Table of Contents

Advertisement

Quick Links

Download this manual
M065/M066
SERVICE MANUAL
005784MIU

Advertisement

Table of Contents
loading

Related Manuals for Ricoh M065

Summary of Contents for Ricoh M065

  • Page 1 M065/M066 SERVICE MANUAL 005784MIU...
  • Page 5 M065/M066 SERVICE MANUAL 005784MIU...
  • Page 7 It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Americas Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH AMERICAS CORPORATION.
  • Page 9 Ricoh Technical Training Program. Untrained uncertified users utilizing information contained in this service manual to repair or modify Ricoh equipment risk personal injury, damage to property or loss of warranty protection. Ricoh Americas Corporation...
  • Page 11 LEGEND PRODUCT COMPANY CODE GESTETNER LANIER RICOH SAVIN M065 SP C430DN LP137CN Aficio SP C430DN CLP37DN M066 SP C431DN LP142CN Aficio SP C431DN CLP42DN LP142CNHW* Aficio SP C431DNHW* CLP42DNHW* LP142CNHT* Aficio SP C431DNHT* CLP42DNHT* *HC (Healthcare models) DOCUMENTATION HISTORY REV. NO.

  • Page 13: Table Of Contents

    M065/M066 TABLE OF CONTENTS PRODUCT INFORMATION PRODUCT INFORMATION ............1-1     SPECIFICATIONS ................1-1     MACHINE CONFIGURATION .............. 1-2     1.2.1 MACHINE CONFIGURATION ............. 1-2     OVERVIEW ................... 1-3     1.3.1 MECHANICAL COMPONENT LAYOUT ........1-3  ...
  • Page 14 TOOLS ..................4-2     EXTERIOR COVERS ................4-3     4.3.1 LEFT COVER ................4-3     4.3.2 RIGHT COVER ................4-4     4.3.3 REAR COVER ................4-5     When Reinstalling the Rear Cover ..........4-5   M065/M066...
  • Page 15 ITB (IMAGE TRANSFER BELT) UNIT ........4-38     4.6.2 IMAGE TRANSFER BELT ............4-40     When Installing the Image Transfer Belt ........4-44   4.6.3 ITB CONTACT MOTOR ............. 4-45     4.6.4 ITB CONTACT SENSOR ............4-46     M065/M066...
  • Page 16 PRESSURE ROLLER ..............4-78     When Reinstalling the Pressure Roller .......... 4-79   4.9.5 HEATING ROLLER FUSING LAMP .......... 4-80     4.9.6 FUSING BELT ................4-84     4.9.7 FUSING, HEATING AND TENSION ROLLER ......4-86     M065/M066...
  • Page 17 4.12.2 BY-PASS TRAY UNIT ............4-118     4.12.3 DUPLEX ENTRANCE SENSOR .......... 4-120     4.12.4 DUPLEX EXIT SENSOR ............. 4-122     4.12.5 FUSING ENTRANCE SENSOR ........... 4-123     4.12.6 DUPLEX/BY-PASS MOTOR ..........4-124     M065/M066...
  • Page 18 SERVICE PROGRAM MODE ............... 5-1     5.1.1 SP TABLES ................. 5-1     5.1.2 SERVICE MODE OPERATION ........... 5-1     Accessing the Required Program ............ 5-1   Inputting a Value or Setting for a Service Program ......5-1   M065/M066...
  • Page 19 5.6.1 CONTROLLER BOARD ............. 5-22   TROUBLESHOOTING TROUBLESHOOTING ............. 6-1     SERVICE CALL CONDITIONS ............. 6-1     PROCESS CONTROL ERROR CONDITIONS ........6-2     TROUBLESHOOTING GUIDE .............. 6-3     IMAGE PROBLEMS ................6-4     M065/M066...
  • Page 20   How to calculate the paper reduction ratio ........7-6   M065/M066 SERVICE MANUAL APPENDICES SEE M065/M066 SERVICE MANUAL APPENDICES SECTION FOR DETAILED TABLE OF CONTENTS PAPER FEED UNIT PB 1020 (M384) SEE SECTION M384 FOR DETAILED TABLE OF CONTENTS...

  • Page 21: Product Information

    PRODUCT INFORMATION APPENDIX: SPECIFICATIONS INSTALLATION APPENDIX: PREVENTIVE MAINTENANCE TABLE PAPER FEED UNIT PB 1020 (M384) PREVENTIVE MAINTENANCE APPENDIX: SERVICE CALL CONDITIONS REPLACEMENT AND ADJUSTMENT APPENDIX: PROCESS CONTROL ERROR CONDITIONS SYSTEM MAINTENANCE REFERENCE APPENDIX: TROUBLESHOOTING GUIDE TROUBLESHOOTING APPENDIX: JAM DETECTION ENERGY SAVING APPENDIX: ELECTRICAL COMPONENT DEFECTS APPENDIX: SP MODE TABLES...

  • Page 23: Read This First

    Read This First Important Safety Notices Responsibilities of the Customer Engineer Customer Engineer Maintenance shall be done only by trained customer engineers who have completed service training for the machine and all optional devices designed for use with the machine. Reference Material for Maintenance Maintenance shall be done using the special tools and procedures prescribed for maintenance of the machine described in the reference materials (service manuals,...
  • Page 24 Power Always disconnect the power plug before doing any maintenance procedure. After switching off the machine, power is still supplied to the main machine and other devices. To prevent electrical shock, switch the machine off, wait for a few seconds, then unplug the machine from the power source. Before you do any checks or adjustments after turning the machine off, work carefully to avoid injury.
  • Page 25 During Maintenance General Before you begin a maintenance procedure: 1) Switch the machine off, 2) Disconnect the power plug from the power source, 3) Allow the machine to cool for at least 10 minutes. Avoid touching the components inside the machine that are labeled as hot surfaces.

  • Page 26: Lithium Batteries

    Lithium Batteries Always replace a lithium battery on a PCB with the same type of battery prescribed for use on that board. Replacing a lithium battery with any type other than the one prescribed for use on the board could lead to an explosion or damage to the PCB.
  • Page 27 After Installation, Servicing Disposal of Used Items Never incinerate used toner or toner cartridges. Toner or toner cartridges thrown into a fire can ignite or explode and cause serious injury. At the work site always carefully wrap used toner and toner cartridges with plastic bags to avoid spillage before disposal or removal.
  • Page 28 Special Safety Instructions for Toner Accidental Physical Exposure Work carefully when removing paper jams or replacing toner bottles or cartridges to avoid spilling toner on clothing or the hands. If toner is inhaled, immediately gargle with large amounts of cold water and move to a well ventilated location.

  • Page 29: Prevention Of Physical Injury

    Toner Disposal Never attempt to incinerate toner, used toner, or empty toner containers (bottles or cartridges). Burning toner can explode and scatter, causing serious burns. Always wrap used toner and empty toner bottles and cartridges in plastic bags to avoid spillage. Follow the local laws and regulations regarding the disposal of such items.

  • Page 30: Observance Of Electrical Safety Standards

    Observance of Electrical Safety Standards The machine and its peripherals must be installed and maintained by a customer service representative who has completed the training course on those models. The NVRAM on the system control board has a lithium battery which can explode if replaced incorrectly.

  • Page 31: Laser Safety

    Laser Safety The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer.
  • Page 32 Symbols, Abbreviations and Trademarks This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are as follows: See or Refer to Clip ring Screw Connector Clamp E-ring Short Edge Feed Long Edge Feed Trademarks ® ® ®...

  • Page 33: Product Information

    PRODUCT INFORMATION R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 35: Specifications

    Specifications 1. PRODUCT INFORMATION 1.1 SPECIFICATIONS See "Appendices" for the following information: "General Specifications" "Supported Paper Sizes" "Software Accessories" "Optional Equipment" M065/M066...

  • Page 36: Machine Configuration

    Machine Configuration 1.2 MACHINE CONFIGURATION 1.2.1 MACHINE CONFIGURATION Item Machine Code Remarks Main Unit M065/ M066 M065 & M066 Up to three tray units can be Paper Feed Unit M384 installed. Caster Table M393 256 MB DIMM Memory D362-21 512 MB DIMM Memory...

  • Page 37: Overview

    12. Standard Paper Feed Tray (Tray 1) 5. ITB (Image Transfer Belt) Unit 13. PSU (Power Supply Unit) 6. Fusing Unit 14. Polygon Mirror Motor 7. Duplex Unit 15. LDU 8. ID Sensor 16. ITB (Image Transfer Belt) Cleaning 9. PTR (Paper Transfer Roller) Unit M065/M066...

  • Page 38: Paper Path

    Overview 1.3.2 PAPER PATH [A]: Duplex Unit [B]: By-pass Tray [C]: Optional Paper Feed Trays (Trays 2, 3, and 4) [D]: Standard Paper Feed Tray (Tray 1) [E]: Standard Paper Exit Tray M065/M066...

  • Page 39: Drive Layout

    This controls the registration rollers. Duplex/By-pass Motor: This controls the duplex entrance, relay, exit, and by-pass feed rollers. Fusing/ Paper Exit Motor: This controls the fusing unit and paper exit rollers. 10. Inverter Motor: This controls the inverter roller. M065/M066...

  • Page 41: Installation

    INSTALLATION R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew 05/17/2011 Removed NOTE; for setting heater. 07/12/2011 Added “Operating Instructions”...

  • Page 43: Installation Requirements

    Install the machine on a strong, level base. (Inclination on any side must be no more than 5 mm.) Do not install the machine in areas that get strong vibrations. 2.1.2 MACHINE LEVEL Front to back: Within 5 mm (0.2") Right to left: Within 5 mm (0.2") M065/M066...

  • Page 44: Machine Space Requirements

    120 V to 127 V, 60 Hz: More than 12 A 220 V to 240 V, 50 Hz/60 Hz: More than 8 A Permissible voltage fluctuation: NA: ±8.66 %/ EU: ±10 % Do not put things on the power cord. M065/M066...

  • Page 45: Optional Unit Combinations

    Options Remarks Up to x 3 User: For installing on Paper Feed Unit PB1020 (M384) the table CE: For installing on the floor Install the caster table Caster Table Type C (M393) if the machine is on the floor. M065/M066...

  • Page 46: Controller Options

    2.2.2 CONTROLLER OPTIONS U: User installation, C: CE installation Options Remarks Hard Disk Drive Option Type 5000 (D362-01) M065: Optional Memory Unit Type G (D362-21) M066: Standard Memory Unit Type I (D435-01) IEEE1284 Interface Board Type A (B679-17) IEEE802.11a/g Interface Unit Type L (M344-01)

  • Page 47: Printer Installation

    If these items are also installed when you move the machine, do not use the grips. Do not remove the tapes before placing the machine. Lower the machine slowly and carefully, so as not to pinch your hands. Remove the tape from the printer. M065/M066...
  • Page 48 Open the left cover [A]. Turn the green lever counterclockwise ( ), and then slowly open the inner cover ( ). Remove the securing pin, as shown, from the transfer unit. Pinch it ( ), and then pull it out ( - ). M065/M066...
  • Page 49 Remove the protective sheet, as shown. Pinch the orange tape ( ), and then pull it out ( ). Turn the green lever clockwise to lock the unit. Close the inner cover. 10. Lock the inner cover by pushing on both ends ( ), and then turning the green lever clockwise ( ). M065/M066...

  • Page 50: Installing The Toner

    Using both hands, push the left cover firmly, until it clicks into place. 12. Put labels "1" on the front of the paper tray. Installing the toner Open the upper cover. Shake the toner bottles up and down seven or eight times. M065/M066...
  • Page 51 Carefully align the label on each toner bottle with the triangular mark on the receiving side. Push in the toner bottle until you hear a clicking sound. Do not repeatedly insert and remove toner bottles. This causes toner leakage. Close the upper cover. M065/M066...

  • Page 52: Loading Paper

    Pinch the green clips on the side guide and the end guide, and then adjust the guides to the paper size being loaded. Load the new paper stack print side up, making sure the paper is flush against the paper guides. M065/M066 2-10...
  • Page 53 Do not hold the left side guide at this time, or skew will occur. Lift the front of the paper tray, and slowly slide the paper tray back until it stops. Make sure that the paper tray is fully inserted to prevent paper jams. 2-11 M065/M066...

  • Page 54: Turning Power On

    " or " " key to select "Language." Press the "OK" key. Press the " " or " " key to select the language you want. Press the "OK" key. Press the "Menu" key to return to the initial screen. M065/M066 2-12...

  • Page 55: Printing The Test Page

    SMC report (SP 5-990). You must select one of the counter methods (developments/prints) in accordance with the contract ( SP5-045-001). If the setting of SP5-930-001 is set to "1 (enabled)", the settings of SP5-930-010, -014 and -016 must be adjusted. 2-13 M065/M066...
  • Page 56 "Menu" key. The "Counter Meter Click SP5-930-001 Method" (SP5-045) sets the "0": OFF Charge type of the counter. You can print the counter from the counter menu. When disabled: The counter menu does not show. M065/M066 2-14...
  • Page 57 -002: shows or sets the fax number SP5-812-001 Telephone of the service station. The number and -002 /Facsimile is printed on the counter list when the "Meter Click Charge" is enabled. User can send a fax message with the counter list. 2-15 M065/M066...

  • Page 58: Moving The Machine

    2) Then do the "Forced Line Position Adj. Mode a" (SP2-111-1). To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. M065/M066 2-16...

  • Page 59: Paper Feed Unit (M384)

    Remove the tape from the paper feed unit. Lift the machine with four people by using the inset grips on both sides of the machine. Align the machine with the two upright pins on the paper feed unit and then lower the machine slowly. 2-17 M065/M066...
  • Page 60 Paper Feed Unit (M384) When installing two or three units, first connect the units to each other (using the same procedure as described above), and then connect them as a single unit to the machine. M065/M066 2-18...

  • Page 61: Caster Table (M393)

    Securing brackets (right rear) Table joint bracket (left) Table joint brackets (right front) Table joint bracket (right rear) Some of these accessories may not be used. It differs depending on how many optional trays are installed in the machine. 2-19 M065/M066...

  • Page 62: Installation Procedure

    If either or both of these items are installed when you move the machine, do not use the handles. For Installing the Caster Table (M393) Only Open the left cover. Inner left lower cover ( x 3) M065/M066 2-20...
  • Page 63 Push the holder [A] down. Remove the holder [A]. Reinstall the inner left lower cover ( x 3). Close the left cover. Install the two pins [A] in the screw holes. Lift the machine and install it on the caster table. 2-21 M065/M066...
  • Page 64 Hold the handle and grips of the machine when you lift and move the machine. Open the duplex unit. 10. Right cover [A] ( x 1) 11. Install the two table joint brackets [A] at the right side ( x 5). 12. Reinstall the right cover ( x 1). M065/M066 2-22...
  • Page 65 Caster Table (M393) 13. Install the table joint bracket [A] at the left side ( x 2). 14. Close the front door. 15. Adjust the plate [A] until it is level by rotating each screw. 2-23 M065/M066...

  • Page 66: For Installing With The Paper Feed Unit (M384)

    Hold the handle and grips of the machine when you lift and move the machine. Open the front door. Right cover ( p.2-20 "For Installing the Caster Table (M393) Only") Remove the right cover [A] of the paper feed unit ( x 2). M065/M066 2-24...
  • Page 67 Install the securing holder [C]. 10. Reinstall the right cover and the right cover of the paper feed unit ( x 2). 11. Remove the left cover [A] of the paper feed unit ( x 2). 12. Remove the screw shown above. 2-25 M065/M066...
  • Page 68 15. Reinstall the right cover of the paper feed unit ( x 2). 16. Close the front door. 17. Adjust the plate until it is level by rotating each screw ( p.2-20 "For Installing the Caster Table (M393) Only"). M065/M066 2-26...

  • Page 69: Tray Heater

    Tray Heater 2.6 TRAY HEATER 2.6.1 COMPONENT CHECK Check the quantity and condition of the accessories against the following list. Description Q'ty Heater cover Tray heater Heater bracket On-standby decal Harness bracket Harness Clamp Screw (M3 x 6) 2-27 M065/M066...

  • Page 70: Tray Heater (Mainframe)

    120V 9W: NA, 230V 9W: EU/AA Rear cover ( p.4-5) Right cover ( p.4-4) Controller box ( p.4-143) Inner left lower cover ( p.4-11) HVPS: CB bracket ( p.4-148 "HVPS: CB Board") Install the heater [A] on the bracket ( x 2). M065/M066 2-28...

  • Page 71: Tray Heater (Optional Unit)

    Tray Heater Remove the two clamps [A]. Attach the two clamps [A] (removed in step 8) to the bracket [B]. 10. Route the harnesses as shown above ( x 2). 2-29 M065/M066...
  • Page 72 12. Reinstall the HVPS: CB bracket. 13. Pass the heater harness [A] through the hole [B] in the controller box (shown in the red circle). 14. Reinstall the controller box. 15. Attach the two clamps [A] to the controller box. M065/M066 2-30...
  • Page 73 16. Connect the relay harness [A] to CN906 [B] ( x 2). 17. Connect the relay harness [A] to the heater harness [C] ( x 2). 18. Reassemble the machine. 19. Attach the on/standby decal [A] to the left-hand side of the main power switch. ⇒ 2-31 M065/M066...

  • Page 74: Component Check

    Tray heater Securing bracket (right rear) Securing holder Securing bracket (left) On-standby decal Edge clamp Clamp Screw (M4 x 8) Screw (M3 x 8) Spring washer ( 4) Spring washer ( 3) Washer ( 4) Washer ( 3) Harness M065/M066 2-32...

  • Page 75: For Installing The Tray Heater In M384

    Tray Heater For Installing the Tray Heater in M384 Pull out the tray [A] from the optional paper tray. Put the tray heater [B] into the optional paper feed unit. 2-33 M065/M066...
  • Page 76 Pass the heater harness [A] through the square hole [B]. Position the tray heater [A] (3 hooks) Install the tray heater [A] in the machine ( x 1 (M4x8) [B], spring washer x 1 ( 4) [C], washer x 1 ( 4) [D]). M065/M066 2-34...
  • Page 77 Install the edge clamp [A] and the six clamps. Connect the relay harness [A] to the heater harness [B] ( x 4). Route the relay harness [A] as shown above ( x 3). Make sure that the connector [B] is placed securely as shown above. 2-35 M065/M066...
  • Page 78 Do steps 10 and 11 if you install another optional paper feed unit below M384. If not, go to step 12. 10. Bracket [A] ( x 1) 11. Install the relay harness [A] as shown above. Repeat steps from 1 to 11 if two or three optional paper feed units are to be M065/M066 2-36...
  • Page 79 Tray Heater installed. 12. Rear cover [A] ( x 1). 13. Bracket [A] ( x 1). 14. Connect the relay harness to the relay harness of the mainframe. 15. Reassemble the machine. 2-37 M065/M066...

  • Page 80: For Installing The Securing Bracket

    (M384). Remove the holder ( p.2-19 "Caster Table (M393)"). Reinstall the inner left lower cover ( x 3). Close the left cover. Remove the left cover of the paper feed unit ( p.2-19 "Caster Table (M393)"). M065/M066 2-38...
  • Page 81 Remove the screw. Install the securing bracket [A] ( x 1 (M3x8) [B], spring washer x 1 ( 3) [C], washer x 1 ( 3) [D]). Remove the right cover of the paper feed unit ( p.2-19 "Caster Table (M393)"). 2-39 M065/M066...
  • Page 82 Tray Heater Install the securing bracket [A] ( x 2 (M4x8) [B], spring washer x 2 ( 4) [C], washer x 2 ( 4) [D]). Install the securing holder [E]. 10. Reassemble the machine. M065/M066 2-40...

  • Page 83: Controller Options

    This machine has I/F card slots for optional I/F connections and SD card slots applications. After you install an option, check that the machine can recognize it. I/F Card Slots Slot [A] is used for one of the optional I/F connections (only one can be installed): IEEE1284, IEEE802.11a/g, Gigabit Ethernet, 2-41 M065/M066...

  • Page 84: Sd Card Slots

    The necessary data for authentication is transferred with the application program from an SD card to another SD card. Authentication fails if you try to use the SD card after you copy the application program from one card to another card. M065/M066 2-42...

  • Page 85: Move Exec

    SD card. Turn the main switch on. Start the SP mode. Select SP5-873-001 "Move Exec". Follow the messages shown on the operation panel. Turn the main switch off. Remove the SD card from SD card slot 2. 2-43 M065/M066...

  • Page 86: Undo Exec

    Remove the SD card from SD card slot 2. This step assumes that the application programs in the SD card are used by the machine. 10. Turn the main switch on. 11. Check that the application programs run normally. M065/M066 2-44...

  • Page 87: Preventive Maintenance

    PREVENTIVE MAINTENANCE R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 89: Maintenance Tables

    Maintenance Tables 3. PREVENTIVE MAINTENANCE 3.1 MAINTENANCE TABLES See "Appendices" for the following information: "User Maintenance Items" M065/M066...

  • Page 91: Replacement And Adjustment

    REPLACEMENT AND ADJUSTMENT R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew 01/14/2011 Added step 5 and 6 to Installing the PCDU. 21 ~ 22 08/10/2011 Added step 7 to Installing the PCDU.

  • Page 93: Before You Start

    Before You Start 4. REPLACEMENT AND ADJUSTMENT 4.1 BEFORE YOU START Turn off the main power switch and unplug the machine before you do the procedures in this section. M065/M066...

  • Page 94: Special Tools

    Loop Back Connector - Parallel C4019503 20X Magnification Scope A2579300 Grease Barrierta – S552R 52039502 Silicon Grease G-501 B6795100 Plug - IEEE1284 Type C D0159500 G104 Yellow Toner Loop back connector - parallel (item 5) requires plug - IEEE1284 type C (item 9). M065/M066...

  • Page 95: Exterior Covers

    Exterior Covers 4.3 EXTERIOR COVERS 4.3.1 LEFT COVER Open the left cover. Remove the waste toner bottle. Release the belt [A]. Remove the two brackets [A] ( x 2) Left cover [B] M065/M066...

  • Page 96: Right Cover

    Exterior Covers 4.3.2 RIGHT COVER Open the duplex unit [A]. Right cover [A] ( x 1) M065/M066...

  • Page 97: Rear Cover

    1) When Reinstalling the Rear Cover Make sure that these hinge covers [A] can be moved smoothly (up and down) after installing the rear cover. If these hinge covers do not move smoothly, try installing the rear cover again. M065/M066...

  • Page 98: Top Cover

    Exterior Covers 4.3.4 TOP COVER Right cover ( p.4-4) Rear cover ( p.4-5) Open the upper cover [A]. Top cover [A] ( x 3) M065/M066...

  • Page 99: When Reinstalling The Top Cover

    Exterior Covers When Reinstalling the Top Cover Make sure that the hook [A] is installed in the hole [B] when reinstalling the top cover. M065/M066...

  • Page 100: Operation Panel

    Exterior Covers 4.3.5 OPERATION PANEL Open the duplex unit ( p.4-4 "Right Cover"). Remove the four screws. Operation panel [A] ( x 1, x 1) M065/M066...

  • Page 101: Inner Left Upper Cover

    Exterior Covers 4.3.6 INNER LEFT UPPER COVER Right cover ( p.4-4) Top cover ( p.4-6) Open the left cover. Inner left upper cover [A] ( x 2) M065/M066...

  • Page 102: Inner Left

    Left cover ( p.4-3) Inner left upper cover ( p.4-9) Inner left lower cover ( p.4-11) Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B]. Inner left front cover [A] ( x 2) M065/M066 4-10...

  • Page 103: Inner Left Rear Cover

    4.3.8 INNER LEFT REAR COVER Left cover ( p.4-3) Rear cover ( p.4-5) Inner left rear cover [A] ( x 2) 4.3.9 INNER LEFT LOWER COVER Open the left cover. Inner left lower cover [A] ( x 3) 4-11 M065/M066...

  • Page 104: Inner Right

    Exterior Covers 4.3.10 INNER RIGHT FRONT COVER Right cover ( p.4-4) Top cover ( p.4-6) Connector cover [A] (hook) Disconnect the six harnesses [A] ( x 1). Release the inner right front cover [A] ( x 2). M065/M066 4-12...

  • Page 105: Inner Right Rear Cover

    Exterior Covers Inner right front cover [A] ( x 6) 4.3.11 INNER RIGHT REAR COVER Rear cover ( p.4-5) Right cover ( p.4-4) Inner right rear cover [A] ( x 3) 4-13 M065/M066...

  • Page 106: Laser Optics

    Do the following settings before removing the laser unit. These are adjustments for skew adjustment motors in the laser unit, main scan start position, and laser diode power. Plug in and turn on the main power switch of the machine. Enter the SP mode. M065/M066 4-14...

  • Page 107: Recovery Procedure For No Replacement Preparation Of Laser Unit

    Disconnect the harness [A] of the skew correction motor. Do steps 1 to 9 of "Before removing the old laser unit". Connect the harness [A] and reinstall the controller box. Plug in and turn on the main power switch. 4-15 M065/M066...

  • Page 108: Removing The Laser Unit

    Removing the laser unit Rear cover ( p.4-5) Right cover ( p.4-4) Controller box ( p.4-143) Development fan duct ( p.4-36 "Development Fan") Bracket [A] ( x 1) Pull out the laser unit [A] ( x 2, x 1, x 1). M065/M066 4-16...

  • Page 109: After Installing A New Laser Unit

    Check that the left and right trim margin is within 4 ± 1 mm. If not, change the standard value for the main scan magnification adjustment. Select "0" with SP2-109-003 after printing the "1-dot trimming pattern. Do the line position adjustment. 4-17 M065/M066...

  • Page 110: Laser Unit Fan

    Controller box ( p.4-143) HVPS: CB bracket ( p.4-148 "HVPS: CB Board") Laser unit fan [A] ( x 1, hooks) When installing the laser unit fan Make sure that the laser unit fan is installed with its decal facing upward. M065/M066 4-18...

