KVH Tri-Sat AutoSwitch
Instructions for TracVision
The following instructions explain how to install and operate the Tri-Sat AutoSwitch Kit on a
TracVision R5SL/R5/R4SL/R4 system.
The Tri-Sat AutoSwitch Kit allows DIRECTV HDTV subscribers to enjoy the Ku-band portion of
the overall high-definition (HD) programming package and switch automatically among the
DIRECTV 101, 110, and 119 satellites when using a DIRECTV H21-200 or H20-600 receiver.
For information on:
Installation
Operation
Advanced Wiring
Diagrams
NOTE: This procedure requires a PC with the latest version of the KVH Flash Update Wizard installed.
The Flash Update Wizard is available to KVH-authorized dealers through the KVH Partner Portal.
Who Should Install the System?
To ensure a safe and effective installation, KVH recommends that a KVH-authorized technician
install the Tri-Sat AutoSwitch Kit. To find a technician near you, please visit www.kvh.com/
wheretogetservice.
Technical Support
If you need technical assistance, please contact KVH Technical Support:
Phone: +1 401 847-3327
E-mail: techs@kvh.com
KVH, TracVision, and the unique light-colored dome with contrasting baseplate are registered trademarks of KVH Industries, Inc.
All other trademarks are property of their respective companies. The information in this document is subject to change without notice.
No company shall be liable for errors contained herein. © 2008 KVH Industries, Inc., All rights reserved. 54-0445 Rev. F
Kit Installation and Operation
™
Refer to:
Page 2
Page 6
Page 9
R5SL/R5/R4SL/R4
®
1
