Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future refer-
ence.
WARNING: If the information in these instruc-
tions are not followed exactly, a fire or explosion
may result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
Patent # 5.664.555
AND
FAN TYPE
DIRECT VENT
WALL FURNACE
For Installation in
Manufactured (Mobile Home),
Modular or Residential Homes
MODEL
DV-55E-5
This appliance may be installed as an OEM
installation in a manufactured home (USA only)
or mobile home and must be installed in ac-
cordance with the manufacturer's instructions
and the Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280, in the
United States, or the Mobile Home Standard,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. A conver-
sion kit is supplied with the appliance.
WARNING: If not installed, operated and
maintained in accordance with the manufactur-
er's instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
Page 1
ACF Greenhouses
Advertisement
Table of Contents
Related Manuals for Empire Heating Systems DV-55E-5
Summary of Contents for Empire Heating Systems DV-55E-5
-
Page 1: Installation Instructions
WALL FURNACE For Installation in Manufactured (Mobile Home), Modular or Residential Homes MODEL Patent # 5.664.555 DV-55E-5 Installer: Leave this manual with the appli- ance. Consumer: Retain this manual for future refer- ence. This appliance may be installed as an OEM... -
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Important Safety Information ........................3 Safety Information for Users of LP Gas ......................4 Requirements for Massachusetts ........................5 Introduction ..............................6 Specifications ...............................6 Gas Supply ..............................7 Gas Conversion Instructions ........................8 Clearances ..............................9 Furnace Installation ..........................9-11 Lighting Instructions ..........................12 Wiring ................................13 Maintenance ...............................14 Operation and Troubleshooting ...................... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE DO NOT OPERATE THIS APPLIANCE WITHOUT FRONT PANEL INSTALLED. • Due to high temperatures the appliance should be located • Installation and repair should be done by a QUALIFIED out of traffic and away from furniture and draperies. SERVICE PERSON. -
Page 4: Safety Information For Users Of Lp Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires and of your household. Someday when there may not be a minute to explosions. In its natural state, propane is odorless and colorless. lose, everyone's safety will depend on knowing exactly what to You may not know all the following safety precautions which can do. -
Page 5: Requirements For Massachusetts
REQUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment 3. SIGNAGE. A metal or plastic identification plate shall be installed in every dwelling, building or structure used in permanently mounted to the exterior of the building at a whole or in part for residential purposes, including those minimum height of eight (8) feet above grade directly in owned or operated by the Commonwealth and where the... -
Page 6: Introduction
INTRODUCTION Introduction Such equipment shall be located, or protected, so it is not subject Always consult your local Building Department regarding to physical damage by a moving vehicle. regulations, codes or ordinances which apply to the installation of Qualified Installing Agency a direct vent wall furnace. -
Page 7: Gas Supply
GAS SUPPLY equate, contact your local authorized installer for installation or Consult the current National Fuel Gas Code, ANSI Z223.1 CAN/ relocation. CGA-B149 (.1 or .2) installation code. Compounds used on threaded joints of gas piping shall be resistant Recommended Gas Pipe Diameter to the action of liquefied petroleum gases. -
Page 8: Gas Conversion Instructions
GAS CONVERSION INSTRUCTIONS Warning: Conversion must be done by a qualified service technician. Main burner orifice(s) and new gas conversion label are provided in conversion kit attached to manifold pipe. CONVERSION INSTRUCTIONS FROM (LP) PROPANE GAS TO NATURAL GAS 1. Make sure gas supply to furnace is off prior to conversion and disconnect electrical power to unit. 2. -
Page 9: Clearances
CLEARANCES 1. Pick a location on a wall with a clear space of 36" (91.4cm) 50,000 BTU (14.6KW) per hour or more shall be located at least high by 43" (109cm) wide in the room. In selecting a location 12" (305mm) from any opening through which flue gases could for installation, it is necessary to provide adequate accessibility enter a building. - Page 10 2" (51mm) TO 13" (330mm) 4" (102mm) CASING WALL 2" (51mm) TO 32" (813mm) BACK WALL MOUNTING BRACKET #10 X 1" #10 X 1/2" WALL BRACKET #10 X 1/2" Figure 6 Figure 4 Installing Wall Bracket (Figures 5 and 6) After finding a location for the furnace, gas supply and vent, the WALL wall bracket must be positioned and installed.
- Page 11 FURNACE INSTALLATION (continued) Vent Terminal (Figure 9) Venting (Figures 7 and 8) Place the 6 3/8" x 6 3/8" (162mm x 162mm) black foam, wall plate This unit is vented directly out the back using the concentric vent gasket within the mounting plate. The 4 3/4" (121mm) diameter tube assembly provided.
-
Page 12: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance does not have a pilot. It is equipped with an C. -
Page 13: Wiring
WIRING The appliance, when installed, must be electrically grounded in accordance thermistor. This sensing bulb can be re-located if necessary to provided with local codes or, in the absence of local codes, with the National for better room air sensing and control. Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, CSA C22.1, Replacement of Thermistor with 24 Volt Wall Thermostat if an external electrical source is utilized. -
Page 14: Maintenance
MAINTENANCE Removing Gas Valve Proper Main Burner Flame 1. Remove front grill assembly. The proper main burner flame will be a blue primary (inner) flame 2. Disconnect manifold union assembly at gas valve. with a larger, lighter blue secondary (outer) blue flame. 3. -
Page 15: Operation And Troubleshooting
OPERATION AND TROUBLESHOOTING Your new furnace should provide many years of trouble free The hot surface ignitor is energized and after a 17 second warm- performance, however, a yearly inspection of the burners , flue up, the gas valve circuit is energized, opening the gas valve and passageways and the outlet vent assembly should be done. -
Page 16: Furnace Control Board
FURNACE CONTROL BOARD DIAGNOSTICS FAULT SEQUENCE CODE — TROUBLE SHOOTING GUIDE # of Blinks Fault Condition Fault Correction Steady On Control OK 1 Flash Temperature limit switch is open -Check Circulating Air Blower Inlet or Grill Outlet for Blockage, Inducer Blower/Circulating Air Blower Run to Cool Heat Exchanger and Limit -Check for Flame Roll Out Condition Causing Roll Out Limit Switch on Burner Box to Open... -
Page 17: How To Order Repair Parts
HOW TO ORDER REPAIR PARTS Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the service person/dealer. All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment. -
Page 18: Parts View
PARTS VIEW Page 18 19563-3-0907 ACF Greenhouses... -
Page 19: Service Notes
SERVICE NOTES 19563-3-0907 Page 19 ACF Greenhouses... - Page 20 Empire Comfort Systems, Inc. 918 Freeburg Ave. Belleville, IL 62220 PH: 618-233-7420 or 800-851-3153 FAX: 618-233-7097 or 800-443-8648 info@empirecomfort.com www.empirecomfort.com Page 20 19563-3-0907 ACF Greenhouses...