  • Page 111: Ldu Shutter Motor

    Laser Optics 4.4.4 LDU SHUTTER MOTOR Duplex unit ( p.4-116) Paper feed unit ( p.4-94) Release the LDU shutter motor [A] ( x 3). LDU shutter motor [A] ( x 2, x 1). 4-19 M065/M066...

  • Page 112: Image Creation

    Open the left cover. Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B]. Turn the ITB lock lever [A] counterclockwise (this step is only needed if you remove the PCDU: K). PCDU [A] M065/M066 4-20...
  • Page 113 PDCU (circled in red below) is inside the hole of the bracket. Do this for all four PDCU’s. Correct Incorrect NOTE: If the white locking tab is not locked into the slot on the bracket, reseat the PDCU until it properly locks into place. 4-21 M065/M066...

  • Page 114: When Installing A New Pcdu

    Release the lock [B]. Remove the waste toner bottle [C]. Put the waste toner bottle [C] into the supplied plastic bag to prevent toner from leaking out of the bottle, and then seal the bag. M065/M066 4-22...

  • Page 115: Toner Supply Tube

    Clean each toner hopper entrance [A] with a vacuum cleaner. PCDUs ( p.4-20) Right cover ( p.4-4) Rear cover ( p.4-5) Top cover ( p.4-6) Inner left upper cover ( p.4-9) Inner right rear cover ( p.4-13) 10. Drive unit fan base ( p.4-73 "Drive Unit Fan") 4-23 M065/M066...
  • Page 116 Image Creation 11. Inner upper right cover [A] ( x 2) 12. Inner upper cover [A] ( x 1) 13. Remove the two screws. M065/M066 4-24...
  • Page 117 14. Release each clamp and disconnect each connector. 15. Release the toner supply motor brackets [A] ( x 3 each) Place the toner supply motor brackets on a sheet of paper [A] because grease may fall from the toner supply motors. 4-25 M065/M066...
  • Page 118 16. Release each toner supply tube [A] by pulling out its gear assembly a short distance. Work carefully when releasing the toner supply tube [A] to avoid spilling toner on clothing or the hands. 17. Release the upper cover sensor [A] (hooks). 18. Release the toner plate [A] ( x 7). M065/M066 4-26...
  • Page 119 Image Creation 19. Remove each clip [A]. Make sure that the clip [A] does not fall inside the machine during maintenance. 20. Turn the toner tube [A] as shown above. 21. Pull out each toner supply tube [A]. 4-27 M065/M066...
  • Page 120 Clean each toner tube entrance with a vacuum cleaner. Work carefully when removing the toner supply tube [A] to avoid spilling toner on clothing or the hands. Do not push the tip [A] of the toner tube because this will spill toner. M065/M066 4-28...

  • Page 121: Toner Supply Motor

    Top cover ( p.4-6) Motor bracket [A] ( x 3, x 1) Toner supply motor [A] ( x 2) If the bushing (white) [B] is removed with toner supply motor, install it in the toner hopper frame (as shown below). 4-29 M065/M066...

  • Page 122: Toner Collection Motor

    Make sure that the bushing (white) [A] is installed in the toner hopper frame [B]. 4.5.5 TONER COLLECTION MOTOR Inner left lower cover ( p.4-11) Inner left front cover ( p.4-10) Motor bracket [A] ( x 2, x 1, x 1) M065/M066 4-30...
  • Page 123 Image Creation Toner collection motor [A] ( x 2) Apply a small amount of "Silicone Grease G501" to the gear of the motor as shown above. 4-31 M065/M066...

  • Page 124: Waste Toner Bottle Full Sensor

    Image Creation 4.5.6 WASTE TONER BOTTLE FULL SENSOR Inner left rear cover ( p.4-11) Sensor bracket [A] ( x 2, x 1) Waste toner bottle full sensor [A] ( x 1, hooks) M065/M066 4-32...

  • Page 125: Waste Toner Bottle Set Sensor

    Image Creation 4.5.7 WASTE TONER BOTTLE SET SENSOR Inner left rear cover ( p.4-11) Sensor bracket [A] ( x 2, x 1) Waste toner bottle set sensor [A] ( x 1, hooks) 4-33 M065/M066...

  • Page 126: Rfid Cpu Board

    Image Creation 4.5.8 RFID CPU BOARD Right cover ( p.4-4) Rear cover ( p.4-5) Top cover ( p.4-6) RFID CPU Board [A] ( x 2, x 2) M065/M066 4-34...

  • Page 127: Rfid Board

    Image Creation 4.5.9 RFID BOARD Right cover ( p.4-4) Rear cover ( p.4-5) Top cover ( p.4-6) RFID board [A] ( x 1, hooks) 4-35 M065/M066...

  • Page 128: Development Fan

    4.5.10 DEVELOPMENT FAN Rear cover ( p.4-5) Right cover ( p.4-4) Controller box ( p.4-143) Development fan duct [A] ( x 4, x 2, x 1) Development fan duct cover [A] (6 hooks) Development fans [A] ( x 2 each) M065/M066 4-36...

  • Page 129: When Installing The Development Fan

    Image Creation When installing the development fan Make sure that the development fan is installed with its decal facing to the rear of the machine. 4-37 M065/M066...

  • Page 130: Image Transfer

    Image Transfer 4.6 IMAGE TRANSFER 4.6.1 ITB (IMAGE TRANSFER BELT) UNIT Open the left cover. Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B]. Turn the ITB lock lever [A] counterclockwise. M065/M066 4-38...
  • Page 131 Image Transfer Open the front door [A]. Opening the front door [A] automatically releases the lock [B] for the ITB unit. Open the upper cover [A]. 4-39 M065/M066...

  • Page 132: Image Transfer Belt

    4.6.2 IMAGE TRANSFER BELT Do not touch or damage the surface of the image transfer belt during servicing. ITB unit ( p.4-38) ITB unit cover [A] and the handles [B] (8 hooks). Three stays [A] ( x 2 each) M065/M066 4-40...
  • Page 133 Image Transfer The left stay [A] ( x 4) Rear holder bracket [A] ( x 2) ITB cleaning unit [A] 4-41 M065/M066...
  • Page 134 Image Transfer Pull the tension roller [A] as shown above. Remove a screw. Front holder bracket [A] M065/M066 4-42...
  • Page 135 10. Remove a screw, and then turn the encoder sensor [A] to the left. When replacing the image transfer belt, work carefully to avoid damaging the encoder sensor [A]. 11. The right stay [A] ( x 1) 12. Stand the ITB unit [A] as shown above. 13. Image transfer belt [B] 4-43 M065/M066...

  • Page 136: When Installing The Image Transfer Belt

    Lubricate a part of the surface of the image transfer belt [A] with yellow toner, and then turn the image transfer belt to the position [B] as shown above. Be sure to use yellow toner from the M065/M066; do not use lubricant powder, developer, or waste toner.

  • Page 137: Itb Contact Motor

    Right cover ( p.4-4) ITB contact motor unit [A] ( x 2, x 1, x 1) ITB contact motor [A] ( x 2) Apply a small amount of "Silicone Grease G501" to the gear of the motor as shown above. 4-45 M065/M066...

  • Page 138: Itb Contact Sensor

    Toner supply bracket: K [A] ( x 3, x 1) Release the toner tube: K [A] by pulling out its gear assembly a short distance. Work carefully when releasing the toner supply tube [A] to avoid spilling toner on clothing or the hands. M065/M066 4-46...
  • Page 139 Image Transfer Sensor holder [A] ( x 1, x 1) ITB contact sensor [A] ( x 1, hooks) 4-47 M065/M066...

  • Page 140: Id Sensor Board

    Image Transfer 4.6.5 ID SENSOR BOARD Fusing unit ( p.4-74) Paper exit unit ( p.4-107) Remove the two screws. ID sensor board bracket [A] ( x 1) ID sensor board cover [A] ( x 1) M065/M066 4-48...

  • Page 141: After Installing A New Id Sensor Board

    Enter the SP mode. Input all correction coefficients [A] for the ID sensor with the SP modes referring to the barcode sheet provided with the new ID sensor board. For example, input "0.99" with SP3-362-013. Exit the SP mode. 4-49 M065/M066...

  • Page 142: Paper Transfer

    To install the PTR unit, pinch the two green locks [A] while you push the unit back into position. Do not insert objects between the metal plate [B] and its black plastic base. Otherwise, the plate could be bent, and this can cause poor image quality. M065/M066 4-50...

  • Page 143: Ptr Contact Motor

    Paper Transfer 4.7.2 PTR CONTACT MOTOR Toner collection motor ( p.4-30) Interlock switch bracket [A] ( x 2, x 4) Motor bracket [A] ( x 2, x 1) 4-51 M065/M066...
  • Page 144 Paper Transfer PTR contact motor [A] ( x 2) Apply a small amount of "Silicone Grease G501" to the gear of the motor as shown above. M065/M066 4-52...

  • Page 145: Ptr Contact Sensor

    Paper Transfer 4.7.3 PTR CONTACT SENSOR Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Motors with bracket ( p.4-68) Sensor bracket [A] ( x 1) PTR contact sensor [A] ( x 1, hooks) 4-53 M065/M066...

  • Page 146: Temperature/Humidity Sensor

    Paper Transfer 4.7.4 TEMPERATURE/HUMIDITY SENSOR Inner left lower cover ( p.4-11) Temperature/Humidity sensor [A] ( x 1, x 1) M065/M066 4-54...

  • Page 147: Drive Unit

    1. ITB unit /drum-K/ development-K motor 6. Vertical transport motor 2. Drum motor: CMY 7. Registration motor 3. Development motor: CMY 8. Duplex/ by-pass motor 4. Development clutch: K 9. Fusing/ paper exit motor 5. Paper feed motor 10.Inverter motor 4-55 M065/M066...

  • Page 148: Gear Unit

    Clean each toner hopper entrance [A] with a vacuum cleaner. ITB unit ( p.4-38) PCDUs ( p.4-20) Remove the four clips. Right cover ( p.4-4) Rear cover ( p.4-5) Top cover ( p.4-6) 10. Inner right rear cover ( p.4-13) 11. Inner right front cover ( p.4-12) M065/M066 4-56...
  • Page 149 Drive Unit 12. Release the upper harness guide [A] and the lower harness guide [B] ( x 4, x all, x all) 13. BCU with bracket ( p.4-145 "BCU") 14. Remove the two screws. 4-57 M065/M066...
  • Page 150 15. Release each clamp and disconnect each connector. 16. Release the toner supply motor brackets [A] ( x 3 each) Place the toner supply motor brackets on a sheet of paper [A] because grease may fall from the toner supply motors. M065/M066 4-58...
  • Page 151 Work carefully when removing the toner supply tube [A] to avoid spilling toner on clothing or the hands. 18. Release the toner supply tubes for M, C and K. Work carefully when releasing the toner supply tubes to avoid spilling toner on clothing or the hands. 4-59 M065/M066...
  • Page 152 19. Gear unit [A] with the toner supply tubes for M, C and K ( x 6). 20. Remove the toner supply tubes for M, C and K [A] from the gear unit [B]. Work carefully when removing the toner supply tubes [A] to avoid spilling toner on clothing or the hands. M065/M066 4-60...

  • Page 153: When Installing The Gear Unit

    Drive Unit When installing the gear unit Make sure that the positioning pin [A] is set correctly when installing the gear unit. 4-61 M065/M066...

  • Page 154: Toner Supply Fan

    When installing the toner supply fan Make sure that the toner supply fan is installed with its decal facing to the left of the machine. Toner Supply Fan Base Right cover ( p.4-4) Toner supply fan base [A] ( x 2, M065/M066 4-62...

  • Page 155: Drum Motor: Cmy

    Drive Unit 4.8.3 DRUM MOTOR: CMY Right cover ( p.4-4) Toner supply fan base ( p.4-62 "Toner Supply Fan") Drum motor: CMY [A] ( x 3, x 1) 4-63 M065/M066...

  • Page 156: Development Motor: Cmy

    Drive Unit 4.8.4 DEVELOPMENT MOTOR: CMY Right cover ( p.4-4) Bracket [A] ( x 1) Development motor: CMY [A] ( x 3, x 1) M065/M066 4-64...

  • Page 157: Itb Unit/ Drum-K/ Development-K Motor

    Drive Unit 4.8.5 ITB UNIT/ DRUM-K/ DEVELOPMENT-K MOTOR Right cover ( p.4-4) ITB unit/ Drum-K/ Development-K motor [A] ( x 3, x 1) 4-65 M065/M066...

  • Page 158: Development Clutch: K

    Development clutch: K cover [A] ( x 2, x 1) Development clutch: K [B] 4.8.7 FUSING/PAPER EXIT MOTOR Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Fusing/paper exit motor [A] ( x 3, x 1) M065/M066 4-66...

  • Page 159: Front Door Sensor

    Drive Unit 4.8.8 FRONT DOOR SENSOR Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Front door sensor [A] ( x 1, hooks) 4-67 M065/M066...

  • Page 160: Motors With Bracket

    Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Release the upper harness guide [A] and the lower harness guide [B] ( x 4, x all, x all) Motors with bracket [A] ( x 4) M065/M066 4-68...

  • Page 161: Registration Motor

    Drive Unit 4.8.10 REGISTRATION MOTOR Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Motors with bracket ( p.4-68) Registration motor [A] ( x 2, timing belt x 1) 4-69 M065/M066...

  • Page 162: Paper Feed Motor

    2, timing belt x 1) 4.8.12 VERTICAL TRANSPORT MOTOR Right cover ( p.4-4) Top cover ( p.4-6) Inner right front cover ( p.4-12) Motors with bracket ( p.4-68) Vertical transport motor [A] ( x 2, timing belt x 1) M065/M066 4-70...

  • Page 163: Drum Phase Sensor: Cmy

    Drive Unit 4.8.13 DRUM PHASE SENSOR: CMY Right cover ( p.4-4) Push the hook, and then release the sensor holder [A]. Drum phase sensor: CMY [A] ( x 1, hooks) 4-71 M065/M066...

  • Page 164: Drum Phase Sensor: K

    Drive Unit 4.8.14 DRUM PHASE SENSOR: K Right cover ( p.4-4) Push the hook, and then release the sensor holder [A]. Drum phase sensor: K [A] ( x 1, hooks) M065/M066 4-72...

  • Page 165: Drive Unit Fan

    Drive unit fan base [A] ( x 2, x 1) Drive unit fan ( x 1, hooks) When installing the drive unit fan Make sure that the drive unit fan is installed with its decal facing to the left of the machine. 4-73 M065/M066...

  • Page 166: Fusing

    When installing the fusing unit Make sure that the both lock levers [A] are locked before closing the duplex unit. Otherwise, these lock levers [A] can be broken. 4.9.2 CLEANING UNIT Fusing unit ( p.4-74) Fusing front cover [A] ( x 2) M065/M066 4-74...

  • Page 167: Pressure Roller Fusing Lamp

    Fusing Cleaning unit [A] ( x 4) 4.9.3 PRESSURE ROLLER FUSING LAMP Fusing front cover ( p.4-74 "Cleaning Unit") Fusing upper cover [A] ( x 4) Fusing lower cover [A] ( x 3) Cleaning unit ( p.4-74) 4-75 M065/M066...
  • Page 168 1 each, spring x 1 each) Release the fusing lamp harness [A] at the right side ( x 1, x 5) Release the fusing lamp harness [A] at the left side ( x 1) Lamp holder [B] ( x 1) M065/M066 4-76...
  • Page 169 Fusing Remove the fusing lamp holder [A] at the right side ( x 1) 10. Pressure roller fusing lamp [A] 4-77 M065/M066...

  • Page 170: Pressure Roller

    Fusing 4.9.4 PRESSURE ROLLER Pressure roller fusing lamp ( p.4-75) Right stay [A] ( x 3) Thermostat holder [A] and thermistor bracket [B] ( x 4). M065/M066 4-78...

  • Page 171: When Reinstalling The Pressure Roller

    When Reinstalling the Pressure Roller When replacing the pressure roller, you have to apply lubricant to the following places. Apply "Barrierta S552R" (0.15g to 0.25g) to the left end [A] and right end [B] of the pressure roller as shown above. 4-79 M065/M066...

  • Page 172: Heating Roller Fusing Lamp

    4.9.5 HEATING ROLLER FUSING LAMP Fusing unit ( p.4-74) Fusing lower cover ( p.4-75 "Pressure Roller Fusing Lamp") Cleaning unit ( p.4-74) Fusing upper cover ( p.4-75 "Pressure Roller Fusing Lamp") Release the pins [A], and then remove the stripper plate [B]. M065/M066 4-80...
  • Page 173 Fusing Release the pins [A], and then remove the bracket [B] ( x 4). Release the fusing lamp harness [A] at the left side ( x 1, x 4). Left stay [A] ( x 3) Remove the screw. 4-81 M065/M066...
  • Page 174 10. Release the fusing lamp harnesses [A], and then remove the plate [B] ( x 2, x 2). 11. Remove the fusing lamp holder [A] ( x 1). 12. Release the fusing lamp harness [A] at the right side ( x 1, x 5) M065/M066 4-82...
  • Page 175 Fusing 13. Right stay [A] ( x 3) 14. Release the fusing lamp harnesses [A] ( x 2). 15. Lamp holder [A] ( x 1) 16. Heating roller fusing lamp [A] 4-83 M065/M066...

  • Page 176: Fusing Belt

    Fusing 4.9.6 FUSING BELT Heating roller fusing lamp ( p.4-80) C-rings and bearings [A] Gear [A] at the left side (C-ring x 1). C-rings and bearings [A] M065/M066 4-84...
  • Page 177 Fusing Remove the fusing belt [A] with rollers, lifting the shafts [B] up. Fusing belt [A] 4-85 M065/M066...

  • Page 178: Fusing, Heating And Tension Roller

    When Reinstalling the Fusing Roller When replacing the fusing roller, you have to apply lubricant to the following places. Apply "Barrierta S552R" (0.1g to 0.2g) to the left end [A] and right end [B] of the fusing roller as shown above. M065/M066 4-86...

  • Page 179: Heating Roller Thermostat

    "Pressure Roller Fusing Lamp") Remove the four screws. Remove the plate [A], and then remove the heating roller thermostats [B]. Do not re-use a thermostat that is already opened. Safety is not guaranteed if you do this. 4-87 M065/M066...

  • Page 180: Heating Roller Thermistor

    Fusing front cover ( p.4-74 "Cleaning Unit") Fusing upper cover ( p.4-75 "Pressure Roller Fusing Lamp") Fusing lower cover ( p.4-75 "Pressure Roller Fusing Lamp") Release the harness [A] ( x 2). Heating roller thermistor [A] ( x 1, x 1) M065/M066 4-88...

  • Page 181: Pressure Roller Thermistor

    Fusing 4.9.10 PRESSURE ROLLER THERMISTOR Cleaning unit ( p.4-74) Thermistor assembly [A] ( x 1, x 1) Pressure roller thermistor [A] ( x 1, x 1) 4-89 M065/M066...

  • Page 182: Pressure Roller Thermostat

    Fusing 4.9.11 PRESSURE ROLLER THERMOSTAT Fusing lower cover ( p.4-75 "Pressure Roller Fusing Lamp") Pressure roller thermostats [A] ( x 2) M065/M066 4-90...

  • Page 183: Thermopile

    Fusing 4.9.12 THERMOPILE Paper exit unit ( p.4-107) Thermopile base [A] ( x 2, x 1) Thermopile cover [A] (hooks) Thermopile [B] 4-91 M065/M066...

  • Page 184: Paper Feed

    Paper Feed 4.10 PAPER FEED 4.10.1 SEPARATION ROLLER Pull out the paper tray. Cover [A] ( x 2) Separation roller [A] ( x 1) M065/M066 4-92...

  • Page 185: Pick-Up And Paper Feed Rollers

    Paper Feed 4.10.2 PICK-UP AND PAPER FEED ROLLERS Pull out the paper tray. Roller holder [A] ( x 1) Pick-up roller [A] Paper feed roller [B] 4-93 M065/M066...

  • Page 186: Paper Feed Unit

    Paper Feed 4.10.3 PAPER FEED UNIT Pull out the paper tray. Duplex unit ( p.4-116) Bracket [A] ( x 1) Release the paper feed unit [A] ( x 1) M065/M066 4-94...
  • Page 187 Paper Feed Paper feed unit [A] ( x 2) 4-95 M065/M066...

  • Page 188: Registration Sensor

    Paper Feed 4.10.4 REGISTRATION SENSOR Duplex unit ( p.4-116) Registration roller guide [A] ( x 2) Bracket [A] ( x 2) Registration sensor [A] ( x 1, hooks) M065/M066 4-96...

  • Page 189: Vertical Transport Sensor

    Paper Feed 4.10.5 VERTICAL TRANSPORT SENSOR Paper feed unit ( p.4-94) Vertical transport sensor bracket [A] ( Vertical transport sensor [A] (hooks) 4-97 M065/M066...

  • Page 190: Paper Height Sensor 1

    Paper Feed 4.10.6 PAPER HEIGHT SENSOR 1 Paper feed unit ( p.4-94) Release the paper height sensor 1 [A] (hooks) Paper height sensor 1 [A] ( M065/M066 4-98...

  • Page 191: Paper Height Sensor 2

    Paper Feed 4.10.7 PAPER HEIGHT SENSOR 2 Paper feed unit ( p.4-94) Paper height sensor 2 bracket [A] ( Paper height sensor 2 [A] ( x1, hooks) 4-99 M065/M066...

  • Page 192: Paper Lift Sensor

    Paper Feed 4.10.8 PAPER LIFT SENSOR Paper feed unit ( p.4-94) Paper lift sensor bracket [A] ( Paper lift sensor [A] ( x1, hooks) M065/M066 4-100...

  • Page 193: Paper End Sensor

    Paper Feed 4.10.9 PAPER END SENSOR Paper feed unit ( p.4-94) Actuator [A] (tab x 2) Paper end sensor [A] ( x1, hooks) 4-101 M065/M066...

  • Page 194: Paper Feed Sensor

    Paper Feed 4.10.10 PAPER FEED SENSOR Paper feed unit ( p.4-94) Release the harness [A] ( x 1) Paper feed sensor bracket [A] ( Paper feed sensor [A] ( x1, hooks) M065/M066 4-102...

  • Page 195: Tray Lift Motor

    Paper Feed 4.10.11 TRAY LIFT MOTOR Inner left lower cover ( p.4-11) Tray lift motor unit [A] ( x 3, x 2, x 1) Tray lift motor bracket [A] ( x 4, spring x 1) 4-103 M065/M066...
  • Page 196 Paper Feed When reassembling, make sure that the gears [A] are set correctly before installing the tray lift motor bracket. Tray lift motor [A] ( x 2) M065/M066 4-104...

  • Page 197: Tray 1 Set Sensor

    Pull out the paper feed tray. Left cover ( p.4-3) Inner left rear cover ( p.4-11) Inner left lower cover ( p.4-11) Sensor holder [A] ( x 3, x 1) Disconnect the connector [A]. Tray 1 set sensor [A] (hooks) 4-105 M065/M066...

  • Page 198: Paper Size Sensor Board

    Paper size sensor board [A] ( x 2, x 2) 4.10.14 CLEANING THE PAPER DUST CONTAINER ITB unit ( p.4-38) PCDU ( p.4-20) Peel off the tape [A] (service parts) and clean the paper dust container [B] with a vacuum cleaner. M065/M066 4-106...

  • Page 199: Paper Exit

    Paper Exit 4.11 PAPER EXIT 4.11.1 PAPER EXIT UNIT Top cover ( p.4-6) Open the upper cover. Inner upper right cover [A] ( x 2) Inner upper cover [A] ( x 1) Inner left upper cover ( p.4-9) 4-107 M065/M066...
  • Page 200 Paper Exit Paper exit unit holder [A] ( x 1) Lift the paper exit unit [A]. Paper exit unit [A] ( x 2) M065/M066 4-108...

  • Page 201: Paper Exit Sensor

    Remove the gear [A] (release the hook shown by the red arrow), and then remove the bushing [B]. Remove the bushing [C] ( x 1). Remove the shaft [A], and then remove the paper exit upper guide [B]. 4-109 M065/M066...
  • Page 202 Paper Exit Paper exit lower guide [A] (hook x 2) Remove the idle roller [A], and release the sensor bracket [B] ( x 1). M065/M066 4-110...

  • Page 203: Inverter Sensor

    Paper Exit Paper exit sensor [A] ( x 1, hooks) 4.11.3 INVERTER SENSOR Paper exit unit ( p.4-107) Release the sensor bracket ( p.4-109 "Paper Exit Sensor"). Inverter sensor [A] ( x 1, hooks) 4-111 M065/M066...

  • Page 204: Paper Overflow Sensor

    Paper exit unit ( p.4-107) Release the sensor bracket ( p.4-109 "Paper Exit Sensor"). Paper overflow sensor [A] ( x 1, hooks) 4.11.5 FUSING EXIT SENSOR Paper exit unit ( p.4-107) Fusing exit sensor [A] ( x 1, x 1) M065/M066 4-112...

  • Page 205: Inverter Motor

    Paper Exit 4.11.6 INVERTER MOTOR Paper exit unit ( p.4-107) Inverter motor [A] ( x 2, x 1, timing belt x 1) 4-113 M065/M066...

  • Page 206: Fusing Cooling Fan

    Fusing cooling fan base [A] ( x 2, x 1) Fusing cooling fan [A] (hooks) When installing the fusing cooling fan Make sure that the fusing cooling fan is installed with its decal facing to the right of the machine. M065/M066 4-114...

  • Page 207: Upper Cover Sensor

    Paper Exit 4.11.8 UPPER COVER SENSOR Paper exit unit ( p.4-107) Upper cover sensor [A] ( x 1, hooks) 4-115 M065/M066...

  • Page 208: Duplex Unit

    "Inner Right Front Cover"). Remove the ground screw [A]. Release the right arm [A] ( x 1). Work carefully when releasing the right arm. This is because the right arm has strong tension and this may cause injury. M065/M066 4-116...

  • Page 209: Duplex Unit

    Duplex Unit Release the left arm [A] ( x 1) Open the duplex unit [A] fully, and then remove it. 4-117 M065/M066...

