface used with the DHCP resource for IP address provisioning. State Displays the current operational state of the DHCP server to assess its availability as a viable IP provisioning resource.
Page 850: Dhcp Bindings
13 - 112 WiNG 5.5 Access Point System Reference Guide 13.3.22.1 DHCP Bindings DHCP Server The DHCP Binding screen displays DHCP binding expiry time, client IP addresses and their MAC address. To view a network’s DHCP Bindings: 1. Select the Statistics menu from the Web UI.
Page 851: Dhcp Networks
Statistics 13 - 113 13.3.22.2 DHCP Networks DHCP Server The DHCP server maintains a pool of IP addresses and client configuration parameters (default gateway, domain name, name servers etc). On receiving a valid client request, the server assigns the computer an IP address, a lease (the validity of time), and other IP configuration parameters.
Page 852: Firewall
13 - 114 WiNG 5.5 Access Point System Reference Guide 13.3.23 Firewall Access Point Statistics A firewall is a part of a computer system or network designed to block unauthorized access while permitting authorized communications. It’s a device or set of devices configured to permit or deny access to the controller or service platform managed network based on a defined set of rules.
Page 853: Packet Flows
Statistics 13 - 115 13.3.23.1 Packet Flows Firewall The Packet Flows screen displays data traffic packet flow utilization. The chart represents the different protocol flows supported, and displays a proportional view of the flows in respect to their percentage of data traffic utilized. Total Active Flows graph displays the total number of flows supported.
Page 854: Denial Of Service
13 - 116 WiNG 5.5 Access Point System Reference Guide 13.3.23.2 Denial of Service Firewall A denial-of-service attack (DoS attack) or distributed denial-of-service attack is an attempt to make a computer resource unavailable to its intended users. Although the means to carry out a DoS attack may vary, it generally consists of concerted efforts to prevent an Internet site or service from functioning efficiently.
Page 855: Ip Firewall Rules
Statistics 13 - 117 13.3.23.3 IP Firewall Rules Firewall Create firewall rules to let any computer to send traffic to, or receive traffic from, programs, system services, computers or users. Firewall rules can be created to take one of the three actions listed below that match the rule’s criteria: •...
Page 856: Mac Firewall Rules
13 - 118 WiNG 5.5 Access Point System Reference Guide 13.3.23.4 MAC Firewall Rules Firewall The ability to allow or deny access point connectivity by client MAC address ensures malicious or unwanted clients are unable to bypass the access point’s security filters. Firewall rules can be created to support one of the three actions listed below that match the rule’s criteria:...
Page 857: Nat Translations
Statistics 13 - 119 Refresh Select the Refresh button to update the screen’s statistics counters to their latest values. 13.3.23.5 NAT Translations Firewall Network Address Translation (NAT) is a technique to modify network address information within IP packet headers in transit. This enables mapping one IP address to another to protect wireless controller managed network address credentials.
Page 858: Dhcp Snooping
13 - 120 WiNG 5.5 Access Point System Reference Guide Forward Dest Port Destination port for the forward NAT flow (contains ICMP ID if it is an ICMP flow). Reverse Source IP Displays the source IP address for the reverse NAT flow.
Page 859 Statistics 13 - 121 Netmask Displays the subnet mask used for DHCP discovery, and requests between the DHCP server and DHCP clients. VLAN Displays the VLAN used as a virtual interface for the newly created DHCP configuration. Lease Time When a DHCP server allocates an address for a DHCP client, the client is assigned a lease (which expires after a designated interval defined by the administrator).
Page 860: Vpn
13 - 122 WiNG 5.5 Access Point System Reference Guide 13.3.24 VPN Access Point Statistics IPSec VPN provides a secure tunnel between two networked peer controllers or service platforms. Administrators can define which packets are sent within the tunnel, and how they are protected. When a tunnelled peer sees a sensitive packet, it creates a secure tunnel and sends the packet through the tunnel to its remote peer destination.
Page 861: Ipsec
Statistics 13 - 123 5. Review the following VPN peer security association statistics: Peer Lists peer IDs for peers sharing security associations (SA) for tunnel interoperability. When a peer sees a sensitive packet, it creates a secure tunnel and sends the packet through the tunnel to its destination.
