Stainless linear outdoor gas fireplace system

Advertisement

P/N 127035-01 Rev. A 01/2014
P127035-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
WARNING: Do not store gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly before install-
ing or servicing this equipment.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
PFS
C
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
This appliance can produce
carbon monoxide which has
no odor.
Using it in an enclosed
space can kill you.
Never use this appliance in
an enclosed space such as
a camper, tent, car or home.
Installation and Operation Instructions
Superior
Stainless Outdoor Linear Fireplace
TM
Models
®
VRE4543EN
US
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appli-
ance and immediately call your gas supplier
or fire department.
AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d'incindie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou la mort.
— Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous
servir des téléphones se trouvant dans le bâtiment
où vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
— L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
VRE4543EP

Advertisement

Table of Contents
loading

Summary of Contents for Superior VRE4543EN

  • Page 1 Installation and Operation Instructions Superior Stainless Outdoor Linear Fireplace P/N 127035-01 Rev. A 01/2014 Models ® VRE4543EN VRE4543EP P127035-01 INSTALLER: Leave this manual with the appliance. Installateur : Laissez cette notice avec l’appareil. CONSUMER: Retain this manual for future reference.
  • Page 2 STAINLESS LINEAR OUTDOOR GAS FIREPLACE SYSTEM OWNER’S OPERATION AND INSTALLATION MANUAL ® WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety ..............3 Wiring Diagram ..........21 Local Codes............5 Troubleshooting ..........22 Product identification ........... 5 Parts ..............25 Product Features ..........5 Specifications ............ 28 Installation ............6 Replacement Parts ..........28 Operation ............17 Service Hints .............
  • Page 4 SAFETY Continued 4. This fireplace shall be used only outdoors in Fireplace become very hot when a well ventilated space and shall not be used in use. Keep children and adults in a building, garage or any other enclosed away from hot surfaces to avoid area.
  • Page 5: Local Codes

    SAFETY Continued LOCAL CODES State of Massachusetts: The installation must be made by a licensed plumber or Install and use fireplace with care. Follow all gas fitter in the Commonwealth of Mas- local codes. In the absence of local codes, sachusetts.
  • Page 6: Installation

    INSTALLATION CLEARANCES CAUTION: This fireplace Minimum clearances to combustibles for the creates warm air currents. fireplace are as follows: These currents move heat to *Back and sides 1" wall surfaces next to fireplace. Perpendicular walls 8" Floor (From bottom of Fireplace) 0"...
  • Page 7 INSTALLATION Continued 17.50" Concrete Board 38" 53.25" Figure 4 - Installing Concrete Board Mantel Figure 2 - Framing Clearances for One from Sided Application Mantel Top of Ref. Depth Ref. Opening Note: All vertical 15.25" 12" 24" measurements are 9" 21"...
  • Page 8 INSTALLATION Continued Figure 6 - (V)LVFO43E Series Dimensions www.SuperiorFireplaces.US.com 127035-01A...
  • Page 9 INSTALLATION Continued Sheet Mantel Clearances for Built-In Metal Installation Screws If placing mantel above built-in fireplace, you must meet minimum clearance between man- tel shelf and top of fireplace opening. NOTICE: If your installation does not meet the minimum clear- Electrical Electrical ances shown, you must do one...
  • Page 10 INSTALLATION Continued External Propane/LP WARNING: Never connect Regulator Supply Tank natural gas fireplace to private (non-utility) gas wells. This gas is commonly known as wellhead gas. Installation Items Needed Vent Before installing fireplace, make sure you Pointing have the items listed below. Down •...
  • Page 11 INSTALLATION Continued Equipment Shutoff 1. Route flexible gas line (provided by in- Valve With 1/8" NPT staller) from equipment shutoff valve to Tap* fireplace. Route flexible gas supply line Natural Gas through one of the access holes on side From Gas Meter of fireplace.
  • Page 12 INSTALLATION Continued PRESSURE TESTING GAS SUPPLY Equipment PIPING SYSTEM Shutoff Valve Propane/ Test Pressures In Excess Of 1/2 PSIG LP Supply (3.5 kPa) Tank 1. Disconnect fireplace with its appliance main gas valve (control valve) and equip- ment shutoff valve from gas supply piping system.
  • Page 13 INSTALLATION Continued FINISHING FIREPLACE FOR UPGRADING (V)LVFO43 TO SEE- INSTALLATION THRU APPLICATION (V)LVFO43 series fireplace come with the rear Removing Rear Panel panel semi-installed. If you will be using the 1. In the rear of the fireplace, locate screws fireplace for a one sided regular application, at top of rear panel and remove as shown you will need to finish the installation of the in Figure 16.
  • Page 14 INSTALLATION Continued Removing False Door Installing Access Door Retaining 1. In the rear of the fireplace, Unlock 3 door Brackets latches on top of firebox using your 1. Screw access door retaining brackets into fingers or the latch opener provided. the inner side face using 2 screws on both the left and right side as shown in Figure 2.
  • Page 15 INSTALLATION Continued 5. Light switch is located on the right hand Installing Access Door side as shown in Figure 24. 1. Place access door into rectangular open- 6. ON/OFF switch is located on the left hand ing in front of the glass door with the side as shown in Figure 24.
  • Page 16 INSTALLATION Continued GLASS PANEL INSTALLATION NOTE: The module must be programmed to the Remote Control Transmitter. The glass panel assembly should be installed • To program the module (make sure the after the fireplace is completely framed and system has power), locate the learn but- finished.
  • Page 17: Operation

