Remote Control
the standard 'sMRx_" commands. Modems that have the variable rate option installed
will also respond to the special 'sMRV_" command.
4.1.3.1 Modulator Filter Rate Assignment
Command:
Response:
Status Only:
Response:
Note: The parameters nnn_mmmm.m may be replaced by N/A to indicate no assignment.
Example:
Command:
Response:
4.1.3.2 Select Modulator Rate
Command:
Response:
Setting the modulator turns off the RF transmitter.
Status Only:
Note: If the MODEM is commanded to a filter (rate) which is not assigned (N/A) the
error 2 message will be returned.
4.1.3.3 Select Modulator Rate Variable
Command:
Response:
*Setting the modulator turns off the RF transmitter.
Status Only:
B-B–4
<add/AMRx_nnn_mmmm.m"cr"
>add/AMRx_nnn_mmmm.m"cr""lf"]
<add/AMRx_"cr"
>add/AMRx_nnn_mmmm.m"cr""lf"]
<add/AMRx_N/A"cr"
>add/AMRx_N/A"cr""lf"]
<add/SMRx_"cr"
>add/SMRx_"cr"RF_OFF"cr""lf"]
see MR command.
<add/SMRV_nnn_mmmm.m"cr"
>add/SMRV_nnn_mmmm.m"cr""lf"] RF_OFF"cr""lf"]
see MR command.
(x = A,B,C, or D Filter designator)
(nnn = 1/2,3/4, or 7/8 Coder rate)
(mmmm.m = 48.0 to 4080.0 (Data rate)
(x = A,B,C, or D Filter designator)
*Variable Rate Option Only*
(nnn = 1/2,3/4, or 7/8 Coder rate)
(mmmm.m = 48.0 to 4080.0 Data rate)