Page 862: Certificates
13 - 124 WiNG 5.5 Access Point System Reference Guide 5. Review the following VPN peer security association statistics: Peer Lists IP addresses for peers sharing security associations (SAs) for tunnel interoperability. When a peer sees a sensitive packet, it creates a secure tunnel and sends the packet through the tunnel to its destination.
Page 863 Statistics 13 - 125 Figure 13-82 Access Point - Certificate Trustpoint screen Certificate Details field displays the following: Subject Name Lists details about the entity to which the certificate is issued. Alternate Subject Displays alternative details to the information specified under the Subject Name field. Name Issuer Name Displays the name of the organization issuing the certificate.
Page 864: Rsa Keys
13 - 126 WiNG 5.5 Access Point System Reference Guide 5. Refer to the Validity field to assess the certificate duration beginning and end dates. 6. Review the Certificate Authority (CA) Details and Validity information to assess the subject and certificate duration periods.
Page 865: Wips
Statistics 13 - 127 13.3.26 WIPS Access Point Statistics A Wireless Intrusion Prevention System (WIPS) monitors the radio spectrum for the presence of unauthorized access points and take measures to prevent an intrusion. Unauthorized attempts to access a controller or service platform managed WLAN is generally accompanied by anomalous behavior as intruding clients try to find network vulnerabilities.
Page 866: Wips Events
13 - 128 WiNG 5.5 Access Point System Reference Guide Blacklisted Client Displays the MAC address of the unauthorized and blacklisted device intruding this access point’s radio coverage area. Time Blacklisted Displays the time when the client was blacklisted by this access point.
Page 867: Sensor Servers
Statistics 13 - 129 Refresh Select the Refresh button to update the screen’s statistics counters to their latest values. 13.3.27 Sensor Servers Access Point Statistics Sensor servers allow the monitor and download of data from multiple sensors and remote locations using Ethernet TCP/IP or serial communication.
Page 868: Captive Portal
13 - 130 WiNG 5.5 Access Point System Reference Guide 13.3.28 Captive Portal Access Point Statistics A captive portal forces a HTTP client to use a special Web page for authentication before using the Internet. A captive portal turns a Web browser into a client authenticator. This is done by intercepting packets regardless of the address or port, until the user opens a browser and tries to access the Internet.
Page 869: Network Time
Statistics 13 - 131 13.3.29 Network Time Access Point Statistics Network Time Protocol (NTP) is central to networks that rely on their Access Point(s) to supply system time. Without NTP, access point supplied network time is unpredictable, which can result in data loss, failed processes, and compromised security. With network speed, memory, and capability increasing at an exponential rate, the accuracy, precision, and synchronization of network time is essential in an access point managed enterprise network.
Page 870: Ntp Association
13 - 132 WiNG 5.5 Access Point System Reference Guide Precision Displays the precision of the time clock (in Hz). The values that normally appear in this field range from -6, for mains-frequency clocks, to -20 for microsecond clocks. Reference Time Displays the time stamp the access point’s clock was last synchronized or corrected.
Page 871: Load Balancing
Statistics 13 - 133 NTP Association screen displays the following: Delay Time Displays the round-trip delay (in seconds) for broadcasts between the NTP server and the access point. Display Displays the time difference between the peer NTP server and the access point’s clock. Offset Displays the calculated offset between the access point and the NTP server.
Page 872 13 - 134 WiNG 5.5 Access Point System Reference Guide Figure 13-90 Access Point - Load Balancing screen Load Balancing screen displays the following: Load Balancing Select any of the options to display any or all of the following information in the graph below: AP Load, 2.4GHz Load, 5GHz Load, and Channel.
Page 873: Environmental Sensors (Ap8132 Models Only)
Statistics 13 - 135 13.3.31 Environmental Sensors (AP8132 Models Only) Access Point Statistics An AP8132 sensor module is a USB environmental sensor extension to an AP8132 model access point. It provides a variety of sensing mechanisms, allowing the monitoring and reporting of the AP8132's radio coverage area. The output of the sensor's detection mechanisms are viewable using either the Environmental Sensor screen.