  • Page 210: By-Pass Tray Unit

    Duplex Unit 4.12.2 BY-PASS TRAY UNIT Open the by-pass tray unit. Release the outer small pegs [A] of the cover. Release the inner large pegs [A] of the tray. M065/M066 4-118...
  • Page 211 Pull the tabs [B] out and remove the tray. When you re-attach the tray, be sure to align the tray as shown at [A] so the peg arms can be inserted into the keyholes. 4-119 M065/M066...

  • Page 212: Duplex Entrance Sensor

    Duplex Unit 4.12.3 DUPLEX ENTRANCE SENSOR Duplex unit ( p.4-116) Disconnect the connector and remove the ground screw. Duplex lower guide plate [A] Duplex upper guide plate [A] ( x 7) M065/M066 4-120...
  • Page 213 Duplex Unit Duplex entrance sensor [A] ( x 1, hooks) 4-121 M065/M066...

  • Page 214: Duplex Exit Sensor

    Duplex Unit 4.12.4 DUPLEX EXIT SENSOR Open the duplex unit. Fusing unit ( p.4-74) Paper transfer roller unit ( p.4-50) Release the sensor bracket [A] ( x 1, x 1) Duplex exit sensor [A] ( x 1, hooks) M065/M066 4-122...

  • Page 215: Fusing Entrance Sensor

    Duplex Unit 4.12.5 FUSING ENTRANCE SENSOR Open the duplex unit. Fusing unit ( p.4-74) Paper transfer roller unit ( p.4-50) Sensor base [A] ( x 2) Sensor cover [A] (hooks) Fusing entrance sensor [B] ( x 1, hooks) 4-123 M065/M066...

  • Page 216: Duplex/By-Pass Motor

    Duplex Unit 4.12.6 DUPLEX/BY-PASS MOTOR Duplex unit ( p.4-116) By-pass tray unit ( p.4-118) Duplex upper guide plate ( p.4-120 "Duplex Entrance Sensor") Guide plate [A] (tabs) Fusing fans ( p.4-133) Operation panel ( p.4-8) M065/M066 4-124...
  • Page 217 Duplex Unit Duplex/By-pass motor cover [A] ( x 1) Right and left arms [A] ( x 2 each) 4-125 M065/M066...
  • Page 218 Duplex Unit Duplex/By-pass motor bracket with the frame [A] ( x 6) 10. Guide plate [A] ( x 4) M065/M066 4-126...
  • Page 219 Duplex Unit 11. Duplex/By-pass motor bracket [A] ( x 3, x 1) 12. Duplex/By-pass motor [A] ( x 2, x 1, gear x1, timing belt x1) 4-127 M065/M066...

  • Page 220: By-Pass Paper End Sensor

    Duplex Unit 4.12.7 BY-PASS PAPER END SENSOR Duplex unit ( p.4-116) Duplex/By-pass motor bracket with the frame ( p.4-124 "Duplex/By-pass Motor") Sensor holder [A] ( x 1) By-pass paper end sensor [A] ( x 1, hooks) M065/M066 4-128...

  • Page 221: By-Pass Feed Roller, Friction Pad

    4.12.8 BY-PASS FEED ROLLER, FRICTION PAD Duplex unit ( p.4-116) Duplex/By-pass motor bracket with the frame ( p.4-124 "Duplex/By-pass Motor") Guide plate ( x 4) Slide the roller holder [A] in the direction of the blue arrow ( x 2). 4-129 M065/M066...
  • Page 222 Duplex Unit By-pass feed roller [A] Slide the roller holder [A] in the direction of the blue arrow. M065/M066 4-130...
  • Page 223 Duplex Unit Release the tension of the bracket [A] by releasing the lock of the solenoid [B] and turning the timing belt [C]. Friction pad [A] (hooks) 4-131 M065/M066...

  • Page 224: Hvps: D

    Turn off the main power switch and unplug the machine before removing the HVPS: D. Open the duplex unit. Fusing unit ( p.4-74) Paper transfer roller unit ( p.4-50) HVPS: D cover [A] ( x 2) HVPS: D [A] ( x 3, x 1) M065/M066 4-132...

  • Page 225: Fusing Fan

    Fusing fan bases [A] ( x 1 each, x 1 each) Fusing fan [A] (hooks) When installing the fusing fan Make sure that the fusing fan is installed with its decal facing to the front of the machine. 4-133 M065/M066...

  • Page 226: Electrical Components

    Electrical Components 4.13 ELECTRICAL COMPONENTS 4.13.1 BOARDS Rear Cover Open Bridge Board Controller Board Controller Box Removal M065/M066 4-134...
  • Page 227 Electrical Components HVPS: CB Board Right Cover Open BCU with bracket Removed HVPS: T1T2 Board 4-135 M065/M066...

  • Page 228: Hdd

    Grasp the handles [A], and then pull out the controller unit [B] ( x 2). HDD assembly [A] ( x 3). The screws shown above are used for the M066 (HDD is standard). The screws for the M065 (HDD is optional) are knob screws. HDD [A] ( x 4, x 2). M065/M066...

  • Page 229: Disposal Of Hdd Units

    If the customer is using the following options, each option function must be set up again. For more, see each reference guide. Data Overwrite Security Unit: See "Security Guide". HDD Encryption Unit: See "Security Guide". ELP NX: see "Enhanced Locked Print NX Administrator's Guide". 4-137 M065/M066...

  • Page 230: Controller Fan

    Controller fan base [A] ( x 1, x 3, x 1) Controller fan [A] ( x 2, x 2) When installing the controller fan Make sure that the controller fan is installed with its decal facing to the front of the machine. M065/M066 4-138...

  • Page 231: Controller Board

    Electrical Components 4.13.4 CONTROLLER BOARD Pull out the controller unit ( p.4-136 "HDD") HDD assembly ( p.4-136 "HDD") Disconnect the connector. Controller board [A] ( x 6) 4-139 M065/M066...

  • Page 232: When Installing The New Controller Board

    Make sure the NVRAM is correctly installed on the controller board. When installing a new HDD unit Turn the main power switch on. The disk is automatically formatted. Install the stamp data using "SP5853". Switch the machine off and on to enable the fixed stamps for use. M065/M066 4-140...

  • Page 233: Bridge Board

    Controller cover ( p.4-143 "Controller Box") Pull out the controller unit ( p.4-136 "HDD") Bridge board ( x 5, x all, x 1) 4.13.6 PSU Rear cover ( p.4-5) Choke coil [A] (EU Only) ( x 2, x 1) 4-141 M065/M066...
  • Page 234 Electrical Components Remove the ground screw. Disconnect all the harnesses ( x 1). PSU [A] ( x 10) M065/M066 4-142...

  • Page 235: Controller Box

    Inner left rear cover ( p.4-11) Controller cover [A] ( x 6: Remove the screws indicated by the red circles as shown above, and loosen the screws indicated by the blue circles.) Disconnect all the harnesses as shown above. 4-143 M065/M066...
  • Page 236 Electrical Components Remove the screw and disconnect the connector. Remove the seven screws. Pull out the controller box [A]. M065/M066 4-144...

  • Page 237: Bcu

    Electrical Components 4.13.8 BCU Right cover ( p.4-4) Disconnect all the harnesses and the clamps. Harness guide [A] ( x 1) BCU [A] ( x 7) 4-145 M065/M066...

  • Page 238: When Installing The New Bcu

    NVRAM slot with the "half-moon" pointing [A] to the downward side. Reassemble the machine. Turn on the main power of the machine. "SC995-01" occurs. Enter the serial number with SP5811-004. Turn the main power of the machine off and on. M065/M066 4-146...

  • Page 239: Removing The Bcu With Bracket

    Electrical Components Removing the BCU with bracket Right cover ( p.4-4) Drive unit fan base ( p.4-73 "Drive Unit Fan") Harness cover [A] ( x 1, hooks) BCU with bracket [A] ( x 3, x all, x all) 4-147 M065/M066...

  • Page 240: Hvps: T1T2 Board

    If the optional tray heater is installed in the machine, the HVPS: CB bracket may be still hot. Wait until the HVPS: CB bracket cools before doing this procedure. Rear cover ( p.4-5) Right cover ( p.4-4) Controller box ( p.4-143) Inner left lower cover ( p.4-11) Disconnect the connector. M065/M066 4-148...
  • Page 241 Electrical Components Disconnect the six connectors ( x 1). Pull out the HVPS: CB bracket [A] ( x 2) HVPS: CB board [A] ( x 6, x all) 4-149 M065/M066...

  • Page 242: Nvram Replacement Procedure

    An error message appears if local user information cannot be stored in an SD card because the capacity is not enough. You cannot do this procedure if the SD card is write-protected. Enter SP mode. Then print out the SMC reports ( SP5-990-001) if possible. M065/M066 4-150...
  • Page 243 You cannot do this procedure if the SD card is write-protected. 12. Go out of SP mode. Then turn the main switch off. Then remove the SD card from SD card slot 2. 13. Turn the main switch on. 4-151 M065/M066...

  • Page 244: Adjustments

    Adjust the CMY gradation scale at the top of the chart by balancing the density of the C, M, and Y gradation scales - the CMY gray scale should change smoothly from minimum to maximum. There should be no coloration. Examine this color adjustment sheet: M065/M066 4-152...
  • Page 245 The NVRAM holds three sets of controller gamma settings: Those saved this time: Controller SP 1101 ToneCtlSet - Tone (Current) Those saved in the previous adjustment: Controller SP 1101 ToneCtlSet - Tone (Prev) The factory settings: Controller SP 1101 ToneCtlSet - Tone (Factory). 4-153 M065/M066...

  • Page 246: Adjustment Procedure

    Set Black 15 Default Value 240 Set Cyan 1 to 15 See Set Black 1 to 15 Set Magenta 1 to 15 See Set Black 1 to 15 Set Yellow 1 to 15 See Set Black 1 to 15 M065/M066 4-154...
  • Page 247 Use Controller SP 1105 "ToneCtlSave" in the controller service menu, to store the new settings in the controller. Reset the controller (press the [Reset] key when the machine is off line) to use the new settings. You must reset the controller to keep the new settings in the controller NVRAM. 4-155 M065/M066...

  • Page 249: System Maintenance Reference

    SYSTEM MAINTENANCE REFERENCE R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 251: Service Program Mode

    Enter the required program mode as explained above. The setting appearing on the display is the current setting. Select the required setting using the " " keys, then press the "OK" key. The previous value remains if the "OK" key is not pressed. M065/M066...

  • Page 252: Exiting Service Mode

    RS: Regular speed xxx HS: High speed xxx As shown in the following table, the process speed (mm/s) depends on the print mode (B&W or Color), resolution, and/or type of paper selected. Some SP mode settings depend on the process speed. M065/M066...
  • Page 253 4. Count Unit R: Rotation S: Prints 5. Environment LL: Low temperature and Low humidity ML: Medium temperature and Low humidity MM: Medium temperature and Medium humidity MH: Medium temperature and High humidity HH: High temperature and High humidity M065/M066...
  • Page 254 If "Alphanumeric" is written to the right of the bracket as shown above, the setting of the SP mode is displayed on the screen using alphanumeric characters instead of only numbers. However, the settings in the bracket in the SP mode table are explained by using only the numbers. M065/M066...

  • Page 255: Bit Switch Programming

    [Escape]: Goes out of the program without saving changes. [OK]: Goes out of the program and saves changes. Push the "Escape" key one or more times until the menu "SP mode (Service) " is shown. Select "End" and push the OK key. M065/M066...

  • Page 256: Firmware Update

    XPS driver data process) PCL Font PCL fonts PCL Font PS Font Adobe PostScript3 fonts PS3 Font Summary Font Summary fonts Font EXP Java VM platform (For Standard Java VM Java VM Java VM v7 std M066) SD card M065/M066...

  • Page 257: Before You Begin

    Java VM platform (For Optional Java VM Java VM Option Java VM v7 M065) SD card 5.2.2 BEFORE YOU BEGIN An SD card is a precision device. Always observe the following precautions when you handle SD cards: Always switch the machine off before you insert an SD card. Never insert the SD card into the slot with the power on.

  • Page 258: Updating Firmware

    Save the files in this folder. Do not save any file outside the folders. (The diagram shows an example. Three folders, log, nvramdata, and prt, are outside romdata. These folders can store debug logs, NVRAM data, and captured files respectively.) M065/M066...

  • Page 259: Update Procedure

    17. Attach the slot cover to the SD card slot 2 ( x 1). 18. Connect the printer to the network physically. 19. Turn on the main power switch. 20. Print the Configuration Page to check that the every firmware is correctly updated: M065/M066...

  • Page 260: Error Handling

    11. Install the SD slot cover on SD card slot 2. If the capacity of SD card is not enough to store the local user information, an error message is displayed. Carefully handle the SD card, which contains user information. Do not take it back to your location. M065/M066 5-10...

  • Page 261: Upload

    The counter in the user code information is initialized after uploading. The information of an administrator and supervisor cannot be downloaded nor uploaded. If there is no data of address book information in the SD card, an error message is displayed. 5-11 M065/M066...

  • Page 262: Handling Firmware Update Errors

    Incorrect ROM data on the SD card, or data is Incorrect SD card version corrupted. SD update data is incorrect. Acquire the Module mismatch - Correct correct data (Japan, Overseas, OEM, etc.) module is not on the SD card) then install again. M065/M066 5-12...
  • Page 263 Controller module download the SD card and tray again, or replace failed controller board. SD update data is incorrect. The data on the Electronic confirmation check SD card is for another machine. Acquire failed correct update data then install again. 5-13 M065/M066...

  • Page 264: Controller Self-Diagnostics

    Power-on self-diagnostics: The machine automatically starts the self-diagnostics just after the power has been turned on. SC detection: The machine automatically detects SC conditions at power-on or during operation. The following shows the workflow of the power-on and detailed self-diagnostics. M065/M066 5-14...

  • Page 265: Nvram Data Upload/Download

    "M0650017.NV". 14. Go out of the SP mode. 15. Turn off the main power switch. 16. Remove the SD card from SD card slot 2. 17. Install the SD slot cover to SD card slot 2. 5-15 M065/M066...

  • Page 266: Downloading Nvram Data

    11. Install the SD slot cover on SD card slot 2. 12. Turn on the main power switch. 13. Check that the NVRAM data is correctly downloaded. This procedure does not download the following data to the NVRAM: Total Count Serial Number M065/M066 5-16...

  • Page 267: Using The Debug Log

    Select "3 SD Card" to save the debug information directly to the SD card if it is inserted in the service slot. Now select "SP5858" and specify the events that you want to record in the debug log. SP5858 (Debug Save When) provides the following items for selection. 5-17 M065/M066...
  • Page 268 Then press"OK". Refer to the two tables below for the 4-digit numbers to enter for each key. The following keys can be set with the corresponding numbers. (The initials in parentheses indicate the names of the modules.) M065/M066 5-18...
  • Page 269 Net File Application GW Print Service Printer Design Language GW Print Service – Print GSP-PM Print Server Module Image Memory Handler System Control Service System Resource Memory Control Service Management Web Document Box Network Control Service WebDB (Document Server) 5-19 M065/M066...

  • Page 270: Retrieving The Debug Log From The Hdd

    SD card. Use a card reader to copy the file and send it for analysis to your local Ricoh representative by email. You can also send the SD card by regular mail if you want.

  • Page 271: Sp5857-016 Create A File On Hdd To Store A Log

    SD card. With the file already created on the SD card for the log file, the data only needs to be recorded; a new log file does not require creation. To create a new log file, do SP5857-012 to delete the debug log data from the SD card. Then do SP5857-017. 5-21 M065/M066...

  • Page 272: Dip Switches

    DIP Switches 5.6 DIP SWITCHES 5.6.1 CONTROLLER BOARD Factory Use Only: Do not change the switch settings. DIP SW No. Default M065/M066 5-22...

  • Page 273: Troubleshooting

    TROUBLESHOOTING R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 275: Service Call Conditions

    Service Call Conditions 6. TROUBLESHOOTING 6.1 SERVICE CALL CONDITIONS See "Appendices" for the following information: "SC Tables" M065/M066...

  • Page 276: Process Control Error Conditions

    Process Control Error Conditions 6.2 PROCESS CONTROL ERROR CONDITIONS See "Appendices" for the following information: "Process Control Results" M065/M066...

  • Page 277: Troubleshooting Guide

    Troubleshooting Guide 6.3 TROUBLESHOOTING GUIDE See "Appendices" for the following information: "Troubleshooting Guide" M065/M066...

  • Page 278: Image Problems

    Colored spots at 33-mm intervals: Development roller Abnormal image at 83-mm intervals: Paper transfer roller Colored spots at 94-mm intervals: OPC drum Spots at 141-mm intervals: Pressure roller Spots at 126-mm intervals: Fusing roller Spots at 204-mm intervals: Fusing belt M065/M066...

  • Page 279: Jam Detection

    Jam Detection 6.5 JAM DETECTION See "Appendices" for the following information: "Jam Detection" M065/M066...

  • Page 280: Electrical Component Defects

    Electrical Component Defects 6.6 ELECTRICAL COMPONENT DEFECTS See "Appendices" for the following information: "Electrical Component Defects" M065/M066...

  • Page 281: Energy Saving

    ENERGY SAVING R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 283: Energy Saver Modes

    If the timers are changed, then the energy saved will be different. For example, if the timers are all set to 240 min., the grey area will disappear, and no energy is saved before 240 min. expires. M065/M066...

  • Page 284: Timer Settings

    The recovery time depends on the model and the region. 18 sec. Sleep Mode Recovery time. M065/M066: 45 sec. Recommendation We recommend that the default settings should be kept. If the customer requests that these settings should be changed, please explain that their energy costs could increase, and that they should consider the effects on the environment of extra energy use.

  • Page 285: Energy Save Effectiveness

    Find the amount of time spent in each mode (subtract the earlier measurement from the later measurement). Multiply this by the power consumption spec for each mode. Convert the result to kWh (kilowatt hours) Here is an example calculation. M065/M066...
  • Page 286 Time 306163.0 308046.0 31.4 177.3 5.56 Energy 003: save Energy (Panel off) Save Time 74000 75111.0 18.5 113.5 004: Low power Power Time 148000 150333 38.9 72.3 2.81 Sleep 005: Off Mode Time 508776.0 520377.0 193.4 1.01 Total 15.91 M065/M066...

  • Page 287: Paper Save

    Duplexing and the combine functions reduce the amount of paper used. This means that less energy overall is used for paper production, which improves the environment. 1. Duplex: Reduce paper volume in half! 2. Combine mode: Reduce paper volume in half! M065/M066...

  • Page 288: Duplex + Combine

    Duplex with combine mode: B = (1) + (3) + (4) (1) Total counter: SP 8581 001 (pages) (2) Single-sided with duplex mode: SP 8421 001 (pages) (3) Single-sided with combine mode: SP 8421 004 (pages) (4) Duplex with combine mode: SP 8421 005 (pages) M065/M066...
  • Page 289 M065/M066 SERVICE MANUAL APPENDICES...
  • Page 291 M065/M066 APPENDICES TABLE OF CONTENTS APPENDIX: SPECIFICATIONS ............1-1     SPECIFICATIONS ..................1-1     1.1.1 GENERAL SPECIFICATIONS ............1-1     SUPPORTED PAPER SIZES ..............1-4     SOFTWARE ACCESSORIES ..............1-6     1.3.1 PRINTER DRIVERS ................. 1-6  ...
  • Page 292 Paper Size Code .................. 6-3   APPENDIX: ELECTRICAL COMPONENT DEFECTS ....7-1     ELECTRICAL COMPONENT DEFECTS ........... 7-1     7.1.1 SENSORS ..................7-1     M065/ M066 ..................7-1   Optional Paper Feed Unit ..............7-7   M065/M066 SM Appendix...
  • Page 293 Table 2: Paper Height Sensor ............8-338   8.1.3 OUTPUT CHECK TABLE ............. 8-339     Printer ....................8-339   8.1.4 TEST PATTERN PRINTING ............8-346     PRINTER SERVICE MODE ..............8-348     8.2.1 SP1-XXX (SERVICE MODE) ............8-348     SM Appendix M065/M066...

  • Page 295: Appendix: Specifications

    APPENDIX: SPECIFICATIONS R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew 12/24/2012 Wristband Tray...

  • Page 297: General Specifications

    1200 x 1200 dpi, 600 x 600 dpi (1 bit), 600 x 600 dpi (2 bit) Adobe PS 3/ PDF: 1200 x 1200 dpi, 600 x 600 dpi (1 bit), 600 x 600 dpi (2 bit) Gradation: 256 gradations M065: 37 ppm LT, 35 ppm A4 Printing Speed M066: 42 ppm LT, 40 ppm A4...
  • Page 298 (16-44 lb) Up to 500 sheets (A4/ LT/ 80 g/m / 20 lb) Output Paper Capacity: Up to 250 sheets (LG) M065: Standard: 384 MB Memory: Up to 768 MB with optional memory M066: Standard: 768 MB M065/M066 SM Appendix...
  • Page 299 220 V - 240 V, 50/60 Hz: More than 8 A (for Europe/Asia) 120 V: 1520 W or less Power Consumption: 220-240 V: 1510 W or less Energy Saver: 6 W or less M065: Color: 68.5 dB (A) Noise Emission: Black and White: 68.3 dB (A) (Sound Power Level) M066: Color: 70.0 dB (A)

  • Page 300: Supported Paper Sizes

    8" x 13" Foolscap 8.5" x 13" Folio SEF 8.25" x 13" 16K SEF 7.25" x 10.5" 102 x 98 x 216 70 x 216 Custom (Width) 4.02" x inch 3.94" x 8.5" 2.76" x 8.5" 8.5" M065/M066 SM Appendix...
  • Page 301 C6 Env. 114 x 162 mm C5 Env. 162 x 229 mm DL Env. 110 x 220 mm Y: Supported: the sensor detects the paper size. Y#: Supported: the user specifies the paper size. N: Not supported SM Appendix M065/M066...

  • Page 302: Software Accessories

    The PS3 drivers are all genuine AdobePS drivers, except for Windows 2000, which uses Microsoft PS. A PPD file for each operating system is provided with the driver. The PS3 driver for Macintosh supports Mac OS 7.6 or later versions. M065/M066 SM Appendix...

  • Page 303: Optional Equipment

    DC 24V, 5V (from the main frame) Power Consumption: Less than 52 W (Printing) Dimensions (W x D x H): 444 mm x 590 mm x 140 mm (17.5" x 23.2" x 5.5") Weight: 12 kg (26.5 lb.) SM Appendix M065/M066...

  • Page 304: Utility Software

    DeskTopBinder Lite Ver.5, management software and can manage both image data converted from paper documents and application files Professional Ver.5 saves in each client's PC. Remote Communication Used to control devices connected to the same network. Gate S Pro M065/M066 SM Appendix...
  • Page 305 APPENDIX: PREVENTIVE MAINTENANCE TABLES R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 307: User Maintenance Items

    An error message shows when a maintenance counter gets to the value above table when the machine's default settings are used. It is not necessary to reset counters for each part. The machine detects new components automatically and resets the necessary counters. SM Appendix M065/M066...

  • Page 308: Cleaning Items

    Paper Feed Unit PB1020 (M384) Item Remarks Feed Roller Dry cloth Separation Roller Dry cloth Pick-up Roller Dry cloth Paper Feed Sensor Dry cloth Vertical Transport Sensor Dry cloth Relay Roller Damp cloth Bottom Plate Pad Damp cloth M065/M066 SM Appendix...

  • Page 309: Appendix: Service Call Conditions

    APPENDIX: SERVICE CALL CONDITIONS R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew 12/14/2011 SC240/241 3/16/2011 SC817 10/10/2011 SC833...

  • Page 311: Sc Tables

    You can reset the machine by turning the Turn the operation switch or main operation switch or main switch power switch off and on. off and on. If the error occurs again, the same SC code is displayed. SM Appendix M065/M066...

  • Page 312: Sc1Xx: Scanning

    Serial number stored in the memory does not have the correct code. NVRAM defective BCU replaced without original NVRAM Reinstall the original NVRAM in the replaced BCU. Turn off and on the main power switch of the copier if a new NVRAM is installed in the BCU. M065/M066 SM Appendix...

  • Page 313: Sc 2Xx: Exposure

    Disconnected or defective harness to polygon motor driver board Defective polygon motor driver board Defective polygon motor Check or replace the harness. Replace the laser unit. Replace the controller. Replace the BCU. SM Appendix M065/M066...
  • Page 314 Disconnected cable from the laser synchronizing detection unit or defective connection Defective laser synchronizing detector Defective LDB Defective BCU Check the connectors. Replace the laser unit. Replace the controller. Replace the BCU. M065/M066 SM Appendix...
  • Page 315 Details (Symptom, Possible Cause, Troubleshooting Procedures) FGATE ON error: Y The PFGATE ON signal does not assert within 5 seconds after processing the image in normal job or MUSIC (line position adjustment) for start position [Y]. See SC 230 for troubleshooting details. SM Appendix M065/M066...
  • Page 316 Details (Symptom, Possible Cause, Troubleshooting Procedures) FGATE ON error: C The PFGATE ON signal does not assert within 5 seconds after processing the image in normal job or MUSIC (line position adjustment) for start position [C]. See SC 230 for troubleshooting details. M065/M066 SM Appendix...
  • Page 317 The bridge board detects LDB error a few times consecutively when LDB unit turns on after LDB initialization. Worn-out LD Disconnected or broken harness of the LD Replace the harness of the LD. Replace the laser unit. Replace the bridge board. SM Appendix M065/M066...
  • Page 318 Overload on the LDU shutter motor Defective LDU shutter sensor Loose or disconnected harnesses between LDU shutter motor and Defective BCU Replace the LDU shutter. Replace the LDU shutter motor. Replace the harnesses between LDU shutter motor and BCU. Replace the BCU. M065/M066 SM Appendix...
  • Page 319 Overload on the LDU shutter motor Defective LDU shutter sensor Loose or disconnected harnesses between LDU shutter motor and Defective BCU Replace the LDU shutter. Replace the LDU shutter motor. Replace the harnesses between LDU shutter motor and BCU. Replace the BCU. SM Appendix M065/M066...
  • Page 320 1 second after turning on or off the LDU shutter motor. Defective LDU shutter motor LDU shutter broken Replace the LDU shutter. Replace the LDU shutter motor. Replace the harnesses between LDU shutter motor and BCU. Replace the BCU. M065/M066 3-10 SM Appendix...

