8

Centering the needle in the needle hole

8.1 For PFAFF 481
12 PFAFF
Requirement
The needle must penetrate the needle hole right in the center.
Set the stitch length at "0" and position the needle right above the needle hole.
Loosen screws 1 and 2.
Position needle bar frame 3 both lengthwise and crosswise of the sewing direction
according to the requirement and tighten screw 1.
Turn the handwheel a few turns to ensure that the needle bar is not under stress in the
needle bar frame and tighten screw 2.
2
3
1