Page 874 13 - 136 WiNG 5.5 Access Point System Reference Guide remains consistently lit, as an administrator can power off the access point’s radios when no activity is detected in the immediate deployment area. For more information, see Environmental Sensor Configuration on page 5-171.
Page 875 Statistics 13 - 137 10.Refer to the Temperature Trend Over Last Day graph to assess whether deployment area temperature is consistent across specific hours of the day. Use this information to help determine whether the AP8132 can be upgraded or powered off during specific hours of the day.
Page 876 13 - 138 WiNG 5.5 Access Point System Reference Guide Figure 13-94 Access Point - Environmental Sensor screen (Humidity tab) 16.Refer to the Humidity table to assess the sensor's detected humidity fluctuations within the AP8132’s immediate deployment area. Humidity is measured in percentage. The table displays the...
Page 877: Wireless Client Statistics
Statistics 13 - 139 13.4 Wireless Client Statistics Statistics The wireless client statistics display read-only statistics for a client selected from within its connected access point directory. It provides an overview of the health of wireless clients in the network. Use this information to assess if configuration changes are required to improve client performance.
Page 878 13 - 140 WiNG 5.5 Access Point System Reference Guide Figure 13-95 Wireless Client - Health screen Wireless Client field displays the following: Client MAC Displays the factory encoded MAC address of the selected wireless client. Hostname Lists the hostname assigned to the client when initially managed by the access point.
Page 879 Statistics 13 - 141 Encryption Lists the encryption scheme applied to the client for interoperation with the access point. Captive Portal Displays whether captive portal authentication is enabled for the client as a guest access Authentication medium to the controller or service platform managed network. RF Quality Index field displays the following: RF Quality Index...
Page 880: Details
13 - 142 WiNG 5.5 Access Point System Reference Guide • 60 and above (High utilization) Traffic Utilization table displays the following: Total Bytes Displays the total bytes processed by the access point’s connected wireless client. Total Packets Displays the total number of packets processed by the wireless client.
Page 881 Statistics 13 - 143 Figure 13-96 Wireless Client - Details screen Wireless Client field displays the following: SSID Displays the client’s Service Set ID (SSID). Hostname Lists the hostname assigned to the client when initially managed by the access point managed network.
Page 882 13 - 144 WiNG 5.5 Access Point System Reference Guide Client Identity Lists the numeric precedence this client uses in establishing its identity amongst its peers. Precedence User Details field displays the following: Username Displays the unique name of the administrator or operator managing the client’s connected access point.
Page 883 Statistics 13 - 145 Displays the Basic Service Set (BSS) the access point belongs to. A BSS is a set of stations that can communicate with one another. Radio Number Displays the access point radio the wireless client is connected to. Radio Type Displays the radio type.
Page 884: Traffic
13 - 146 WiNG 5.5 Access Point System Reference Guide 13.4.3 Traffic Wireless Client Statistics The traffic screen provides an overview of client traffic utilization in both the transmit and receive directions. This screen also displays a RF quality index.
Page 885 Statistics 13 - 147 Tx Dropped Packets Displays the client’s number of dropped packets while transmitting to its connected access point. Tx Retries Displays the total number of client transmit retries with its connected access point. Rx Errors Displays the errors encountered by the client during data transmission. The higher the error rate, the less reliable the connection or data transfer between client and connected access point.
Page 886: Wmm Tspec
13 - 148 WiNG 5.5 Access Point System Reference Guide R-Value R-value is a number or score used to quantitatively express the quality of speech in communications systems. This is used in digital networks that carry Voice over IP (VoIP) traffic.
Page 887: Association History
Statistics 13 - 149 Direction Type Displays whether the WMM TPSEC data stream is in the uplink or downlink direction. Request Time Lists each sequence number’s request time for WMM TPSEC traffic in the specified direction. This is time allotted for a request before packets are actually sent. Used Time Displays the time the client used TSPEC.
Page 888: Graph
13 - 150 WiNG 5.5 Access Point System Reference Guide Channel Lists the channel shared by both the access point and client for interoperation, and to avoid congestion with adjacent channel traffic. Band Lists the 2.4 or 5GHz radio band this clients and its connect access point are using for transmit and receive operations.
