System Overview — Front Panel of the SX/LX Model
Figure 2 Front Panel of the SuperStack II Switch 9300 SX/LX Model
1000BASE-LX Ports
1000BASE-SX Port
1000 Base - LX
TX
1
RX
TX
2
RX
TX
4
RX
TX
5
RX
S
O
ETUP
VERVIEW
10BASE-TX
Out-of-band
Management Port
10 Base - TX
1000 Base - SX
Pckt
Stat
TX
3
RX
1000 Base - SX
TX
6
RX
TX
7
RX
TX
8
RX
1000BASE-SX Ports
Console Port
Allows you to connect a workstation
to the Switch 9300 system for
management access
Console
Fault
Power
TX
9
RX
TX
10
RX
TX
11
RX
LEDs
Provide information about
the system and each port
Status
green
= enabled, link OK
flashing green = disabled, link OK
off
= link fail
Packet
Status
Super Stack II
TX
12
RX
Switch 9300