  • Page 321: Sc3Xx: Image Processing - 1

    Color development motor slip due to an increase in the torque caused by connected components. Defective motor. Adjust the torque properly by replacing or cleaning the PCDU. Replace the PCDU. Replace the development motor: CMY if load torque is normal. SM Appendix 3-11 M065/M066...
  • Page 322 Harness between TD sensor and development unit defective Defective TD sensor. Check the black, magenta, cyan, or yellow TD sensor connector and harness between the TD sensor and PCDU for damage. Check the drawer connector of the PCDU. Replace the PCDU. M065/M066 3-12 SM Appendix...
  • Page 323 A drawer connector disconnected, loose, defective TD sensor defective Check the black, magenta, cyan, or yellow TD sensor connector and harness between the TD sensor and development unit for damage. Check the drawer connector of the PCDU. Replace the PCDU. SM Appendix 3-13 M065/M066...
  • Page 324 Heat seal not removed from a new developer pack TD harness sensor disconnected, loose or defective TD sensor defective Harness between TD sensor and drawer disconnected, defective Different developer density from initial developer density Remove the heat seal from each PCDU. Replace the PCDU. M065/M066 3-14 SM Appendix...
  • Page 325 Shorted 24 V fuse on the PSU Defective interlock system Check or replace the harness. Check if torque output value for drum/development motor is proper if not replace the unit. Replace the drum/development motor: K. Replace the 24V fuse on the PSU. SM Appendix 3-15 M065/M066...
  • Page 326 Shorted 24 V fuse on the PSU Defective interlock system Check or replace the harness. Check if torque output value for drum motor is proper if not replace the unit. Replace the drum motor: CMY. Replace the 24V fuse on the PSU. M065/M066 3-16 SM Appendix...

  • Page 327: Sc4Xx: Image Processing - 2

    After replacing the ID sensor, input the ID sensor correction coefficient with SP3362-013 and -018. For details, refer to "ID sensor board" in the Replacement and Adjustment section. Check the spring at the PTR unit contact lever. Replace the BCU. Replace the ITB unit. SM Appendix 3-17 M065/M066...
  • Page 328 Check the harness connection of the ITB rotation sensor. Check the trash or scratch on the encoder disc surface of the ITB rotation sensor. Check if the ITB unit is correctly set. Replace the ITB unit motor. Replace the ITB unit. M065/M066 3-18 SM Appendix...
  • Page 329 BCU detects a short in the power pack 10 times at D (ac). Damaged insulation on the high-voltage supply cable Damaged insulation around the high-voltage power supply. Replace the high-voltage supply cable. Replace the high-voltage power supply unit. Replace the BCU. SM Appendix 3-19 M065/M066...
  • Page 330 An error signal is detected for 0.2 seconds when charging the drum unit. High voltage leak Broken harness Defective drum unit Defective HVPS-CB board Check or replace the harness. Replace the PCDU. Replace the HVPS-CB board. M065/M066 3-20 SM Appendix...
  • Page 331 Toner collection motor damaged Disconnect or defective harness Defective BCU Check or replace the harness. Replace the toner collection motor. Replace the BCU Check and retry the connecting procedure. SM Appendix 3-21 M065/M066...
  • Page 332 The thermistor output of the humidity sensor was not within the prescribed range (0.01V to 2.4V). Temperature and humidity sensor harness disconnected, loose, defective Temperature and humidity sensor defective Check the connector and harness. Replace the temperature/humidity sensor. M065/M066 3-22 SM Appendix...

  • Page 333: Sc5Xx: Paper Feed And Fusing

    Paper lift sensor connection loose, disconnected, or damaged Paper lift sensor defective Tray lift motor connection loose, disconnected, or damaged Tray lift motor defective Check or replace the harness. Replace the tray lift motor. Replace the BCU. SM Appendix 3-23 M065/M066...
  • Page 334 Defective development fan 1 or development fan 2 Disconnected or defective harness Defective BCU Check or replace the harness. Replace the development fan 1 (SC530) or development fan 2 (SC531). Replace the BCU. M065/M066 3-24 SM Appendix...
  • Page 335 The motor lock signal error is detected for 10 seconds after the motor lock signal was first detected. Defective fusing fan 2 Disconnected or defective harness Defective BCU Check or replace the harness. Replace the fusing fan 2. Replace the BCU. SM Appendix 3-25 M065/M066...
  • Page 336 The motor lock signal error is detected for 10 seconds after the motor lock signal was first detected. Defective toner supply fan Disconnected or defective harness Defective BCU Check or replace the harness. Replace the toner supply fan. Replace the BCU. M065/M066 3-26 SM Appendix...
  • Page 337 10 seconds after turning on the fusing cooling fan. Disconnected harness of the fusing cooling fan Defective fusing cooling fan Defective BCU Check or replace the harness of the fusing cooling fan. Replace the fusing cooling fan. Replace the BCU. SM Appendix 3-27 M065/M066...
  • Page 338 The temperature measured by the heating roller thermopile does not reach 0°C for 6 seconds. Loose connection of the heating roller thermopile Defective heating roller thermopile Defective thermopile Check if the heating roller thermopile is firmly connected. Replace the heating roller thermopile. M065/M066 3-28 SM Appendix...
  • Page 339 Defective heating roller lamp Check if the thermopile is firmly connected. Clean the surface of the thermopile lens. Test the conductance for the thermopile and the heating roller Replace the thermopile. Replace the heating roller lamp. SM Appendix 3-29 M065/M066...
  • Page 340 During stand-by mode or a print job, the detected heating roller temperature reaches 250 °C. Defective PSU Defective BCU Defective heating roller thermistor (end) Defective fusing control system Replace the PSU. Replace the BCU. Replace the heating roller thermistor (end). M065/M066 3-30 SM Appendix...
  • Page 341 This error is defined when the detected zero cross signal is less than 45. Defective fusing lamp relay Defective fusing lamp relay circuit Unstable power supply Check the power supply source. Replace the shorted 24V fuse on the PSU. Replace the PSU SM Appendix 3-31 M065/M066...
  • Page 342 Dirty or defective thermistor (end) Heating roller fusing lamp broken Defected thermostat Defective heating roller fusing lamp Check if the heating roller thermistor (end) is firmly connected. Replace the heating roller thermistor (end). Replace the heating roller fusing lamp. M065/M066 3-32 SM Appendix...
  • Page 343 Heating roller fusing lamp overheat 2 (hardware error) The heating roller thermistor (end) detects 250°C or more. Defective heating roller thermistor (end) Defective PSU Defective BCU Defective fusing control system Replace the heating roller thermistor (end). Replace the PSU. Replace the BCU. SM Appendix 3-33 M065/M066...
  • Page 344 This SC is activated only when SP1159-001 is set to "1" (default "0"). Paper jam in the fusing unit. Remove the paper that is jammed in the fusing unit. Then make sure that the fusing unit is clean and has no obstacles in the paper feed path. M065/M066 3-34 SM Appendix...
  • Page 345 Details (Symptom, Possible Cause, Troubleshooting Procedures) Pressure roller overheat 3 (software error) The detected fusing roller temperature stays at 230°C or more for 1 second. Defective PSU Defective BCU Replace the pressure roller thermistor (center). Replace the PSU. Replace the BCU. SM Appendix 3-35 M065/M066...
  • Page 346 When the fusing unit is not running in the ready condition, the pressure roller fusing lamp keeps ON full power for 30 seconds or more. Broken pressure roller thermostat Broken pressure roller fusing lamp Replace the pressure roller fusing lamp. Replace the pressure roller thermostat. Replace the PSU. M065/M066 3-36 SM Appendix...

  • Page 347: Sc6Xx: Device Communication

    This SC is not issued for this machine. When a communication error signal between the 2nd paper bank and 3rd paper bank is received. Loose or disconnected connector Check the connection between the main machine and paper feed unit. SM Appendix 3-37 M065/M066...
  • Page 348 A sampling of the control data sent from the BCU reveals an abnormality. Controller board defective External noise BCU defective Check the connection between the controller board and BCU. Replace the controller board. Replace the BCU. M065/M066 3-38 SM Appendix...
  • Page 349 ID2 is not exactly 17 bytes. ID2 includes text which cannot be printed. ID2 is all filled by spaces. ID2 is null. Clear the RC Gate data. Reinstall the RC Gate after writing the common certificate. SM Appendix 3-39 M065/M066...
  • Page 350 Details (Symptom, Possible Cause, Troubleshooting Procedures) Engine board mismatch error Engine board and controller mismatch detected. Wrong engine board installed. Wrong controller board installed. Check the type of engine board and controller board. Replace the BCU. Replace the controller board. M065/M066 3-40 SM Appendix...
  • Page 351 Defective RFID CPU board Defective RFID board No memory chip on the toner cartridge 061-164 Noise Replace the toner cartridge. Turn the main power off and on. Replace the RFID CPU board. Replace the RFID board. SM Appendix 3-41 M065/M066...
  • Page 352 Details (Symptom, Possible Cause, Troubleshooting Procedures) RFID: Unit check error The machine gets RFID communication error even the toner cartridges have not been installed in the machine. Caused by noise Turn the main power switch off and on. M065/M066 3-42 SM Appendix...
  • Page 353 The I2C bus communication is not established due to an error other than a buffer shortage. Loose connection Defective BCU Defective LD controller board Turn the main switch off and on. Check the cable connection. Replace the laser unit. Replace the BCU. SM Appendix 3-43 M065/M066...

  • Page 354: Sc8Xx: Overall System

    Due to a control error, a RAM overflow occurred during system processing. One of the following messages was displayed on the operation panel. [0x5032] HAIC-P2 error System program defective Controller board defective [0x6261] HDD error Optional board defective Replace controller firmware [554C] USB error M065/M066 3-44 SM Appendix...
  • Page 355 Replace the controller. When the problem cannot be fixed with the above procedure, the following information displayed on the screen needs to be fed back to a technical support center. SC code Detailed error code Program address SM Appendix 3-45 M065/M066...
  • Page 356 Replace the mother board Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Wireless LAN card not detected The wireless LAN card is not detected before communication is established, though the wireless LAN board is detected. Loose connection Check the connection. M065/M066 3-46 SM Appendix...
  • Page 357 Replace the wireless LAN card/board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) USB interface error The USB interface cannot be used due to a driver error. Defective USB driver Loose connection Check the connection. Replace the USB board. SM Appendix 3-47 M065/M066...
  • Page 358 NVRAM data encryption error 2: An error occurs before the NVRAM data is encrypted. [30] Defective controller board Replace the controller board. Other error: A serious error occurs while the data is encrypted. [31] Same as SC991 M065/M066 3-48 SM Appendix...
  • Page 359 Power failure during the data encryption: The data encryption (NVRAM and HDD) has not been completed. Power failure during the data encryption Initialize the HDD. Data read/write error: The DMAC error is detected twice or more. [10] Same as SC863 SM Appendix 3-49 M065/M066...
  • Page 360 Replace the HDD. Replace the controller. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD: Read error The data stored in the HDD cannot be read correctly. Defective HDD Defective controller Replace the HDD. Replace the controller. M065/M066 3-50 SM Appendix...
  • Page 361 Store correct data in the SD card. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) SD card error The SD card is ejected from the slot. Install the SD card. Turn the main switch off and on. SM Appendix 3-51 M065/M066...
  • Page 362 Defective software program Defective HDD Incorrect path to the server Back up the address book data and Initialize the address book data and the user information. (Restore the address book data if possible.) Replace the HDD. M065/M066 3-52 SM Appendix...
  • Page 363 Delete All error 1: HDD An error is detected while all of the HDD or NVRAM are formatted physically by the DataOverwriteSecurity Unit. DataOverwriteSecurity Unit (SD card) not installed Defective HDD Install the DataOverwriteSecurity Unit. Replace the HDD. SM Appendix 3-53 M065/M066...
  • Page 364 Invalid log encryption key due to defective NVRAM data -003 Initialize the HDD. Disable the log encryption setting with SP9730-004 ("0" is off.) Log Data Error 4 -004 Unusual log encryption function due to defective NVRAM data Initialize the HDD. M065/M066 3-54 SM Appendix...
  • Page 365 Details (Symptom, Possible Cause, Troubleshooting Procedures) TPM system authentication error The system firmware is not authenticated by TPM (security chip). Incorrect updating for the system firmware Defective flash ROM on the controller board Replace the controller board. SM Appendix 3-55 M065/M066...
  • Page 366 When WEB browser was opened Cycle the machine off/on. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Software error A software error occurred in the GW controller. Cycle the machine off/on Update controller firmware Controller board defective M065/M066 3-56 SM Appendix...

  • Page 367: Sc9Xx: Miscellaneous

    Printer font error A necessary font is not found in the SD card. A necessary font is not found in the SD card. The SD card data is corrupted. Check that the SD card has the correct data. SM Appendix 3-57 M065/M066...
  • Page 368 An error undetectable by any other SC code occurred Print the "Logging Data" with SP5990-004 and then check the SP7990. If 498-Engine is found in the SP7990; Check the harness connection of the temperature/humidity sensor. Replace the temperature/humidity sensor. M065/M066 3-58 SM Appendix...
  • Page 369 SP5825-001, after that turn the main power off and on. Incorrect type controller installed Defective controller -003 Replace the controller with the correct type. Incorrect model controller installed. -004 Replace the controller with the correct model. SM Appendix 3-59 M065/M066...
  • Page 370 No applications start within 60 seconds after the power is turned on. Loose connection of RAM-DIMM, ROM-DIMM Defective controller Software problem Check if the DIMM memory is correctly connected. Reinstall the controller system firmware. Replace the controller. M065/M066 3-60 SM Appendix...
  • Page 371 SMC - Logging (SP5-990-004) Printer driver settings used when the problem occurs All data displayed on the screen (SC code, error code, and program address where the problem is logged.) Image file which causes the problem, if possible SM Appendix 3-61 M065/M066...
  • Page 373 APPENDIX: PROCESS CONTROL ERROR CONDITIONS R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 375: Appendix: Process Control Error Conditions

    Vt is more than 0.7V Make sure that the heat seal on the when Vcnt is 4.3V and Vcnt error 2 development unit is not removed. Vcnt is less than 4.7V Defective TD sensor when Vcnt is Vt target SM Appendix M065/M066...
  • Page 376 The machine starts developer initialization after you set “Enable” in SP3-902-005, 006, 007, or 008. Developer initialization automatically resumes when you open and close the front door or turn the main switch off and on if an error other than Error 8 occurs. M065/M066 SM Appendix...

  • Page 377: Process Control Self-Check Result

    When the K5 is more ID sensor pattern density is too high coefficient than the value of or low. (K5) SP3-362-003 or less ID sensor or shutter is defective. than the value of maximum/ Same as 53 minimum error SP3-362-004, the SM Appendix M065/M066...
  • Page 378 ID sensor pattern density is too high Not enough data can error during or low. be sampled during the gamma Hardware defective gamma correction. correction Same as 53 Unexpected Power Failure Process control fails. error Check the power source. M065/M066 SM Appendix...

  • Page 379: Vsg Adjustment Result

    Poor connection is more than ID sensor Defective IOB "Voffset output error Replace the ID sensor. Threshold" Check the connection. (SP3-324-004) Replace the IOB board. Vsg adjustment Other cases Adjustment has not been Retry SP3-321-010. error completed. SM Appendix M065/M066...

  • Page 380: Line Position Adjustment Result

    Not used in this machine. the target Out of the ID sensors have correctly detected the patterns adjustment for line position adjustment, but a shift of See Note range patterns is out of adjustable range. Not used M065/M066 SM Appendix...
  • Page 381 APPENDIX: TROUBLESHOOTING GUIDE R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 383: Appendix: Troubleshooting Guide

    Defective image transfer Replace the image transfer belt unit belt unit. No image is printed. Incorrect action of paper Check the guide and the transfer roller paper transfer roller. Defective HVPS Replace HVPS. Defective BCU Replace the BCU. SM Appendix M065/M066...

  • Page 384: All-Black Print

    BCU positioning cover. Image transfer belt not C, M, or Y is missing. Check the belt tension unit. contacting PCDU Defective the drum motor: Replace the drum motor: CMY. Defective BCU Replace the BCU. M065/M066 SM Appendix...

  • Page 385: Light Print

    Check the image transfer contacting PCDU belt unit. Printed images are too weak. Defective PCDU Replace the PCDU. Defective paper transfer Repair the paper transfer roller roller. Defective fusing unit Replace the fusing unit. Defective BCU Replace the BCU. SM Appendix M065/M066...

  • Page 386: Repeated Spots Or Lines On Prints

    Defective image transfer roller inches) transfer roller. Replace the image Defective image transfer belt At intervals of 82 mm (3.23 transfer belt drive roller or drive roller or image transfer inches) image transfer belt idling belt idling roller roller. M065/M066 SM Appendix...

  • Page 387: Dark Vertical Line On Prints

    Necessary actions Defective PCDU Replace the PCDU. Defective image transfer Replace the image transfer White lines or bands appear belt unit belt unit. in images of all toner colors. Defective paper transfer Replace the paper transfer roller roller. SM Appendix M065/M066...

  • Page 388: Missing Parts Of Images

    Possible cause Necessary actions Defective PCDU Replace the PCDU. Unexpected dots of the Defective image transfer Replace the image transfer same color appear at belt unit belt unit. irregular intervals. Defective fusing unit Replace the fusing unit. M065/M066 SM Appendix...

  • Page 389: Dark Irregular Streaks On Prints

    Symptom Possible cause Necessary actions Non-standard paper in use Use recommended paper. Some parts of images are Select an appropriate media Incorrect media type mode not fused very well. mode. Defective fusing unit Replace the fusing unit. SM Appendix M065/M066...

  • Page 390: Image Skew

    Defective registration roller Repair the paper feed unit. Incorrect action of paper Check the paper transfer transfer roller roller. Defective BCU Replace the BCU. Incorrect installation of Uninstall the paper tray units paper tray and re-install them. M065/M066 SM Appendix...

  • Page 391: Background Stain

    Replace the toner cartridge. Images are not printed in Defective image transfer Replace the image transfer the areas around the paper belt unit belt unit. edges. Image transfer belt not Check the image transfer contacting PCDU belt unit. SM Appendix M065/M066...

  • Page 392: Image Not Centered When It Should Be

    Adjust the paper guide position correctly. Images do not come to the center. Incorrect margin setting Adjust the margin setting. Defective BCU Replace the BCU. Incorrect installation of Uninstall the paper tray units paper tray and re-install them. M065/M066 5-10 SM Appendix...

  • Page 393: Appendix: Jam Detection

    APPENDIX: JAM DETECTION R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 395: Paper Jam Display

    Paper is not fed from tray 4. 7504 8 Bypass: ON Paper is not fed from the by-pass tray. 7504 9 Duplex: ON Paper is jammed at the duplex unit. 7504 11 V-Transport 1: ON Vertical transport sensor 1 does not SM Appendix M065/M066...
  • Page 396 P-Feed 4: OFF Paper feed sensor 4 does not turn off. Vertical transport sensor 1 does not turn 7504 51 V-Transport 1: OFF off. Vertical transport sensor 2 does not turn 7504 52 V-Transport 2: OFF off. M065/M066 SM Appendix...

  • Page 397: Paper Size Code

    B5 SEF (8EH) 14 (0EH) B5 LEF DLT SEF (A0H) 38 (26H) LT LEF LG SEF (A4H) 44 (2CH) HLT LEF LT SEF (A6H) 133 (85H) A4 SEF HLT SEF (ACH) 134 (86H) A5 SEF Others (FFH) SM Appendix M065/M066...
  • Page 399 APPENDIX: ELECTRICAL COMPONENT DEFECTS R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...

  • Page 401: Appendix: Electrical Component Defects

    Electrical Component Defects 7. APPENDIX: ELECTRICAL COMPONENT DEFECTS 7.1 ELECTRICAL COMPONENT DEFECTS 7.1.1 SENSORS M065/ M066 Sensor Name/ CN No./ Active Condition Symptom Sensor Board Name Pin No. Open Drum Phase Sensor CN108/2 SC381 (CMY) Shorted Open Drum Phase Sensor...
  • Page 402 "Check the Left Cover is closed and the Open Waste Toner Bottle is set correctly" is displayed. Waste Toner Bottle CN118/16 Left cover open Set Sensor cannot be detected. Shorted Waste toner bottle set cannot be detected. M065/M066 SM Appendix...
  • Page 403 Paper overflow is not Shorted detected. Paper is not Open detected. Jam C Paper Exit Sensor CN104/6 Paper is Shorted detected. Jam C Open CN110/2, 5, ID Sensor SC400 8, 11 Shorted Open Thermistor CN125/5, 7 SC554, SC544 Shorted SM Appendix M065/M066...
  • Page 404 Remaining paper volume is wrong. Shorted Open Paper is not detected. Paper is Paper Feed Sensor CN129/4 Shorted detected. Jam A Paper is not Open detected. Jam A Vertical Transport CN129/7 Sensor Paper is Shorted detected. Jam A M065/M066 SM Appendix...
  • Page 405 Jam B Paper is not Open detected. Jam Z Duplex Entrance CN126/A8 Sensor Paper is Shorted detected. Jam Z Paper is not Open detected. Jam Z Duplex Exit Sensor CN126/A11 Paper is Short detected. Jam Z SM Appendix M065/M066...
  • Page 406 By-pass Paper End Jam A CN126/B8 Sensor Paper end is Shorted detected. Paper is not Open detected. Jam Z Inverter Sensor CN126/A2 Paper is Shorted detected. Jam Z Open Fusing Exit Sensor CN104/12 Jam C Shorted M065/M066 SM Appendix...

  • Page 407: Optional Paper Feed Unit

    Jam Y1, Y2, Y3 Open Paper is not detected. Paper is Paper Lift Sensor CN101/7 Shorted detected. Jam Y1, Y2, Y3 Paper end is Open detected. Paper End Sensor CN101/4 Paper end is not Shorted detected. Jam Y1, Y2, Y3 SM Appendix M065/M066...

  • Page 408: Blown Fuse Conditions

    5VS power to the IPU not supplied. FU101 15A/250V 8A/250V Fusing SC occurs. FU102 10A/250V 6.3A/250V No response Power to all the anti-condensation heaters FU103 2A/250V 2A/250V not supplied. 7.1.3 LEDS No LEDs are used for this model (except for the Network Interface). M065/M066 SM Appendix...

  • Page 409: Appendix: Sp Mode Tables

    APPENDIX: SP MODE TABLES R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew 08/31/2010 Updated SP2192. Requires Engine Firmware ver. 1.04:02. 05/17/2011 Removed SP5805-001.

