Varistor-A Board; Varistor-B Board; Varistor-C Board; Varistor-D Board - Icom IC-7400 Service Manual

[VARISTOR-A BOARD]

REF ORDER
NO. NO.
D1 1790001760 S.VARISTOR
EP1 6910012350 S.BEAD
EP2 0910054330 PCB

[VARISTOR-B BOARD]

REF ORDER
NO. NO.
D1 1790001760 S.VARISTOR
R1 7510001100 S.THERMISTOR
R2 7510001100 S.THERMISTOR
EP1 6910012350 S.BEAD
EP2 0910054341 PCB
[VARISOR-C BOARD]
REF ORDER
NO. NO.
D1 1790001760 S.VARISTOR
EP1 6910012350 S.BEAD
EP2 0910054350 PCB
[VARISOR-D BOARD]
REF ORDER
NO. NO.
D1 1790001760 S.VARISTOR
R1 7510001100 S.THERMISTOR
R2 7510001100 S.THERMISTOR
EP1 6910012350 S.BEAD
EP2 0910054361 PCB
DESCRIPTION
MA30-(TX)
MMZ1608Y 102BT
B 5718
DESCRIPTION
MA30-(TX)
NTCCM1608 4LH 104KC
NTCCM1608 4LH 104KC
MMZ1608Y 102BT
B 5719A
DESCRIPTION
MA30-(TX)
MMZ1608Y 102BT
B 5720
DESCRIPTION
MA30-(TX)
NTCCM1608 4LH 104KC
NTCCM1608 4LH 104KC
MMZ1608Y 102BT
B 5721A
6 - 22
[TUNER UNIT]
REF ORDER
NO. NO.
Q1 1590000680 S.TRANSISTOR
Q2 1590000680 S.TRANSISTOR
Q3 1590000680 S.TRANSISTOR
Q4 1590000680 S.TRANSISTOR
Q5 1590000680 S.TRANSISTOR
Q6 1590000680 S.TRANSISTOR
Q7 1590000680 S.TRANSISTOR
Q8 1590000680 S.TRANSISTOR
Q9 1590000680 S.TRANSISTOR
Q10 1590000680 S.TRANSISTOR
Q11 1590000680 S.TRANSISTOR
Q12 1590000680 S.TRANSISTOR
Q13 1590000680 S.TRANSISTOR
Q14 1590000680 S.TRANSISTOR
Q15 1590000680 S.TRANSISTOR
D1 1750000370 S.DIODE
D2 1750000370 S.DIODE
D3 1750000370 S.DIODE
D4 1750000370 S.DIODE
D5 1750000370 S.DIODE
D6 1750000370 S.DIODE
D7 1750000370 S.DIODE
D8 1750000370 S.DIODE
D9 1750000370 S.DIODE
D10 1750000370 S.DIODE
D11 1750000370 S.DIODE
D12 1750000370 S.DIODE
D13 1750000370 S.DIODE
D14 1750000370 S.DIODE
D15 1750000370 S.DIODE
L1 6200003950 S.COIL
L3 6110003600 COIL
L4 6110003590 COIL
L5 6110003020 COIL
L6 6110003030 COIL
L7 6110003020 COIL
L8 6110003030 COIL
L9 6110003480 COIL
L11 6110003480 COIL
L12 6110003480 COIL
L13 6180003290 COIL
L14 6180003290 COIL
L15 6180003290 COIL
L16 6180003290 COIL
L17 6180003290 COIL
L18 6180003290 COIL
L19 6180003290 COIL
L20 6180003290 COIL
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030006880 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030006880 S.CERAMIC
C8 4030006880 S.CERAMIC
C11 4030006880 S.CERAMIC
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030006880 S.CERAMIC
C15 4030006880 S.CERAMIC
C16 4030006880 S.CERAMIC
C17 4030006880 S.CERAMIC
C18 4030006880 S.CERAMIC
C19 4030006880 S.CERAMIC
C20 4030006880 S.CERAMIC
C21 4030006880 S.CERAMIC
C22 4030006880 S.CERAMIC
C23 4030006880 S.CERAMIC
C24 4030006880 S.CERAMIC
C25 4030006880 S.CERAMIC
C26 4030006880 S.CERAMIC
C27 4030006880 S.CERAMIC
C28 4030006880 S.CERAMIC
C29 4030006880 S.CERAMIC
C30 4030006880 S.CERAMIC
DESCRIPTION
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DTC114EUA T106
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DA221 TL
HF50ACC 322513-T
LA-555
LA-554
LA-489
LA-490
LA-489
LA-490
LA-536
LA-536
LA-536
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
S.=Surface mount