    INSTALLATION Continued Note: Reference only, not to scale IGNITOR ASSEMBLY The ignitor assembly is factory preset for Ignitor proper ignition of the burner. Alterations may have occurred during shipping and handling. Ground Call a qualified service person to readjust the Electrode ignitor assembly if necessary.
  • Page 18 OPERATION Continued LIGHTING • If lighting appliance for the first time each season, it may take several attempts INSTRUCTIONS before supply gas can reach pilot and This appliance requires 120V electricity for main burners. normal operation. Control module should be •...
  • Page 19: Cleaning And Maintenance

    CLEANING AND MAINTENANCE home center may carry compressed air in a WARNING: Turn off fireplace can. If using compressed air in a can, please and let cool before cleaning. follow the directions on the can. If you don’t follow directions on the can, you could dam- age the ignitor.
  • Page 20: Inspecting Burners

    INSPECTING BURNERS BURNER PRIMARY AIR HOLES BURNER FLAME PATTERN Air is drawn into the burner through the holes WARNING: If yellow tipping in the fitting at the burner entrance. These occurs, your fireplace could holes may become blocked with dust or lint. Periodically inspect these holes for any block- produce increased levels of age and clean if needed.
  • Page 21: Wiring Diagram

    WIRING DIAGRAM www.SuperiorFireplaces.US.com 127035-01A...
  • Page 22: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. Note: All troubleshooting items are listed in order of operation. Remote /Ignitor has a special feature. It will allow heat from the burner to dry the probe and burner assembly due to excess moisture, caused by rain, humidity or condensation.
  • Page 23 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1. Manifold pressure is too low 1. Contact local natural or propane/LP gas company 2. Burner orifice clogged 2. Clean burner (see Cleaning and Maintenance, page 18) or replace burner orifice(s) Burner backfiring during com- 1.
  • Page 24 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
  • Page 25: Parts

    PARTS MODELS VRE4543EN AND VRE4543EP www.SuperiorFireplaces.US.com 127035-01A...
  • Page 26 PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 27 of this manual. PART NO. DESCRIPTION QTY. VRE4543EN VRE4543EP 126396-01 Pilot Bracket • • 126396-02 Pilot Bracket Top •...
  • Page 27 PARTS MODELS VRE4543EN AND VRE4543EP This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 27 of this manual. NO. PART NO. DESCRIPTION VRE4543EN VRE4543EP QTY. 125847-01 Top Spacer •...
  • Page 28: Specifications

    SPECIFICATIONS VRE4543EN VRE4543EP • Rating (Variable): 25/39,000 Btu/Hr • Rating (Variable): 29/37,000 Btu/Hr • Gas Type: Natural Gas • Gas Type: Propane/LP Gas • Ignition: Electronic • Ignition: Electronic • Pressure Manifold Setting: 3.5" W.C. • Pressure Manifold Setting: 10.5" W.C.
  • Page 29: Warranty

    THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior™ Brand gas fireplace, Stove or Insert ("Product") to be free from defects in materials and workmanship at the time of manufacture. The Product body and firebox carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only.
  • Page 30 NOTES...
  • Page 31 KEEP THIS WARRANTY Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. www.SuperiorFireplaces.US.com 127035-01A...
  • Page 32 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 127035-01 1-800-655-2008 Rev. A www.IHP.US.com 01/14 P127035-01...