  • Page 411: System Service Mode

    [–9 to 9 / 0.4 / 0.1 mm/step] 011 By-pass: Thick1 *ENG [–9 to 9 / -1.3 / 0.1 mm/step] 012 By-pass: Thick2 *ENG [–9 to 9 / -2.1 / 0.1 mm/step] 013 By-pass: Thick3 *ENG [–9 to 9 / -1.9 / 0.1 mm/step] SM Appendix M065/M066...
  • Page 412 Decreasing a value: an image is moved to the front edge of paper. 001 By-pass *ENG 002 Paper Tray 1 *ENG 003 Paper Tray 2 *ENG [–4 to 4 / 0.0 / 0.1 mm/step] 004 Paper Tray 3 *ENG 005 Paper Tray 4 *ENG 006 Duplex *ENG M065/M066 SM Appendix...
  • Page 413 [–20 to 20 / -3 / 1 mm/step] 019 By-pass:Plain:1200dpi *ENG [–20 to 20 / -3 / 1 mm/step] 020 By-pass:M-Thick:1200dpi *ENG [–20 to 20 / -3 / 1 mm/step] 021 By-pass:Thick1:1200dpi *ENG [–20 to 20 / -4 / 1 mm/step] SM Appendix M065/M066...
  • Page 414 005 Idling Time: M-Thick: BW *ENG [0 to 10 / 2 / 1 sec/step] 006 Idling Time: M-Thick: FC *ENG 007-009 Specifies the thereshold temperature of the paper feed before a job. M065/M066 SM Appendix...
  • Page 415 Sets the heating roller offset temperature at the end of the heating roller. This value is one of the thresholds to determine if the machine is at the heating roller target temperature during warm-up. 010 Stand-By: Center * ENG [50 to 180 / 160 / 1 deg/step] SM Appendix M065/M066...
  • Page 416 020 Off Mode: Ends *ENG [0 to 180 / 0 / 1 deg /step] Off Mode:P-Roller *ENG [0 to 170 / 0 / 1 deg /step] Specifies the pressure roller temperature in the sleep mode. M065/M066 SM Appendix...
  • Page 417 048 Thick 1: FC: Duplex:Center *ENG 049 Thick 1: FC: Duplex:Ends *ENG [100 to 180 / 165 / 1 deg /step] 050 Thick 1: BW: Simplex:Center *ENG 051 Thick 1: BW: Simplex: Ends *ENG 052 Thick 1: BW: Duplex:Center *ENG SM Appendix M065/M066...
  • Page 418 *ENG 071 SP 2:BW:Simplex:Ends *ENG 072 SP 2:BW:Duplex:Center *ENG 073 SP 2:BW:Duplex:Ends *ENG 074 SP 3:FC:Simplex:Center *ENG 075 SP 3:FC:Simplex:Ends *ENG [100 to 200 / 160 / 1 deg/step] 076 SP 3:FC:Duplex:Center *ENG 077 SP 3:FC:Duplex:Ends *ENG M065/M066 SM Appendix...
  • Page 419 *ENG 114 M-Thick: FC: Duplex: Ends *ENG 115 M-Thick: BW: Simplex: Ends *ENG 116 M-Thick: BW: Duplex: Ends *ENG 120 Plain2: FC: Simplex:Center *ENG [100 to 180 / 160 / 1 deg/step] 121 Plain2: FC: Simplex:Ends *ENG SM Appendix M065/M066...
  • Page 420 *ENG 143 Glossy: Plain1: Ends *ENG 144 Glossy: Plain2:Center *ENG 145 Glossy: Plain2: Ends *ENG 146 Glossy: MThick:Center *ENG [100 to 180 / 135 / 1 deg/step] 147 Glossy: MThick: Ends *ENG 160 F: Thick1:FC:Simplex:Center *ENG M065/M066 8-10 SM Appendix...
  • Page 421 212 F: Plain1:Simplex:Press *ENG [50 to 160 / 105 / 1 deg/step] 213 F: Plain2:Simplex:Press *ENG [50 to 160 / 110 / 1 deg/step] 214 F: MThick:Simplex: Press *ENG [50 to 160 / 115 / 1 deg/step] SM Appendix 8-11 M065/M066...
  • Page 422 235 Glossy: Plain2: Duplex: Press *ENG 236 Glossy: MThick: Duplex: Press *ENG [50 to 160 / 90 / 1 deg/step] 237 F: Thick1:Duplex: Press *ENG 238 F: SP 1:Duplex: Press *ENG 239 F: SP 2:Duplex: Press *ENG M065/M066 8-12 SM Appendix...
  • Page 423 *ENG [0 to 120 / 0 / 1 sec/step] Specifies the fusing rotation time before executing SP1109-001. Stop Time * ENG [5 to 30 / 20 / 1 sec/step] Specifies the time for measuring the nip. SM Appendix 8-13 M065/M066...
  • Page 424 (specified with SP1112-002) is detected, the value of this SP is subtracted from the heating roller temperature. 005 Offset Temp:Low *ENG [0 to 15 / 5 / 0.1 deg/step] 006 Offset Temp:High *ENG [0 to 15 / 3 / 0.1 deg/step] M065/M066 8-14 SM Appendix...
  • Page 425 Specifies the threshold temperature of the pressure roller for entering the wait time mode (SP1-113-004). On/Off SW Timer *ENG [0 to 999 / 300 / 1 sec/step] Specifies the interval for entering the PID control from the On/Off control. SM Appendix 8-15 M065/M066...
  • Page 426 [-10 to 10 / 0 / 1 deg/step] Specifies the temperature correction for the heating roller (ends) when the paper width is 226 mm or more. The start time of this SP can be adjusted with SP1116-019. M065/M066 8-16 SM Appendix...
  • Page 427 022 Center Temp.1:MThick 023 Ends Temp.1:MThick 024 Center Temp.2:MThick 025 Ends Temp.2:MThick [-10 to 10 / 0 / 1 deg/step] 030 Center Temp.1:Other 031 Ends Temp.1:Other 032 Center Temp.2:Other 033 Ends Temp.2:Other SM Appendix 8-17 M065/M066...
  • Page 428 [-30 to 0 / 0 / 1 deg] 007 Pattern 1: HM: P-Roll *ENG [0 to 60 / 0 / 1 deg] 008 Pattern 2: MM: H-Roll *ENG [-30 to 0 / -5 / 1 deg] M065/M066 8-18 SM Appendix...
  • Page 429 016 SP 1: Ends *ENG 017 SP 2: Center *ENG [0 to 100 / 75 / 1 %] 018 SP 2: Ends *ENG 019 SP 3: Center *ENG [0 to 100 / 40 / 1 %] SM Appendix 8-19 M065/M066...
  • Page 430 [-5000 to 5000 / 0 / 100msec] 033 Time Set:Half *ENG [Fgate Timer] Specifies the additional duty to the heating roller fusing lamp for each paper type. These values are added to the duty decided by the PID control. M065/M066 8-20 SM Appendix...
  • Page 431 [0 to 100 / 30 / 1 %] 058 F:Special1: Center *ENG 059 F:Special1: End *ENG 060 F:Special2: Center *ENG 061 F:Special2: End *ENG 062 F:Plain2: Center *ENG [0 to 100 / 20 / 1 %] 063 F:Plain2: End *ENG SM Appendix 8-21 M065/M066...
  • Page 432 008 High: 2nd CPM *ENG [10 to 100 / 50 / 5 %] 009 High: 3rd CPM *ENG [10 to 100 / 25 / 5 %] 010 Hi: 1-CPM DwnTemp. *ENG [160 to 240 / 210/ 1 deg/step] M065/M066 8-22 SM Appendix...
  • Page 433 CMY): 182 ColorOpcMot (Drum Motor: *ENG [-80 to 80 / 0/ 1 step] CMY): 85 FusingMot (Fusing/ Paper Exit *ENG Motor): 260 [-4 to 4 / 1.85 / 0.1 %] FusingMot (Fusing/ Paper Exit *ENG Motor): 182 SM Appendix 8-23 M065/M066...
  • Page 434 045 VerticalTransport:Thick2: Low *ENG 046 VerticalTransport:Thick3: Low *ENG 047 By-pass:Plain: Low *ENG 048 By-pass:Plain: High *ENG 049 By-pass:M-Thick: Low *ENG [-4 to 4 / 0 / 0.1 %] 050 By-pass:M-Thick: High *ENG 051 By-pass:Thick1: Low *ENG M065/M066 8-24 SM Appendix...
  • Page 435 072 Reverse CCW: M-Thick: High *ENG 073 Reverse CCW: Thick1: Low *ENG 074 Reverse CCW: Thick1: Middle *ENG 075 Reverse CCW: Thick2: Low *ENG 101 Offset: 260: Color *ENG [-11 to 11 / 0/ 1 step] SM Appendix 8-25 M065/M066...
  • Page 436 *ENG 006 Feed-STM ON: Thick *ENG [-10 to 10 / 0/ 1 mm/step] 007 Feed-Start: Low *ENG 014 By-pass Solenoid ON: Low *ENG [-10 to 40 / 0/ 1 mm/step] 015 By-pass Solenoid ON: Middle *ENG M065/M066 8-26 SM Appendix...
  • Page 437 J-GtSOL2 (Junction Gate *ENG Solenoid): OFF: High Tray2,3,4: Feed-Solenoid ON: *ENG [-10 to 25 / 0/ 2.5 mm/step] Plain Tray2,3,4: Feed-Solenoid OFF: *ENG Plain [-10 to 10 / 0/ 1 mm/step] 031 Tray2,3,4: Feed-Clutch OFF: *ENG SM Appendix 8-27 M065/M066...
  • Page 438 005 Fusing Exit Fan2 *ENG [0 to 600 / 0/ 1 sec/step] 006 PSU Fan *ENG 007 P_Toner_Fan (Toner Supply Fan) *ENG 008 Image Form Fan (Drive Unit Fan) *ENG 009 P_FUSNS (Fusing Cooling Fan) *ENG M065/M066 8-28 SM Appendix...

  • Page 439: Sp2-Xxx (Drum)

    (SP2-007-xxx to SP2-011-xxx). These SPs are activated only when SP2-012-1 is set to "1: manual control". 001 Plain: Bk *ENG 002 Plain: C *ENG [0 to 3000 / 2100 / 10V/step] 003 Plain: M *ENG 004 Plain: Y *ENG SM Appendix 8-29 M065/M066...
  • Page 440 001 Environmental Target: Bk *ENG 002 Environmental Target: C *ENG [0 to 3000 / 790 / 10 A/step] 003 Environmental Target: M *ENG 004 Environmental Target: Y *ENG [0 to 3000 / 850 / 10 A/step] M065/M066 8-30 SM Appendix...
  • Page 441 A/step] 2012 [Charge Output Control] DFU Selects the AC voltage control type. [0 or 1 / 0 / 1 /step] 001 AC Voltage *ENG 0: Process control 1: Manual control (AC voltages are decided with SP2006.) SM Appendix 8-31 M065/M066...
  • Page 442 [0 to 100 / 24.0 / 0.01 g/m /step] Displays the current temperature. 007 Current Temp.: Display *ENG [0 to 100 / 0 / 1 deg/step] Displays the current relative humidity. 008 Relative Humidity: Display *ENG [0 to 100 / 0 / 1%RH/step] M065/M066 8-32 SM Appendix...
  • Page 443 [0 to 20 / 1 / 0.1 deg/step] 011 RH Change: Thresh S *ENG [0 to 50 / 5 / 1 %RH/step] 012 AH Change: Thresh S *ENG [0 to 20 / 1 / 0.1 g/m /step] SM Appendix 8-33 M065/M066...
  • Page 444 004 Y Main Scan: Dot *ENG 005 Bk: Sub Scan: Line *ENG 006 C: Sub Scan: Line *ENG [–800 to 800 / 0 / 1 line/step] 007 M: Sub Scan: Line *ENG 008 Y: Sub Scan: Line *ENG M065/M066 8-34 SM Appendix...
  • Page 445 [–15 to 15 / -4 / 1 sub-dot/step] 019 Main Beam-Pitch: Y: Dot *ENG [–20 to 20 / 9 / 1 dot/step] 020 Main Beam-Pitch: Y: Subdot *ENG [–15 to 15 / -4 / 1 sub-dot/step] SM Appendix 8-35 M065/M066...
  • Page 446 001 Bk: Standard Speed *ENG [50 to 120 / 100 / 1%/step] Decreasing a value makes lines 002 C: Standard Speed *ENG thinner on the output. Increasing a value makes lines 003 M: Standard Speed *ENG M065/M066 8-36 SM Appendix...
  • Page 447 001 Warming-Up *ENG [0 to 60 / 10 / 1 sec/step] 002 Job End *ENG [Image Parameter] 2107 001 Image Gamma Flag *ENG [0 or 1 / 1 / 1 /step] 002 Shading Correction Flag *ENG SM Appendix 8-37 M065/M066...
  • Page 448 1: All colors, 2: Magenta, 3: Yellow, 4: Cyan 006 Density: Bk Specifies the color density for the test pattern. 007 Density: C [0 to 15 / 15 / 1 /step] 008 Density: M 0: Lightest density 15: Darkest density 009 Density: Y M065/M066 8-38 SM Appendix...
  • Page 449 [Skew Adjustment] 2117 Specifies a skew adjustment value for the skew motor M, C or Y. 001 Pulse: C *ENG 002 Pulse: M *ENG [–100 to 100 / 0 / 1 pulse/step] 003 Pulse: Y *ENG SM Appendix 8-39 M065/M066...
  • Page 450 001 PWM: Bk *ENG 002 PWM: C *ENG 003 PWM: M *ENG 004 PWM: Y *ENG [0 to 1024 / 0 / 1/step] 005 PWM: Front *ENG 006 PWM: Center *ENG 007 PWM: Rear *ENG M065/M066 8-40 SM Appendix...
  • Page 451 001 Maximum: Bk *ENG 002 Maximum: C *ENG 003 Maximum: M *ENG 004 Maximum: Y *ENG [0 to 5.5 / 0 / 0.01V/step] 005 Maximum: Front *ENG 006 Maximum: Center *ENG 007 Maximum: Rear *ENG SM Appendix 8-41 M065/M066...
  • Page 452 002 Maximum 2: C *ENG 003 Maximum 2: M *ENG 004 Maximum 2: Y *ENG [0 to 5.5 / 0 / 0.01V/step] 005 Maximum 2: Front *ENG 006 Maximum 2: Center *ENG 007 Maximum 2: Rear *ENG M065/M066 8-42 SM Appendix...
  • Page 453 [-255 to 255 / 58 / 1sub-dot/step] 031 Bk: LD1 Area4 *ENG 032 Bk: LD1 Area5 *ENG [-255 to 255 / 143 / 1sub-dot/step] 033 Bk: LD1 Area6 *ENG 034 Bk: LD1 Area7 *ENG [-255 to 255 / 47 / 1sub-dot/step] SM Appendix 8-43 M065/M066...
  • Page 454 [-255 to 255 / 56 / 1sub-dot/step] 083 C: LD1 Area4 *ENG [-255 to 255 / 57 / 1sub-dot/step] 084 C: LD1 Area5 *ENG [-255 to 255 / 143 / 1sub-dot/step] 085 C: LD1 Area6 *ENG M065/M066 8-44 SM Appendix...
  • Page 455 [-255 to 255 / -192 / 1sub-dot/step] 134 M: LD1 Area3 *ENG [-255 to 255 / 60 / 1sub-dot/step] 135 M: LD1 Area4 *ENG 136 M: LD1 Area5 *ENG [-255 to 255 / 142 / 1sub-dot/step] SM Appendix 8-45 M065/M066...
  • Page 456 [-255 to 255 / -233 / 1sub-dot/step] 185 Y: LD1 Area2 *ENG [-255 to 255 / -194 / 1sub-dot/step] 186 Y: LD1 Area3 *ENG [-255 to 255 / 60 / 1sub-dot/step] 187 Y: LD1 Area4 *ENG M065/M066 8-46 SM Appendix...
  • Page 457 204 Y: LD2 Area8 *ENG [-255 to 255 / -25 / 1sub-dot/step] 205 Y: LD2 Area9 *ENG 206 Y: LD2 Area10 *ENG [-255 to 255 / 0 / 1sub-dot/step] 207 Y: LD2 Area11 *ENG 208 Y: LD2 Area12 *ENG SM Appendix 8-47 M065/M066...
  • Page 458 [50 to 150 / 98.4 / 0.1 %/step] 017 Bk: LD2 Area 0 *ENG [50 to 150 / 100 / 0.1 %/step] 018 Bk: LD2 Area 1 *ENG [50 to 150 / 98.4 / 0.1 %/step] M065/M066 8-48 SM Appendix...
  • Page 459 [50 to 150 / 100.3 / 0.1 %/step] 042 C: LD1 Area 9 *ENG [50 to 150 / 101.2 / 0.1 %/step] 043 C: LD1 Area 10 *ENG [50 to 150 / 102.1 / 0.1 %/step] SM Appendix 8-49 M065/M066...
  • Page 460 [50 to 150 / 98 / 0.1 %/step] 067 M: LD1 Area 2 *ENG [50 to 150 / 97.9 / 0.1 %/step] 068 M: LD1 Area 3 *ENG [50 to 150 / 98.6 / 0.1 %/step] M065/M066 8-50 SM Appendix...
  • Page 461 [50 to 150 / 100.3 / 0.1 %/step] 091 M: LD2 Area 10 *ENG [50 to 150 / 100 / 0.1 %/step] 092 M: LD2 Area 11 *ENG 093 M: LD2 Area 12 *ENG [50 to 150 / 99.6 / 0.1 %/step] SM Appendix 8-51 M065/M066...
  • Page 462 [50 to 150 / 98.1 / 0.1 %/step] 117 Y: LD2 Area 4 *ENG [50 to 150 / 98.4 / 0.1 %/step] 118 Y: LD2 Area 5 *ENG [50 to 150 / 99.3 / 0.1 %/step] M065/M066 8-52 SM Appendix...
  • Page 463 [Vertical Line Width] DFU 001 600dpi:Bk *ENG 002 600dpi:C *ENG 003 600dpi:M *ENG 004 600dpi:Y *ENG [10 to 15 / 15 / 1 /step] 005 1200dpi:Bk *ENG 006 1200dpi:C *ENG 007 1200dpi:M *ENG 008 1200dpi:Y *ENG SM Appendix 8-53 M065/M066...
  • Page 464 009 S. Scan Shift: Center: C *ENG [–21000 to 21000 / 0 / 0.001 um/step] 010 S. Scan Shift: RIght: C *ENG 011 M. Cor.: Dot: C *ENG [–511 to 511 / 0 / 1 dot/step] M065/M066 8-54 SM Appendix...
  • Page 465 *ENG [–1600 to 1600 / 0 / 1 line/step] 038 S. Cor.: 1200 Subdot: M *ENG [–2 to 2 / 0 / 0.001 line/step] 039 Skew: Y *ENG [–5000 to 5000 / 0 / 0.001 um/step] SM Appendix 8-55 M065/M066...
  • Page 466 *ENG When line shifts are not corrected by the automatic line position adjustment, do this SP. Increasing a value reduces the 003 Y Magnification *ENG image in the main scan direction. Decreasing a value enlarges the M065/M066 8-56 SM Appendix...
  • Page 467 [–1 to 1 / 0 / 0.001 /line] 026 S. Scan: Low: Dot: C *ENG [-1600 to 1600 / 1 / 1 line] 027 S. Scan: Low: Subdot: C *ENG [–1 to 1 / 0 / 0.001 /line] SM Appendix 8-57 M065/M066...
  • Page 468 [–1 to 1 / 0 / 0.001 /line] 038 S. Scan: Low: Dot: Y *ENG [-1600 to 1600 / 5 / 1 line] 039 S. Scan: Low: Subdot: Y *ENG [–1 to 1 / 0 / 0.001 /line] M065/M066 8-58 SM Appendix...
  • Page 469 [0 or 1 / 1 / 1 boolean /step] 010 Area Mag.: Subdot: Y *ENG [0 or 1 / 0 / 1 boolean /step] 0: Adjusted with Bk 011 S. Scan Cor. Setting *ENG 1: Adjusted in minimum shift among four colors SM Appendix 8-59 M065/M066...
  • Page 470 [–131071 to 131071 / 84 / 1 bit/step] 021 ch 2: Filter: Front: a1 *ENG [–131071 to 131071 / 125869 / 1 bit/step] 022 ch 2: Filter: Front: a2 *ENG [–131071 to 131071 / –60488 / 1 bit/step] M065/M066 8-60 SM Appendix...
  • Page 471 *ENG version 1.04:02 to avoid unnecessary occurrences of SC285 (MUSIC error). 008 ch 1: 4th *ENG 009 ch 2: 1st *ENG 010 ch 2: 2nd *ENG 011 ch 2: 3rd *ENG 012 ch 2: 4th *ENG SM Appendix 8-61 M065/M066...
  • Page 472 SP2-193-008 or SP2-193-009 is satisfied. Temp Change *ENG [0 to 100 / 5 / 1 deg/step] Adjust the temperature change threshold for the line position adjustment (Mode b: adjustment once). The timing for line position adjustment depends on M065/M066 8-62 SM Appendix...
  • Page 473 [0 to 999 / 200 / 1 page/step] BW+FC Page: Full Color Job Before: *ENG [0 to 999 / 200 / 1 page/step] 016 Page: Power ON:BW+FC *ENG [0 to 999 / 200 / 1 page/step] SM Appendix 8-63 M065/M066...
  • Page 474 [10 to 40 / 20 / 10 ms/step] 002 TM Sensor Position *ENG [100 to 150 / 114.6 / 0.1 mm/step] 2198 [Music A/D Interval] DFU 001 ADC Trigger *ENG [7.5 to 20 / 10 / 0.1 s/step] M065/M066 8-64 SM Appendix...
  • Page 475 After deactivating Process Control with SP3-041-001, the values in these SP modes are used for printing. 001 Bk *ENG 002 C *ENG [0 to 800 / 450 / 1 –V/step] 003 M *ENG 004 Y *ENG SM Appendix 8-65 M065/M066...
  • Page 476 [0 to 100 / 16 / 0.01 g/m /step] Adjusts the threshold value between MM and MH. Absolute Humidity: Threshold 4 *ENG [0 to 100 / 24 / 0.01 g/m /step] Adjusts the threshold value between MH and HH. M065/M066 8-66 SM Appendix...
  • Page 477 [10 to 250 / 100 / 5 %/step] Adjusts the bias of the paper transfer roller 002 Paper Transfer *ENG between images. [0 to 230 / 0 / 1 - A/step] SM Appendix 8-67 M065/M066...
  • Page 478 Adjusts the current for the image transfer belt in B/W mode for M-Thick paper. Image Transfer:Low Speed *ENG [0 to 80 / 7 / 1 Adjusts the current for the image transfer belt in B/W mode for thick 1 paper. M065/M066 8-68 SM Appendix...
  • Page 479 Adjusts the current for the image transfer belt for Cyan in full color mode for M-Thick paper. Image Transfer: Middle Spd:Y *ENG [0 to 80 / 15 / 1 Adjusts the current for the image transfer belt for Yellow in full color mode for M-Thick paper. SM Appendix 8-69 M065/M066...
  • Page 480 [1 to 100 / 54 / 1 /step] 010 Image Transfer: Middle Spd:M *ENG [1 to 100 / 54 / 1 /step] 011 Image Transfer: Middle Spd:Y *ENG [1 to 100 / 55 / 1 /step] M065/M066 8-70 SM Appendix...
  • Page 481 002 Paper Transfer: Normal: 2nd *ENG [0 to 230 / 23 / 1 – A /step] 003 Paper Transfer: Low: 1st *ENG [0 to 230 / 15 / 1 – A /step] 004 Paper Transfer: Low: 2nd *ENG SM Appendix 8-71 M065/M066...
  • Page 482 007 Paper Transfer: Low: 1st: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [100 to 995 / 200 / 5%/step] 008 Paper Transfer: Low : 2nd:S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) M065/M066 8-72 SM Appendix...
  • Page 483 [100 to 995 / 220 / 5%/step] 015 PaperTransfer: Low:1st:S4 *ENG 139 mm > S4 size (Paper width) [100 to 995 / 330 / 5%/step] 016 Paper Transfer: Low 2nd: S4 *ENG 139 mm > S4 size (Paper width) SM Appendix 8-73 M065/M066...
  • Page 484 010 Paper Transfer: Normal: 2nd: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 135 / 5%/step] 011 Paper Transfer: Low: 1st: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) M065/M066 8-74 SM Appendix...
  • Page 485 004 Paper Transfer: Low: 2nd: S1 *ENG S1 size ≥ 194 mm (Paper width) [1 to 100 / 19 / 1/step] 005 Paper Transfer: Normal: 1st: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-75 M065/M066...
  • Page 486 [1 to 100 / 38 / 1/step] 015 Paper Transfer: Low: 1st: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 11 / 1/step] 016 Paper Transfer: Low: 2nd: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-76 SM Appendix...
  • Page 487 008 Paper Transfer: Low : 2nd:S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 11 / 1/step] 009 Paper Transfer: Normal: 1st: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) SM Appendix 8-77 M065/M066...
  • Page 488 [1 to 100 / 35 / 1/step] 015 Paper Transfer: Low: 1st: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 78 / 1/step] 016 Paper Transfer: Low: 2st: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-78 SM Appendix...
  • Page 489 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Normal: 1st *ENG 006 Separation DC: Normal: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-79 M065/M066...
  • Page 490 002 Paper Transfer: Normal: 2nd *ENG 003 Paper Transfer: Low: 1st *ENG [0 to 995 / 100 / 5 %/step] 004 Paper Transfer: Low: 2nd *ENG 005 Separation DC: Normal: 1st *ENG 006 Separation DC: Normal: 2nd *ENG M065/M066 8-80 SM Appendix...
  • Page 491 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG 2425 [HH-Small: L-Edge Correction] 001 Paper Transfer: Standard & Low: 1 *ENG [0 to 995 / 100 / 5 %/step] 002 Paper Transfer: Standard & Low: 2 *ENG SM Appendix 8-81 M065/M066...
  • Page 492 001 Separation DC: Standard Spd: 1st *ENG 002 Separation DC: Standard Spd: 2nd *ENG [0 to 6000 / 2000 / 10 -V/step] 003 Separation DC: Low Spd: 1st *ENG 004 Separation DC: Low Spd: 2nd *ENG M065/M066 8-82 SM Appendix...
  • Page 493 Paper Transfer: Standard: 1Side: *ENG Paper Transfer: Standard: 2Side: [100 to 995 / 100 / 5 %/step] *ENG S1 size ≥ 194 mm (Paper width) 003 Paper Transfer: Low: 1: S1 *ENG 004 Paper Transfer: Low: 2: S1 *ENG SM Appendix 8-83 M065/M066...
  • Page 494 [100 to 995 / 220 / 5 %/step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 330 / 5 %/step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-84 SM Appendix...
  • Page 495 Paper Transfer: Standard: 1Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 325 / 5 %/step] Paper Transfer: Standard: 2Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) SM Appendix 8-85 M065/M066...
  • Page 496 Paper Transfer: Standard: 1Side: *ENG 194 mm > S2 size ≥ 165 mm (Paper width) Paper Transfer: Standard: 2Side: [1 to 100 / 8 / 1 /step] *ENG 194 mm > S2 size ≥ 165 mm M065/M066 8-86 SM Appendix...
  • Page 497 139 mm > S4 (Paper width) Paper Transfer: Standard: 2Side: *ENG [1 to 100 / 8 / 1 /step] 139 mm > S4 015 Paper Transfer: Low: 1: S4 *ENG (Paper width) 016 Paper Transfer: Low: 2: S4 *ENG SM Appendix 8-87 M065/M066...
  • Page 498 Paper Transfer: Standard: 1Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [1 to 100 / 16 / 1 /step] Paper Transfer: Standard: 2Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) M065/M066 8-88 SM Appendix...
  • Page 499 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5 %/step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-89 M065/M066...
  • Page 500 002 Paper Transfer: Standard: 2 *ENG 003 Paper Transfer: Low: 1st *ENG [0 to 995 / 100 / 5 %/step] 004 Paper Transfer: Low: 2nd *ENG 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG M065/M066 8-90 SM Appendix...
  • Page 501 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-91 M065/M066...
  • Page 502 *ENG [0 to 230 / 12 / 1 – A /step] [Thin: Bias: FC] 2457 Adjusts the current for the paper transfer roller for thin paper in full color mode. Normal: 260 mm/sec, Low: 85 mm/sec M065/M066 8-92 SM Appendix...
  • Page 503 [100 to 995 / 220 / 5% /step] *ENG 139 mm > S4 (Paper width) [100 to 995 / 220 / 5% /step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-93 M065/M066...
  • Page 504 [1 to 100 / 8 / 1 /step] Paper Transfer: Standard: 1Side: *ENG 194 mm > S2 size ≥ 165 mm (Paper width) 007 Paper Transfer: Low: 1: S2 *ENG [1 to 100 / 21 / 1 /step] M065/M066 8-94 SM Appendix...
  • Page 505 007 Paper Transfer: Low: 1: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 9 / 1 /step] Paper Transfer: Standard: 1Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) SM Appendix 8-95 M065/M066...
  • Page 506 001 Paper Transfer: Standard: 1st *ENG [0 to 50 / 0 / 2 mm/step] 003 Paper Transfer: Low: 1st *ENG 005 Separation DC: Standard: 1st *ENG [0 to 50 / 30 / 2 mm/step] 007 Separation DC: Low: 1st *ENG M065/M066 8-96 SM Appendix...
  • Page 507 Standard: 260 mm/sec, Low: 85 mm/sec 001 Paper Transfer: Standard: 1st *ENG 003 Paper Transfer: Low: 1st *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: Standard: 1st *ENG 007 Separation DC: Low: 1st *ENG SM Appendix 8-97 M065/M066...
  • Page 508 Not used 003 Paper Transfer: Low Spd: 1st *ENG [0 to 230 / 9 / 1 – A /step] 004 Paper Transfer: Low Spd: 2nd *ENG [0 to 230 / 12 / 1 – A /step] M065/M066 8-98 SM Appendix...
  • Page 509 007 Paper Transfer: Low: 1: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [100 to 995 / 160 / 5%/step] 008 Paper Transfer: Low: 2: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-99 M065/M066...
  • Page 510 [100 to 995 / 100 / 5%/step] S1 size ≥ 194 mm (Paper width) 003 Paper Transfer: Low: 1: S1 *ENG 004 Paper Transfer: Low: 2: S1 *ENG 005 Paper Transfer: Middle: 1st: S2 *ENG [100 to 995 / 150 / 5%/step] M065/M066 8-100 SM Appendix...
  • Page 511 [100 to 995 / 200 / 5%/step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-101 M065/M066...
  • Page 512 [1 to 100 / 19 / 1/step] Paper Transfer: Middle: 2nd: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) 011 Paper Transfer: Low: 1: S3 *ENG [1 to 100 / 18 / 1/step] M065/M066 8-102 SM Appendix...
  • Page 513 004 Paper Transfer: Low: 2: S1 *ENG S1 size ≥ 194 mm (Paper width) [1 to 100 / 2 / 1/step] 005 Paper Transfer: Middle: 1st: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-103 M065/M066...
  • Page 514 [1 to 100 / 13 / 1/step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 25 / 1/step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-104 SM Appendix...
  • Page 515 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Middle: 1st *ENG 006 Separation DC: Middle: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-105 M065/M066...
  • Page 516 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: Middle: 1st *ENG 006 Separation DC: Middle: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG M065/M066 8-106 SM Appendix...
  • Page 517 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Middle: 1st *ENG 006 Separation DC: Middle: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-107 M065/M066...
  • Page 518 [Thick 1: Edge-Env. Correct] DFU 017 Separation DC: Middle: 1st *ENG 018 Separation DC: Middle: 2nd *ENG [1 to 100 / 30 / 1 /step] 019 Separation DC: Low: 1st *ENG 020 Separation DC: Low: 2nd *ENG M065/M066 8-108 SM Appendix...
  • Page 519 Adjusts the current for the paper transfer roller for thick2 paper in full color mode. 001 Paper Transfer: 1st *ENG [0 to 230 / 12 / 1 – A /step] 002 Paper Transfer: 2nd *ENG [0 to 230 / 20 / 1 – A /step] SM Appendix 8-109 M065/M066...
  • Page 520 [100 to 995 / 200 / 5% /step] 015 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5% /step] 016 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-110 SM Appendix...
  • Page 521 [100 to 995 / 200 / 5% /step] 015 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5% /step] 016 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-111 M065/M066...
  • Page 522 [1 to 100 / 18 / 1 /step] 015 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 22 / 1 /step] 016 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-112 SM Appendix...
  • Page 523 [1 to 100 / 13 / 1 /step] 015 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 38 / 1 /step] 016 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-113 M065/M066...
  • Page 524 001 Paper Transfer: 1st *ENG 002 Paper Transfer: 2nd *ENG [0 to 50 / 0 / 2mm/step] 003 Separation DC: 1st *ENG 004 Separation DC: 2nd *ENG M065/M066 8-114 SM Appendix...
  • Page 525 001 Paper Transfer: 1st *ENG 002 Paper Transfer: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 003 Separation DC: 1st *ENG 004 Separation DC: 2nd *ENG SM Appendix 8-115 M065/M066...
  • Page 526 [0 to 230 / 8 / 1 – A /step] [OHP: Bias: FC] 2608 Adjusts the current for the paper transfer roller for OHP in full color mode. 001 Paper Transfer *ENG [0 to 230 / 21 / 1 – A /step] M065/M066 8-116 SM Appendix...
  • Page 527 [100 to 995 / 150 / 5% /step] 011 Paper Transfer: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 200 / 5% /step] 015 Paper Transfer: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-117 M065/M066...
  • Page 528 [1 to 100 / 12 / 1 /step] 011 Paper Transfer: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [1 to 100 / 12 / 1 /step] 015 Paper Transfer: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-118 SM Appendix...
  • Page 529 SP2603 and SP2608 are multiplied by these SP values. The paper trailing edge area can be adjusted with SP2624. 001 Paper Transfer *ENG [0 to 995 / 100 / 5%/step] 002 Separation DC *ENG SM Appendix 8-119 M065/M066...
  • Page 530 Adjusts the current for the paper transfer roller for thick paper 3 in black-and-white mode. 001 Paper Transfer: 1st *ENG [0 to 230 / 9 / 1 – A /step] 002 Paper Transfer: 2nd *ENG [0 to 230 / 12 / 1 – A /step] M065/M066 8-120 SM Appendix...
  • Page 531 [100 to 995 / 200 / 5%/step] 007 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 008 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-121 M065/M066...
  • Page 532 [100 to 995 / 200 / 5%/step] 007 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 008 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-122 SM Appendix...
  • Page 533 [1 to 100 / 24 / 1 /step] 007 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 22 / 1 /step] 008 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-123 M065/M066...
  • Page 534 [1 to 100 / 24 / 1 /step] 007 Paper Transfer: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 27 / 1 /step] 008 Paper Transfer: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-124 SM Appendix...
  • Page 535 001 Paper Transfer: 1st *ENG 002 Paper Transfer: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 003 Separation DC: 1st *ENG 004 Separation DC: 2nd *ENG SM Appendix 8-125 M065/M066...
  • Page 536 [1 to 100 / 30 / 1 /step] 016 Separation DC: 2nd *ENG [Thick 3: Edge-Env. Correct] DFU 019 Separation DC: 1st *ENG [1 to 100 / 30 / 1 /step] 020 Separation DC: 2nd *ENG M065/M066 8-126 SM Appendix...
  • Page 537 [0 to 230 / 25 / 1- A /step] 003 Paper Transfer: Low: 1st *ENG [0 to 230 / 12/ 1- A /step] 004 Paper Transfer: Low: 2nd *ENG [0 to 230 / 14 / 1- A /step] SM Appendix 8-127 M065/M066...
  • Page 538 Paper Transfer: Standard: 1Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 390 / 5%/step] Paper Transfer: Standard: 2Side: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) M065/M066 8-128 SM Appendix...
  • Page 539 003 Paper Transfer: Low: 1: S1 *ENG 004 Paper Transfer: Low: 2: S1 *ENG [100 to 995 / 135 / 5%/step] Paper Transfer: Standard: 1Side: *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-129 M065/M066...
  • Page 540 [100 to 995 / 220 / 5%/step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 330 / 5%/step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-130 SM Appendix...
  • Page 541 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 10 / 1 /step] 007 Paper Transfer: Low: 1: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-131 M065/M066...
  • Page 542 [1 to 100 / 10 / 1 /step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 12 / 1 /step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-132 SM Appendix...
  • Page 543 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 10 / 1 /step] 007 Paper Transfer: Low: 1: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) SM Appendix 8-133 M065/M066...
  • Page 544 [1 to 100 / 37 / 1 /step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 41 / 1 /step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-134 SM Appendix...
  • Page 545 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5% /step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-135 M065/M066...
  • Page 546 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2mm /step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG M065/M066 8-136 SM Appendix...
  • Page 547 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5% /step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-137 M065/M066...
  • Page 548 016 Separation DC: Low: 2nd *ENG [M-Thick:Edge-Env.Correct] DFU 017 Separation DC: Standard: 1st *ENG 018 Separation DC: Standard: 2nd *ENG [1 to 100 / 50 / 1 /step] 019 Separation DC: Low: 1st *ENG 020 Separation DC: Low: 2nd *ENG M065/M066 8-138 SM Appendix...
  • Page 549 [0 to 230 / 25 / 1 – A /step] 003 Paper Transfer: Low: 1st *ENG [0 to 230 / 12 / 1 – A /step] 004 Paper Transfer: Low: 2nd *ENG [0 to 230 / 14 / 1 – A /step] SM Appendix 8-139 M065/M066...
  • Page 550 [100 to 995 / 390 / 5%/step] Paper Transfer: Standard: 2nd: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 135 / 5%/step] 011 PaperTransfer:Low:1st:S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper M065/M066 8-140 SM Appendix...
  • Page 551 194 mm > S2 size ≥ 165 mm (Paper width) [100 to 995 / 200 / 5%/step] Paper Transfer: Standard: 2nd: *ENG 194 mm > S2 size ≥ 165 mm (Paper width) 007 Paper Transfer:Low:1st:S2 *ENG [100 to 995 / 135 / 5%/step] SM Appendix 8-141 M065/M066...
  • Page 552 139 mm > S4 (Paper width) [100 to 995 / 220 / 5%/step] 015 PaperTransfer:Low:1st:S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 330 / 5%/step] 016 PaperTransfer:Low:2nd:S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-142 SM Appendix...
  • Page 553 008 Paper Transfer:Low:2nd:S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 14 / 1 /step] Paper Transfer: Standard: 1st: *ENG 165 mm > S3 size ≥ 139 mm (Paper width) SM Appendix 8-143 M065/M066...
  • Page 554 Paper Transfer: Standard: 2nd: [1 to 100 / 43 / 1 /step] *ENG S1 size ≥ 194 mm (Paper width) [1 to 100 / 37 / 1 /step] 003 Paper Transfer:Low:1st:S1 *ENG S1 size ≥ 194 mm (Paper width) M065/M066 8-144 SM Appendix...
  • Page 555 [1 to 100 / 39 / 1 /step] 012 PaperTransfer:Low:2nd:S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) Paper Transfer: Standard: 1st: [1 to 100 / 7 / 1 /step] *ENG 139 mm > S4 (Paper width) SM Appendix 8-145 M065/M066...
  • Page 556 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG M065/M066 8-146 SM Appendix...
  • Page 557 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-147 M065/M066...
  • Page 558 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Standard: 1st *ENG 006 Separation DC: Standard: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG M065/M066 8-148 SM Appendix...
  • Page 559 [SP 1: Edge-Env. Correct] DFU 017 Separation DC: Standard: 1st *ENG 018 Separation DC: Standard: 2nd *ENG [1 to 100 / 50 / 1 /step] 019 Separation DC: Low: 1st *ENG 020 Separation DC: Low: 2nd *ENG SM Appendix 8-149 M065/M066...
  • Page 560 002 Paper Transfer: Middle: 2nd *ENG 003 Paper Transfer: Low: 1st *ENG [0 to 230 / 12 / 1 – A /step] 004 Paper Transfer: Low: 2nd *ENG [0 to 230 / 18 / 1 – A /step] M065/M066 8-150 SM Appendix...
  • Page 561 009 Paper Transfer: Middle: 1Side: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [100 to 995 / 270 / 5%/step] 010 Paper Transfer: Middle: 2Side: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) SM Appendix 8-151 M065/M066...
  • Page 562 005 Paper Transfer: Middle: 1Side: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [100 to 995 / 160 / 5%/step] 006 Paper Transfer: Middle: 2Side: S2 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) M065/M066 8-152 SM Appendix...
  • Page 563 [100 to 995 / 200 / 5%/step] 015 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 016 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-153 M065/M066...
  • Page 564 *ENG 194 mm > S2 size ≥ 165 mm (Paper width) [1 to 100 / 20 / 1 /step] 009 Paper Transfer: Middle: 1Side: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) M065/M066 8-154 SM Appendix...
  • Page 565 002 Paper Transfer: Middle: 2Side: S1 *ENG S1 size ≥ 194 mm (Paper width) [1 to 100 / 13 / 1 /step] 003 Paper Transfer: Low: 1: S1 *ENG S1 size ≥ 194 mm (Paper width) SM Appendix 8-155 M065/M066...
  • Page 566 012 Paper Transfer: Low: 2: S3 *ENG 165 mm > S3 size ≥ 139 mm (Paper width) [1 to 100 / 2 / 1 /step] 013 Paper Transfer: Middle: 1Side: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-156 SM Appendix...
  • Page 567 004 Paper Transfer: Low: 2nd *ENG [0 to 995 / 100 / 5%/step] 005 Separation DC: Middle: 1st *ENG 006 Separation DC: Middle: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-157 M065/M066...
  • Page 568 001 Paper Transfer: Middle: 1st *ENG 002 Paper Transfer: Middle: 2nd *ENG 003 Paper Transfer: Low: 1st *ENG [0 to 995 / 100 / 5%/step] 004 Paper Transfer: Low: 2nd *ENG 005 Separation DC: Middle: 1st *ENG M065/M066 8-158 SM Appendix...
  • Page 569 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: Middle: 1st *ENG 006 Separation DC: Middle: 2nd *ENG 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-159 M065/M066...
  • Page 570 Low: 85 mm/sec 003 Paper Transfer: Low: 1st *ENG [0 to 230 / 9 / 1 – A /step] 004 Paper Transfer: Low: 2nd *ENG [0 to 230 / 12 / 1 – A /step] M065/M066 8-160 SM Appendix...
  • Page 571 [100 to 995 / 200 / 5%/step] 007 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 008 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-161 M065/M066...
  • Page 572 [100 to 995 / 200 / 5%/step] 007 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [100 to 995 / 435 / 5%/step] 008 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-162 SM Appendix...
  • Page 573 [1 to 100 / 24 / 1 /step] 007 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 22 / 1 /step] 008 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) SM Appendix 8-163 M065/M066...
  • Page 574 [1 to 100 / 24 / 1 /step] 007 Paper Transfer: Low: 1: S4 *ENG 139 mm > S4 (Paper width) [1 to 100 / 27 / 1 /step] 008 Paper Transfer: Low: 2: S4 *ENG 139 mm > S4 (Paper width) M065/M066 8-164 SM Appendix...
  • Page 575 Low: 85 mm/sec 003 Paper Transfer: Low: 1st *ENG 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG SM Appendix 8-165 M065/M066...
  • Page 576 Low: 85 mm/sec 003 Paper Transfer: Low: 1st *ENG 004 Paper Transfer: Low: 2nd *ENG [0 to 50 / 0 / 2 mm/step] 007 Separation DC: Low: 1st *ENG 008 Separation DC: Low: 2nd *ENG M065/M066 8-166 SM Appendix...
  • Page 577 004 DevRev: Bk *ENG [Image Transfer Rev Time] DFU 2904 Adjusts the time for how long the image transfer belt motor reverses after job end. 003 All *ENG [0 to 800 / 70 / 10 msec/step] SM Appendix 8-167 M065/M066...
  • Page 578 SP after consecutive full color image printouts in the full color mode. If this SP is set to "0", the image transfer belt does not move away. 001 Bk Image Count *ENG [0 to 10 / 0 / 1 sheet/step] M065/M066 8-168 SM Appendix...
  • Page 579 010 Shutter Open *ENG [0 to 500 / 100 / 10 msec/step] 011 Shutter Close *ENG [0 to 500 / 180 / 10 msec/step] [Skip] 014 Shutter Open/ Close *ENG [0 or 1 / 1 / 1/step] SM Appendix 8-169 M065/M066...
  • Page 580 1: ENC Control SC443 Count *ENG [0 to 3 / 0 / 1 /step] Displays the detection times of SC443. [0 or 1 / 1 / 1 /step] 003 BkTransferMotorCtrl 85 *ENG 0: FG Control 1: ENC Control M065/M066 8-170 SM Appendix...
  • Page 581 2971 [BW Non-Image:Bias ON] DFU 001 T1 BW:Bias On:Standard *ENG [-360 to 80 / 0 / 10 msec/step] 002 T1 BW:Bias On:Middle *ENG [-780 to 210 / 0 / 10 msec/step] 003 T1 BW:Bias On:Low *ENG SM Appendix 8-171 M065/M066...

