Bosch Recording Station Appliance
4.4.2

Inner Rails/Inner Rail Extensions

The chassis includes a set of inner rails in two sections:
–
–
The inner rails are pre-attached to the chassis, and do not interfere with normal use of the
chassis if you decide not to use a 19-inch rack. The inner rail extension is attached to the inner
rail to mount the chassis in the rack.
Installing the Inner Rails
1.
2.
3.
4.4.3

Outer Rails

Outer rails attach to the rack and hold the chassis in place. The outer rails for the s chassis
extend between 30 inches and 33 inches.
Installing the Outer Rails to the Rack
1.
2.
3.
4.
Bosch Security Systems
inner rails
inner rail extensions.
Place the inner rail extensions on the side of the chassis aligning the hooks of the chassis
with the rail extension holes. Make sure the extension faces "outward" just like the pre-
attached inner rail.
Slide the extension toward the front of the chassis.
Secure the chassis with 2 screws as illustrated. Repeat steps for the other inner rail
extension.
Secure the back end of the outer rail to the rack, using the screws provided.
Press the button where the two outer rails are joined to retract the smaller outer rail.
Hang the hooks of the rails onto the rack holes and if desired, use screws to secure the
front of the outer rail onto the rack.
Repeat steps 1-3 for the remaining outer rail.
Hardware Installation Manual
Rack Installation | en 39
- | V1 | 2011.10
