Page 1: Dvd Player
DVD PLAYER & VIDEO CASSETTE RECORDER HR-XVC37U INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which are located on the rear of cabinet. Retain this information for future reference. Model No. Serial No. LPT0896-001B... - Page 2 Dear Customer, Thank you for purchasing the JVC DVD player & VHS video cassette recorder. Before use, please read the safety information and precautions to ensure safe use of your new unit. CAUTIONS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 3: Safety Instructions
IMPORTANT PRODUCT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing. - Page 4 1. Accessories To avoid personal injury: Do not place this product on an unstable cart, stand, tripod, bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.
-
Page 5: Moisture Condensation
Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. As an E Partner, JVC has determined that this ® NERGY product or product model meets the E for energy efficiency. -
Page 6: Table Of Contents
DISC INFORMATION About Discs ... 7 INDEX INSTALLING YOUR NEW UNIT Basic Connections ... 14 S-VIDEO Connection ... 15 Component Video Connection ... 16 INITIAL SETTINGS Plug & Play Set ... 17 Monitor Set (DVD deck) ... 18 Language ... 20 Clock Set ... -
Page 7: Disc Information
DISC INFORMATION About Discs Playable Discs You can use the discs with the following logos for playback only. DVD VIDEO Video CD/Super Video CD (8 cm /12 cm disc) Audio CD (8 cm /12 cm disc) CD-DA files The following discs also can be played back. •... - Page 8 DVD VIDEO Marks Sometimes marks are printed on a DVD disc and/or on its packaging to indicate information regarding the contents and functions of a disc. Check marks indicating the contents and functions of a disc. Note, however, that in some cases a disc may not include a mark even for a function it supports.
-
Page 9: Care And Handling Of Discs
Placing a Disc Open the disc tray. Press OPEN/CLOSE (x) on the DVD deck to open the disc tray. ● Pressing the button again closes the disc tray. ● Do not block the disc tray with your hand while it is opening or closing as this may result in hardware failure. -
Page 10: Index
FRONT VIEW A Power Button (POWER (1)) B VCR Indicator pg. 29, 34 C VHS Cassette Loading Slot D VCR/DVD Button pg. 29, 34, 42 E Disc Tray F Stop Button (STOP (8)) pg. 29, 34, 42 G DVD Indicator pg. -
Page 11: Rear View
REAR VIEW A Region Number Label pg. 7 B AC Power Cord pg. 14 C S-video Output Connector (S VIDEO OUTPUT) pg. 15 D Antenna Input Connector (VHF/UHF IN) pg. 14 E Digital Audio Output Connectors (DIGITAL AUDIO OUT (OPTICAL/COAXIAL)) pg. - Page 12 ON-SCREEN DISPLAY (VCR deck) If you press ON SCREEN on the Remote when “SUPERIMPOSE” is set to “ON” ( indicators appear on the TV screen. For On-screen display for DVD deck, refer to “Using the on-screen bar” ( A Operation Mode Indicators B Tape Speed (SP/EP) C Tape Position Indicator The tape position indicator...
- Page 13 Buttons with a small dot on the left side of the name (POWER (1), TV/VCR, TV/VCR CH +/–, TV VOL+/–, MUTE) can also be used to operate a JVC’s TV after setting the TV/VCR/ DVD switch to the left. A VCR Button pg.
-
Page 14: Installing Your New Unit
Basic Connections Antenna or Cable Coaxial cable Flat feeder Matching transformer (not supplied) AC Outlet AUDIO/VIDEO OUTPUT AC Power Cord Back of unit Audio/video cable (not supplied) To Audio/video input connectors It’s essential that your unit be properly connected. THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO OPERATION CAN BE PERFORMED. -
Page 15: S-Video Connection
Hi-Fi stereo sound reproduction. To operate the unit with your TV using the S-VIDEO connection, set your TV to its AV mode. You can also use the TV/VCR button on the unit’s Remote to set JVC TV to the AV RF cable mode. -
Page 16: Component Video Connection
To operate the unit with your TV using the Component Video connection, set your TV to its AV mode. You can also use the RF cable TV/VCR button on the unit’s Remote to set JVC TV to the AV (supplied) mode. -
Page 17: Initial Settings
INITIAL SETTINGS Plug & Play Set Auto Clock Set/Auto Tuner Set ATTENTION If you use a cable box, Plug&Play will not function; set the clock and tuner channels separately. ( Depending on areas or reception conditions, the unit may not receive the Auto clock setting data from the PBS channel. -
Page 18: Monitor Set (Dvd Deck)
Monitor Set (DVD deck) You can select the monitor type depending the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs. ● Turn on the TV and select the VCR channel (or AV mode). ● Slide the TV/VCR/DVD switch to the right. INITIAL SETTINGS (cont.) Turn on the unit. - Page 19 * The default setting is bold in the table below. 8 MONITOR TYPE 16:9 (Wide television conversion): Select this when the aspect ratio of your TV is fixed to 16:9 (wide TV). The unit automatically adjusts the screen width of the output signal correctly when playing back a picture whose aspect ratio is 4:3.