Page 889: Customer Support
CUSTOMER SUPPORT Motorola Solutions Support Center Motorola Solutions responds to calls by email or telephone within the time limits set forth in support agreements. If you purchased your product from a Motorola Solutions business partner, contact that business partner for support.
Page 890 A - 2 WiNG 5.5 Access Point System Reference Guide...
Page 891: Appendix B, Publicly Available Software
APPENDIX B PUBLICLY AVAILABLE SOFTWARE B.1 General Information This document contains information regarding licenses, acknowledgments and required copyright notices for open source packages used in these Motorola Solutions products: Access Points • AP8232 • AP8132 • AP7181 • AP7161 • AP7131 •...
Page 892: Open Source Software Used
• RFS4011 • WS5100 For instructions on how to obtain a copy of any source code being made publicly available by Motorola Solutions related to Open Source Software distributed by Motorola Solutions, you may send a request in writing to: MOTOROLA SOLUTIONS, INC.
Page 893 Publicly Available Software B - 3 Name Version License binutils 2.19.1 http://www.gnu.org/software/binutils/ GNU General Public License, version 2 bison http://www.gnu.org/software/bison/ GNU General Public License, version 2 bluez http://www.bluez.org/ GNU General Public License, version 2 bridge 1.0.4 http://www.linuxfoundation.org/collaborate/wo GNU General Public rkgroups/networking/bridge/ License, version 2 bridge-utils...
Page 894 B - 4 WiNG 5.5 Access Point System Reference Guide Name Version License freeradius 2.0.2 http://www.freeradius.org/ GNU General Public License, version 2 4.1.2 http://gcc.gnu.org/ GNU General Public License, version 2 http://www.gnu.org/software/gdb/ GNU General Public License, version 3 gdbm 1.8.3 http://www.gnu.org/s/gdbm/...
Page 895 Publicly Available Software B - 5 Name Version License kexec-tools 2.0.3 http://kernel.org/pub/linux/utils/kernel/kexec/ GNU General Public License, version 2 libcares 1.7.1 http://c-ares.haxx.se/ The BSD License libcurl 7.30.0 http://curl.haxx.se/libcurl/ The BSD License libdevmapper 2.02.66 ftp://sources.redhat.com/pub/lvm2/old GNU Lesser General Public License 2.1 libexpat 2.0.0 http://expat.sourceforge.net/ MIT License...
Page 896 B - 6 WiNG 5.5 Access Point System Reference Guide Name Version License libreadline http://cnswww.cns.cwru.edu/php/chet/readline GNU General Public /rltop.html License, version 2 libtool 1.5.24 http://www.gnu.org/software/libtool/ GNU General Public License, version 2 libusb 0.1.12 http://www.libusb.org/ GNU Lesser General Public License, version libvirt 0.9.11...
Page 897 Publicly Available Software B - 7 Name Version License mkyaffs None http://www.yaffs.net/ GNU General Public License, version 2 mod_ssl 2.8.3.1-1.3.41 http://www.modssl.org/ The BSD License 2009-05-05 http://www.linux-mtd.infradead.org/ GNU General Public License, version 2 mtd-utils 1.4.4 http://www.linux-mtd.infradead.org/ GNU General Public License, version 2 mtd-utils 2009-02-27 http://www.linux-mtd.infradead.org/...
Page 898 B - 8 WiNG 5.5 Access Point System Reference Guide Name Version License pdnsd 1.2.5 http://members.home.nl/p.a.rombouts/pdnsd/ GNU General Public License, version 2 picocom http://code.google.com/p/picocom/ GNU General Public License, version 2 ping None The BSD License pkg-config 0.22 http://pkg-config.freedesktop.org/wiki/ GNU General Public...
Page 899 Publicly Available Software B - 9 Name Version License samba 3.5.1 http://www.samba.org GNU General Public License, version 3 4.1.2 http://www.gnu.org/software/sed/ GNU General Public License, version 2 smarttools http://smartmontools.sourceforge.net GNU General Public License, version 2 snmpagent 5.0.9 http://sourceforge.net/ The BSD License sqlite3 3070900 http://www.sqlite.org/...