  • Page 582: Sp3-Xxx (Process)

    [0 or 1 / 0 / 1 /step ] Executes the process control that is 005 With Normal MUSIC normally done at the same time as MUSIC. This SP does the MUSIC (line position adjustment) once. M065/M066 8-172 SM Appendix...
  • Page 583 010 Result: Latest 9 *ENG 3013 [TD Sen Initial Setting] Developer Initialization Setting 001 Execution: ALL 002 Execution: COL 003 Execution: Bk [0 or 1 / 0 / 1/step] 004 Execution: C 005 Execution: M 006 Execution: Y SM Appendix 8-173 M065/M066...
  • Page 584 Specifies the manual toner supply time for each color. 001 Supply Time: Bk *ENG 002 Supply Time: C *ENG [0 to 30 / 4 / 1 sec/step] 003 Supply Time: M *ENG 004 Supply Time: Y *ENG M065/M066 8-174 SM Appendix...
  • Page 585 009 Upper Counter: Y *ENG or lower limit error. 010 Lower Counter: Bk *ENG [0 to 99 / 0 / 1 times/step] 011 Lower Counter: C *ENG 012 Lower Counter: M *ENG 013 Lower Counter: Y *ENG SM Appendix 8-175 M065/M066...
  • Page 586 [0 or 1 / 0 / 1/step] 006 Execution Flag: C *ENG 0: Flag OFF, 1: Flag ON This flag is cleared after executing TD 007 Execution Flag: M *ENG sensor initialization. 008 Execution Flag: Y *ENG M065/M066 8-176 SM Appendix...
  • Page 587 0: Not Execute *ENG Control 1: Process Control 2: TC Control Selects the process control mode that is done before ACC. [0 to 2 / 0 / 1/step] Pattern Caluculation 0: FIXED *ENG Method 1: INITIALIZED 2: CALCULATED SM Appendix 8-177 M065/M066...
  • Page 588 4: Repeat three times (No consumption mode) 5: Repeat three times (Toner is supplied only when the toner density is too low, and toner is consumed only when the toner density is too dark.) 6 to 9: Disabled M065/M066 8-178 SM Appendix...
  • Page 589 C-pattern: Bk *ENG [0 to 255 / 5 / 1 time/step] Specifies the belt mark generating time for checking the black toner density when toner density is detected to be low at the toner density adjustment. SM Appendix 8-179 M065/M066...
  • Page 590 Adjusts the LD duty for the toner consumption mode at the toner density adjustment. In toner consumption mode, toner is discharged when the detected development gamma values (SP3611-001) exceed the target values (SP3611-005) by more than the specified thresholds (SP3239-009). M065/M066 8-180 SM Appendix...
  • Page 591 [0 to 4 / 4 / 1/step] Alphanumeric 0: FIXED (with the supply rates stored with 002 C *ENG SP 3401) 1: PID (Vtref_Fixed) 003 M *ENG 2: PID (Vtref_Control) 3: MBD (Vtref_Fixed) 004 Y *ENG 4: MBD (Vtref_Control) SM Appendix 8-181 M065/M066...
  • Page 592 009 Toner Remaining: Bk *ENG 010 Toner Remaining: C *ENG [–50000 to 600 / 0 / 0.001 g/step] 011 Toner Remaining: M *ENG 012 Toner Remaining: Y *ENG M065/M066 8-182 SM Appendix...
  • Page 593 Displays the consumed toner amount calculated with the pixel count for each 028-031 color. 028 Pixel: Consumption: Bk *ENG 029 Pixel: Consumption: C *ENG [0 to 3000 / 0 / 0.001 g/step] 030 Pixel: Consumption: M *ENG 031 Pixel: Consumption: Y *ENG SM Appendix 8-183 M065/M066...
  • Page 594 046 Bottle Motor Off Time: Bk *ENG 047 Bottle Motor Off Time: C *ENG [0 to 0 x FFFFFFFF / 0 / 1 sec/step] 048 Bottle Motor Off Time: M *ENG 049 Bottle Motor Off Time: Y *ENG M065/M066 8-184 SM Appendix...
  • Page 595 004 Repeat: Y *ENG [TE Count: Display] 3131 Display the number of toner end detections for each color. 001 Bk *ENG 002 C *ENG [0 to 99 / 0 / 1 time/step] 003 M *ENG 004 Y *ENG SM Appendix 8-185 M065/M066...
  • Page 596 009 Mid TC Shift: Bk *ENG 010 Mid TC Shift: C *ENG 011 Mid TC Shift: M *ENG [-0.5 to 0.5 / 0 / 0.01 V/step] 012 Mid TC Shift: Y *ENG 013 Low TC Shift: Bk *ENG M065/M066 8-186 SM Appendix...
  • Page 597 011 182 Current: M *ENG 012 182 Current: Y *ENG [2.45 to 5 / 3.5 / 0.01 V/step] 013 182 Initial: Bk *ENG 014 182 Initial: C *ENG 015 182 Initial: M *ENG 016 182 Initial: Y *ENG SM Appendix 8-187 M065/M066...
  • Page 598 009 Pixel Correction: Bk *ENG [-5 to 5.5 / 0 / 0.01 V/step] 010 Pixel Correction: C *ENG 011 Pixel Correction: M *ENG [-5 to 5 / 0 / 0.01 V/step] 012 Pixel Correction: Y *ENG M065/M066 8-188 SM Appendix...
  • Page 599 Adjusts the lower limit of the TD sensor 013 Lower Sensitivity *ENG sensitivity. [0.2 to 0.5 / 0.209 / 0.001 V/wt% /step] 014 TD Thresh H/M *ENG [1 to 10 / 4 / 0.1 wt%/step] 015 TD Thresh M/L *ENG SM Appendix 8-189 M065/M066...
  • Page 600 013 TC Upper Limit:Display: C *ENG [1 to 15 / 10 / 0.1 wt% /step] 014 TC Upper Limit:Display: M *ENG 015 TC Upper Limit:Display: Y *ENG 016 Process Control Thresh *ENG [0 to 255 / 15 / 1 time/step] M065/M066 8-190 SM Appendix...
  • Page 601 038 PID:I: MidSpd *ENG [0 to 5 / 0.7 / 0.01 /step] 039 PID:I: LowSpd *ENG [0 to 5 / 0.33 / 0.01 /step] 040 PID:P: MidSpd *ENG [0 to 5 / 0.7 / 0.01 /step] SM Appendix 8-191 M065/M066...
  • Page 602 *ENG [0 to 5 / 1 / 0.01 /step] 095 SMITH: LowSpd *ENG 100 Int:Conserve:I:K *ENG 101 Int:Conserve:I:C *ENG 102 Int:Conserve:I:M *ENG [-1000 to 1000 / 0 / 0.0001 /step] 103 Int:Conserve:I:Y *ENG 110 ANCrefCons:K *ENG M065/M066 8-192 SM Appendix...
  • Page 603 181 ANCLA: C *ENG [0 to 10 / 0.57 / 0.01 /step] 182 ANCLA: M *ENG [0 to 10 / 0.6 / 0.01 /step] 183 ANCLA: Y *ENG [0 to 10 / 0.63 / 0.01 /step] SM Appendix 8-193 M065/M066...
  • Page 604 *ENG 216 PIX:TBL:7 *ENG 217 PIX:TBL:8 *ENG [0 to 5 / 1 / 0.01 /step] 218 PIX:TBL:9 *ENG 219 PIX:TBL:10 *ENG 220 PIX:TBL:11 *ENG 221 PIX:TBL:12 *ENG 222 PIX:COR:K *ENG 223 PIX:COR:C *ENG 224 PIX:COR:M *ENG M065/M066 8-194 SM Appendix...
  • Page 605 [0.5 to 9.99 / 2.18 / 0.01 /step] 002 Conversion Coeff.:C *ENG 003 Conversion Coeff.:M *ENG [0.5 to 9.99 / 2.24 / 0.01 /step] 004 Conversion Coeff.:Y *ENG [0.5 to 9.99 / 2.18 / 0.01 /step] SM Appendix 8-195 M065/M066...
  • Page 606 012 Vt Integral Control: Y *ENG 013 Vt Sum Times: Bk *ENG 014 Vt Sum Times: C *ENG [1 to 255 / 20 / 1 time/step] 015 Vt Sum Times: M *ENG 016 Vt Sum Times: Y *ENG M065/M066 8-196 SM Appendix...
  • Page 607 008 Pixel Proportion 3: Y *ENG 009 Vt Integral Value: Bk *ENG 010 Vt Integral Value: C *ENG [-255 to 255 / 0 / 0.01 /step] 011 Vt Integral Value: M *ENG 012 Vt Integral Value: Y *ENG SM Appendix 8-197 M065/M066...
  • Page 608 Adjusts the parameter for Vtref correction at the process control. 001 (+)Consumption: Bk *ENG 002 (+)Consumption: C *ENG 003 (+)Consumption: M *ENG [0 to 1 / 0.08 / 0.01 V/step] 004 (+)Consumption: Y *ENG 005 (-)Consumption: Bk *ENG 006 (-)Consumption: C *ENG M065/M066 8-198 SM Appendix...
  • Page 609 [0 to 255 / 158 / 1 V/step] 007 Offset: M *ENG DC charge bias = Development bias x (1 + 0.001 x SP3-241-001 to -004) + these 008 Offset: Y *ENG values SM Appendix 8-199 M065/M066...
  • Page 610 015 Middle Speed: Offset: M *ENG 016 Middle Speed: Offset: Y *ENG 017 Low Speed Coeff.:Bk *ENG 018 Low Speed Coeff.:C *ENG [-1000 to 1000 / 123 / 1 /step] 019 Low Speed Coeff.:M *ENG 020 Low Speed Coeff.:Y *ENG M065/M066 8-200 SM Appendix...
  • Page 611 012 Low Speed: Coef: Y *ENG 013 Low Speed: Offset: Bk *ENG 014 Low Speed: Offset: C *ENG [0 to 200 / 0 / 1 V/step] 015 Low Speed: Offset: M *ENG 016 Low Speed: Offset: Y *ENG SM Appendix 8-201 M065/M066...
  • Page 612 "Average M" is defined when the number of developed pages does not reach the number specified with SP3251-018. 009 Average M: Bk *ENG 010 Average M: C *ENG [0 to 100 / 5 / 0.01 %/step] 011 Average M: M *ENG 012 Average M: Y *ENG M065/M066 8-202 SM Appendix...
  • Page 613 [0 to 100 / - / 0.01 %/step] 026 Latest Coverage: M *ENG 027 Latest Coverage: Y *ENG Displays the threshold of whether to perform developer churning or not. DevAgi. Theresh BF *ENG [0 to 100 / 20 / 1 %/step] ProCon SM Appendix 8-203 M065/M066...
  • Page 614 *ENG 009 Voffset TM (Center) *ENG [0 to 5.5 / 0 / 0.01 V/step] 010 Voffset TM (Rear) *ENG 3321 [Vsg Adjust: Exe.] Execute the ID sensor initialization setting 010 P/TM Sensor All for all sensors M065/M066 8-204 SM Appendix...
  • Page 615 *ENG 002 Ifsg: C *ENG 003 Ifsg: M *ENG 004 Ifsg: Y *ENG [0 to 50 / 0 / 0.1 mA/step] 005 Ifsg TM (Front) *ENG 006 Ifsg TM (Center) *ENG 007 Ifsg TM (Rear) *ENG SM Appendix 8-205 M065/M066...
  • Page 616 9: Unexpected error 005 Latest 4 *ENG 3: Offset voltage error 006 Latest 5 *ENG 2: Vsg adjustment value error 1: O.K 007 Latest 6 *ENG 008 Latest 7 *ENG 009 Latest 8 *ENG 010 Latest 9 *ENG M065/M066 8-206 SM Appendix...
  • Page 617 009 K5 Approximate Method *ENG 0:Linear, 1: Curve 010 K2: U/L Limit Coeff. 1 *ENG [0 to 1 / 0 / 0.01 /step] K2: Upper Limit *ENG [–0.2 to 0.4 / 0.03 / 0.01 /step] Correction SM Appendix 8-207 M065/M066...
  • Page 618 [0 to 2500 / 930 / 1 msec/step] Adjusts the processing timing for the pattern that is used for the line position 004 MUSIC Delay Time *ENG adjustment. [-2500 to 2500 / 300 / 1 msec/step] M065/M066 8-208 SM Appendix...
  • Page 619 *ENG [Toner Supply Rate: Display] 3411 Displays the current toner supply rate. 001 Latest: Bk *ENG 002 Latest: C *ENG [0 to 100 / - / 1 %/step] 003 Latest: M *ENG 004 Latest: Y *ENG SM Appendix 8-209 M065/M066...
  • Page 620 001 Maximum: Bk *ENG Adjusts the maximum time carried over 002 Maximum: C *ENG from a previous toner supply mode. 003 Maximum: M *ENG [0 to 10000 / 1000 / 1 msec/step] 004 Maximum: Y *ENG M065/M066 8-210 SM Appendix...
  • Page 621 005 MUSIC: BW *ENG [0 to 2000 / 0 / 1 page/step] 006 MUSIC: FC *ENG 007 Vsg Adj. *ENG 008 Charge AC Control *ENG 009 MUSIC: Power ON: BW *ENG 010 MUSIC: Power ON: FC *ENG SM Appendix 8-211 M065/M066...
  • Page 622 Correction Coeff. 1: Interrupt: *ENG [0 to 1 / 0.1 / 0.01/step] Correction Coeff. 2: Interrupt: *ENG [0 to 1 / 1 / 0.01/step] Correction Coeff. 1: Interrupt: *ENG [0 to 1 / 0.25 / 0.01/step] M065/M066 8-212 SM Appendix...
  • Page 623 [1 to 12 / 1 / 1/step] 003 Day *ENG [1 to 31 / 1 / 1/step] 004 Hour *ENG [0 to 23 / 0 / 1/step] 005 Minute *ENG [0 to 59 / 0 / 1/step] SM Appendix 8-213 M065/M066...
  • Page 624 001 Dev. Motor Rotation: Display: Bk *ENG 002 Dev. Motor Rotation: Display: C *ENG [0 to 1000 / 0 / 0.1 m/step] 003 Dev. Motor Rotation: Display: M *ENG 004 Dev. Motor Rotation: Display: Y *ENG M065/M066 8-214 SM Appendix...
  • Page 625 022 Pattern Number: Upper limit *ENG [0 to 255 / 16 / 1 time/step] [10 to 2550 / 130 / 10 023 Toner Consumption Pattern Area *ENG /step] 024 Supply Coefficient *ENG [0 to 2.55 / 0.8 / 0.01/step] SM Appendix 8-215 M065/M066...
  • Page 626 004 Toner End Recovery: Y *ENG 005 Vsg Adjustment *ENG 006 Developer Agitation *ENG 007 Process Control *ENG [0 to 2 / 0 / 1/step] 0: OFF. 1: ON (once), 2: ON (twice) 008 MUSIC *ENG M065/M066 8-216 SM Appendix...
  • Page 627 Adjusts the threshold temperature for entering the ITB idle rotation after the process control. 005 Temp. Range Thresh:T2 *ENG [20 or 30 / 25 / 1 deg/step] 006 Temp. Range Thresh:T1 *ENG [0 or 15 / 15 / 1 deg/step] SM Appendix 8-217 M065/M066...
  • Page 628 Absolute Humidity *ENG [0 to 99 / 6 / 1 g/m /step] Change Adjusts the maximum execution time for Maximum Execution *ENG the process control at stand-by. Number [0 to 99 / 10 / 1 time/step] M065/M066 8-218 SM Appendix...
  • Page 629 /kV /step] 012 Y (Standard Target Set) *ENG Turns on or off the environmental correction for target development 013 Environmental Correction *ENG gamma. [0 or 1 / 1 / - ] 0: Not Correct, 1: Correct SM Appendix 8-219 M065/M066...
  • Page 630 001 Standard Speed:Bk *ENG 002 Standard Speed:C *ENG 003 Standard Speed:M *ENG [0 to 800 / 550 / 1 -V/step] 004 Standard Speed:Y *ENG 005 Middle Speed:Bk *ENG 006 Middle Speed:C *ENG M065/M066 8-220 SM Appendix...
  • Page 631 006 Middle Speed:C *ENG [0 to 2000 / 690 / 1 -V/step] 007 Middle Speed:M *ENG 008 Middle Speed:Y *ENG 009 Low Speed:Bk *ENG 010 Low Speed:C *ENG 011 Low Speed:M *ENG 012 Low Speed:Y *ENG SM Appendix 8-221 M065/M066...
  • Page 632 006 Middle Speed:C *ENG [0 to 200 / 100 / 1 %/step] 007 Middle Speed:M *ENG 008 Middle Speed:Y *ENG 009 Low Speed:Bk *ENG 010 Low Speed:C *ENG 011 Low Speed:M *ENG 012 Low Speed:Y *ENG M065/M066 8-222 SM Appendix...
  • Page 633 [0 to 2.55 / 0 / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / 9 / 1 /step] 016 182 Adjustment: Vtcnt *ENG [0 to 5 / 4 / 0.01 V/step] SM Appendix 8-223 M065/M066...
  • Page 634 [0 to 2.55 / 0 / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / 9 / 1 /step] 016 182 Adjustment: Vtcnt *ENG [0 to 5 / 4 / 0.01 V/step] M065/M066 8-224 SM Appendix...
  • Page 635 [0 to 2.55 / 0 / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / 9 / 1 /step] 016 182 Adjustment: Vtcnt *ENG [0 to 5 / 4 / 0.01 V/step] SM Appendix 8-225 M065/M066...
  • Page 636 [0 to 2.55 / 0 / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / 9 / 1 /step] 016 182 Adjustment: Vtcnt *ENG [0 to 5 / 4 / 0.01 V/step] M065/M066 8-226 SM Appendix...
  • Page 637 [0 to 100000 / 100000 / 1 sheet /step] 011 PixCntThreshold 2 *ENG [0 to 1000000 / 120000 / 1 /step] Displays the date of the near full 014 Full Detection Date *ENG detection for the PCDU toner collection bottle. SM Appendix 8-227 M065/M066...
  • Page 638 [0 or 1 / 0 / - ] 007 Developer: M *ENG 0: OFF, 1: ON 008 Developer: Y *ENG 009 PCU: Bk *ENG [0 or 1 / 0 / - ] 0: OFF, 1: ON 010 PCU: C *ENG M065/M066 8-228 SM Appendix...
  • Page 639 3902-015: This is for the image transfer 016 Fusing Belt *ENG belt cleaning unit. 017 ITB Cleaning Unit *ENG 018 PTR Unit *ENG [0 or 1 / 0 / - ] 0: OFF, 1: ON 020 Waste Toner Bottle *ENG SM Appendix 8-229 M065/M066...