-
Page 20: Language
Language Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. INITIAL SETTINGS (cont.) On-screen Language Set (VCR deck) This VCR deck offers you the choice to view on-screen messages in 3 different languages. Turn on the unit. - Page 21 On-screen Language Set (DVD deck) This DVD deck offers you the choice to view on-screen messages in 3 different languages. You can change the language setting manually as required. Turn on the unit. Press POWER (1). Select the DVD deck. On the unit Press VCR/DVD repeatedly so that the DVD indicator lights up.
- Page 22 INITIAL SETTINGS (cont.) Menu/Audio/Subtitle Language Set (DVD deck only) Some DVD discs contain the DVD menu display, audio, subtitle in the multiple languages. With these discs, you can set the default language as you like. The procedure shows how to set “MENU LANGUAGE” on the DVD Set Up menu screen as an example.
-
Page 23: Language Code List
Language Code List Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byelorussian Bulgarian Bihari Bislama Bengali, Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish Bhutani Greek Esperanto Estonian Basque Persian Finnish Fiji Faroese Frisian Irish Scots Gaelic Galician Guarani Gujarati Hausa Hindi... -
Page 24: Clock Set
Clock Set Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. INITIAL SETTINGS (cont.) Perform clock setting only if the clock has not been set correctly by the Plug&Play setting. Preparations Turn on the unit. -
Page 25: Manual Clock Set
Semiauto Clock Set You can change the host channel/D.S.T. (Daylight Saving Time)/ time zone setting manually. First follow steps A to E in “Preparations” ( pg. 24), then go to the following steps. NOTE: The time set previously will be erased when “AUTO CLOCK”, “HOST CH”, “D.S.T.”... -
Page 26: Tuner Set
Tuner Set ● Turn on the TV and select the VCR channel (or AV mode). ● Slide the TV/VCR/DVD switch to the right. INFORMATION The unit selects the correct band (TV or CATV) automatically during Auto Channel Set. The selected band will be displayed on the right side of “BAND”... -
Page 27: Manual Channel Set
Manual Channel Set You can add the channels you want or delete the channels you do not want manually. Turn on the unit. Press POWER (1). Select the VCR deck. On the unit Press VCR/DVD repeatedly so that the VCR indicator lights up. -
Page 28: Progressive Scan Mode Set
Progressive Scan Mode Set (VCR deck/DVD deck) PROGRESSIVE SCAN PROGRESSIVE SCAN MODE SET This unit supports the progressive scan system (eg. 480p*) as well as the conventional interlaced scan system (eg. 480i*). If your TV equipped with component video connectors supports the progressive video input, you can enjoy a high quality picture by setting the progressive scan mode to active on both the VCR deck and the DVD deck. -
Page 29: Operations On Vcr Deck
OPERATIONS ON VCR DECK Basic Playback Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. Clean the video heads using a dry cleaning cassette — TOL-3F — when: Rough, poor picture appears while a tape is played back. The picture is unclear or no picture appears. -
Page 30: Playback Features
Playback Features Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. ATTENTION In the search, still, slow-motion or frame-by-frame playback mode, the picture will be distorted. the noise bars will appear. there may be a loss of color. -
Page 31: Index Search
Skip Search During playback, press SKIP SEARCH 1 to 6 times to skip over unwanted sections. Each press initiates a 30-second period of fast-motion playback. Normal playback resumes automatically. To resume normal playback during a Skip Search, press PLAY (4). Index Search Your unit automatically marks index codes at the beginning of... -
Page 32: Next Function Memory
OPERATIONS ON VCR DECK (cont.) Next Function Memory The Next Function Memory “tells” the unit what to do after rewinding. Before continuing, make sure the unit is in the Stop mode. a- For Automatic Start Of Playback Press REW (3), then press PLAY (4) within 2 seconds. -
Page 33: Manual Tracking
Manual Tracking CH +/– Your unit is equipped with automatic tracking control. During playback, you can override this and adjust the tracking manually by pressing the CH buttons. Override automatic tracking. During playback, press SP/EP on the Remote. Adjust the tracking manually. Press CH + or –... -
Page 34: Basic Recording
Basic Recording Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. Recording Resume Function If there is a power outage during recording, Instant Timer Recording or timer recording ( pg. 34, 35, 37), the recording will resume automatically when power is restored to the unit unless the unit’s memory backup has expired. -
Page 35: Recording Features
