22 en | Maintenance
3.1.2

Removing/Replacing Hard Drives

Removing Hard Drive Carriers from the Chassis
1. Press the release button on the drive carrier. This extends the drive carrier handle.
2. Use the handle to pull the drive carrier out of the chassis.
1
2
The drives are mounted in drive carriers to simplify their installation and removal from the
chassis. These carriers also help promote proper airflow for the drive bays.
CAUTION!
Except for short periods of time (swapping hard drives), do not operate the chassis without
the drive carriers.
- | V1 | 2011.10
Drive carrier
Dummy drive
Hardware Installation Manual
Bosch Recording Station Appliance
