Related Manuals for Uniden XDECT 6135BTU Series
Summary of Contents for Uniden XDECT 6135BTU Series
- Page 1 XDECT 6135BTU Series For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
-
Page 2: Important Notice
Important Safety Instructions! When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • This unit is NOT waterproof. DO NOT expose this unit to moisture. •... - Page 3 XDECT 6135BTU SErIES OwNEr’S MaNUal what's in the box? You will also find: Accessory handset and XDECT 6135BTU charger base with answering Not pictured: system and cordless handset xRecha rgeable battery (BT-694 or BT-694s) x Battery cover x Belt clip...
-
Page 4: Table Of Contents
CONTENTS Features of XDECT 6135 BTU series ............3 Installing Your Phone ..................4 Setting Up the Mobilelink Bluetooth™ Connection .........5 Getting to Know Your Phone ..............7 Using the Handset Menu ......................10 Using Your Phone ..................12 Using Your Bluetooth Connection ................... 13 Finding a Lost Handset ........................ -
Page 5: Features Of Xdect 6135 Btu Series
There is usually a fee for this service. Name Tag, Personal Ring and Call Block features require incoming Caller ID data. Based on normal use with full battery charge. Specifications subject to change. Visit the XDECT 6135BTU webpage on the Uniden website for the latest information. -
Page 6: Installing Your Phone
INSTallING YOUr PhONE Charge the Battery 1. Unpack all handsets, battery packs, and battery covers. If you need to remove a cover, press in on the notch and slide the cover down and off. 2. Line up the battery connector with the jack inside the handset;... -
Page 7: Setting Up The Mobilelink Bluetooth™ Connection
SETTING UP ThE MOBIlElINK BlUETOOTh™ CONNECTION The XDECT 6135BTU with MobileLink technology can connect with mobile phones that support the Bluetooth V2.1 handsfree profile. Visit our website on the front cover or contact customer service for a detailed list of tested mobile phones. ♦If you are not certain of the profiles supported by your Bluetooth phone or if you have difficulty pairing your phone to the XDECT 6135BTU, see the manual that came with your phone. - Page 8 1. When your phone accepts the Bluetooth connection, the XDECT 6135BTU sounds a confirmation tone. The Bluetooth device number icon on the base and the handset display light up. # Most mobile phones automatically transfer the audio to a Bluetooth device as soon as it pairs;...
-
Page 9: Getting To Know Your Phone
GETTING TO KNOw YOUr PhONE Parts of the Base Bluetooth device FIND ANSWER DELETE number HANDSET ON/OFF USB Charging Port (Standard size) Message counter DOWN Charging REV/ FWD/ SPEAKER PLAY/ contacts FLASH MUTE STOP Key (icon) what it does x In standby: function is not available. x When a call comes in, answer the call or join in a speaker ( conference call. -
Page 10: Parts Of The Handset
Parts of the handset what it does (icon) x In standby: increase the ringer volume. Headset x During a call: increase the audio jack Earpiece volume. x In any menu or list: move the Status cursor up one line. x In standby: open the menu. Display menu/ x In any menu or list: select the... - Page 11 Key (icon) what it does x In standby: open the redial list. redIal/pause x When entering a phone number: insert a 2-second pause. x Press and hold to lock/unlock the keypad. x In standby: decrease the ringer volume. x During a call: decrease the audio volume. down x In any menu or list: move the cursor down one line.
-
Page 12: Using The Handset Menu
Using the handset Menu With the phone in standby, press If you don't press any keys to open the menu. MENU/SELECT for about 30 seconds, the Press MENU/SELECT handset exits the menu. choose that option. Bluetooth Setup Handset Setup Base Setup T-coil Ringer Tones Personal Ring... -
Page 13: Base Setup Menu
Menu Option what it does LCD Contrast Change the contrast of the display. Caller Turn Text-To-Speech on or off to hear CID information. Announce HD Audio Turn HD Audio on or off. Menu Base Setup These settings affect the base. Menu Option what it does Caller Turn Text-To-Speech on or off to hear CID information. -
Page 14: Using Your Phone
Entering Text on Your Phone ♦Use the 12-key dial pad anytime you want to enter text into your phone (a name in the phonebook, the handset banner, etc.). ♦If two letters in a row use the same key, enter the first letter; wait for the cursor to move to the next space and enter the second letter. -
Page 15: Using Your Bluetooth Connection
Using Your Bluetooth Connection After you have paired your mobile phone with the XDECT 6135BTU (see page 5), you can make and receive calls from your mobile phone through the XDECT 6135BTU. To use the Bluetooth menu options, press with the phone in moBIle standby, then select a mobile phone. -
Page 16: Staying In Range
Staying in range Your system will alert you when you are out of range (or about to go out of range). If... Then... the handset and base are the handset sounds an error tone and connected (intercom call) and no Out of Range displays. -
Page 17: Using Call Waiting
To… Press... , then use the keys to enter the list. down open the CID list Up to 5 entries display at a time. open the redial list redIal/pause to select the previous number. to select the next number. down scroll through the lists In CID list: to show details... -
Page 18: Using An Optional Headset
will hear the new caller after a short pause. To return to the original caller, press and then press on a land line call, or press Home/FlasH on a mobile phone call again. On the base, press twice to moBIle FlasH accept a waiting call. - Page 19 If you delete the pairing information for a mobile phone, the downloaded phonebook from that phone will also be deleted. To... Press... , then select the phone name and then pHoneBook open the phonebook View Number. to scroll through the entries from A to Z. down to scroll from Z to A.