Recording Features Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. Accidental erasure prevention To prevent accidental recording on a recorded cassette, remove its safety tab. To record on it later, cover the hole with adhesive tape. -
Page 36: Tape Remaining Time
OPERATIONS ON VCR DECK (cont.) Elapsed Recording Time Indication Set the counter display. Press DISPLAY until a counter reading appears on the front display panel. Reset the counter. Press C.RESET before starting recording or playback. The counter is reset to “0:00:00” and shows the exact elapsed time as the tape runs. -
Page 37: Express Timer Programing
Express Timer Programing Before performing Express Timer Programing: Make sure that the unit’s built-in clock is set properly. Insert a cassette with the safety tab in place. The unit will come on automatically. Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. - Page 38 Enter the channel position. Press CH +/–. Set the tape speed. Press SP/EP. Return to the normal screen. Press PROG. or ENTER. “PROGRAM COMPLETED” appears on the TV screen for about 5 seconds, then the normal screen appears. If “PROGRAM NOT COMPLETED PROGRAM OVERLAP”...
- Page 39 Check, cancel and change programs Disengage the timer mode. Press TIMER, then press POWER (1). Access the Program Check screen. Press PROG. CHECK. Access the Program screen. Press PROG. CHECK again to check more information. Each time you press PROG. CHECK, the next program’s information appears.
-
Page 40: When Programs Overlap Each Other
ATTENTION If there is a conflict in the timer schedule and one program overlaps with another, only the parts shown below in gray will be recorded. Pattern 1: The program with the lower program number will be recorded. 10:00 11:00 Program 1 CH10 Program 2... -
Page 41: Satellite Auto Recording
Satellite Auto Recording This function allows you to automatically record a satellite program which is timer-programed on your external DBS receiver. Connect a DBS receiver to the unit’s AUDIO/VIDEO input (F-1) connector and program the timer on the DBS receiver. The unit starts or stops recording by the signals input from the DBS receiver. -
Page 42: Operations On Dvd Deck
Basic Playback Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. ATTENTION You can not use the DVD deck when the VCR deck is in the Automatic Satellite Recording standby and recording mode. You can use the DVD deck when the VCR deck is in the timer standby mode. -
Page 43: Playback Features
Playback Features Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. ATTENTION When the unit is switched to the VCR deck during playback mode on the DVD deck, the unit enters Resume Stop mode on the DVD deck. - Page 44 OPERATIONS ON DVD DECK (cont.) Locating the start point of the item or skip the item Press SKIP (2) or SKIP (6) during playback. Example: To locate the beginning of item B from the current position, press SKIP (2) twice. To locate the beginning of item D from the current position, press SKIP (6) once.
-
Page 45: Resume Function
Still Picture/Frame-By-Frame Playback Pause during playback. Press PAUSE (9). Activate frame-by-frame playback. Press PAUSE (9) to advance a still picture. To resume normal playback, press PLAY (4). Slow Motion During playback, press PAUSE (9), then press REW (3) for reverse slow motion playback, or FF (5) for forward slow motion playback. -
Page 46: D Phonic
OPERATIONS ON DVD DECK (cont.) 3D Phonic 3D Phonic function allows you to get a simulated surround effect from your stereo system. You can enjoy the vertical surround sound with your 2-channel stereo system. Access the selection menu. Press 3D-PHONIC during playback. The current setting appears on the right bottom corner of the TV screen. -
Page 47: Vfp Function
VFP function — Adjusting the picture quality The VFP (Video Fine Processor) function enables you to adjust the picture character according to the type of programing, picture tone or personal preference. NOTE: Before you start operation; The VFP setting screen disappears if no operations are done for more than about 10 seconds. -
Page 48: Using The On-Screen Bar
Using the on-screen bar You can check disc information while the disc is loaded and you can use some functions using the on-screen bar. The on-screen bar allows you the various playback operations. OPERATIONS ON DVD DECK (cont.) How to Access the on-screen bar Press ON SCREEN twice whenever a disc is loaded. - Page 49 Basic operation on the on-screen bar Example: When selecting the Repeat mode of DVD During playback Access the on-screen bar. Press ON SCREEN twice. The on-screen bar appears on the TV screen. The currently selected item is highlighted. Select menu item. Press w e to move the highlight to ENTER.
