MODEL
HT-SB60
SOUND BAR HOME THEATER SYSTEM
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating your SHARP product.
HT-SB60 Sound Bar Home Theater system consisting of HT-SB60 (sound bar system) and CP-SW60 (active
subwoofer system).
TRE BLE
BAS S
Note:
This product is recommended for flat panel TV (LED, LCD and plasma).
Accessories
The following accessories are included.
Remote Control
(RRMCGA297AWSA)
Wall Mount Angle x 2
(LANGKA167AW01)
TINSZB412AWZZ
OPERATION MANUAL
Subwoofer Stand x 2
(GITAUA022AW01)
Pattern Paper
(TCAUHA031AWZZ)
Audio Cable x 1
(QCNWGA080AWPZ)
ENGLISH
HDMI Cable x 1
(QCNWGA077AWPZ)
Printed in Malaysia
12L R AS 1
Advertisement
Table of Contents
Related Manuals for Sharp HT-SB60
Summary of Contents for Sharp HT-SB60
-
Page 1: Operation Manual
SOUND BAR HOME THEATER SYSTEM OPERATION MANUAL Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. HT-SB60 Sound Bar Home Theater system consisting of HT-SB60 (sound bar system) and CP-SW60 (active subwoofer system). -
Page 2: Special Notes
Special Notes FCC Radiation Exposure Statement This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. It must not be co-located or operating in conjunction with any other antenna or transmitter. Operation is subject to the following two conditions: CAUTION: TO REDUCE THE RISK OF ELECTRIC 1. -
Page 3: Important Safety Instructions
Important Safety Instructions Electricity is used to perform many useful functions, but it 17) Object and Liquid Entry - Never push objects of any kind can also cause personal injuries and property damage if into this product through openings as they may touch improperly handled. -
Page 4: For U.s. Customer Only
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. -
Page 5: Volume Control
This unit should only be used within the range of 41°F - 4" (10 cm) 95°F (5°C - 35°C). ● SHARP is not responsible for damage due to improper use. Refer all servicing to a SHARP authorised service center. 4" (10 cm) 4"... -
Page 6: Front View
Controls and indicators (continued) Display Subwoofer FRONT VIEW REAR VIEW DIGITAL DIGITAL Reference Page 1. Dolby Digital Indicator ..... 13 2. - Page 7 “ON” or switch the “STAND-BY”. input source. Channel Up Switch up/ Volume Up Turn up/ and Down down the TV and Down down the TV Buttons channels. Buttons volume. Note: Some models of SHARP TV may not be operable.
-
Page 8: Sound Bar Preparation
Driving screws Installing the sound bar SHARP designed the sound bar so you may hang them on the wall. Use proper screws (not supplied). See below for Align the wall mount slot at the sound bar to the wall mount angle. -
Page 9: Placing The System
Placing the system Notes: Installation image: ● As the sound from the system is omni-directional, you can place the sound bar anywhere you like. However, it is recommended to place it as close to the TV as possible. ● The front panel of the sound bar is not removable. Caution: ●... -
Page 10: Hdmi Connection
TV menu. For details, refer to the operation manual of the TV. If you are unable to select external speaker setting from the TV menu (E.g. For SHARP LCD TV, it is named as AQUOS ●... -
Page 11: Audio Connections To Tvs, Dvd Players, Vcrs, Etc
Audio connections to TVs, DVD players, VCRs, etc. Other connection (without HDMI) The illustration below shows the flows of audio and video signals. Audio signal DVD/Blu-ray Video signal Disc Player Digital tuner, etc. Notes: ● Refer to the operation manual of the equipment to be connected. ●... -
Page 12: Remote Control
“AQUOS speaker is enabled” message will be ● Exposing the sensor on the sound bar to strong light displayed if SHARP LCD TV does not detect HT-SB60 may interfere with operation. Change the lighting or the during power on. However the message “AQUOS audio direction of the sound bar. -
Page 13: Sound Mode
General control (continued) ● When pairing is successful: Muting On sound bar: “PAIRING” disappears. The volume is muted temporarily when pressing the (MUTE) On subwoofer: indicator turns blue. button on the remote control. Press again to restore the volume. Note: When the sound bar is turned off and back on again, Subwoofer muting is canceled. - Page 14 This sound bar can be set to turn off automatically if no signal is control detected. 1. Press the APC button repeatedly to select the time. You can operate Sharp TVs with this system’s remote control. APC 20 min APC 15 min...
-
Page 15: Troubleshooting Chart
Wireless connection Make sure there is no obstacles If something is wrong with this product, check the following cannot be established. (especially metal) blocking before calling your authorized SHARP dealer or service center. between the sound bar and subwoofer. General ●... -
Page 16: Maintenance
Specifications Maintenance As part of our policy of continuous improvement, SHARP Cleaning the cabinet reserves the right to make design and specification changes for product improvement without prior notice. The Periodically wipe the cabinet with a soft cloth. performance specification figures indicated are nominal Caution: values of production unit.