  • Page 640: Sp5-Xxx (Mode)

    001 Counter Method *CTL 0: Developments 1: Prints [Toner Refill Detection Display] 5051 Enables or disables the toner refill detection display. [0 or 1 / 0 / - ] Alphanumeric 001 - *CTL 0: ON 1: OFF M065/M066 8-230 SM Appendix...
  • Page 641 [0 to 2 / 1: NA, 2: EU / 1] 1.NA 2.EU ASIA *ENG 0: Japan, 1: NA, 2: EU Selects the paper size type (for originals and paper). After changing the value, turn the main power switch off and on. SM Appendix 8-231 M065/M066...
  • Page 642 This changes the feeding tray after the paper in the tray where the machine has been feeding paper has been run out of. This SP is activated only when a customer selects the "Auto Paper Selsct". M065/M066 8-232 SM Appendix...
  • Page 643 DOM: +540 (Tokyo) NA: -300 (New York) 5302 EU: + 60 (Paris) CH: +480 (Peking) TW: +480 (Taipei) AS: +480 (Hong Kong) KO: +540 (Korea) 002 Time Difference *CTL# [-1440 to 1440 / Area / 1 min./step ] SM Appendix 8-233 M065/M066...
  • Page 644 4th digit: The day of the week. [0 to 7 = Sunday to Saturday] 5th and 6th digits: The hour. [00 to 23] The 7th and 8 digits must be set to "00". The digits are counted from the left. Make sure that SP5-307-1 is set to "1". M065/M066 8-234 SM Appendix...
  • Page 645 SDK3 Certification *CTL Method SDK certification device *CTL Bit 0: SDK authentication 0: Off (Default), 1: On (SDK authentication enabled) Selects the SDK authentication setting. Bit 2: Administrator log in setting 0: Off (Default), 1: On SM Appendix 8-235 M065/M066...
  • Page 646 This SP is referenced only when SP5411-4 is set to "1" (On). Password Null Not *CTL [0 to 1 / 0 / 1] Permit 0: Password NULL not permitted. 1: Password NULL permitted. 006 Detail Option *CTL M065/M066 8-236 SM Appendix...
  • Page 647 ID and password after a lockout has 004 Cancellation Time *CTL occurred. This setting is used only if SP5413-3 is set to "1" (on). [1 to 9999 / 60 / 1 min.] SM Appendix 8-237 M065/M066...
  • Page 648 [0 to 100 / 30 / 1 attempt] Sets the time limit to stop a password attack once such an attack has been 002 Detect Time *CTL detected. [1 to 10 / 5 / 1 sec.] M065/M066 8-238 SM Appendix...
  • Page 649 [10 to 30 / 10 / 1 sec.] Sets the wait time to slow down the speed of certification when an excessive 003 Productivity Fall Wait *CTL number of access attempts have been detected. [0 to 9 / 3 / 1 sec.] SM Appendix 8-239 M065/M066...
  • Page 650 These SP codes determine how the authentication failures are displayed. Determines whether an error code appears in the system log after a user 001 System Log Disp *CTL authentication failure occurs. [0 to 1 / 0 / 1] 0: Off, 1: On M065/M066 8-240 SM Appendix...
  • Page 651 "1" when an SC is not detected during a set number of copied sheets (for example, default 1500 sheets). The error alarm occurs when the SC error alarm counter reaches "5". 001 - *CTL [0 to 255 / 20 / 100 copies /step] SM Appendix 8-241 M065/M066...
  • Page 652 0: At replacement 1: At near end 128 Interval :Others 133 Interval :A4 134 Interval :A5 142 Interval :B5 [250 to 10000 / 1000 / 1 /step] 164 Interval :LG 166 Interval :LT 172 Interval :HLT M065/M066 8-242 SM Appendix...
  • Page 653 0: Off, 1: On 011 Supply Manegement Report Call 012 Jam/Door Open Call Memory Clear (SP5-801) The following tables list the items that are cleared. The serial number information, meter charge setting and meter charge counters are not cleared. SM Appendix 8-243 M065/M066...
  • Page 654 (NCS: Network Control Service) Initializes the DCS (Delivery Control Service) 014 Clear DCS Setting settings. Initializes the UCS (User Information Control 015 Clear UCS Setting Service) settings. Initializes the MIRS (Machine Information Report 016 MIRS Setting Service) settings. M065/M066 8-244 SM Appendix...
  • Page 655 [0 to 65535 / 0 / 1 time/step ] 003 RET. *ENG 004 EXE.ALL *ENG 005 EXE.K *ENG 006 EXE.M *ENG [0 to 1 / 0 / 1 /step ] 007 EXE.C *ENG 008 EXE.Y *ENG SM Appendix 8-245 M065/M066...
  • Page 656 Facsimile *CTL Sets the fax or telephone number for a service representative. This number is printed on the Counter List. This can be up to 20 characters (both numbers and alphabetic characters can be input). M065/M066 8-246 SM Appendix...
  • Page 657 SSL Disable Uses or does not use the RCG certification by SSL when calling the RCG. [0 to 1 / 0 / 1 /step] 0: Uses the RCG certification 1: Does no use the RCG certification SM Appendix 8-247 M065/M066...
  • Page 658 This SP displays the Embedded RC Gate installation end flag. 0: Installation not completed 1: Installation completed Install Status This SP displays the Embedded RC Gate installation status. 0: RCG device not registered 1: RCG device registered 2: Device registered M065/M066 8-248 SM Appendix...
  • Page 659 This SP sets the port number of the proxy server used for communication between Embedded RC Gate-N and the gateway. This setting is necessary to set up Embedded RC Gate-N. This port number is customer information and is not printed in the SMC report. SM Appendix 8-249 M065/M066...
  • Page 660 GW connection. The rescue certification setting is completed and the GW URL is being notified of the certification update request. The notification of the request for certification update has completed M065/M066 8-250 SM Appendix...
  • Page 661 An SSL error notification has been issued. Issued after the certification has expired. Notification of shift from a common authentication to an individual certification. Notification of a common certification without ID2. Notification that no certification was issued. Notification that GW URL does not exist. SM Appendix 8-251 M065/M066...
  • Page 662 [NV-RAM Download] Downloads the UP and SP mode data from an SD card to the NVRAM. For 5825 details, see the "NVRAM Data Upload/Download" in the "System Maintenance Reference" of the Field Service Manual. 001 - M065/M066 8-252 SM Appendix...
  • Page 663 1: OFF (Automatically printed) Validates or invalidates the job spooling function for each protocol. 0: Validates 1: Invalidates bit0: LPR Job Spooling bit1: FTP (Protocol) bit2: IPP bit3: SMB bit4: BMLinkS bit5: DIPRINT bit6: sftp bit7: (Reserved) SM Appendix 8-253 M065/M066...
  • Page 664 Ethernet or wireless LAN (802.11b) in the format: 156 IPv6 Manual Address "Manual Set Address" + "Prefix Length" The IPv6 address consists of a total 128 bits configured in 8 blocks of 16 bits each. M065/M066 8-254 SM Appendix...
  • Page 665 236 Web Item visible bit0: Net RICOH bit1: Consumable Supplier bit2-15: Reserved (all) Displays or does not display the link to Net RICOH Web shopping link on the top page and link page of the web system. visible [0 to 1 / 1 / 1]...
  • Page 666 Adjust the upper 4 bits to set the maximum number of channels. EU: [1 to 13 / 13 / 1/step] NA: [1 to 11 / 11 / 1/step] AS: [1 to 14 / 14 / 1/step] M065/M066 8-256 SM Appendix...
  • Page 667 0 x 09 - 22M (reserved) Selects the WEP key. [00 to 11 / 00 / 1 binary] 00: Key #1 5840 011 WEP Key Select *CTL 01: Key #2 (Reserved) 10: Key #3 (Reserved) 11: Key #4 (Reserved) SM Appendix 8-257 M065/M066...
  • Page 668 Netfiles: Jobs to be printed from the 001 Setting 1 *CTL document server using a PC and the DeskTopBinder software Adjusts the debug program modesetting. Bit7: 5682 mmseg-log setting 002 Setting 2 *CTL 0: Date/Hour/Minute/Second 1: Minute/Second/Msec. 0 to 6: Not used M065/M066 8-258 SM Appendix...
  • Page 669 007 PnP Serial Number *CTL Displays the PnP Serial Number. Displays a message of the unspported USB device for the USB host slot. 100 Notify Unsupport *CTL [0 or 1 / 1 / -] 0: Not displayed, 1: Displayed SM Appendix 8-259 M065/M066...
  • Page 670 Procedure 1. Turn the machine off. 2. Install a new HDD. 3. Turn the machine on. 4. The address book and its initial data are created on the HDD automatically. M065/M066 8-260 SM Appendix...
  • Page 671 This feature does not work if the card is 053 Clear Backup Info write-protected. After you do this SP, go out of the SP mode, and then turn the power off. Do not remove the SD card until the Power LED stops flashing. SM Appendix 8-261 M065/M066...
  • Page 672 063 Complexity Option 2 DFU 064 Complexity Option 3 DFU 065 Complexity Option 4 DFU Shows the status of the encryption function 094 Encryption Stat for the address book data. M065/M066 8-262 SM Appendix...
  • Page 673 Access Ctrl: uadministration (Lower 4bits) 210 Setting: LogType: Job1 211 Setting: LogType: Job2 212 Setting: LogType: Access 213 Setting: Primary Srv 214 Setting: Secondary Srv 215 Setting: Start Time 216 Setting: Interval Time 217 Setting: Timing SM Appendix 8-263 M065/M066...
  • Page 674 [Remote ROM Update] 5856 Allows the technician to upgrade the firmware using a local port (IEEE1284) when updating the remote ROM. [0 to 1 / 0 / 1/step] 002 Local Port *CTL 0: Disable 1: Enable M065/M066 8-264 SM Appendix...
  • Page 675 012 Erase SD Card Debug Data 013 Free Space on SD Card 014 Copy SD to SD (Latest 4 MB) 015 Copy SD to SD (Latest 4 MB Any Key) 016 Make HDD Debug 017 Make SD Debug SM Appendix 8-265 M065/M066...
  • Page 676 These SPs allow you to set up to 10 keys for log 004 Key 4 files for functions that use common memory on the controller board. 005 Key 5 [–9999999 to 9999999 / 0 / – ] 006 Key 6 007 Key 7 008 Key 8 M065/M066 8-266 SM Appendix...
  • Page 677 SMTP. Communication stops if this time is exceeded. Selects the protocol for the mail reception. [0 to 3 / 1 / 1] 009 Mail Receive Protocol 0: No reception 1: POP3 2: IMAP4 3: SMTP SM Appendix 8-267 M065/M066...
  • Page 678 The received mail is discarded if the remaining portion of the mail is not received during this prescribed time. 021 MDN Response RFC2298 Compliance [0 to 1 / 1 / – ] Determines whether RFC2298 compliance is switched on for MDN reply mail. 0: No 1: Yes M065/M066 8-268 SM Appendix...
  • Page 679 0: Enable, 1: Disable Adds or does not add the date field to the header of the alert mail. 005 Add Date Field *CTL [0 or 1 / 0 / – ] 0: Not added, 1: Added SM Appendix 8-269 M065/M066...
  • Page 680 This SP copies back the application programs from an SD card in SD Card Slot 2 to the original SD card in SD card slot 002 Undo Exec 1. Use this menu when you have mistakenly copied some programs by using "Move Exec" (SP5873-1). M065/M066 8-270 SM Appendix...
  • Page 681 (*.txt) prefixed with the 001 - *CTL number of the machine. Insert the SD card in SD card Slot 2 (lower slot). Select SP5887 then touch [EXECUTE]. Touch [Execute] in the message when you are prompted. SM Appendix 8-271 M065/M066...
  • Page 682 [Plug & Play Maker/Model Name] Selects the brand name and the production name for Windows Plug & Play. This information is stored in the NVRAM. If the NVRAM is defective, these names should be registered again. After selecting, press OK. M065/M066 8-272 SM Appendix...
  • Page 683 Displays or does not display the end display for the ITB unit. This SP is activated only when the 014 ITB Unit *ENG SP5930-001 is set to "1". [0 or 1 / 1 / -] 0: OFF, 1: ON SM Appendix 8-273 M065/M066...
  • Page 684 If it is detected, SC610 occurs. [SP print mode] 5990 Prints out the SMC sheets. 001 All (Data List) 002 SP (Mode Data List) 004 Logging Data 005 Diagnostic Report 006 Non-Default 024 SDK/J Summary 025 SDK/J Appli.Info M065/M066 8-274 SM Appendix...

  • Page 685: Sp7-Xxx (Data Log)