-
Page 50: Repeat Playback
Repeat Playback You can repeat playback as you like according to the type of disc. DVD VIDEO: during playback Audio CD: during playback or in stop mode Video CD/SVCD: in stop mode or during playback with PBC deactivated When using the on-screen bar Access the on-screen bar. - Page 51 A-B Repeat Playback You can repeat the desired part. Access the on-screen bar. Press ON SCREEN twice. The on-screen bar appears on the TV screen. Select menu item. Press w e to move the highlight to ENTER. The following pop-up window appears under the selected item.
-
Page 52: Time Search
OPERATIONS ON DVD DECK (cont.) Time Search You can play back a disc from the desired point by specifying the elapsed time from the beginning of the current title (for DVD VIDEO) or the disc (for Audio CD/Video CD) using the Time Search. - Page 53 Chapter Search You can start playback the desired chapter using the on-screen bar. Access the on-screen bar. Press ON SCREEN twice. The on-screen bar appears on the TV screen. Select menu item. Press w e to move the highlight to ENTER.
-
Page 54: Subtitle Selection
Subtitle Selection You can select subtitle language. During playback When using the on-screen bar Access the on-screen bar. Press ON SCREEN twice. The on-screen bar appears on the TV screen. Select menu item. Press w e to move the highlight to ENTER. -
Page 55: Angle Selection
Angle Selection You can enjoy a variety of scene angles if the DVD VIDEO disc contains “multi-angle” parts, where multiple cameras were used to shoot the same scene from different angles. If the disc contains “multi-angle” parts, “ screen at the beginning of the “multi-angle” part when “ON SCREEN GUIDE”... - Page 56 Audio Language Selection Some DVD discs contain the multiple audio. You can select the audio language of movies (DVD VIDEO). During playback When using the on-screen bar Access the on-screen bar. Press ON SCREEN twice. The on-screen bar appears on the TV screen.
- Page 57 Audio Channel Selection When you play certain karaoke (Video CD/SVCD), you can enjoy karaoke by selecting the audio channel to play. The sound of each audio channel depends on the contents of the disc. During playback When using the on-screen bar Access the on-screen bar.
-
Page 58: Parental Lock
Parental Lock This function restricts playback of DVD VIDEO discs which contain violent (and other) scenes according to the level set by the user. For example, if a movie which includes violent scenes supports the parental lock feature, such scenes which you do not want to let children view can be cut or replaced with other scenes. -
Page 59: To Change The Settings
Enter the password. Press the number keys to enter a four-digit number as your password, then press ENTER. The highlight moves to “EXIT”. Return to the OTHERS menu screen. Press ENTER. The “ OTHERS” menu resumes. To return to the normal screen Press SET UP. - Page 60 Country/Area Code List for Parental Lock Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaijan Bosnia and Herzegovina Barbados Bangladesh Belgium Burkina Faso Bulgaria Bahrain Burundi Benin Bermuda Brunei Darussalam Bolivia...
- Page 61 Saint Lucia Liechtenstein Sri Lanka Liberia Lesotho Lithuania Luxembourg Latvia Libyan Arab Jamahiriya Morocco Monaco Moldova, Republic of Madagascar Marshall Islands Mali Myanmar Mongolia Macau Northern Mariana Islands Martinique Mauritania Montserrat Malta Mauritius Maldives Malawi Mexico Malaysia Mozambique Namibia New Caledonia Niger Norfolk Island Nigeria...