Page 900 B - 10 WiNG 5.5 Access Point System Reference Guide Name Version License usbutils 0.73 http://www.linux-usb.org/ GNU General Public License, version 2 util-linux 2.20 http://www.kernel.org/pub/linux/utils/util-linux GNU General Public License, version 2 valgrind 3.5.0 http://valgrind.org/ GNU General Public License, version 2 wanpipe 3.5.18...
Page 901: Oss Licenses
Publicly Available Software B - 11 B.3 OSS Licenses B.3.1 Apache License, Version 2.0 Apache License Version 2.0, January 2004 http://www.apache.org/licenses/ TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION 1. Definitions. "License" shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9 of this document.
Page 902 B - 12 WiNG 5.5 Access Point System Reference Guide of their Contribution(s) with the Work to which such Contribution(s) was submitted. If You institute patent litigation against any entity (including a cross-claim or counterclaim in a lawsuit) alleging that the Work or a Contribution incorporated within the Work constitutes direct or contributory patent infringement, then any patent licenses granted to You under this License for that Work shall terminate as of the date such litigation is filed.
Page 903: The Bsd License
Publicly Available Software B - 13 harmless for any liability incurred by, or claims asserted against, such Contributor by reason of your accepting any such warranty or additional liability. END OF TERMS AND CONDITIONS B.3.2 The BSD License Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1.
Page 904 B - 14 WiNG 5.5 Access Point System Reference Guide 1. Definitions 1. "Adaptation" means a work based upon the Work, or upon the Work and other pre-existing works, such as a translation, adaptation, derivative work, arrangement of music or other alterations of a literary or artistic work, or phonogram or...
Page 905 Publicly Available Software B - 15 chosen by them; to perform the Work to the public by any means or process and the communication to the public of the performances of the Work, including by public digital performance; to broadcast and rebroadcast the Work by any means including signs, sounds or images.
Page 906 B - 16 WiNG 5.5 Access Point System Reference Guide 2. You may Distribute or Publicly Perform an Adaptation only under the terms of: (i) this License; (ii) a later version of this License with the same License Elements as this License; (iii) a Creative Commons jurisdiction license (either this or a later license version) that contains the same License Elements as this License (e.g., Attribution-ShareAlike 3.0 US));...
Page 907 Publicly Available Software B - 17 5. Representations, Warranties and Disclaimer UNLESS OTHERWISE MUTUALLY AGREED TO BY THE PARTIES IN WRITING, LICENSOR OFFERS THE WORK AS-IS AND MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND CONCERNING THE WORK, EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF TITLE, MERCHANTIBILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT, OR THE ABSENCE OF LATENT OR OTHER DEFECTS, ACCURACY, OR THE PRESENCE OF ABSENCE OF ERRORS, WHETHER OR NOT DISCOVERABLE.
Page 908: Dropbear License
B - 18 WiNG 5.5 Access Point System Reference Guide any general, special, incidental or consequential damages arising in connection to this license. Notwithstanding the foregoing two (2) sentences, if Creative Commons has expressly identified itself as the Licensor hereunder, it shall have all rights and obligations of Licensor.
Page 909: Gnu General Public License, Version 2
Publicly Available Software B - 19 loginrec is written primarily by Andre Lucas, atomicio.c by Theo de Raadt. strlcat() is (c) Todd C. Miller ===== Import code in keyimport.c is modified from PuTTY's import.c, licensed as follows: PuTTY is copyright 1997-2003 Simon Tatham. Portions copyright Robert de Bath, Joris van Rantwijk, Delian Delchev, Andreas Schultz, Jeroen Massar, Wez Furlong, Nicolas Barry, Justin Bradford, and CORE SDI S.A.
Page 910 B - 20 WiNG 5.5 Access Point System Reference Guide Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and passed on, we want its recipients to know that what they have is not the original, so that any problems introduced by others will not reflect on the original authors' reputations.
Page 911 Publicly Available Software B - 21 In addition, mere aggregation of another work not based on the Library with the Library (or with a work based on the Library) on a volume of a storage or distribution medium does not bring the other work under the scope of this License. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the Library.
