- Page 1 A n a l o g C o n t e m p o r a r y S e r i e s Master User Guide Petite Phone Model A2211 - Analog Corded 1-line Petite Phone Model A2221 - Analog Corded 2-line Petite Phone Model A2321 - Analog Corded 2-line Trimstyle Phone...
-
Page 2: Important Safety Instructions
Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: This product should be installed by a qualified technician. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS). -
Page 3: Table Of Contents
Table of contents Parts checklist ..........................1 Telephone layout ..........................2 Analog Corded 1-line Petite Phone - A2211 ..................2 Analog Corded 2-line Petite Phone - A2221 ..................3 Analog Corded 2-line Trimstyle Phone - A2321 ................4 Installation .............................5 Analog Corded 1-line/2-line Petite Phone - A2211/A2221 .............5 Analog Corded 2-line Trimstyle Phone - A2321 ................5... -
Page 4: Parts Checklist
Parts checklist Items contained in the respective telephone package: Model name Model Parts included number Analog Corded 1-line A2211 Petite Phone Telephone base with Corded Mounting Telephone faceplate and overlay handset bracket line cord Analog Corded 2-line A2221 Petite Phone... -
Page 5: Telephone Layout
Telephone layout Analog Corded 1-line Petite Phone - A2211 MESSAGE WAITING LED Switch hook FAX/DATA port Wall mount clip Speed Dial keys PROGRAM (recessed key) PAUSE (recessed key) FLASH +/VOLUME -/VOLUME MUTE RINGER VOL IN USE light HOLD Speed Dial key... -
Page 6: Analog Corded 2-Line Petite Phone - A2221
Telephone layout Analog Corded 2-line Petite Phone - A2221 MESSAGE WAITING LED Switch hook FAX/DATA port Wall mount clip Speed Dial keys PROGRAM (recessed key) PAUSE (recessed key) FLASH +/VOLUME Speed Dial key -/VOLUME MUTE RINGER VOL LINE 1 HOLD LINE 2 CONF... -
Page 7: Analog Corded 2-Line Trimstyle Phone - A2321
Telephone layout Analog Corded 2-line Trimstyle Phone - A2321 MESSAGE WAITING LED Switch hook FAX/DATA port Wall mount clip FLASH LINE 1 LINE 1 LED LINE 2 LED LINE 2 +/VOLUME HOLD RINGER VOL MUTE -/VOLUME... -
Page 8: Installation
Installation Analog Corded 1-line/2-line Petite Phone - A2211/A2221 Analog Corded 2-line Trimstyle Phone - A2321 Telephone base installation The telephone can be adapted to desktop use or mounted on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Connect the telephone line cord to the telephone base and route along the wire duct. - Page 9 Installation Analog Corded 1-line/2-line Petite Phone - A2211/A2221 Analog Corded 2-line Trimstyle Phone - A2321 Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).
-
Page 10: Telephone Settings
Telephone settings Analog Corded 1-line/2-line Petite Phone - A2211/A2221 Analog Corded 2-line Trimstyle Phone - A2321 Default settings are indicated by asterisks (*). Setting Options Adjustable by: Handset earpiece volume 1, 2*, 3, 4 User and administrator (for models A2211 and A2221 only) - Page 11 Place the sticker back in place. Speed Dial keys For models A2211 and A2221, there are up to 11 programmable guest-service (Speed Dial) keys. Program these keys to automatically dial telephone numbers or to activate telephone system features. To program a Speed Dial key in A2211: Remove the faceplate and overlay if they are on the telephone base.
-
Page 12: Telephone Operation
Telephone operation Analog Corded 1-line Petite Phone - A2211 Receive a call When there is an incoming call, the telephone rings. The MESSAGE WAITING and IN USE LED flashes. To answer a call: Lift the corded handset from the telephone base. The IN USE LED illuminates in orange. -
Page 13: Analog Corded 2-Line Petite Phone - A2221
Telephone operation Analog Corded 2-line Petite Phone - A2221 Receive a call When there is a line 1 incoming call, the telephone rings. The MESSAGE WAITING LED and LINE 1 key flash. • • When there is a line 2 incoming call, the telephone rings. LINE 2 key flashes. To answer a call: Lift the cordless handset. - Page 14 Telephone operation Analog Corded 2-line Petite Phone - A2221 Conference call This telephone allows three-way conversations. To initiate a conference call: Place a call to the first party. Press HOLD to place the first party on hold. Place a second call on the other line. Once the second party is on the line, press CONF to start a three-way conference.
-
Page 15: Analog Corded 2-Line Trimstyle Phone - A2321
Telephone operation Analog Corded 2-line Trimstyle Phone - A2321 Receive a call • When there is a line 1 incoming call, the telephone rings. The MESSAGE WAITING LED flashes and LINE 1 key flashes in red. When there is a line 2 incoming call, the telephone rings. LINE 2 key flashes in red. •... -
Page 16: Appendix
Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, visit our website at www.vtechhotelphones.com or call 1-888-907-2007. telephone does not work at all. • Make sure the telephone line is plugged into the TEL port of the telephone base. •... -
Page 17: Vtech Hospitality Limited Warranty Program
If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty. -
Page 18: Fcc, Acta And Ic Regulations
For repair procedures, follow the instructions outlined under VTech Hospitality limited warranty program in the user’s manual. If this equipment is causing harm to the telephone network, your telephone service provider may temporarily discontinue your telephone service. -
Page 19: Maintenance
DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND/OR TELEPHONE LINE CORD FROM THE WALL. Then remove the telephone by the unplugged cords. Technical specifications Analog Corded 1-line/2-line Petite Phone - A2211/A2221 Power requirement Line powered 24V or 4V... -
Page 20: Index
Index A2211 2 5–6 7– Technical specifications 16 A2221 3 5–6 7– 10–11 Telephone layout 2–4 A2321 4 7– Telephone operation 9–12 Telephone settings 7– Terminate a conference call 11 Troubleshooting 13 Call waiting 9 Checklist 1 Conference call 11... - Page 21 A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008. Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5. VTech is the registered trademark of VTech Holdings Limited.