-
Page 62: About Mp3 Disc
About MP3 Disc This unit can playback CD discs recorded by the MP3 format (we refer to those discs as MP3 discs in this manual). Operations for MP3 discs are similar to those for Audio CD discs, though there are some restrictions and differences. What is MP3? MP3 is the abbreviation of “MPEG1 Audio Layer 3.”... -
Page 63: Mp3 Playback
MP3 Playback You can search and play back desired groups and tracks using the MP3 control display. Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. NOTES: PLAY (4), STOP (8), PAUSE (9), SKIP (2) and SKIP (6) buttons function the same as with Audio CD discs, however, REW (3) and FF (5) buttons do not function for MP3 playback. -
Page 64: Track Selection
OPERATIONS ON DVD DECK (cont.) Track selection To start playback by specifying the track number Press the number keys (0-10, +10) to enter the track number. ● The entered number appears in the track number indication and playback starts from the track you have specified. Example: To select 3: Press 3. -
Page 65: About Jpeg Disc
About JPEG Disc This unit can playback CD discs recorded by the JPEG format (we refer to those discs as JPEG discs in this manual). Operations for JPEG discs are similar to those for Audio CD discs, though there are some restrictions and differences. What is JPEG? JPEG is the abbreviation of “Joint Photographic Expert Group.”... -
Page 66: Jpeg Playback
JPEG Playback You can search and play back desired groups and files using the JPEG control display. Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. NOTES: PLAY (4), STOP (8), PAUSE (9), SKIP (2) and SKIP (6) buttons function the same as with Audio CD discs, however, REW (3) and FF (5) buttons do not function for JPEG playback. - Page 67 File selection To start slide-show playback by specifying the file number Press the number keys (0-10, +10) to enter the file number. ● The slide-show playback starts from the file you have specified. ● To display only the selected file, then press ENTER. To start slide-show playback from that file, press ENTER again.
-
Page 68: Editing (Vcr Deck)
Edit From A Camcorder Recorder AUDIO input VIDEO input Audio/video cable (not supplied) To AUDIO/VIDEO Output connectors Player EDITING (VCR DECK) You can use a camcorder as the source player and your unit as the recording deck. Slide the TV/VCR/DVD switch to the right. Make connections. -
Page 69: Edit To Or From Another Video Recorder
Edit To Or From Another Video Recorder Player TV receiver Audio/video cable Another recorder Recorder Recorder Audio/video cable TV receiver Another recorder Player You can use your unit as the source player or as the recording deck. Slide the TV/VCR/DVD switch to the right. Make connections. -
Page 70: Dubbing (From Dvd To Vcr)
Dubbing (from DVD to VCR) Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. EDITING (VCR DECK) (cont.) You can dub selected scenes from the DVD disc to a cassette, starting and stopping wherever you wish. -
Page 71: Editing (Dvd Deck)
EDITING (DVD DECK) Digital Audio Dubbing Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. Digital audio device (MD deck etc.) Optical cable (not supplied) Note for connection: Remove the protection cap from the optical cable. -
Page 72: Remote
Functions Remote A/B/C/D Code Switching The Remote is capable of controlling four JVC video units independently. Each of units can respond to one of four codes (A, B, C or D). The remote control is preset to send A code signals because your unit is initially set to respond to A code signals. -
Page 73: Connecting To A Dolby Digital Decoder Or An Amplifier With Built-In Dts (Dvd Deck Only)
Connecting To A Dolby Digital Decoder or An Amplifier With Built-in DTS (DVD deck only) These instructions enable you to connect your unit to a Dolby Digital Decoder or an amplifier with built-in DTS. To DIGITAL AUDIO input Make connections. Connect the unit and a Dolby Digital Decoder or an amplifier with built-in DTS using either an optional optical cable or an optional coaxial cable. -
Page 74: Subsidiary Settings
Mode Set (VCR deck) Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. SUBSIDIARY SETTINGS You can change various mode settings on the Function Set screen by following the procedure described below. For each mode setting, see pages 75 to 77. - Page 75 8 PICTURE CONTROL NORM EDIT SOFT SHARP 8 3DNR ON (PLAY) 8 SUPERIMPOSE This feature helps you to adjust the playback picture quality according to your preference. Normally select “NORM”. NORM: Picture quality is adjusted automatically. EDIT: Minimizes picture degradation during editing (recording and playback).
- Page 76 8 AUTO SP]EP TIMER 8 VIDEO STABILIZER 8 BLUE BACK When this function is set to “ON”, the unit automatically switches to EP mode to allow complete recording if there is not enough tape to record the entire program while timer-recording in SP mode. For Example: Recording a program of 140 minutes in length onto a 120-minute tape Approximately 110 minutes...
- Page 77 8 2ND AUDIO RECORD 8 AUDIO MONITOR HI-FI HI-FI L HI-FI R NORM 8 AUTO POWER OFF When this function is set to “ON”; If a SAP program is received, the SAP audio is recorded on both the normal and Hi-Fi tracks.