Page 912 B - 22 WiNG 5.5 Access Point System Reference Guide and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified version is interface-compatible with the version that the work was made with.
Page 913: B.3.6 Gnu Lesser General Public License 2.1
Publicly Available Software B - 23 distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice. This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.
Page 914 B - 24 WiNG 5.5 Access Point System Reference Guide This license, the Lesser General Public License, applies to some specially designated software packages--typically libraries--of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully about whether this license or the ordinary General Public License is the better strategy to use in any particular case, based on the explanations below.
Page 915 Publicly Available Software B - 25 The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference between a "work based on the library" and a "work that uses the library". The former contains code derived from the library, whereas the latter must be combined with the library in order to run.
Page 916 B - 26 WiNG 5.5 Access Point System Reference Guide part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you;...
Page 917 Publicly Available Software B - 27 a. Accompany the work with the complete corresponding machine-readable source code for the Library including whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the work is an executable linked with the Library, with the complete machine-readable "work that uses the Library", as object code and/or source code, so that the user can modify the Library and then relink to produce a modified executable...
Page 918: Gnu General Public License, Version 3
B - 28 WiNG 5.5 Access Point System Reference Guide distribute the Library at all. For example, if a patent license would not permit royalty-free redistribution of the Library by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Library.
Page 919 Publicly Available Software B - 29 Copyright (C) 2007 Free Software Foundation, Inc. Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The GNU General Public License is a free, copyleft license for software and other kinds of works. The licenses for most software and other practical works are designed to take away your freedom to share and change the works.
Page 920 B - 30 WiNG 5.5 Access Point System Reference Guide TERMS AND CONDITIONS 0. Definitions. "This License" refers to version 3 of the GNU General Public License. "Copyright" also means copyright-like laws that apply to other kinds of works, such as semiconductor masks.
Page 921 Publicly Available Software B - 31 2. Basic Permissions. All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
Page 922 B - 32 WiNG 5.5 Access Point System Reference Guide A compilation of a covered work with other separate and independent works, which are not by their nature extensions of the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or distribution medium, is called an "aggregate"...
Page 923 Publicly Available Software B - 33 modified object code on the User Product (for example, the work has been installed in ROM). The requirement to provide Installation Information does not include a requirement to continue to provide support service, warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has been modified or installed.
Page 924 B - 34 WiNG 5.5 Access Point System Reference Guide However, if you cease all violation of this License, then your license from a particular copyright holder is reinstated (a) provisionally, unless and until the copyright holder explicitly and finally terminates your license, and (b) permanently, if the copyright holder fails to notify you of the violation by some reasonable means prior to 60 days after the cessation.
Page 925 Publicly Available Software B - 35 requirements of this License, to extend the patent license to downstream recipients. "Knowingly relying" means you have actual knowledge that, but for the patent license, your conveying the covered work in a country, or your recipient's use of the covered work in a country, would infringe one or more identifiable patents in that country that you have reason to believe are valid.
Page 926: Isc License
B - 36 WiNG 5.5 Access Point System Reference Guide THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS"...
Page 927 Publicly Available Software B - 37 The "Minimal Corresponding Source" for a Combined Work means the Corresponding Source for the Combined Work, excluding any source code for portions of the Combined Work that, considered in isolation, are based on the Application, and not on the Linked Version.
Page 928: Gnu General Public License 2.0
B - 38 WiNG 5.5 Access Point System Reference Guide option 4d0, the Installation Information must accompany the Minimal Corresponding Source and Corresponding Application Code. If you use option 4d1, you must provide the Installation Information in the manner specified by section 6 of the GNU GPL for conveying Corresponding Source.)
Page 929 Publicly Available Software B - 39 For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights.
Page 930 B - 40 WiNG 5.5 Access Point System Reference Guide Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing it).
Page 931 Publicly Available Software B - 41 machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange. If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code.
Page 932 B - 42 WiNG 5.5 Access Point System Reference Guide It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction means you cannot use both them and the Library together in an executable that you distribute.
