C W
ONFIGURING THE
Parameter
DHCP Parameters
Function
Default Gateway
Subnet Mask
Name Server 1
Name Server 2
Start IP Address
Number of IP
If all the information is correct, click NEXT to complete the Setup
Wizard. You should now have Internet access. If any of the
information is not correct, click BACK to get to the appropriate
screen, modify the information, and then continue the configuration.
The information you supplied will be saved and the main screen of
the Web User Interface will appear.
If at any time you want to validate your Internet settings, click Status.

Advanced Setup

Click Home in the upper right-hand corner. The left-hand side of the
page displays the main menu and the right-hand side shows
descriptive information.
20
54M ADSL R
IRELESS BPS
Description
Shows the DHCP function is enabled or disabled.
LAN IP address of the Wireless 54Mbps ADSL Router.
The network subnet mask.
Primary DNS server IP address.
Alternate DNS server IP address.
Start IP address of DHCP pool of assigned IP addresses.
Number of IP addresses available for assignment by the
DHCP server.