-
Page 78: Mode Set (Dvd Deck)
Mode Set (DVD deck) Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. You can change various mode settings on the Mode Set screen by following the procedure described below. For each mode setting, see pages 79 to 81. -
Page 79: Picture Settings
Picture Settings 8 MONITOR TYPE 16:9 4:3 LB 4:3 PS 8 PICTURE SOURCE AUTO FILM VIDEO 8 SCREEN SAVER 8 FILE TYPE AUDIO STILL PICTURE Audio Settings 8 DIGITAL AUDIO OUTPUT PCM ONLY DOLBY DIGITAL/PCM STREAM/PCM You can select the monitor type depending the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs. - Page 80 8 DOWN MIX DOLBY SURROUND STEREO 8 D. RANGE COMPRESSION AUTO Playback discs DVD VIDEO with 48 kHz, 16/20/24 bit linear DVD VIDEO with DTS DVD VIDEO with Dolby Digital Audio CD/Video CD Audio CD with DTS MP3 disc NOTES: The unit is not equipped with the DTS 5.1 channel decoding function.
-
Page 81: Child Lock
Others Settings 8 RESUME 8 ON SCREEN GUIDE Child Lock Turn on the TV and select the VCR channel (or AV mode). Slide the TV/VCR/DVD switch to the right. You can disable the unit’s operation. Set the Child Lock. Press and hold POWER (1) on the Remote for more than 10 seconds while the unit is turned on. -
Page 82: Troubleshooting
If you are using the AV or S-VIDEO, Component Video connection, set the TV to its AV mode. Try manual tracking. ( pg. 33) Use a dry cleaning cassette ECL-3F, or consult your JVC dealer. Try manual tracking. ( pg. 33) -
Page 83: Playback (Dvd Deck)
PLAYBACK (DVD deck) SYMPTOM 1. The button do not work. 2. The DVD deck can not be operated. 3. “X” appears on the TV screen. 4. “REGION CODE ERROR!” appears on the TV screen. 5. The disc cannot be played back. 6. - Page 84 MP3 Playback (DVD deck) SYMPTOM 1. A disc cannot be played. 2. Not MP3 files but JPEG files are played. 3. The MP3 control display appears on the TV screen, but no operation can be performed. JPEG Playback (DVD deck) SYMPTOM 1.
- Page 85 TIMER RECORDING (VCR deck) SYMPTOM 1. Timer recording won’t work. 2. Timer programing is not possible. 3. “#” on the front display panel won’t stop blinking. 4. “#”, “ ” and “$” on the front display panel won’t stop blinking. 5.
- Page 86 OTHER PROBLEMS SYMPTOM 1. The image of TV broadcast appears distorted on the TV screen. 2. Whistling or howling is heard from the TV during camcorder recording. 3. When scanning channels, some of them are skipped over. 4. The channel cannot be changed. 5.
-
Page 87: Questions And Answers
QUESTIONS AND ANSWERS PLAYBACK Q. What happens if the end of the tape is reached during playback or search? A. The tape is automatically rewound to the beginning. Q. During search, slow, still and frame-by-frame playback, I can’t hear any audio. What’s the problem? A. -
Page 88: Specifications
GENERAL Power requirement : AC 120 V Power consumption Power on : 26 W Power off : 2.0 W Temperature Operating : 5°C to 40°C (41°F to 104°F) Storage : –20°C to 60°C (–4°F to140°F) Operating position : Horizontal only Dimensions (WxHxD) : 435 mm x 93 mm x 272 mm (17.12 in x 3.66 in x 10.71 in) -
Page 89: List Of Terms
LIST OF TERMS ... 51 A-B Repeat Playback About Discs ... 65 JPEG ... 62 ... 9 Placing a Disc ... 7 Playable Discs ... 7 Region Number ... 7 Unplayable Discs ... 55 Angle Selection ... 57 Audio Channel Selection ... - Page 90 ... 32 Next Function Memory ... 42 OPERATIONS ON DVD DECK ... 29 OPERATIONS ON VCR DECK ... 19 Pan&Scan Parental Lock ... 60 Country/Area Code List ... 59 To change the settings To set Parental Lock for the first time To temporarily release the Parental Lock ...
-
Page 91: Warranty (Only In U.s.a.)
WHAT WE WILL DO: If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. - Page 92 TO OUR VALUED CUSTOMER THANK YOU FOR PURCHASING THIS JVC PRODUCT. WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE. NEED HELP ON HOW TO HOOK UP? NEED ASSISTANCE ON HOW TO OPERATE? NEED TO LOCATE A JVC SERVICE CENTER?
