  • Page 1: Manual Del Propietario

    Owner’s Manual Manual del Propietario 01808 (3400 PSI) Questions? Help is just a moment away! Preguntas? La ayuda es justa un momento lejos! Call: Pressure Washer Helpline - 1-800-743-4115 M-F 8-5 CT Llame: Línea Directa del Lavador a Presión - 1-800-743-4115 M-F 8-5 CT BRIGGS &...

  • Page 2: Table Of Contents

    3400 PSI Pressure Washer TABLE OF CONTENTS SAFETY RULES Safety Rules........2-4 This is the safety alert symbol.
  • Page 3 3400 PSI Pressure Washer WARNING DANGER Fuel and its vapors are extremely flammable and Running engine gives off carbon monoxide, an explosive. odorless, colorless, poison gas. Fire or explosion can cause severe burns or Some chemicals or detergents may be harmful if death.
  • Page 4 3400 PSI Pressure Washer WARNING CAUTION Excessively high or low operating speeds increase risk Running engines produce heat and hot exhaust of injury and damage to pressure washer. gases. Temperature of muffler and nearby areas can reach or exceed 150°F (65°C). •...

  • Page 5: Know Your Pressure Washer

    3400 PSI Pressure Washer KNOW YOUR PRESSURE WASHER Read this owner’s manual and safety rules before operating pressure washer. Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. Fuel Tank Oil Fill/Dipstick Throttle Lever...

  • Page 6: Assembly

    3400 PSI Pressure Washer ASSEMBLY PREPARING PRESSURE WASHER FOR USE IMPORTANT: Read entire owner’s manual before you attempt to assemble or operate your new pressure washer. If you have any problems with the assembly of your pressure washer or if parts are missing or damaged, call the Remove Pressure Washer From pressure washer helpline at 1-800-743-4115.

  • Page 7: Add Engine Oil And Fuel

    3400 PSI Pressure Washer Secure handle to pressure washer using four provided Add Engine Oil and Fuel flange nuts. • Place pressure washer on a level surface. Slowly tip pressure washer back in place and insert • Refer to engine owner’s manual and follow oil and fuel multi–colored Spray tips in spaces provided in handle.

  • Page 8: Checklist Before Starting Engine

    3400 PSI Pressure Washer Connect garden hose (not to exceed 50 feet in length) Figure 3 — Connect High Pressure Hose to Spray Gun to water inlet.Tighten by hand (Figure 4). Connect high CAUTION pressure hose here. There MUST be at least ten feet of unrestricted garden hose between the pressure washer inlet and any flow shut off device, such as a ‘Y’...

  • Page 9: Operation

    3400 PSI Pressure Washer HOW TO USE PRESSURE Select desired quick connect spray tip and insert it into end of nozzle extension (see “How To Use Spray WASHER Tips”). Engage safety latch to spray gun trigger (Figure 6). If you have any problems operating your pressure washer, Figure 6 —...

  • Page 10: How To Use Spray Tips

    3400 PSI Pressure Washer How to Use Spray Tips Cleaning and Applying Chemical The nozzle extension quick–connect allows the use of IMPORTANT: Use soaps designed specifically for several different spray tips. Each spray tip provides a pressure washers. Household detergents could damage different spray pattern (Figure 7).

  • Page 11: Pressure Washer Rinsing

    3400 PSI Pressure Washer Make sure garden hose is connected to water inlet. Increase or decrease spray pressure by turning Check that high pressure hose is connected to spray pressure control knob counterclockwise or clockwise gun and pump; start engine. respectively (Figure 8).

  • Page 12: Product Specifications

    3400 PSI Pressure Washer SPECIFICATIONS PRESSURE WASHER MAINTENANCE Rated Pressure ..3,400 PSI Flow Rate ..4.0 gallons per minute (gpm) Check and Clean Inlet Screen Detergent ..Use detergent approved for pressure washers Examine the screen on the water inlet.

  • Page 13: Nozzle Maintenance

    3400 PSI Pressure Washer Check Gun and Nozzle Extension To remove contaminants from the pump, follow these steps: Examine the hose connection to the spray gun and make Set up pressure washer as described in “Preparing sure it is secure. Test the trigger by pressing it and making Pressure Washer For Use”.

  • Page 14: Engine Maintenance

    3400 PSI Pressure Washer Reinstall spray tip and in-line filter into nozzle Change pump oil as follows: extension. Clean area around brass oil drain plug at bottom of Reconnect nozzle extension to spray gun. pump. Reconnect water supply, turn on water, and start Remove oil drain plug.

  • Page 15: Storage

    3400 PSI Pressure Washer PREPARING THE UNIT NOTE: PumpSaver is available as an optional accessory. It is not included with the pressure washer. Contact the nearest FOR STORAGE authorized service center to purchase PumpSaver. CAUTION Water should not remain in the unit for long periods of time.

  • Page 16: Troubleshooting

    3400 PSI Pressure Washer TROUBLESHOOTING Problem Cause Correction Low pressure spray tip installed. Replace spray tip with high pressure spray tip. Water inlet is blocked. Clear inlet. Inadequate water supply. Provide adequate water flow. Inlet hose is kinked or leaking. Straighten inlet hose, patch leak.

  • Page 17: Replacement Parts

    3400 PSI Pressure Washer EXPLODED VIEW AND PARTS LIST — MAIN UNIT Item Part # Description Item Part # Description B190548AGS BASE 13 95458GS QUICK CONNECT BB3861CGS HANDLE 14 190146GS PUSHNUT BB4105GS BUMPER 15 B1436BGS B4805GS HOSE 16 B4847GS KIT, Spray Tips 30809GS GROMMET 17 192136GS...
  • Page 18 3400 PSI Pressure Washer EXPLODED VIEW — PUMP...
  • Page 19 3400 PSI Pressure Washer PARTS LIST — PUMP Item Part # Qty Description Item Part # Qty Description 110B2126GS 1 Cap 24 150B2126GS 1 Gas Engine Flange 10887628PGS 1 Circlip 25 22237GS 4 Washer, Lock 112B2126GS 1 Snap Ring 26 23645GS 4 Screw 113B2126GS 1 Bearing...
  • Page 20 3400 PSI Pressure Washer EXPLODED VIEW — UNLOADER...
  • Page 21 3400 PSI Pressure Washer PARTS LIST — UNLOADER Item Part # Qty Description Item Part # Qty Description 153B2126GS 0 Complete Unloader 24 226B2327GS 1 Inlet Bolt 210B2327GS 1 Hose Tail 25 248B2327GS 1 Plug 95458GS 1 Quic Disconnect 26 155B2327GS 1 Screw 231B2327GS 3 O-Ring...

  • Page 22: Warranty

    BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC EQUIPMENT OWNER WARRANTY POLICY LIMITED WARRANTY Briggs & Stratton Power Products Group, LLC will repair or replace, free of charge, any part(s), of the equipment that is defective in material or workmanship or both. Transportation charges on parts submitted for repair or replacement under this warranty must be borne by purchaser. This warranty is effective for the time periods and subject to the conditions stated below.
