SECTION 7
7-1 IC-M604
[CHASSIS PARTS]
REF. NO. ORDER NO.
J1 6510004880 Antenna connector MR-DSE-01
W1 8900015950 Cable OPC-1175A
W2 8900011460 Cable OPC-1176
W3 8900011161 Cable OPC-1128A
W4 8900011811 Cable OPC-1197A-1
W5 8900011821 Cable OPC-1198A-1
W6 8900011831 Cable OPC-1200A-1
MP1 8010020510 2577 A-chassis
MP2 8210019050 2577 rear panel assembly
8210023130 2577 rear panel (B) assembly
MP3 8930058271 2577 F-packing-1
MP4 8930058260 2577 R-packing
MP5 8930058460 2577 bush plate
MP6 8110007800 2577 module cover
MP7 8930058480 2577 module plate
MP8 8510014900 2577 shield cover
MP9 8930034300 1542 ANT seal
MP10 8930058780 2577 sheet
MP11 8810008661 Screw B0 3 × 8 NI-ZC3 (BT)
MP12 8810008661 Screw B0 3 × 8 NI-ZC3 (BT)
MP13 8820001210 2438 screw
MP14 8820001210 2438 screw
MP15 8820001210 2438 screw
MP16 8820001210 2438 screw
MP17 8810004301 Screw M3 × 10 ZK3
MP19 8930052290 O-ring (AD)
MP20 8930058450 2577 IC clip
MP21 8930058470 2577 IC plate
MP22 8930049040 Insulation plate (FQ)
MP23 8930055040 2438 cap
MP25 8930059021 Thermally sheet (AI)-1
MP26 8810008661 Screw B0 3 × 8 NI-ZC3 (BT)
[MAIN UNIT]
REF. NO. ORDER NO.
EP3 6910002161 Shield case-BM7H-LF
MP1 8510014870 2577 RX-VCO case
MP2 8510014880 2577 TX-VCO case
MP3 8510014890 2577 DBM case
MP4 8510014890 2577 DBM case
MP5 8510015100 2577 shield case
MP6 8930059350 2577 earth plate
MP9 8930063240 2577 earth spring
MP10 8930071140 2577 A-earth plate
[LOGIC UNIT]
REF. NO. ORDER NO.
DS1 5030002390 LCD HLM7784-010100
S1 2230001170 Switch SPPH220200
MP1 8930058440 2577 LCD holder
MP2 8210019060 2577 reflector
MP3 8930058910 2577 LCD sheet
MP4 8930058900 Rubber sheet (BB)
[AF UNIT]
REF. NO. ORDER NO.
W6 8900011871 Cable OPC-1203A
Screw abbreviations B0, BT: Self-tapping
FH: Flat head
SUS: Stainless
NI-ZU: Nickel-Zinc
MECHANICAL PARTS
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
[BLACK] 1
[GRAY] 1
1
1
1
1
1
1
1
1
7
3
6
6
2
2
2
8
1
1
1
5
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
2
DESCRIPTION QTY.
1
PH: Pan head
ZK: Black
NI: Nickel

[FRONT UNIT]

REF. NO. ORDER NO.
SP1 2510001210 SPEAKER 066P0804
W1 8900015550 Cable OPC-1658
MP1 8210023090 2577 front panel (C) assembly
8210023100 2577 front panel (D) assembly
MP12 8610011240 Knob N-295
MP12 8610013010 Knob N-295 (B)
MP13 8610011240 Knob N-295
MP13 8610013010 Knob N-295 (B)
MP14 8610011210 Knob N-293
MP14 8610013000 Knob N-293 (B)
MP17 8930059540 Compression ring R102-P
MP18 8810008661 Screw B0 3 × 8 NI-ZC3 (BT)
MP19 8930059200 O-ring (AT)
MP20 8930053030 2345 earth plate
MP21 8850001981 Plain washer M10 10 × 16 × 0.8 ZC3
MP22 8930052280 O-ring (AC)
MP23 8930058790 2577 SP NET
[CONNECT UNIT]
REF. NO. ORDER NO.
J1 6510022440 Connector LTW-8MP-C
J2 6510022440 Connector LTW-8MP-C
J3 6510023620 Connector LTWBU-10PMMP-LC
[DIAL UNIT]
REF. NO. ORDER NO.
S1 2250000470 Switch EVQ-V9C00116E
[SQL UNIT]
REF. NO. ORDER NO.
R1 7210002360 Variable resistor TP96N97-15F-10KA-1301
[VR UNIT]
REF. NO. ORDER NO.
R1 7210003080 Variable resistor TP96N97-15F-10KA-2345
[ACCESSORIES]
REF. NO. ORDER NO.
W1 8900011440 Cable OPC-1174
P1 6510023310 LTWD-06BFFA-L180
P2 6510023300 LTWB-03BFFA-L180
MC1 Optional product HM-126RB
Optional product HM-126RG
MP1 8950005110 2289 mic hanger
MP2 8610010561 2040 knob bolt-1
8610011260 2040 knob bolt (C)-1
MP3 8010018860 2455 bracket
8010020520 2455 bracket (B)
MP4 8310050900 2438 warning sticker
MP5 8810001490 Screw PH A M5 × 20 SUS
MP6 8850000500 Spring washer M5 SUS
MP7 8850000180 Flat washer M5 SUS
MP8 8810004700 Screw PH A M3 × 16 SUS
MP9 8930059480 Sponge (GZ)
Accessories illustation is shown at the next page.
