Operation / Installation
RINNAI SPLIT SOLAR HOT WATER
The appliance must be installed, commissioned and serviced by an
authorised person in accordance with all applicable local rules and
NOTE
regulations.
The collector flow and return pipes should be 15mm copper tube or
alternative tube supplied by Rinnai.
WARNING
Plastic pipe must not be used. Plastic pipe is not suited to the high
water temperatures and pressures that may occur in the collector
flow and return system.
Certain systems may require some components to be supplied by
the Installer.
NOTE
NOT SUITABLE AS A POOL OR SPA HEATER
Manual
SYSTEMS
All Rinnai gas products
W169
are A.G.A. certified.
SAI Global
AS 2712
Lic No.1849
SAI Global
