How To Order Repair Parts; Parts List - Empire Heating Systems DVC-35-1SPP Installation Instructions And Owner's Manual

Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information . . .
Furnace Model Number
Furnace Serial Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, IL 62222-0529
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
INDEX PART
NO. NUMBER
1 DV-1213
2 R-3165
3 DV-1204
4 DV-1202
5 DV-1205
6 DV-1249
7 DV-1230
8 DV-1233
9 DV-1224
10 R-3161
11 R-3166
12 DV-1246
13 8720130
14 8520141
15 8520142
16 R-3164
17 DV-1251
18 R-6176
19 R-3175
20 DV-1255
20 15666
21 DV-1253
22 DV-1252
23 DV-1257
24 R-3162
25 R-3163
26 R-3232
26 R-3233
27 742126
27 P-88-61
28 DV-1236
29 DV-1259
30 722040
31 852051
32 R-3170
32 R-3171
32 R-2148
32 R-5655
33 R-2708
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
12430-3-0903

HOW TO ORDER REPAIR PARTS

PARTS LIST

DESCRIPTION
TOP PLATE
DOOR CLIP (2 REQUIRED)
CASING SIDE - RIGHT
CASING BACK
CASING SIDE - LEFT
AIR DROP
TURBULATOR (3 REQUIRED)
OUTLET BOX REAR
OUTLET BOX COVER
FAN BLADE
FAN MOTOR
MOTOR MOUNTING BRACKET
BUSHING (4 REQUIRED)
RUBBER GROMMET
(4 REQUIRED)
BRASS BUSHING
(4 REQUIRED)
DOOR CLIP (2 REQUIRED)
INNER SHIELD - RIGHT (INCLUDES
NO. 22)
FAN CONTROL SWITCH
LIMIT SWITCH
INNER SHIELD FRONT (USA)
INNER FRONT ASSEMBLY
(CANADA)
INNER SHIELD COVER PLATE (2
REQUIRED)
INNER SHIELD -LEFT (INCLUDES
NO. 22)
EXCHANGER ASSEMBLY
FILTER
FILTER RETAINER
PILOT - NAT (IP ONLY)
PILOT - LPG (IP ONLY)
ORIFICE - NAT (3 REQUIRED)
ORIFICE - LPG (3 REQUIRED)
MANIFOLD
FRONT PANEL
MANIFOLD UNION
BUSHING 3/8 X 1/2
GAS VALVE - NAT (IP ONLY)
GAS VALVE - LPG (IP ONLY)
GAS VALVE - NAT (SPP ONLY)
GAS VALVE - LPG (SPP ONLY)
PIEZO IGNITOR (SPP ONLY)
Part Description
Part Number
INDEX PART
NO. NUMBER
34 DV-781
35 712098
36 FF-160
37 DV-1240
38 DV-1265
39 712059
40 DV-775
40 DV-691
41 712045
42 DV-1235
43 R-3031
44 DV-1239
45 UH-810
45 UH-452
46 R-1995
46 8720100
47 UH-451
48 DV-572
49 872056
50 872053
51 8720148
52 DV-1215
53 R-3034
53 R-3035
54 GWT-021
55 R-3180
56 R-2256
57 R-6389
58 DV-1273
59 DV-1355
60 DV-1354
61 DV-131
62 DV-769
NOT SHOWN DV-1261
NOT SHOWN 742158
NOT SHOWN 742266
NOT SHOWN 742154
NOT SHOWN R-3265
NOT SHOWN R-3172
NOT SHOWN R-3173
NOT SHOWN R-3236
DESCRIPTION
OBSERVATION HOLE COVER WITH MICA
GASKET - OBS HOLE
PIEZO BRACKET (SPP ONLY)
BURNER COMPARTMENT FRONT
BURNER COMPARTMENT BODY
GASKET - TUBE SEAL
SEAL BRACKET (SPP ONLY)
SEAL BRACKET (IP ONLY)
MANIFOLD GASKET
PILOT BRACKET (IP ONLY)
BURNER (3 REQUIRED)
BURNER BRACKET
TRANSFORMER MOUNTING BRACKET (SPP
ONLY)
TRANSFORMER MOUNTING BRACKET (IP
ONLY)
TRANSFORMER (SPP ONLY)
TRANSFORMER (IP ONLY)
JUNCTION BOX COVER
JUNCTION BOX
BUSHING
CORD SET
BUSHING
BOTTOM PLATE
PILOT - NAT (SPP ONLY)
PILOT - LPG (SPP ONLY)
PILOT BRACKET (SPP ONLY)
ELECTRODE AND WIRE (SPP ONLY)
THERMOCOUPLE -18" (SPP ONLY)
WALL THERMOSTAT - 24 VOLT
VENT KIT COMPLETE
FLUE OUTLET TUBE
AIR INLET TUBE
OUTSIDE MOUNTING PLATE
VENT CAP
PILOT TUBING
PILOT ORIFICE - NAT (SPP ONLY)
PILOT ORIFICE - LPG (SPP ONLY)
PILOT ORIFICE - NAT (IP ONLY)
PILOT ORIFICE - LPG (IP ONLY)
WIRE HARNESS (SPP ONLY)
WIRE HARNESS (IP ONLY)
WIRE (IP ONLY)
Page 19
