USER SET MODE KEY
➥ Push and hold to enter user set mode.
• During user set mode, push this key to select an item, and
change the value or condition using push [CH Up]/[CH Down].
➥ Push and hold this key again to exit user set mode.
User set mode is also available via the 'Power ON function.'
Refer to p. 13 also.
OPT OUT KEYS
Push to control the output signal level from the optional unit
connector.
DIGITAL KEY (BIIS operation only)
➥ Push to select the call ID list, transmit message and stand-
by condition. Toggles between queue channel and
received message record indication after queue channel is
selected.
➥ Push and hold to select queue channel indication.
✩ STATUS UP/DOWN KEYS (BIIS operation only)
➥ While in the standby condition, push (or rotate)* to display
the transmit status indication and select a status number.
➥ When a received SDM is displayed, push (or rotate)* to
cancel the automatic scroll and scroll the message manu-
ally.
➥ When an SDM that contains more than 12 characters is
displayed, push (or rotate)* to scroll the message manually.
*Rotate when this function is assigned to [DIAL].
PANEL DESCRIPTION
D For Digital mode operation only
INDIVIDUAL KEY
➥ Push to enter the individual ID code selection mode directly.
Then select the desired individual ID code using [CH Up]/
[CH Down]. (p. 12)
➥ Push to stop the beep emission when receiving a matched
individual ID code.
TALKGROUP KEY
➥ Push to enter the talkgroup ID code selection mode directly.
Then select the desired talkgroup ID code using [CH Up]/
[CH Down]. (p. 12)
➥ Push to stop the beep emission when receiving a matched
talkgroup ID code.
1
1
7
