Pll Unit - Icom IC-A200 Service Manual

[MAIN UNIT]
REF ORDER
NO. NO.
J4 6510003430 CNR B07B-EH-S
J5 6510003420 CNR B06B-EH-S
J6 6510010020 CNR RTB-1.5-2F
J7 6910001040 CNR IPS-1136
J13 6510007020 CNR TMP-J01X-V6
J14 6510007020 CNR TMP-J01X-V6
J15 6510007020 CNR TMP-J01X-V6
J21 6510003390 CNR B03B-EH-S
J22 6510003400 CNR B04B-EH-S
J23 6510003410 CNR B05B-EH-S
J24 6510003400 CNR B04B-EH-S
J26 6510003420 CNR B06B-EH-S
J27 6510007020 CNR TMP-J01X-V6
J28 6510007020 CNR TMP-J01X-V6
J29 6910001040 CNR IPS-1136
J30 6910001040 CNR IPS-1136
J31 6910001040 CNR IPS-1136
J32 6910001040 CNR IPS-1136
J33 6910001040 CNR IPS-1136
J34 6910001040 CNR IPS-1136
F1 5210000061 FUS FGB 5A PBF (FGB0 125V)
F2 5220000020 HOL S-N5051
DS1 5080000190 LMP HRS-3110A
DS2 5080000190 LMP HRS-3110A
S1 2230000130 SW SPPJ22588A
S2 2230000130 SW SPPJ22588A
S3 6910006800 TML OHD-5D 60B
6910006840 SW TR-60B50
T1 5910000740 TSM 12T03
W11 7120000380 JMP JPW 01 R-01
W46 7120000490 JMP ERD25T0

[PLL UNIT]

REF ORDER
NO. NO.
IC1001 1130009230 S.IC LMX2306TM
Q1001 1510000620 S.TR 2SA1576 S
Q1002 1560000540 S.FET 2SK880 Y
Q1003 1530002050 S.TR 2SC3661 TA
Q1004 1530002050 S.TR 2SC3661 TA
D1001 1790001280 S.DIO MA111
L1001 6200000970 S.COIL NL322522T 100K 10U
R1001 7030000380 S.RES 1K MCR10
R1002 7030000380 S.RES 1K MCR10
R1003 7030000380 S.RES 1K MCR10
R1004 7030000220 S.RES 47 MCR10
R1005 7030000540 S.RES 22K MCR10
R1006 7030000530 S.RES 18K MCR10
R1007 7030000260 S.RES 100 MCR10
R1008 7030000380 S.RES 1K MCR10
R1009 7030000350 S.RES 560 MCR10
R1011 7030000500 S.RES 10K MCR10
R1012 7030000380 S.RES 1K MCR10
R1013 7030000380 S.RES 1K MCR10
R1014 7030000380 S.RES 1K MCR10
R1015 7030000380 S.RES 1K MCR10
R1016 7030000560 S.RES 33K MCR10
R1017 7030000140 S.RES 10 MCR10
C1001 4030004740 S.CER 0.0047 C2012 B
C1002 4030004740 S.CER 0.0047 C2012 B
C1003 4030004740 S.CER 0.0047 C2012 B
C1004 4030004760 S.CER 0.1 C2012 25V F
C1005 4550004010 S.TAN 1 10V MSVA2
C1006 4550004010 S.TAN 1 10V MSVA2
DESCRIPTION
except [USA] only
except [USA]
[USA]
[USA], [FRG] only
except [USA] only
DESCRIPTION
[PLL UNIT]
REF ORDER
NO. NO.
C1007 4030004720 S.CER
C1008 4510008490 S.ELE
C1009 4550000560 S.TAN
C1010 4030004710 S.CER
C1011 4030004760 S.CER
C1012 4030004740 S.CER
C1016 4030004710 S.CER
J1001 6510000770 S.TAN
J1002 6510004900 CNTR
[VCO UNIT]
REF ORDER
NO. NO.
Q2001 1530002031 S.TR
Q2002 1530002022 S.TR
Q2003 1530002022 S.TR
Q2004 1560000341 S.FET
D2001 1720000320 S.VAR
D2002 1720000320 S.VAR
D2003 1720000320 S.VAR
L2001 6200001470 S.COIL NL322522T R12J-3 0.12U
L2002 6200001470 S.COIL NL322522T R12J-3 0.12U
L2003 6200000910 S.COIL LQN2A 82NM 82N
L2004 6200000910 S.COIL LQN2A 82NM 82N
L2005 6200003330 S.COIL NL322522T 1R0J-3 1U
L2006 6130002581 COIL
L2007 6200003320 S.COIL NL322522T 3R3J-3 3.3U
L2008 6200001830 S.COIL NL322522T 100J 10U
R2001 7030000260 S.RES
R2002 7030000460 S.RES
R2003 7030000360 S.RES
R2004 7030000260 S.RES
R2005 7030000460 S.RES
R2006 7030000360 S.RES
R2007 7030000160 S.RES
R2008 7030000160 S.RES
R2009 7030000470 S.RES
R2010 7030000220 S.RES
R2011 7030000280 S.RES
R2012 7030000390 S.RES
R2013 7030000260 S.RES
R2014 7030000250 S.RES
R2015 7030000620 S.RES
R2016 7030000620 S.RES
R2017 7030000380 S.RES
R2018 7030000380 S.RES
C2001 4010006210 CER
C2002 4030004710 S.CER
C2003 4030004520 S.CER
C2004 4010006210 CER
C2005 4030004710 S.CER
C2006 4030004520 S.CER
C2007 4030004500 S.CER
C2009 4030004740 S.CER
C2010 4030004380 S.CER
C2011 4030004740 S.CER
C2012 4030004810 S.CER
C2013 4030004820 S.CER
C2014 4030004900 S.CER
C2015 4610001270 S.TRI
C2016 4030004740 S.CER
C2017 4030004740 S.CER
J2001 6510005210 CNR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
8 - 4
DESCRIPTION
0.001 C2012 B
10 16V EEE-S A
0.33 35V SVA
470P C2012 B
0.1 C2012 25V F
0.0047 C2012 B
470P C2012 B
3022-04A
3022-05A
DESCRIPTION
2SC3772 3 E
2SC3770 3 E
2SC3770 3 E
2SK210 Y F
1T32
1T32
1T32
LB-282-LF
100 MCR10
4.7K MCR10
680 MCR10
100 MCR10
4.7K MCR10
680 MCR10
15 MCR10
15 MCR10
5.6K MCR10
47 MCR10
150 MCR10
1.2K MCR10
100 MCR10
82 MCR10
100K MCR10
100K MCR10
1K MCR10
1K MCR10
47P 50V HE
470P C2012 B
22P C2012
47P 50V HE
470P C2012 B
22P C2012
18P C2012
0.0047 C2012 B
1P C2012
0.0047 C2012 B
4P C2012 CH
5P C2012 CH
18P C2012 CH
ECR-JA010A12W 10P
0.0047 C2012 B
0.0047 C2012 B
3022-03A
S.=Surface mount