-
Page 20: Adding Phonebooks Entries (Home Only)
adding Phonebook Entries (home only) With the phone in standby, open the phonebook. Select Home and then Create New. Enter a name and number and select a personal ring. ♦Enter the phone number (up to 32 digits) exactly as you would dial it. ♦If you need the phone to wait before sending the next set of digits, press to insert a 2-second pause. -
Page 21: Using Special Features
USING SPECIal FEaTUrES DND (Do Not Disturb) You can silence the ringers on the base and all handsets for a specific period of time; the answering system answers any incoming calls without playing anything through the speaker. 1. With the phone in standby, press and hold # on any handset. -
Page 22: Multihandset Features
Menu Option what it does Add an entry to your call block list. The phone will prompt Create New you to enter a name and phone number. Block all calls from numbers reported by CID as "Private." Private Number (This does not count as one of the 20 entries.) Unknown Block all calls from numbers reported by CID as Number... -
Page 23: Conference Calling (2 Line)
Conference Calling (2 line) A landline call and a mobile call can be connected in conference using the Line Conference feature. ♦When an outside call comes in on the land line and then another outside call via a mobile, two handsets and the base can join in a conference call with the outside callers (5-way conference). -
Page 24: Intercom
Intercom ♦Whenever the phone is in standby, you can make an intercom call between handsets without using the phone line. ♦You can make an intercom call from any handset, but only two handsets can be in an intercom call at any time. ♦If an outside call comes in during an intercom page, the phone cancels the page so you can answer the incoming call. -
Page 25: Using The Answering System
USING ThE aNSwErING SYSTEM # The answering system works with land line calls only. answering System Options (Ans. Setup) You can set or change the answering system options from any handset. Just open the menu and select Ans. Setup. Menu Option what it does Enter a 2-digit PIN so you can access your answering Security Code... -
Page 26: Personalizing The Greeting
Personalizing the Greeting Your personal outgoing message or greeting can be from 2 to 30 seconds long. If you don’t record a greeting, the system uses a pre- recorded greeting: Hello, no one is available to take your call. Please leave a message after the tone. -
Page 27: Screening Your Calls
To... From the base From a handset Press message/mute Press play/stop. select Play Messages. play new The system announces the number of new and old messages messages, then plays each new message (followed by the day and time) in the order it was received. After the new messages play, the system plays the old messages. -
Page 28: Using The System While You're Away From Home
Using the System while You're away from home You can dial in to your answering system from any touch-tone phone. Before you can use this feature, you must program a security code. Programming a Security Code With the phone in standby, open the menu; select Ans. -
Page 29: Important Information
IMPOrTaNT INFOrMaTION Solving Problems If you have any trouble with your phone, check this section first. If you need help, visit the customer support page of our website listed on the front cover. General problems Possible solutions x Check the telephone cord connection. No handsets can x Disconnect the base AC adapter for a few minutes;... - Page 30 Caller ID problems Possible solutions Caller ID displays x You may have to change the line mode. Contact briefly and then Customer Service for instructions. clears. Multi-handset Possible solutions problems I can’t transfer calls. x Reset the handset (see page 30). Two handsets can’t x See if any handset is in Privacy Mode.
-
Page 31: Installing A Line Filter Or Dsl Filter
Bluetooth problems Possible solutions x Making sure your phone is in pairing mode. Check your phone’s manual for instructions on Bluetooth device pairing. x Making sure your phone supports the Bluetooth hands-free profile. x Making sure your phone is in range of the base. The XDECT 6135BTU x If XDECT 6135BTU appears in your mobile phone’s won’t pair with my... -
Page 32: Resetting Handsets
liquid Damage CaUTION: If the base is covered in liquid, disconnect the adapter and phone cord from the wall before touching it. If the liquid is only on the exterior housing of the base or handset, wipe it off and use as normal. If you can hear liquid inside the housing: 1. -
Page 33: Adapter And Battery Information
♦Do not charge the batteries in any charger other than the one specified in the owner's manual. Using another charger may damage the battery or cause it to explode. rechargeable batteries must be recycled or disposed of properly. Uniden works to reduce lead content in our products and accessories. -
Page 34: Mounting The Base Unit On A Wall
Mounting the base unit on a wall This phone can be mounted on any standard telephone wall plate. Route the AC adapter and the telephone cord through the hole of the wall mount bracket. Line up the four tabs on the wall mount bracket (two at the top and two at the bottom) with the four notches on the bottom of the base. - Page 35 Place the mounting slots over the pins on the wall plate. Wall plate Slide the base down to lock it into place. (To AC outlet) Removing the wall-mount bracket At the bottom of the base, lift up on the release latch between the two bottom tabs and push the bracket up.
-
Page 36: Index
INDEX Answer Machine Date & Time .......... 11 Call Screen ........25 De-register the handset ....30 Get Messages ........ 23 Distinctive ringer (see Personal Ring) Greeting (Outgoing Message) ..23 Do Not Disturb (DND) ......19 Record / Change / Delete ....23 On/Off .......... - Page 37 Making calls ........17 Storing ..........17 Viewing .......... 17 Chain dialing ........18 Privacy mode ........21 Redialing a call ....... 9, 14 Register the handset ......30 Resetting the handset ....... 30 Ringer Ringer melodies & tones ..... 10 Ringer volume ........
-
Page 38: One-Year Limited Warranty
ONE-YEar lIMITED warraNTY IMPORTANT Satisfactory evidence of the original purchase is required for warranty service Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may... - Page 39 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 40 ©2012 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in Vietnam U01UN456BZZ(0)
