“a potentially hazardous situa- tion which, if not avoided, could result in Call: 01-800-024-13-13 for help or visit death or injury.” our website: www.karcher.com.mx CAUTION indicates “a potentially hazardous situa- tion which, if not avoided, may result in minor or moderate injury or in property damage incidents.”...
IMPORTANT SAFETY INSTRUCTIONS Read the operating instructions of Do not use acids, alkaline, solvents, the engine manufacturer before or any flammable material in this start-up and follow the safety instruc- product. These products can cause tions carefully. physical injuries to the operator and irreversible damage to the machine.
WATER SUPPLY (Cold Water Only) Flow rate of water supply must not CAUTION fall below 2.8 GPM (gallons per When connecting the water inlet to minute). the water supply mains, local regula- Flow rate can be determined by run- tions of your water company must be ning the water for one minute into an observed.
Page 7
Assembling Illustration Description Tools re- quired Position wheels onto each 1/2” wrench or axle followed by the washer use alternative (C) and then the nut (A). size 13mm. Hand tighten with 1/2” (or 13mm) socket wrench. Attach accessory plate to top Phillips Srew- handle.
Page 8
Illustration Description Tools re- quired Place the quick connect noz- none zle in the nozzle holder. The holders use a snap forward feature. Push down and snap the noz- zle forward until you hear it click into place. This feature allows you to fold the handle backward with the nozzles remaining securely in place.
Page 9
Illustration Description Tools re- quired Pull back the springloaded none collar on the end of the wand to insert your choice of quick connect nozzle. Release the collar and push none the nozzle until the collar clicks. Attach the high pressure hose none to the spray gun.
OPERATING INSTRUCTIONS STEP 6: CAUTION Unlock the trigger gun safety lock. Do not run the engine with a high or low Trigger the gun to eliminate trapped oil level as this can cause engine dam- air, wait for a steady flow of water to age.
USING THE ACCESSORIES WARNING 40° spray angle = White nozzle To avoid serious injury never point For moderate dirt accumulation over a spray nozzle at yourself, other per- large surface. sons or animals. Quick connect nozzles The color-coded quick connect nozzles provide a wide array of spray widths 65°...
Page 12
For Kärcher Detergents, check Adjust the detergent dosing valve to your retailer or visit our website: the desired dosage www.karcher-usa.com/home Kärcher detergents available in USA / Mexico: – All Purpose & Vehicle Cleaner – Exterior House Cleaner –...
TAKING A BREAK ..five minutes or more STEP 1: STEP 2: Engine with manual throttle: Release trigger and engage gun safety lock. Move the throttle lever to the SLOW position. Allow the engine to idle for a few seconds, then move the throt- tle lever to the STOP position.
Kärcher-Autho- rized Service Center for repair. (You can locate a service center in your area online at www.karcher-usa.com/ser- vice.) Pump Maintenance The pump on your Kärcher pressure washer does not require maintenance.
CLEANING TIPS sweeping motion keeping the spray Deck Cleaning nozzle approximately 6 inches from the (with or without detergent). Pre-rinse cleaning surface. deck and surrounding area with fresh CAUTION water. If using Kärcher Deck Wash, ap- Do not use Dirtblaster spray nozzle ply to surface at low pressure.
Page 16
For removing extremely faces with plenty of drinking water. stubborn dirt, it may be necessary to For additional cleaning tips, visit our move the spray nozzle even closer to website at www.karcher-usa.com/ the surface for greater dirt cutting ac- home tion. CAUTION...
TROUBLESHOOTING CAUTION Remove the spark plug cable to prevent accidental ignition of the engine before making any repair. Symptom Cause Solution Engine will not No gasoline Fill gas tank start Choke is not in the correct Pull the choke rod to the position.
Page 18
Oil Drip. Oil seals are damaged or worn. Call Customer Support If you encounter any additional difficul- USA: 1-800-537-4129 ties not listed, please call for help or visit www.karcher-usa.com/home our website. Canada: 1-800-465-4980 www.karcher-canada.com Mexico: 01-800-024-13-13 www.karcher.com.mx English...