    SMC (logging) outputs. 001 Latest 002 Latest 1 003 Latest 2 004 Latest 3 005 Latest 4 *CTL 006 Latest 5 007 Latest 6 008 Latest 7 009 Latest 8 010 Latest 9 SM Appendix 8-275 M065/M066...
  • Page 686 007 Latest 6 008 Latest 7 009 Latest 8 010 Latest 9 [Total Paper Jam Counter] 7502 Displays the total number of jams detected. 001 - * CTL [0 to 9999 / 0 / 1 sheet/step ] M065/M066 8-276 SM Appendix...
  • Page 687 *CTL 014 Vertical Transport 4: ON *CTL 017 Registration: ON *CTL 018 Fusing Entrance: ON *CTL 019 Fusing Exit: ON *CTL 020 Paper Exit: ON *CTL 025 Duplex Exit: ON *CTL 027 Duplex Entrance: ON *CTL SM Appendix 8-277 M065/M066...
  • Page 688 "p.6-1 "Jam Detection"" 053 Bank SEF Sensor 2 *CTL 054 Bank SEF Sensor 3 *CTL 057 Regist Sensor *CTL 060 Exit Sensor *CTL 065 Duplex Exit Sensor *CTL 067 Duplex Entrance Sensor *CTL 068 Inverter Sensor *CTL M065/M066 8-278 SM Appendix...
  • Page 689 Displays the 10 most recently detected paper jams. 001 Latest 002 Latest 1 003 Latest 2 004 Latest 3 005 Latest 4 *CTL 006 Latest 5 007 Latest 6 008 Latest 7 009 Latest 8 010 Latest 9 SM Appendix 8-279 M065/M066...
  • Page 690 004 Page: PCU: M 005 Page: PCU: Y 006 Page: Development Unit: Bk 007 Page: Development Unit: C 008 Page: Development Unit: M 009 Page: Development Unit: Y 014 Page: ITB Unit 015 Page: ITB Cleaning Unit M065/M066 8-280 SM Appendix...
  • Page 691 034 Rotation: PCU: Y 035 Rotation: Development Unit: Bk 036 Rotation: Development Unit: C 037 Rotation: Development Unit: M 038 Rotation: Development Unit: Y 043 Rotation:ITB Unit 044 Rotation: ITB Cleaning Unit 045 Rotation: Fusing Unit SM Appendix 8-281 M065/M066...
  • Page 692 065 Rotation (%): Development Unit: Bk 066 Rotation (%): Development Unit: C 067 Rotation (%): Development Unit:M 068 Rotation (%): Development Unit: Y 073 Rotation (%): ITB Unit 074 Rotation (%): ITB Cleaning Unit 075 Rotation (%): Fusing Unit M065/M066 8-282 SM Appendix...
  • Page 693 103 Page (%): ITB Unit 104 Page (%): ITB Cleaning Unit 105 Page (%): Fusing Unit *ENG [0 to 255 / - / 1 %/step] 106 Page (%): Fusing Roller 107 Page (%): Fusing Belt 108 Page (%): PTR Unit SM Appendix 8-283 M065/M066...
  • Page 694 007 Development Unit: Bk 008 Development Unit: C 009 Development Unit: M 010 Development Unit: Y 011 Development Unit: All 017 ITB Unit 018 ITB Cleaning Unit 019 Fusing Unit 020 Fusing Roller 021 Fusing Belt 022 PTR Unit M065/M066 8-284 SM Appendix...
  • Page 695 Displays the memory capacity of the controller system. 001 - *CTL [Replacement Counter] 7853 Displays the PM parts replacement number. 001 PCU: Bk 002 PCU: C 003 PCU: M 004 PCU: Y 005 Development Unit: Bk 006 Development Unit: C SM Appendix 8-285 M065/M066...
  • Page 696 SPs. Color1 counter: SP8601-021 Color2 counter: SP8601-022 Color3 counter: SP8601-023 001 Coverage Range 1 *CTL [1 to 200 / 5 /1] 002 Coverage Range 2 *CTL [1 to 200 / 20 /1] M065/M066 8-286 SM Appendix...
  • Page 697 Displays the number of sheets printed with the previous maintenance units. -019 [0 to 9999999 / 0 / 1 page/step ] 001 Page: PCU: Bk 002 Page: PCU: C 003 Page: PCU: M 004 Page: PCU: Y 005 Page: Development Unit: Bk SM Appendix 8-287 M065/M066...
  • Page 698 033 Rotation: PCU: M 034 Rotation: PCU: Y 035 Rotation: Development Unit: Bk 036 Rotation: Development Unit: C 037 Rotation: Development Unit: M 038 Rotation: Development Unit: Y 043 Rotation: ITB Unit 044 Rotation: ITB Cleaning Unit M065/M066 8-288 SM Appendix...
  • Page 699 068 Rotation %: Development Unit: Y 073 Rotation %: ITB Unit 074 Rotation %: ITB Cleaning Unit 075 Rotation %: Fusing Unit 076 Rotation %: Fusing Roller 077 Rotation %: Fusing Belt 078 Rotation %: PTR Unit SM Appendix 8-289 M065/M066...
  • Page 700 098 Page (%): Development Unit: Y 103 Page (%): ITB Unit 104 Page (%): ITB Cleaning Unit 105 Page (%): Fusing Unit 106 Page (%): Fusing Roller 107 Page (%): Fusing Belt 108 Page (%): PTR Unit M065/M066 8-290 SM Appendix...
  • Page 701 014 End History *ENG 015 Refill Information *ENG 016 Attachment: Total Counter *ENG 017 Attachment: Color Counter *ENG 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG 021 End Date *ENG SM Appendix 8-291 M065/M066...
  • Page 702 014 End History *ENG 015 Refill Information *ENG 016 Attachment: Total Counter *ENG 017 Attachment: Color Counter *ENG 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG 021 End Date *ENG M065/M066 8-292 SM Appendix...
  • Page 703 014 End History *ENG 015 Refill Information *ENG 016 Attachment: Total Counter *ENG 017 Attachment: Color Counter *ENG 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG 021 End Date *ENG SM Appendix 8-293 M065/M066...
  • Page 704 014 End History *ENG 015 Refill Information *ENG 016 Attachment: Total Counter *ENG 017 Attachment: Color Counter *ENG 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG 021 End Date *ENG M065/M066 8-294 SM Appendix...
  • Page 705 *ENG information log 4 for Bk. 015 Attachment: Total Counter 016 Refill Information 017 Serial No. 018 Attachment Date Displays the toner bottle *ENG information log 5 for Bk. 019 Attachment: Total Counter 020 Refill Information SM Appendix 8-295 M065/M066...
  • Page 706 *ENG information log 4 for M. 015 Attachment: Total Counter 016 Refill Information 017 Serial No. 018 Attachment Date Displays the toner bottle *ENG information log 5 for M. 019 Attachment: Total Counter 020 Refill Information M065/M066 8-296 SM Appendix...
  • Page 707 *ENG information log 4 for C. 015 Attachment: Total Counter 016 Refill Information 017 Serial No. 018 Attachment Date Displays the toner bottle *ENG information log 5 for C. 019 Attachment: Total Counter 020 Refill Information SM Appendix 8-297 M065/M066...
  • Page 708 *ENG information log 4 for Y. 015 Attachment: Total Counter 016 Refill Information 017 Serial No. 018 Attachment Date Displays the toner bottle *ENG information log 5 for Y. 019 Attachment: Total Counter 020 Refill Information M065/M066 8-298 SM Appendix...
  • Page 709 006 Fusing Belt *ENG 013 PCU: Bk *ENG 014 PCU: C *ENG 015 PCU: M *ENG 016 PCU: Y *ENG 017 Development Unit:Bk *ENG 018 Development Unit:C *ENG 019 Development Unit:M *ENG 020 Development Unit:Y *ENG SM Appendix 8-299 M065/M066...
  • Page 710 016 Page: Fusing Roller 017 Page: Fusing Belt 018 Page: PTR Unit 031 Rotation: PCU: Bk 032 Rotation: PCU: C 033 Rotation: PCU: M 034 Rotation: PCU: Y 035 Rotation: Development Unit: Bk 036 Rotation: Development Unit: C M065/M066 8-300 SM Appendix...
  • Page 711 [0 to 999999999 / 300000 / 1000 007 Amount:T-Collect Bottle *ENG mg/step] 011 Page: ITB Unit *ENG [0 to 999999 / 100000 / 1000 sheet/step] 013 Page: Fusing Unit *ENG [0 to 999999 / 120000 / 1 sheet/step] SM Appendix 8-301 M065/M066...
  • Page 712 Day Threshold: Fusing *ENG Roller Day Threshold: Fusing *ENG Belt 038 Rotation: PCU: Bk *ENG *ENG 039 Rotation: PCU: C [0 to 999999999 / 0 / 1 mm/step] 040 Rotation: PCU: M *ENG *ENG 041 Rotation: PCU: Y M065/M066 8-302 SM Appendix...
  • Page 713 002 0<T<=5:0<=H<30 003 0<T<=5:30<=H<70 004 T<=5: 70<=H<=100 005 5<T<15: 0<=H<30 006 5<T<15: 30<=H<55 *ENG [0 to 99999999 / - / 1 mm/step] 007 5<T<15: 55<=H<80 008 5<T<15: 80<=H<=100 009 15<=T<25: 0<=H<30 010 15<=T<25: 30<=H<55 011 15<=T<25: 55<=H<80 SM Appendix 8-303 M065/M066...
  • Page 714 013 25<=T<30: 0<=H<30 014 25<=T<30: 30<=H<55 015 25<=T<30: 55<=H<80 016 25<=T<30: 80<=H<=100 017 30<=T: 0<=H<30 018 30<=T: 30<=H<55 019 30<=T: 55<=H<80 020 30<=T: 80<=H<=100 [Operation Env. Log Clear] 7954 Clears the operation environment log. 001 - M065/M066 8-304 SM Appendix...

  • Page 715: Sp8-Xxx: Data Log

    Most of the SPs in this group are prefixed with a letter that indicates the mode of operation (the mode of operation is referred to as an "application"). Before reading the Group 8 Service Table, make sure that you understand what these prefixes mean. SM Appendix 8-305 M065/M066...
  • Page 716 LCDs of printers and faxes that also use these SPs. Read over the list of abbreviations below and refer to it again if you see the name of an SP that you do not understand. M065/M066 8-306 SM Appendix...
  • Page 717 Print) used to store the job on the document server, for example. Dev Counter Development Count, no. of pages developed. Dup, Duplex Duplex, printing on both sides Emul Emulation Full Color Post-print processing, i.e. finishing (punching, stapling, etc.) Full Bleed No Margins GenCopy Generation Copy Mode SM Appendix 8-307 M065/M066...
  • Page 718 Pages. A page is the total scanned surface of the original. Duplex pages count as two pages, and A3 simplex count as two pages if the A3/DLT counter SP is switched ON. PJob Print Jobs Paper M065/M066 8-308 SM Appendix...
  • Page 719 SMC report. Server TonEnd Toner End TonSave Toner Save TXJob Send, Transmission Yellow, Magenta, Cyan YMCK Yellow, Magenta, Cyan, Black All of the Group 8 SPs are reset with SP5 801 1 Memory All Clear. SM Appendix 8-309 M065/M066...
  • Page 720 When an image received from Palm 2 is received and stored, the L: counter increments. When the customer prints a report (user code list, for example), the O: counter increments. However, for fax reports and reports executed from the fax application, the F: counter increments. M065/M066 8-310 SM Appendix...
  • Page 721 8 06x 9 Three-IN-Fold Not used 8 06x 10 Three-OUT-Fold Not used 8 06x 11 Four-Fold Not used 8 06x 12 KANNON-Fold Not used 8 06x 13 Perfect-Bind Not used 8 06x 14 Ring-Bind Not used SM Appendix 8-311 M065/M066...
  • Page 722 8 07x 5 5 Pages 8 07x 12 501 to 700 Pages 8 07x 6 6 to 10 Pages 8 07x 13 701 to 1000 Pages 8 07x 7 11 to 20 Pages 8 07x 14 1001 to Pages M065/M066 8-312 SM Appendix...
  • Page 723 - All reports done in the service mode (service summaries, engine maintenance reports, etc.) - Test prints for machine image adjustment. - Error notification reports. - Partially printed pages as the result of a copier jam. SM Appendix 8-313 M065/M066...
  • Page 724 2 pages on 1 side (2-Up) 8 42x 7 4> 4 pages on 1 side (4-Up) 8 42x 8 6> 6 pages on 1 side (6-Up) 8 42x 9 8> 8 pages on 1 side (8-Up) M065/M066 8-314 SM Appendix...
  • Page 725 Pages that are only partially printed with the n-Up functions are counted as 1 page. Here is a summary of how the counters work for Booklet and Magazine modes: Booklet Magazine Original Pages Count Original Pages Count SM Appendix 8-315 M065/M066...
  • Page 726 O:PrtPGS/Ppr Size *CTL [0 to 9999999/ 0 / 1] 8 447 These SPs count by print paper size the number of pages printed by Other applications. 8 44x 1 A3 8 44x 2 A4 M065/M066 8-316 SM Appendix...
  • Page 727 8 44x 7 LG 8 44x 8 LT 8 44x 9 HLT 8 44x 10 Full Bleed 8 44x 254 Other (Standard) 8 44x 255 Other (Custom) These counters do not distinguish between LEF and SEF. SM Appendix 8-317 M065/M066...
  • Page 728 Not used 8 451 12 Tray 11 Not used 8 451 13 Tray 12 Not used 8 451 14 Tray 13 Not used 8 451 15 Tray 14 Not used 8 451 16 Tray 15 Not used M065/M066 8-318 SM Appendix...
  • Page 729 These SPs count by paper type the number pages printed by the printer application. 8 46x 1 Normal 8 46x 2 Recycled 8 46x 3 Special 8 46x 4 Thick 8 46x 5 Normal (Back) 8 46x 6 Thick (Back) 8 46x 7 OHP 8 46x 8 Other SM Appendix 8-319 M065/M066...
  • Page 730 These SPs count the number of pages printed with the Toner Save feature switched on. Note: These SPs return the same results as this SP is limited to the Print application. [0 to 9999999/ 0 / 1] M065/M066 8-320 SM Appendix...
  • Page 731 These SPs count by printer emulation mode the total number of pages printed. 8 514 1 RPCS 8 514 2 RPDL 8 514 3 8 514 4 8 514 5 8 514 6 GL/GL2 8 514 7 8 514 8 RTIFF SM Appendix 8-321 M065/M066...
  • Page 732 8 524 Not used 8 52x 1 Sort 8 52x 2 Stack 8 52x 3 Staple 8 52x 4 Booklet 8 52x 5 Z-Fold 8 52x 6 Punch 8 52x 7 Other 8 52x 8 Inside-Fold M065/M066 8-322 SM Appendix...
  • Page 733 8 531 Staples *CTL Not used 8 551 T:FIN Books *CTL Not used 8 551 1 Perfect-Bind 8 551 2 Ring-Bind 8 554 T:FIN Books *CTL Not used 8 554 1 Perfect-Bind 8 554 2 Ring-Bind SM Appendix 8-323 M065/M066...
  • Page 734 8 581 17 Twin Color Mode Print 8 581 18 Full Color Print (Twin) 8 581 19 Mono Color Print (Twin) 8 581 20 Full Color Total (CV) 8 581 21 Mono Color Total (CV) 8 581 22 Full Color Print (CV) M065/M066 8-324 SM Appendix...
  • Page 735 8 601 1 B/W 8 601 2 Color 8 601 11 B/W Printing Pages 8 601 12 Color Printing Pages 8 601 21 Coverage Counter 1 8 601 22 Coverage Counter 2 8 601 23 Coverage Counter 3 SM Appendix 8-325 M065/M066...
  • Page 736 These SPs count the frequency of use (number of rotations of the development rollers) for black and other color toners. 8 771 1 Total 8 771 2 K 8 771 3 Y 8 771 4 M 8 771 5 C M065/M066 8-326 SM Appendix...
  • Page 737 Note: This precise method of measuring remaining toner supply (1% steps) is better than other machines in the market that can only measure in increments of 10 (10% steps). 8 801 1 K 8 801 2 Y 8 801 3 M 8 801 4 C SM Appendix 8-327 M065/M066...
  • Page 738 These SPs display the number of scanned sheets on which the coverage of each color is from 11% to 20%. 8 861 1 BK 8 861 2 Y 8 861 3 M 8 861 4 C M065/M066 8-328 SM Appendix...
  • Page 739 [0 to 9999999/ 0 / 1] 8 891 These SPs display the amount of the remaining current toner for each color. 8 891 1 BK 8 891 2 Y 8 891 3 M 8 891 4 C SM Appendix 8-329 M065/M066...
  • Page 740 8 921 2 Coverage (%): Y 8 921 3 Coverage (%): M 8 921 4 Coverage (%): C 8 921 11 Coverage/P: BK 8 921 12 Coverage/P: Y 8 921 13 Coverage/P: M 8 921 14 Coverage/P: C M065/M066 8-330 SM Appendix...
  • Page 741 Total time when SC errors have been staying. Total time when paper jams have been staying 8 941 7 PrtJam during printing. 8 941 9 Supply PM Unit End Total time when toner end has been staying SM Appendix 8-331 M065/M066...
  • Page 742 8 999 9 Printer Two Color 8 999 13 Duplex 8 999 14 Coverage: Color (%) 8 999 15 Coverage: BW (%) 8 999 16 Coverage: Color Print Page (%) 8 999 17 Coverage: BW Print Page (%) M065/M066 8-332 SM Appendix...

  • Page 743: Input Check Table

    5803 11 Fusing Entrance Sensor Paper detected Paper not detected 5803 13 Duplex Entrance Sensor Paper detected Paper not detected 5803 14 Duplex Exit Sensor Paper detected Paper not detected 5803 15 Registration Sensor Paper detected Paper not detected SM Appendix 8-333 M065/M066...
  • Page 744 Normal Lock 5803 46 Laser Unit Fan: Lock Normal Lock 5803 47 Feed Fan: Lock Normal Lock 5803 48 Transfer Belt Contact Sensor Not contact Contact Paper Transfer Roller Contact 5803 49 Not contact Contact Sensor M065/M066 8-334 SM Appendix...
  • Page 745 5803 74 Inverter Sensor Inverter gate open Inverter gate close 5803 75 Fusing Cooling Fan: Lock Normal Lock 5803 76 Toner Supply Fan: Lock Normal Lock 5803 77 Bank Feed Sensor 1 Paper detected Paper not detected SM Appendix 8-335 M065/M066...
  • Page 746 5803 80 Bank Vertical Feed Sensor 1 Paper detected Paper not detected 5803 81 Bank Vertical Feed Sensor 2 Paper detected Paper not detected 5803 82 Bank Vertical Feed Sensor 3 Paper detected Paper not detected 5803 94 LD OFF Check:Factory M065/M066 8-336 SM Appendix...

  • Page 747: Table 1: Paper Size Switch (Tray)

    *1: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP 5-131-001. *2: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of SP 5-131-001. SM Appendix 8-337 M065/M066...

  • Page 748: Table 2: Paper Height Sensor

    System Service Mode Table 2: Paper Height Sensor 0: Deactivated, 1: Activated (actuator inside sensor) Remaining paper Paper height sensor 1 Paper height sensor 2 Full ~ 350 350 ~ 150 150 ~ 50 50 ~ 0 M065/M066 8-338 SM Appendix...

  • Page 749: Output Check Table

    5804 26 Drum Motor: CMY: 85mm/s 5804 31 Feed Motor: 364mm/s 5804 32 Feed Motor: 260mm/s 5804 33 Feed Motor: 182mm/s 5804 34 Feed Motor: 85mm/s 5804 39 Registration Motor: 260mm/s 5804 40 Registration Motor: 182mm/s 5804 41 Registration Motor: 85mm/s SM Appendix 8-339 M065/M066...
  • Page 750 5804 77 Vertical Feed Motor: 364mm/s 5804 78 Vertical Feed Motor: 260mm/s 5804 79 Vertical Feed Motor: 182mm/s 5804 80 Vertical Feed Motor: 85mm/s 5804 83 Transfer Belt Contact Motor: CW 5804 84 Transfer Belt Contact Motor: CCW M065/M066 8-340 SM Appendix...
  • Page 751 5804 103 Fusing Fan 1: L 5804 104 Polygon Motor: Standard Speed 5804 105 Polygon Motor: Middle Speed 5804 106 Polygon Motor: Low Speed 5804 107 Fusing Fan 2: H 5804 108 Fusing Fan 2: L 5804 112 Drive Unit Fan SM Appendix 8-341 M065/M066...
  • Page 752 5804 132 PP: Charge DC: C 5804 133 PP: Charge DC: K 5804 134 PP: Development: Y 5804 135 PP: Development: M 5804 136 PP: Development: C 5804 137 PP: Development: K 5804 138 PP: D M065/M066 8-342 SM Appendix...
  • Page 753 5804 168 PP: Charge AC: K: 260mm/s 5804 169 PP: Charge AC: K: 182mm/s 5804 170 PP: Charge AC: K: 85mm/s 5804 181 HST Sensor: Y 5804 182 HST Sensor: M 5804 183 HST Sensor: C SM Appendix 8-343 M065/M066...
  • Page 754 5804 197 RFID COM ON: C 5804 198 RFID COM ON: M 5804 199 RFID COM ON: Y 5804 216 LD1: K 5804 217 LD2: K 5804 218 LD1: C 5804 219 LD2: C 5804 220 LD1: M M065/M066 8-344 SM Appendix...
  • Page 755 5804 239 Bank Feed Clutch 1 5804 240 Bank Feed Clutch 2 5804 241 Bank Feed Clutch 3 5804 242 Bank Pick-up Solenoid 1 5804 243 Bank Pick-up Solenoid 2 5804 244 Bank Pick-up Solenoid 3 SM Appendix 8-345 M065/M066...

  • Page 756: Test Pattern Printing

    Press the "OK" key to start the test print. 10. Check the test pattern. 11. Enter SP Mode, and then reset all settings to the default values. Turnning off the power can reset all settings to the default values. 12. Exit SP mode. M065/M066 8-346 SM Appendix...
  • Page 757 Band (Vertical) Grid Horizontal Line Band (Horizontal) Grid Pattern Small Checkered Flag Pattern Grid Pattern Large Grayscale (Vertical Margin) Argyle Patter Small Grayscale (Horizontal Margin) Argyle Patter Large Two Beam Independent Pattern (1dot) Full Dot Pattern SM Appendix 8-347 M065/M066...

  • Page 758: Printer Service Mode

    Enable: Print jobs will be saved to an SD Card in the GW SD slot. bit 5 bit 6 bit 7 0: Disable 1: Enable [RPCS,PCL]: Printable area frame border Prints all RPCS and PCL jobs with a border around the printable area. M065/M066 8-348 SM Appendix...
  • Page 759 Disable: The machine ability to change the PDL processor mid-job. Some host systems submit jobs that contain both PS and PCL5e/c. If Auto PDL switching is disabled, these jobs will not be printed properly. bit 4 bit 5 bit 6 bit 7 SM Appendix 8-349 M065/M066...
  • Page 760 HP4000/HP8000. In other words, the left margin defined in the job (usually "<ESC>*r0A") will be changed to "<ESC>*r1A" bit 3 bit 4 bit 5 bit 6 bit 7 1001 Bit Switch 004 Bit Switch 4 DFU M065/M066 8-350 SM Appendix...
  • Page 761 1: Pattern1 Change the number of PS criterion used by the PS interpreter to determine whether a job is PS data or not. Pattern3: includes most PS commands. Pattern1: A small number of PS tags and headers SM Appendix 8-351 M065/M066...
  • Page 762 If this is disabled, simplex pages or the last page of an odd-paged duplex job are not routed through the duplex unit. This could result in problems with letterhead/pre-printed pages. Only affects pages specified as Letterhead paper. 1001 Bit Switch 006 Bit Switch 6 DFU M065/M066 8-352 SM Appendix...
  • Page 763 3 code) BW jobs submitted without a user code will be printed even if user code authentication is enabled. Note: Color jobs will not be printed without a valid user code. bit 4 to 7 SM Appendix 8-353 M065/M066...
  • Page 764 1003 003 Delete Program 1004 [Print Summary] Prints the service summary sheet (a 1004 001 Service Summary summary of all the controller settings). 1005 [Display Version] Displays the version of the controller 1005 001 Printer Version firmware. M065/M066 8-354 SM Appendix...
  • Page 765 1101 3 Tone (Current) [ToneCtlSet] Sets the printing mode (resolution) for the printer gamma adjustment. The asterisk (*) shows which mode is set. 00: *1200x1200Photo 1102 01: 600x600Text 02: 1200x1200Text 03: 1200x600Text 04: 600x600Photo 05: 1200x600Photo SM Appendix 8-355 M065/M066...
  • Page 766 1104 043 Set Magenta 3 1104 063 Set Yellow 3 1104 004 Set Black 4 1104 024 Set Cyan 4 [0 to 255 / 64 / 1/step] 1104 044 Set Magenta 4 1104 064 Set Yellow 4 M065/M066 8-356 SM Appendix...
  • Page 767 Set Cyan 9 [0 to 255 / 144 / 1/step] 1104 049 Set Magenta 9 1104 069 Set Yellow 9 1104 010 Set Black 10 [0 to 255 / 160 / 1/step] 1104 030 Set Cyan 10 SM Appendix 8-357 M065/M066...
  • Page 768 1104 054 Set Magenta 14 1104 074 Set Yellow 14 1104 015 Set Black 15 1104 035 Set Cyan 15 [0 to 255 / 240 / 1/step] 1104 055 Set Magenta 15 1104 075 Set Yellow 15 M065/M066 8-358 SM Appendix...
  • Page 769 [0 to 100 / 100% / 1/step] 1109 002 Image 0 to 100 / 50% / 1/step] 1109 003 Line 0 to 100 / 30% / 1/step] 1109 004 Paint 0 to 100 / 30% / 1/step] SM Appendix 8-359 M065/M066...

  • Page 770: Paper Feed Unit Pb

    M384 PAPER FEED UNIT PB 1020 PB1020T* *HC (HEALTHCARE MODEL) R E V I S I O N H I S T O RY P a ge D a t e A d de d /U pd at e d /N ew None...
  • Page 772 M384 (PAPER FEED UNIT PB 1020) TABLE OF CONTENTS REPLACEMENT AND ADJUSTMENT ..........1     EXTERNAL COVERS ................... 1     1.1.1 LEFT COVER ..................1     1.1.2 RIGHT COVER ..................1     PICK-UP, PAPER FEED AND SEPARATION ROLLERS ......2  ...
  • Page 774 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...

  • Page 776: Replacement And Adjustment

    External Covers 1. REPLACEMENT AND ADJUSTMENT 1.1 EXTERNAL COVERS Turn off the main power switch and unplug the machine before attempting any procedure in this section. 1.1.1 LEFT COVER Left cover [A] ( x2). 1.1.2 RIGHT COVER Right cover [A] ( x2).

  • Page 777: Pick-Up, Paper Feed And Separation Rollers

    Pick-up, Paper Feed and Separation Rollers 1.2 PICK-UP, PAPER FEED AND SEPARATION ROLLERS 1.2.1 SEPARATION ROLLER Pull out the paper tray. Cover [A] ( x 2) Separation roller [A] ( x 1) M384...

  • Page 778: Pick-Up And Paper Feed Rollers

    Pick-up, Paper Feed and Separation Rollers 1.2.2 PICK-UP AND PAPER FEED ROLLERS Pull out the paper tray. Roller holder [A] ( x 1) Pick-up roller [A] Paper feed roller [B] M384...

  • Page 779: Electrical Components

    Electrical Components 1.3 ELECTRICAL COMPONENTS 1.3.1 PAPER FEED MOTOR Right cover ( p.1) Paper feed motor bracket [A] ( Paper feed motor [A] ( M384...

  • Page 780: Drive Board

    Electrical Components 1.3.2 DRIVE BOARD Right cover ( p.1) Drive board [A] ( M384...

  • Page 781: Cooling Fan

    Electrical Components 1.3.3 COOLING FAN Right cover ( p.1) Cooling fan base [A] ( Cooling fan [A] ( When installing the cooling fan Make sure that the cooling fan is installed with its decal facing to the front of the paper feed unit.

  • Page 782: Paper Feed Clutch

    Electrical Components 1.3.4 PAPER FEED CLUTCH Right cover ( p.1) Paper feed clutch bracket [A] ( Paper feed clutch holder [A] ( x1, bushing x1) Paper feed clutch [B] M384...

  • Page 783: Tray Lift Motor

    Electrical Components 1.3.5 TRAY LIFT MOTOR Left cover ( p.1) Tray lift motor bracket [A] ( Two gears [A] ( x1 each) Tray lift motor [A] ( M384...

  • Page 784: Paper Size Sensor Board

    Electrical Components 1.3.6 PAPER SIZE SENSOR BOARD Left cover ( p.1) Paper size sensor board [A] ( 1.3.7 TRAY SET SENSOR Left cover ( p.1) Tray set sensor holder [A] ( Tray set sensor [A] ( x1, hooks) M384...

  • Page 785: Paper Feed Sensor

    Electrical Components 1.3.8 PAPER FEED SENSOR Paper feed sensor bracket [A] ( Paper feed sensor [A] ( x1, hooks) M384...

  • Page 786: Vertical Transport Sensor

    Electrical Components 1.3.9 VERTICAL TRANSPORT SENSOR Vertical transport sensor bracket [A] ( Vertical transport sensor [A] ( x1, hooks) M384...

  • Page 787: Paper End Sensor

    Electrical Components 1.3.10 PAPER END SENSOR Upper rear cover [A] ( Upper front cover [A] ( Remove the actuator [A]. M384...

  • Page 788: Paper Height Sensor 1

    Electrical Components Paper end sensor [A] ( x1, hooks) 1.3.11 PAPER HEIGHT SENSOR 1 Upper rear cover ( p.12 "Paper End Sensor") Upper front cover ( p.12 "Paper End Sensor") Remove the actuator [A]. Paper height sensor 1 [A] ( x1, hooks) M384...

  • Page 789: Paper Lift Sensor

    Electrical Components 1.3.12 PAPER LIFT SENSOR Upper rear cover ( p.12 "Paper End Sensor") Upper front cover ( p.12 "Paper End Sensor") Paper lift sensor bracket [A] ( Paper lift sensor [A] ( x1, hooks) M384...

  • Page 790: Paper Height Sensor 2

    Electrical Components 1.3.13 PAPER HEIGHT SENSOR 2 Upper rear cover ( p.12 "Paper End Sensor") Upper front cover ( p.12 "Paper End Sensor") Paper height sensor 2 bracket [A] ( Paper height sensor 2 [A] ( x1, hooks) M384...