Page 933: Gnu Lesser General Public License, Version 2.1
Publicly Available Software B - 43 13.The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.
Page 934 B - 44 WiNG 5.5 Access Point System Reference Guide To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the library, or if you modify it.
Page 935 Publicly Available Software B - 45 "Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library.
Page 936 B - 46 WiNG 5.5 Access Point System Reference Guide source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange. If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code.
Page 937 Publicly Available Software B - 47 It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction means you cannot use both them and the Library together in an executable that you distribute.
Page 938: B.3.12 Gnu Lesser General Public License, Version 2.1
B - 48 WiNG 5.5 Access Point System Reference Guide Each version is given a distinguishing version number. If the Library specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation.
Page 939 Publicly Available Software B - 49 To protect your rights, we need to make restrictions that forbid distributors to deny you these rights or to ask you to surrender these rights. These restrictions translate to certain responsibilities for you if you distribute copies of the library or if you modify For example, if you distribute copies of the library, whether gratis or for a fee, you must give the recipients all the rights that we gave you.
Page 940 B - 50 WiNG 5.5 Access Point System Reference Guide A "library" means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of those functions and data) to form executables.
Page 941 Publicly Available Software B - 51 3. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the Library. To do this, you must alter all the notices that refer to this License, so that they refer to the ordinary GNU General Public License, version 2, instead of to this License.
Page 942 B - 52 WiNG 5.5 Access Point System Reference Guide executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified version is interface-compatible with the version that the work was made with.
Page 943: Mit License
Publicly Available Software B - 53 software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice. This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.
Page 944: Mozilla Public License, Version 2
B - 54 WiNG 5.5 Access Point System Reference Guide B.3.14 Mozilla Public License, version 2 Version 2.0 1. Definitions 1.1. Contributor means each individual or legal entity that creates, contributes to the creation of, or owns Covered Software. 1.2. Contributor Versionâ means the combination of the Contributions of others (if any) used by a Contributor and that particular Contribution.
Page 945 Publicly Available Software B - 55 2. under Patent Claims of such Contributor to make, use, sell, offer for sale, have made, import, and otherwise transfer either its Contributions or its Contributor Version. 2.2. Effective Date The licenses granted in Section 2.1 with respect to any Contribution become effective for each Contribution on the date the Contributor first distributes such Contribution.
Page 946 B - 56 WiNG 5.5 Access Point System Reference Guide 3. Responsibilities 3.1. Distribution of Source Form All distribution of Covered Software in Source Code Form, including any Modifications that You create or to which You contribute, must be under the terms of this License. You must inform recipients that the Source Code Form of the Covered Software is governed by the terms of this License, and how they can obtain a copy of this License.
Page 947 Publicly Available Software B - 57 non-compliance by some reasonable means, this is the first time You have received notice of non-compliance with this License from such Contributor, and You become compliant prior to 30 days after Your receipt of the notice. 5.2.
Page 948: The Open Ldap Public License
B - 58 WiNG 5.5 Access Point System Reference Guide 10.3. Modified Versions If you create software not governed by this License, and you want to create a new license for such software, you may create and use a modified version of this License if you rename the license and remove any references to the name of the license steward (except to note that such modified license differs from this License).
Page 949: Wu-Ftpd Software License
Publicly Available Software B - 59 Copyright (c) 1998-2000 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. 2.
Page 950: Zlib License
B - 60 WiNG 5.5 Access Point System Reference Guide Portions Copyright (c) 1980, 1985, 1988, 1989, 1990, 1991, 1993, 1994 The Regents of the University of California. Portions Copyright (c) 1993, 1994 Washington University in Saint Louis. Portions Copyright (c) 1996, 1998 Berkeley Software Design, Inc.
Page 951 Publicly Available Software B - 61 3. This notice may not be removed or altered from any source distribution. Jean-loup Gailly Mark Adler jloup@gzip.org madler@alumni.caltech.edu jloup@gzip.org madler@alumni.caltech.edu...
Page 952 B - 62 WiNG 5.5 Access Point System Reference Guide...
Page 954 MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2013 Motorola Solutions, Inc. All Rights Reserved.
